Lightolier Lytecaster 3401MREX User manual

03-03
3 3/4" (95mm) aperture Lytecaster
Low Voltage MR16 12V Recessed Downlight
Low-Profile Electronic Remodeler
Complete fixture consists of Reflector Trim & Power Pack. Select each separately
POWER PACK CUT-OUT
3401MREX 3 3/4 po.(95mm) Accepts most 3 3/4" (95mm) & 4 3/4"(121mm) 300 & 400 serie trims ;
4 3/4" (121mm) see Reflector Trim specification sheets.
Features Accessories
Power Pack : Ideal for remodeling. Swivel junction box for tight plenum Thermal Protector Replacement : 1970
spaces. Snap-off covers permits wiring from below.
Socket : Porcelain body ; Two-pin (GX5.3 base) Pre-wired with 18 ga. Teflon Labels : CSA , UL
250º leads to junction box.
Transformer: Electronic, 60VA, class 2 transformer, 120 volt primary, nominal Damp or Wet location rated depending on trim used.
12 volt secondary .
Thermal Protector : Meets CSA/UL requirements. Insulation, if used, must
be kept 3" (76mm) away from luminaire sides and junction box.
WE RESERVE THE RIGHT TO CHANGE DETAILS OF DESIGN, MATERIALS AND FINISH, IN ANY WAY
THAT WILL NOT ALTER INSTALLED APPEARANCE OR REDUCE FUNCTION AND PERFORMANCE.
Lightolier CFI, 3015 Louis Amos Lachine, (Quebec) H8T 1C4
REFLECTOR TRIM
3401MREX
