Lightolier SL111B2 User manual

Features
Ballast Channel: 0.05" (1.3rnm) min. thick, 1-1/2" x 1-1/2" (38mm x 38mm) brushed
and anodized extruded aluminum ballast channel. Provided with knock-outs and
threaded holes to accept all mounting accessories.
Channel Cover: 0.04" (1mm) thick brushed and anodized aluminum ballast cover.
Press-fit installation. No visible hardware.
Multi-Function Block (2): Solid brushed and anodized aluminum finish. Retains
lampholder housing to the ballast channel. Also functions as a wireway for
continuous rows and patterns.
Spiral Louver: 0.022" (56mm) to 0.089" (2.3mm) thick painted aluminum. Slide over
the lamp and attach as a ground to the luminaire to operate the lamp properly.
Orbit Louver: 0.015" (0.38mm) thick painted aluminum semi-diffused. Slide over the
lamp and attach as a ground to the luminaire to operate the lamp properly.
Wand: 0.125" (3.2mm) thick brushed and anodized aluminum tubing.
Plug Insert (2): 0.56" (14min) dia. 0.31" (8mm) min, deep. Solid brushed and
anodized aluminum finish. Hide the holes at each end of ballast channel when
luminaire is not row mounted.
Lampholder Housing (2): 0.08" (2mrn) min. thick, 1" (25mm) square brushed and
anodized aluminum with turret style locking socket.
KUBIK 1.5 SL111B2
Page 1 of 5 Louver Stand-Off Unit
Dimensions
Ordering guide (complete luminaire consist of unit & power feed)
Unit/Louver Cat. No. Shielding Lamp (linear) Volts Ballast Type Finish
SL111B228PIU 120/277V
SL111B228PIH 2-28W T5 347V Programmed Rapid Start
SL111B254PIU SPR 120/277V Units: Brushed and Anodized Aluminum
SL111B254PIH ORB 347V Spiral Louver: Textured Light Grey (paint)
SL111B254MZ1 2-54W T5 HO 120V Orbit Louver: Semi-diffused
SL111B254MZ2 277V Dimming Mark 10 Anodized Aluminum
SL111B254PCU 120/277V Dimming PowerSpec HDF
Lightolier www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2008 Philips Group • SL111B2.pdf
Canlyte www.canlyte.com
3015 Louis-Amos, Lachine, Québec H8T 1C4 • [phone] • [phone]
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
46-3/16"
(1173mm)
6-1/4"
(158mm)
1"
(25mm)
1-1/2"
(38mm)
Lampholder Housing Channel Cover Ballast
Wand
Multi-Function Block Plug Insert
44-1/2"
(1130mm)
2"
(51mm)
43-1/2"
(1105mm) 1-3/8"
(35mm)
3-1/2"
(89mm)
SPR: Add to unit. The Spiral
louver produces refined, effective
lengthwise shielding to minimize add
to direct view of the light source.
ORB: Add to unit. The Orbit louver
displays perfect balance as it
rotates into any number of positions
from uplight to downlight to wall
washing. (Position shown below).
Lightolier is a Philips group brand

Job Information Type:
Lightolier www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2008 Philips Group • SL111B2.pdf
Canlyte www.canlyte.com
3015 Louis-Amos, Lachine, Québec H8T 1C4 • [phone] • [phone]
Accessories/Options
Cat. No. Finish Feed Canopy Kit
SL003JLG
SL003JWH
Textured Light Grey
White
Mounts to end or middle of the channel for power feed from
3" (76mm) or 4" (102mm) octagonal outlet box. Kit includes
one 0.05" (1.3mm) thick, 4-1/2" (114mm) grounded square steel
plate. Comes with 4 wires 18 AWG, 10 Amps max.
4-1/2"
(114 mm)
Square
Cat. No. Finish Invisible Feed Kit
SL003K Corrosion Protected Accepts conduit or cable with 3/8" (10mm) or 1/2" (13mm)
electrical connector (by others). Kit includes one 0.06" (1.5mm)
thick wall by 1/2" (13mm) dia. seamless steel stem and,
one 0.09" (2.3mm) thick by 5/8" (16mm) by 15/16" (24mm) dia.
aluminum connector. (20 Amps max.)
Cat. No. Finish Power Feed Stem Kit
SLO03M18LG
SLO03M36LG
SLO03M48LG
SLO03M72LG
SLO03M18WH
SLO03M36WH
SL003M48WH
SLO03M72WH
18" Textured Light Grey
36" Textured Light Grey
48" Textured Light Grey
72" Textured Light Grey
18" White
36" White
48" White
72" White
Mounts to a 3" (76mm) or 4" (102mm) octagonal outlet box
Kit includes one 0.024" (0 6mm) thick, 5" (127mm) round steel
canopy, and one 0.06" (1.5mm) thick, 1/2" (13mm) dia. seamless
steel stem, available in 4 different lengths and two decorative
cylinder head screws. Complete installation of Power Feed
Stem Kit. Field cuttable, re-thread stem 1/4-18 NPS. Comes
with 5 pre-assembled wires. 10 Amps max.
Cat. No. Finish Stem Mounting Kit (non-electrical)
SLO04M18LG
SLO04M36LG
SLO04M48LG
SLO04M72LG
SLO04M18WH
SLO04M36WH
SLO04M48WH
SLO04M72WH
18" Textured Light Grey
36" Textured Light Grey
48" Textured Light Grey
72" Textured Light Grey
18" White
36" White
48" White
72" White
Mounts to a 3" (76mm) or 4" (102mm) octagonal outlet box
Kit includes one 0.024" (0 6mm) thick, 5" (127mm) round steel
canopy, and one 0.06" (1.5mm) thick, 1/2" (13mm) dia. seamless
steel stem, available in 4 different lengths and two decorative
cylinder head screws. Complete installation of Power Feed
Stem Kit. Field cuttable, re-thread stem 1/4-18 NPS.
Cat. No. Finish Grid Ceiling Feed Kit
SL003LLG
SL003LWH
Textured Light Grey
White
Mounts along runner or at the intersection of runners. Kit
Includes one 2-1/8” (54mm) deep by 4” (102mm) grounded
octagonal outlet box, one 0.05” (1.3mm) thick universal
crossbar, one 4-1/2” (114mm) white plastic square, and two
t-bar clips 5/32” (4mm) thick spacer, one 0.04” (1 mm) thick
aluminum canopy and two t-bar wrap around clips. Comes
with 4 wires 18 AWG, 10 Amps max.
KUBIK 1.5 SL111B2
Page 2 of 5 Louver Stand-Off Unit
Lightolier is a Philips group brand

KUBIK 1.5 SL111B2
Page 3 of 5 Louver Stand-Off Unit
Job Information Type:
Lightolier www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2008 Philips Group • SL111B2.pdf
Canlyte www.canlyte.com
3015 Louis-Amos, Lachine, Québec H8T 1C4 • [phone] • [phone]
Cat. No. Finish Power Feed Cable Kit
SL003NLG
SL003NWH
Textured Light Grey
White
Mounts to a 3" (76mm) or 4" (102mm) octogonal outlet box.
Kit includes one 0.024" (0.6mm) thick, 5" (127mm) round steel
canopy, one 0.05" (1.3mm) thick grounded crossbar threaded
stud, one 0.046" (1.2mm), 96" (2438mm) long aircraft galvanized
cable with zinc plated hanger adjusting glider hardware,
two white plastic cable stay and one 18 AWG (AWM), 10 feet
(3048mm) long white cord, 10 Amps max.
Cat. No. Finish Extension Blank (4')
SL003P4 Brushed Aluminum Permits power feed between two 1.5" x 1.5" (38mm x 38mm)
brushed and anodized units in a straight run with supplied
extra wires 18 AWG, 10 Amps max, and wire connectors
to energize them. Includes one 46-3/16" (1173mm) long
extruded aluminum channel and cover, two solid aluminum
multi-function blocks as a wireway, plug inserts and wire
connectors.
46-3/16"
(1173 mm)
Cat. No. Finish Invisible Coupler
SL003Q Zinc plated Invisible coupler for joining two Kubik 1.5 units together
mechanically or/and electrically. Recommended for direct
surface mounting. Comes with 4 wires 18 AWG, 10 Amps max.
Cat. No. Finish 5 Face Connector (1-lamp unit)
SL003R Brushed Aluminum Kubik 1.5 units coupled with exclusive solid brushed and
anodized aluminum 5-face connectors and power feed can
satisfy virtually any layout requirement. The connector permits
you to create square, rectangular, continuous rows, L, T,
X configurations. Includes four threaded couples, plug insert
(3), four wires 18 AWG and wire connectors, 10 Amps max.
Kubik 1.5
1.5"
(38 mm)
Cat. No. Finish Cable Mounting Kit (non-electrical)
SL004NLG
SL004NWH
Textured Light Grey
White
Mounts to a 3" (76mm) or 4" (10mm) octagonal outlet box.
Kit includes one 0.024" (0.6mm) thick, 5" (127mm) round steel
canopy, one 0.05" (1 3mm) thick grounded crossbar, threaded
stud, one 0.046" (1.2mm), 96' (2438mm) long galvanized
aircraft galvanized cable with zinc plated hanger and
adjusting glider hardware. Can be used with either Cable
or Stem Power Feed Kit.
Cat. No. Finish 5 Face Connector (2-lamp unit)
SL003S Brushed Aluminum Kubik 1.5 units coupled with exclusive solid brushed and
anodized aluminum 5-face connectors and power feed can
satisfy virtually any layout requirement. The connector permits
you to create square, rectangular, continuous rows, L, T, X
configurations. Includes four threaded couples, plug insert (3),
four wires 18 AWG and wire connectors, 10 Amps max.
Lightolier is a Philips group brand

KUBIK 1.5 SL111B2
Page 4 of 5 Louver Stand-Off Unit
Options and Accessories
Emergency Lighting: Electronic Bodine slim profile battery pack. The emergency
ballast senses the power failure and immediately switches to emergency mode
by illuminating the lamp at a reduced lumen output for a minimum of 90 mins. The
battery fully recharges within 24 hours. Add suffix (EM) to the catalogue numbers.
DALI Interface: Digital Addressable Lighting Interface available upon request
for individual luminaires. Ballast 120 volts or 277 volts only. Consult your
Lightolier representative.
Markings
cULus Listed. Suitable for damp locations.
Mounting
Direct Mount: No mounting directely are possible at the ceiling no to the wall.
Suspended Mount: Single stem or aircraft cable with round canopy suitable for
mounting one standard outlet box for plaster ceiling exposed installation or suspended
ceilings mounts. Stem and cable mounts can both be used on the same luminaire.
Patterns: Suitable for different patterns in continuous row mounting.
Electrical
Ballast: Electronic slim profile 1 lamp 28W T5 or 54W T5HO linear ballast.
U: Universal voltage ballast automatically detects 120V to 277V, 50 or 60Hz
operations.
1: 120V ballast only.
2: 277V ballast only.
H: 347V ballast only.
Lampholder: G5 plug-in base, miniature Bi-pin.
Finish
Natural brushed and anodized aluminum. All painted parts are
powder coat paint process.
ZONE
DEG
ALONG 22.5 45 67.5 ACROSS
0 454 454 454 454 454
5 452 454 455 454 452
15 414 421 441 454 461
25 347 364 408 450 465
35 269 300 368 441 473
45 177 224 327 433 483
55 79 145 283 420 491
65 24 72 238 379 433
75 10 32 156 257 307
85 0 16 100 213 277
90 0 14 94 203 265
95 0 16 100 213 277
105 10 32 156 257 307
115 24 72 238 379 433
125 79 145 283 420 491
135 177 224 327 433 483
145 269 300 368 441 473
155 347 364 408 450 465
165 414 421 441 454 461
175 452 454 455 454 452
180 454 454 454 454 454
COEFFICIENTS OF UTILIZATION
ZONAL CAVITY METHOD * EFFECTIVE FLOOR CAVITY REFLECTANCE = .20
80 70 50
Wall Reflectance
70 50 30 10 70 50 30 10 50 30 10
DETERMINED IN ACCORDANCE WITH CURRENT IES PUBLISHED PROCEDURES
LUMINAIRE INPUT WATTS = 62.8
Room Cavity Ratio
ZONE LUMENS % LAMP % LUMINAIRE
0-30 354 6.82 11.01
0-40 585 11.27 18.21
0-60 1092 21.02 33.97
0-90 1608 30.94 50.00
40-90 1023 19.67 31.79
60-90 515 9.92 16.03
90-180 1608 30.94 50.00
0-180 3217 61.88 100.00
DISTRIBUTION
CANDLEPOWER CURVE
Performance
CANDLEPOWER
REPORT NO: CB903
CAT. NO: SL111B228PIUSPR
2 x 28W T5 at 2600 Lumens
Efficiency: 61.9 %
Candela at Nadir: 454cd
0°
90°90°
180°
300
600
900
0 .66 .66 .66 .66 .61 .61 .61 .61 .52 .52 .52
1 .60 .57 .54 .52 .55 .52 .50 .48 .44 .42 .41
2 .54 .49 .45 .41 .50 .45 .42 .39 .38 .35 .33
3 .49 .43 .38 .34 .45 .40 .36 .32 .34 .30 .28
4 .45 .38 .33 .29 .41 .35 .31 .27 .30 .26 .23
5 .41 .33 .28 .24 .37 .31 .26 .23 .26 .22 .20
6 .38 .30 .25 .21 .34 .28 .23 .19 .23 .20 .17
7 .35 .27 .21 .18 .32 .25 .20 .17 .21 .17 .15
8 .32 .24 .19 .15 .29 .22 .18 .14 .19 .15 .13
9 .29 .22 .17 .13 .27 .20 .16 .13 .17 .13 .11
10 .27 .20 .15 .12 .25 .18 .14 .11 .15 .12 .10
Job Information Type:
Lightolier www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2008 Philips Group • SL111B2.pdf
Canlyte www.canlyte.com
3015 Louis-Amos, Lachine, Québec H8T 1C4 • [phone] • [phone]
Lightolier is a Philips group brand

Job Information Type:
Lightolier www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2008 Philips Group • SL111B2.pdf
Canlyte www.canlyte.com
3015 Louis-Amos, Lachine, Québec H8T 1C4 • [phone] • [phone]
KUBIK 1.5 SL111B2
Page 5 of 5 Louver Stand-Off Unit
Patterns
SL003M
SL004M
SL004M
SL004M
SL004M
SL004M
SL004M
SL003M
SL003M SL003M
SL003M
SL003S
SL003R SL003R
SL003S
SL003R
SL003S
SL003S
SL003S
SL003P4SL111B2SPR
SL111B2SPR
SL111B2SPR
SL111B2SPR
SL111B2ORB
SL111B2SPR
SL111B2SPR
SL111B2SPR
SL111B2SPR
SL111B2SPR
SL111B2SPR
SL111B2SPR
SL111B2SPR
SL111B2SPR
SL111B2SPR
SL111B2SPR
SL111B2SPR
SL004N
SL004N
SL004N
SL004N
SL004N
SL004N
SL004N
SL004N
SL003N
SL003N
SL003S
SL004N SL004N
Lightolier is a Philips group brand
