Calculite®HID Downlight C6T6VN
Page 1 of 2 6" Aperture, 2pc Vertical, T6 Narrow Beam
7" (176 mm) Dia.
5 3/4" (146 mm) Dia.
Features
1. Upper Reflector: Clear anodized aluminum, 0.040" (16-ga.). Provides narrow
beam optics ideal for high ceilings. Also available in medium and wide beam,
see C4T4VM and C4T4VW specification sheets.
2. Aperture Cone: Provides 50° visual cut-off to lamp and lamp image; self-
flange in painted white or aperture-matching polished flange. Consult factory
for other finishes.
3. Lamp Shield: High-temperature glass as required by code, captive during
re-lamping. Light diffusion provides exceptionally smooth beam.
4. Socket Housing: Galvanized steel, pre-wired with G12 pulse rated socket.
Snaps onto upper reflector for secure attachment without tools; assures
proper lamp alignment to optics for consistent performance.
5. Mounting Frame: 0.048" (18-ga.) galvanized steel. Vertical adjustment
mechanism accommodates mounting to virtually any ceiling system using
mounting bars (provided, or 1/2" EMT tubing (by others). Single locking
feature secures all adjustments. Alignment holes and markings allow fixture
to be preset prior to installation.
6. Mounting Ring: 0.048"(18-ga.) galvanized steel. Designed for vertical
adjustment from above or below for ceilings from 0" to 2" thick. Center-line
notches allow consistent alignment of multiple fixtures.
7. Mounting Bars: 0.048" (18-ga.) pre-installed, telescoping bars extend to
30" long and lock securely into position. Built-in locking tabs provide positive
attachment to common T-bar systems. Self-centering feature simplifies
installation in 24" O.C. grid systems. Attaches to steel or wood joists without
accessories.
8. Trim Retention Springs: Rust resistant springs secure reflector/housing for
quick, tool-less installation.
9. Ballast / Socket Housing / Cover Assembly:Snaps onto junction box
without tools for inspection and ballast replacement, accessible from below.
10.Junction Box:0.048" (18-ga.) galvanized steel. UL listed for 8 No. 12 AWG,
90°C through branch circuit conductors. Allows inspection from below.
11. Thermal Protector:(Not Shown) Meets NEC and UL requirements. Do not
install insulation above nor within 3" (76mm) of any part of the luminaire.
Electrical
Electronic Ballast: 120 or 277V, 50/60 Hz., encased, high power factor, T.H.D.
<15%, thermally and transient protected, RMI/RFI complies with FCC Part 18
non-consumer equipment, shut-down circuit at end of lamp life, sound rating “A”,
-5°F (-20°F for 150W) minimum starting temperature, Type 1 outdoor rating.
Electrical (cont.)
150W Magnetic Ballast: 120/277V dual voltage, 60 Hz., encased and potted,
HX-HPF circuit type, high power factor, sound rating “B”, -20°F minimum starting
temperature, Type 1 Outdoor rating.
Ballast ANSI Code Voltage Max. Amps Input Watts
39W MH M130 120/277 0.39/0.17 44
70W MH M139 120/277 0.67/0.29 78
150W MH M142 120/277 1.40/0.60 169/166
*150W MH M142 120/277 3.70/1.60 180
*Magnetic Ballast
Options and Accessories
Auxiliary: Add suffix Ato Frame-In Kit and Reflector Trim. See Spec.Sheet
”A/E“. For 277 electronic consult factory
Emergency: Add suffix Eto Reflector Trim and Frame-In Kit. See Spec. Sheet
“A /E”.
Slope Ceiling Adapters: See Specification Sheet SCA.
Chicago Plenum: Consult Factory.
Labels
cULus (Suitable for Damp Locations), I.B.E.W. For 150W, install fixtures with
minimum spacing; 3 feet from center-to center of adjacent luminaries, 3” from
top of luminaire to overhead building member; 1 1/2 feet from luminaire center to
side building member.
Reflector Trim Frame-In Kit Lamp
C6T6VN CLW Specular Clear, White Painted Flange.
CLP Specular Clear, Matching Flange.
CCDW Comfort Clear Diffuse, White Painted Flange.
CCDP Comfort Clear Diffuse, Matching Flange.
CCZW Champagne Bronze, White Painted Flange.
CCZP Champagne Bronze, Matching Flange.
C639T6E1 Electronic 120V 39W T6 Ceramic Metal Halide
C639T6E2 Electronic 277V 39W T6 Ceramic Metal Halide
C670T6E1 Electronic 120V 70W T6 Ceramic Metal Halide
C670T6E2 Electronic 277V 70W T6 Ceramic Metal Halide
C615T6E1 Electronic 120V 150W T6 Ceramic Metal Halide
C615T6E2 Electronic 277V 150W T6 Ceramic Metal Halide
C615T6U Magnetic 120V/277V 150W T6 Ceramic Metal Halide
7" (176 mm) Dia.
5 3/4" (146 mm) Dia.
7" (176 mm) Dia.
5 3/4" (146 mm) Dia.
Top View: Magnetic Ballast
Top View: Electronic Ballast
Ceiling Cutout: 6 9/16” (167 mm) Dia.

Lightolier is a Philips group brand
Job Information Type:
Calculite®HID Downlight C6T6VN
Page 2 of 2 6" Aperture, 2pc Vertical, T6 Narrow Beam
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2012 Philips Group • C0312
CEILING 80% 70% 50% 30%
WALL 70 50 30 10 50 10 50 10 50 10 0
RCR
0 .76 .76 .76 .76 .74 .74 .71 .71 .68 .68 .64
1 .73 .72 .71 .70 .71 .68 .68 .66 .66 .64 .61
2 .71 .68 .66 .65 .67 .64 .65 .63 .63 .61 .59
3 .68 .65 .63 .61 .64 .60 .63 .59 .61 .58 .57
4 .66 .62 .59 .57 .61 .57 .60 .56 .59 .56 .54
5 .63 .59 .56 .54 .59 .54 .57 .53 .57 .53 .52
6 .61 .57 .54 .52 .56 .51 .55 .51 .55 .51 .50
7 .59 .54 .51 .49 .54 .49 .53 .49 .52 .48 .47
8 .57 .52 .49 .47 .51 .46 .51 .46 .50 .46 .45
9 .54 .49 .46 .44 .49 .44 .48 .44 .48 .44 .43
10 .52 .47 .44 .42 .47 .42 .46 .42 .46 .42 .41
LUMINAIRE INPUT WATTS = 44
ANGLE MEAN CP LUMENS
0 3984
5 3765 352
10 3218
15 2533 716
20 1816
25 1212 583
30 795
35 570 368
40 407
45 189 155
50 14
55 2 4
60 0
65 0 0
70 0
75 1 1
80 0
85 0 0
90 0
ZONAL LUMENS AND PERCENTAGES
ZONE LUMENS % LAMP %LUMINAIRE
0-30 1650 48.53 75.77
0-40 2017 59.35 92.67
0-60 2176 64.02 99.96
0-90 2177 64.05 100.00
40-90 159 4.70 7.33
60-90 0 .02 .04
90-180 0 .00 .00
0-180 2177 64.05 100.00
39W T6 PHILIPS METAL HALIDE LAMP. LUMEN RATING = 3400 LMS. AROMAT ELECTRONIC BALLAST, CL Finish
Coefficients of Utilization
LUMINANCE SUMMARY
CD. / SQ. M.
ANGLE MEAN CD/SQ M
45 16034
55 175
65 0
75 162
85 0
** EFFICIENCY = 64.0% ** CERTIFIED TEST REPORT NO. 2336FR, DATE: OCT 24, 2003
SC = 0.6 COMPUTED BY LSI PROGRAM **TEST-LITE**
CANDLEPOWER DISTRIBUTION
CEILING 80% 70% 50% 30%
WALL 70 50 30 10 50 10 50 10 50 10 0
RCR
0 .75 .75 .75 .75 .73 .73 .70 .70 .67 .67 .63
1 .72 .71 .69 .68 .70 .67 .67 .65 .64 .63 .60
2 .69 .67 .65 .63 .66 .63 .64 .61 .62 .60 .58
3 .67 .64 .61 .59 .63 .59 .61 .58 .60 .57 .55
4 .64 .61 .58 .56 .60 .56 .59 .55 .58 .54 .53
5 .62 .58 .55 .53 .57 .52 .56 .52 .55 .52 .50
6 .60 .55 .52 .50 .55 .50 .54 .50 .53 .49 .48
7 .57 .53 .50 .48 .52 .47 .51 .47 .51 .47 .46
8 .55 .50 .47 .45 .50 .45 .49 .45 .49 .45 .44
9 .53 .48 .45 .43 .47 .43 .47 .42 .46 .42 .41
10 .51 .46 .43 .40 .45 .40 .45 .40 .44 .40 .39
LUMINAIRE INPUT WATTS = 78
ANGLE MEAN CP LUMENS
0 7054
5 6730 630
10 5887
15 4740 1334
20 3463
25 2357 1129
30 1584
35 1148 737
40 812
45 377 310
50 33
55 7 11
60 4
65 2 2
70 0
75 0 0
80 0
85 0 0
90 0
70W T6 PHILIPS METAL HALIDE LAMP. LUMEN RATING = 6600 LMS. AROMAT ELECTRONIC BALLAST, CL Finish
Coefficients of Utilization
LUMINANCE SUMMARY
CD. / SQ. M.
ANGLE MEAN CD/SQ M
45 31949
55 688
65 350
75 0
85 0
** EFFICIENCY = 62.9% ** CERTIFIED TEST REPORT NO. 2334FR, DATE: OCT 14, 2003
SC = 0.6 COMPUTED BY LSI PROGRAM **TEST-LITE**
CANDLEPOWER DISTRIBUTION
ZONAL LUMENS AND PERCENTAGES
ZONE LUMENS % LAMP %LUMINAIRE
0-30 3093 46.88 74.48
0-40 3830 58.04 92.22
0-60 4151 62.91 99.95
0-90 4153 62.94 100.00
40-90 323 4.89 7.78
60-90 2 .03 .05
90-180 0 .00 .00
0-180 4153 62.94 100.00
CEILING 80% 70% 50% 30%
WALL 70 50 30 10 50 10 50 10 50 10 0
RCR
0 .73 .73 .73 .73 .71 .71 .68 .68 .65 .65 .61
1 .70 .69 .67 .66 .68 .65 .65 .63 .63 .61 .59
2 .67 .65 .63 .61 .64 .61 .62 .59 .60 .58 .56
3 .65 .62 .59 .57 .61 .57 .59 .56 .58 .55 .54
4 .62 .59 .56 .54 .58 .54 .57 .53 .56 .53 .51
5 .60 .56 .53 .51 .55 .51 .54 .50 .53 .50 .49
6 .58 .53 .50 .48 .53 .48 .52 .48 .51 .47 .46
7 .55 .51 .48 .46 .50 .45 .50 .45 .49 .45 .44
8 .53 .48 .45 .43 .48 .43 .47 .43 .47 .43 .42
9 .51 .46 .43 .41 .46 .41 .45 .41 .45 .40 .40
10 .49 .44 .41 .39 .43 .39 .43 .38 .43 .38 .38
LUMINAIRE INPUT WATTS = 167
ANGLE MEAN CP LUMENS
0 13758
5 13134 1232
10 11593
15 9424 2655
20 7028
25 4935 2359
30 3491
35 2551 1627
40 1766
45 816 671
50 70
55 12 22
60 4
65 7 5
70 3
75 1 2
80 0
85 0 0
90 0
150W T6 PHILIPS METAL HALIDE LAMP. LUMEN RATING = 14000 LMS. AROMAT ELECTRONIC BALLAST, CL Finish
15000
7500
Coefficients of Utilization
LUMINANCE SUMMARY
CD. / SQ. M.
ANGLE MEAN CD/SQ M
45 69119
55 1223
65 1001
75 344
85 0
** EFFICIENCY = 61.2% ** CERTIFIED TEST REPORT NO. 2333FR, DATE: OCT 13, 2003
SC = 0.7 COMPUTED BY LSI PROGRAM **TEST-LITE**
CANDLEPOWER DISTRIBUTION
ZONAL LUMENS AND PERCENTAGES
ZONE LUMENS % LAMP %LUMINAIRE
0-30 6246 44.62 72.86
0-40 7873 56.24 91.83
0-60 8566 61.19 99.92
0-90 8573 61.24 100.00
40-90 700 5.00 8.17
60-90 6 .05 .08
90-180 0 .00 .00
0-180 8573 61.24 100.00
Zonal Cavity Method - Effective Floor Cavity Reflectance = 20%
Zonal Cavity Method - Effective Floor Cavity Reflectance = 20%
Zonal Cavity Method - Effective Floor Cavity Reflectance = 20%
2,000
3,500
15,000
30°
60°
30°
60°
30°
60°
1,000
3,000
4,000
1,750
5,250
7,000
7,500
3,750
11,250
