Lightolier Calculite ProSpec PA1A7050 User manual

Top View
13 1/8"
13/4"
8"
13"
Depth
83/4"
5" L X 5" W Opening
10 3/8" L X 10" W
17"
5
6
7
89
10
11
12, 13
14
12
3
4
Flanged Trimless
5"
Ceilin Cutout: 6 3/16" L x 6 3/16" W
Orderin Information: AR 70 Series A
Cat. No. Lamp Ceilin Trim Aperture Finish
PA1A705EBL (1) 50W AR 70 Overlap Black with White Flange
PA1A705EWL (1) 50W AR 70 Overlap White with White Flange
PA1A7053EBTL (1) 50W AR 70 Trimless Black
PA1A705EWTL (1) 50W AR 70 Trimless White
PA1A705EBL = (Flanged) Black/White
PA1A705EWL = (Flanged) White
PA1A705EBTL = (Trimless) Black
PA1A705EWTL = (Trimless) White
Calculite®ProSpec®Linear Downlight PA1A7050
Page 1 o 2 1 Light AR 70 Series A
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Li htolier a Genlyte Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details o design, materials and inish.
© 2011 Genlyte Group LLC • C0711
Features
1. Aperture Frame: Provides clean support or lamp holders and overlapping
lange or trimless installation. Extruded aluminum. Rigidly welded together
on all corners.
2. Media Cartrid e: Allows convenient loading and removal o up to two
accessories (including lamp cover glass; lamp cover glass may be replaced
with solid glass accessory). Easily installed and removed or lamping with a
simple twisting motion. Constructed o diecast aluminum.
3. Cross Blade Louver: Extruded aluminum. 1" deep, provides additional
shielding and can be easily removed.
4. Adjustable Rin : Allows 360° horizontal and 35° (on width) and 45° (on
diagonal) vertical adjustment.
5. Tortiontite Sprin : For easy installation o aperture rame.
6. Housin : Die ormed 22 ga. steel. Finish: Black.
7. Mountin Brackets: Adjustable vertically rom outside o housing.
8. Thermal Protector: Meets NEC, UL , and CSA requirements.
9. Lampholder: double contact bayonet base with 250°C #18 gauge Te lon®
leads.
10.Junction Box: 14 ga. steel, 4" x 3 1/2" x 2" box. Allows inspection rom
below.
11.Lamp and Accessory Support: .032" steel, lared or easy entry o Media
Cartridge.
12.Lens Retainin Rin : .093" spring steel rod. Holds accessories in place.
13.Lamp Guard: Heat resistant clear glass. Lamp manu acturers requirement.
14.Transformer Housin : Die ormed 18 ga. steel.
Electrical
Electronic Transformers: O er reliable operation and are accessible
rombelow or servicing. 12V Secondary.
Dimmin Controls: Use only dimmers speci ically designed or use with
electronic trans ormers. Low Voltage ixtures may produce audible sound when
used with dimmers, which may be objectionable in acoustically critical areas.
Finish
All painted inishes are powder coated baked enamel.
Options & Accessories
Accessories: 2 1/2" dia. series, ilters, lenses, screens and louvers. (2)
accessories maximum, including lamp cover glass. Lamp guard glass may be
replaced with solid glass accessory.
Labels
UL/cUL (Suitable or Damp Location), I.B.E.W.
Te lon®is a registered trademark o E.I. DuPont.
Add a “1” or 120v or “2” or 277v at the end o the catalog number or voltage

3000 2000
50W AR111
FL (T-H) 30°
Data are based on bare lamp photometrics. Dashed lines in beam spreads
indicate narrow axes o oval shaped beams.
FC is initial ootcandles at center o beam.
Land Ware to the point that the candlepower drops 50% o maximum.
Li htin Performance Data
LBeam length
BBeam width
CDistance to center o beam
DDistance
AAiming angle
FC Foot candles
Lamp data shown is typical, and is based on
bare lamp photometrics. Contact lamp
manu acturers or availability and
per ormance.
DFC LW DC FC LW DC FC LW DC FC LW
Lamps Beam Spread CBCP Rated
(To 50% CBCP) Lie (Hrs.)
Lamp 0° Aimin An le 30° Aimin An le 45° Aimin An le 60° Aimin An le
8’ 234 1.4’ 1.4’
12’ 104 2.1’ 2.1’
16’ 59 2.8’ 2.8’
20’ 38 3.5’ 3.5’
7’ 4.0’ 199 1.6’ 1.4’
10’ 5.8’ 97 2.3’ 2.0’
13’ 7.5’ 58 3.0’ 2.6’
16’ 9.2’ 38 3.7’ 3.2’
3’ 5.2’ 208 2.1’ 1.0’
4’ 6.9’ 117 2.9’ 1.4’
5’ 8.7’ 75 3.6’ 1.7’
6’ 10.4’ 52 4.3’ 2.1’
5’ 5.0’ 212 1.8’ 1.2’
7’ 7.0’ 108 2.5’ 1.7’
9’ 9.0’ 65 3.2’ 2.2’
11’ 11.0’ 44 3.9’ 2.7’
15000 2000
50W AR70
SP (T-H) 10°
4’ 125 2.1’ 2.1’’
6’ 56 3.2’ 3.2’
8’ 31 4.3’ 4.3’
10’ 20 5.4’ 5.4’
3’ 1.7’ 144 2.2’ 1.9’
5’ 2.9’ 52 3.7’ 3.1’
7’ 4.0’ 27 5.1’ 4.3’
9’ 5.2’ 16 6.6’ 5.6’
1’ 1.7’ 250 2.7’ 1.1’
2’ 3.5’ 63 5.5’ 2.1’
3’ 5.2’ 28 8.2’ 3.2’
4’ 6.9’ 16 10.9’ 4.3’
3’ 3.0’ 79 3.5’ 2.3’
4’ 4.0’ 44 4.6’ 3.0’
5’ 5.0’ 28 5.8’ 3.8’
6’ 6.0’ 20 6.9’ 4.5’
2000 2000
50W AR70
FL (T-H) 30°
4’ 125 2.1’ 2.1’’
6’ 56 3.2’ 3.2’
8’ 31 4.3’ 4.3’
10’ 20 5.4’ 5.4’
3’ 1.7’ 144 2.2’ 1.9’
5’ 2.9’ 52 3.7’ 3.1’
7’ 4.0’ 27 5.1’ 4.3’
9’ 5.2’ 16 6.6’ 5.6’
1’ 1.7’ 225 2.7’ 1.1’
2’ 3.5’ 56 5.5’ 2.1’
3’ 5.2’ 25 8.2’ 3.2’
4’ 6.9’ 14 10.9’ 4.3’
3’ 3.0’ 71 3.5’ 2.3’
4’ 4.0’ 40 4.6’ 3.0’
5’ 5.0’ 25 5.8’ 3.8’
6’ 6.0’ 18 6.9’ 4.5’
1800 2000
50W AR70
FL GOLD (T-H) 30°
8’ 211 1.4’ 1.4’
12’ 94 2.1’ 2.1’
16’ 53 2.8’ 2.8’
20’ 34 3.5’ 3.5’
7’ 4.0’ 199 1.6’ 1.4’
10’ 5.8’ 97 2.3’ 2.0’
13’ 7.5’ 58 3.0’ 2.6’
16’ 9.2’ 38 3.7’ 3.2’
3’ 5.2’ 188 2.1’ 1.0’
4’ 6.9’ 105 2.9’ 1.4’
5’ 8.7’ 68 3.6’ 1.7’
6’ 10.4’ 47 4.3’ 2.1’
5’ 5.0’ 191 1.8’ 1.2’
7’ 7.0’ 97 2.5’ 1.7’
9’ 9.0’ 59 3.2’ 2.2’
11’ 11.0’ 39 3.9’ 2.7’
13500 2000
50W AR70
SP GOLD (T-H) 10°
Aimin An le: 0° 30° 45° or 60° Horizontal 30° 45° or 60° Vertical
15’ 222 1.3’ 1.3’
20’ 125 1.7’ 1.7’
25’ 80 2.2’ 2.2’
30’ 56 2.6’ 2.6’
10’ 5.8’ 325 1.2’ 1.0’
15’ 8.7’ 144 1.7’ 1.5’
20’ 11.5’ 81 2.3’ 2.0’
25’ 14.4’ 52 2.9’ 2.5’
8’ 8.0’ 276 1.4’ 1.0’
12’ 12.0’ 123 2.1’ 1.5’
16’ 16.0’ 69 2.8’ 2.0’
20’ 20.0’ 44 3.5’ 2.5’
5’ 8.7’ 250 1.8’ 0.9’
8’ 13.9’ 98 2.6’ 1.4’
11’ 19.1’ 52 3.9’ 1.9’
14’ 24.2’ 32 4.9’ 2.4’
50000 2000
50W AR111
NSP (T-H) 5°
6’ 83 3.2’ 3.2’
8’ 47 4.3’ 4.3’
10’ 30 5.4’ 5.4’
12’ 21 6.4’ 6.4’
5’ 2.9’ 78 3.7’ 3.1’
7’ 4.0’ 40 5.1’ 4.3’
9’ 5.2’ 24 6.6’ 5.6’
11’ 6.4’ 16 8.1’ 6.6’
3’ 3.0’ 118 3.5’ 2.3’
5’ 5.0’ 42 5.8’ 3.6’
7’ 7.0’ 22 8.1’ 5.3’
9’ 9.0’ 13 10.4’ 6.8’
2’ 3.5’ 94 5.5’ 2.1’
3’ 5.2’ 42 8.2’ 3.2’
4’ 6.9’ 23 10.9’ 4.3’
5’ 8.7’ 15 13.7’ 5.4’
60°
Calculite®ProSpec®Linear Downlight PA1A7050
Page 2 o 2 1 Light AR 70 Series A
