Lightolier DMP01 User manual

DMP01
Decorative, Pattern Maker LED
Page 1 of 2
Job Information Type:
Job Name:
Cat. No.:
Notes:
Catalog Number Finish Lamp Wattage Color Temp Voltage
DMP01WLW White LED 1W 3000K 120-240V
DMP01WLSA Satin Aluminum LED 1W 3000K 120-240V
4 ½"
(114 mm)
2 ¼"
(58 mm)
2 ¾"
(70 mm)
2 ⅛"
(54 mm)
2 ¾"
(70 mm)
2 ¼"
(58 mm)
1316" (20 mm)
2"
(51 mm)
1316"
(20 mm)
2"
(51 mm)
Square in
Square Design

DMP01
Decorative, Pattern Maker LED
Page 2 of 2
Philips Lightolier
e: [email protected]
t: [phone]
w: www.lightolier.com
DMP01 May 31, 2011
Specifications are subject to change without notice.
© Koninklijke Philips Electronics N.V., 2011.All rights reserved.
Job Information Type:
Features
1. Heat Sink/Driver Housing: Die-cast aluminum.
2. Lens: Injection molded acrylic sandblasted with clear
polished edges, developed for optimum optical output.
3. Face Plate: Die-cast aluminum.
4. Light Shield: Die-cut .020” thick aluminum (not shown).
5. Decorative Light Diffuser: Die-cast aluminum.
6. Switch Box Mounting Plate: 18ga. C.R.S. zinc plated,
for mounting to a 31/2” deep switch box.
Electrical
LED: (1) 1W 3000K white LED. Average expected life, under
normal operating conditions is 50,000 hours with lumen
maintenance of 70% of original light output.
Driver: Class 2 power supply.
Electrical (continued)
Voltage: 120V
Output Wattage: 1 W
Input Current (max.): 65 mA
Frequency: 50/60 Hz
Output Voltage (VDC): 4 V
Constant Current: 350 mA
Finish
Satin aluminum with protective clearcoat.
Matte white powder coat.
Labels
cULus Listed. Suitable for wet locations.
Wall mount only.
4 ½"
(114 mm)
2 ¼"
(58 mm)
2 ¾"
(70 mm)
2 ⅛"
(54 mm)
2 ¾"
(70 mm)
2 ¼"
(58 mm)
1316" (20 mm)
2"
(51 mm)
1316"
(20 mm)
2"
(51 mm)
