Lightolier JS Series User manual

Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
For Factory Technical Information: [phone] • Fax [phone]
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © Philips Group S ction 3A/Folio H96-5 R v. A
JETSTAR JS S ri s 13-1/4" Wid
Pag 1 of 2 Surfac Wraparound, 13-1/4" Width, 48" Nominal L ngth, 2 or 4 Lamp T8
F atur s
• Id al for low c iling h ight applications wh r r c ss d units
cannot b us d.
• 2-1/2" total d pth.
• St p-back housing for an appar nt d pth of 1-3/4".
• Effici ncy 90.7% (2 lamps).
• Effici ncy 81.3% (4 lamps).
• A shallow profil and lin ar prismatic sid s combin to r duc
c iling contrast.
• Virgin acrylic l ns with on -pi c xtrud d prismatic patt rn 12
bottom and lin ar prism sid walls.
• Shi lding hing s from ith r sid (s lf-l v ling).
• Full-l ngth ballast cov r snaps-in, snaps-out (no tools).
• Individual or continuous row installations..
• Suitabl for mounting on low-d nsity c llulos fib rboard surfac s.
• Suitabl for damp locations.
36" (914mm)
40" (1016mm)
44" (1118mm)
45-15/16" (1167mm)
48" (1219mm)
7/8" DIA. K.O. (1)
2-1/2"
(61mm)
5" (127mm)
13-1/4" (339mm)
stem/canopy sets lens hinges either side
Dim nsions
F atur s
2-1/2"
(61mm)
13-1/4" (339mm)
9/32" x 1/2" K.O. (2)
7/8" DIA. K.O. (8)
5/8" DIA. K.O. (2)

Job Information Type:
For Factory Technical Information: [phone] • Fax [phone]
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © Philips Group S ction 3A/Folio H96-5 R v. A
JETSTAR JS S ri s 13-1/4" Wid
Pag 2 of 2 Surfac Wraparound, 13-1/4" Width, 48" Nominal L ngth, 2 or 4 Lamp T8
Options/Acc ssori s
Canopy Spac r: Susp nds fixtur approximat ly 1-1/2" from surfac . Ord r Catalog
Numb r: ASC CSP.
St m and Canopy S ts: Susp nds fixtur 6", 12", 18" or 24" from surfac . Catalog
Numb r: ASC6 CSP (6"), ASC12 CSP (12"), ASC18 CSP (18"), ASC24 CSP (24").
Fusing: Int rnal fast-blow fusing. SUFFIX: A.
Int rnal slow-blow fusing. SUFFIX: C.
Sp cifications
P rformanc : In an installation of 2 lamp 32W luminair s in a room cavity ratio of 1,
with r fl ctanc of 80% c iling, 50% wall, 20% floor, th C.U. shall not b l ss than
.92. To r duc glar th av rag brightn ss at 65° shall not xc d 2497 footlamb rts.
To control v iling r fl ctions, luminair output in th 30° - 90° zon shall b not l ss
than 75.8%.
Sp cifications (continu d)
Mat rials: Chassis parts ar di -form d cod gaug cold roll d st l.
Housing is r inforc d for rigidity. R fractor–on -pi c virgin acrylic.
Finish: Chassis xt rior–whit bak d poly st r nam l. Cavity–whit bak d poly-
st r nam l minimum r fl ctanc 86%. Phosphat und rcoating.
L ns: On -pi c xtrud d prismatic patt rn 12 bottom and lin ar prism sid walls.
El ctrical: Th rmally prot ct d class “P” ballast C.B.M. approv d, non PCB. If K.O. is
within 3" of ballast, us wir suitabl for at l ast 90°.
Lab ls: I.B.E.W./UL and ULc List d.
This product may hav a m rcury containing lamp. Manag in accord with Disposal
Laws. S : www.lampr cycl .org
JETSTAR:
Surface
Luminaire
Fixtur
L ngth:
4=4'
FFiixxttuurr WWiiddtthh::
BB=14" Wide
Lamp
Quantity:
2=2 Lamps
4=4 Lamps
LLaammpp::
(By Others)
3322=T8, 4' Length
Voltag :
120, 277 or
UNV=120 277
Options:
Add appropriate suffix
to catalog no., ie: (A)
BBaallllaasstt TTyypp::
<20THD <10THD
2 2 Lamp Elec. T8 SSOO**HHI**
1 4 Lamp Elec. T8 OO44**HH44**
LOL Dimming T8 PPSS––
*Instant Start Standard
Other dimming options. Consult factory.
JS B4
Ord ring Information
Explanation of Catalog Numb r. Exampl : JS4B432UNVH4
Mod l No. JS4B232UNVHI
LER = FP - 81.6 IW - 57 BF - 0.90
Comparativ y arly lighting n rgy cost p r
1000 lum ns = $2.94
R port Numb r: 28876-1
Catalog Numb r: JS4B232UNVHI
Lamps: (2) F32T8
Luminair : J t Star surfac luminair with
cl ar wraparound prismatic l ns.
Ballast: ICN-2P32-N
R port is bas d on 2850 Lum ns p r lamp.
Effici ncy: 90.7%
AVERAGE AVERAGE AVERAGE AVERAGE
IN DEG. 0-DEG. 45-DEG. 90-DEG.
45 3628. 3934. 4101.
55 3205. 3584. 3677.
65 2121. 2371. 2497.
75 1444. 1668. 2221.
85 1134. 1709. 2901.
LUMINANCE DATA IN CANDELA/SQ. METER
COEFFICIENTS OF UTILIZATION –
ZONAL CAVITY METHOD. EFFECTIVE
FLOOR CAVITY REFLECTANCE 0.200
RC 80 50 30
RW 70 50 30 50 30 10 50 30 10
01 97 92 89 85 82 79 80 77 75
02 88 81 75 74 69 65 70 66 63
03 80 71 64 65 60 55 62 57 53
04 74 63 55 58 52 47 55 50 45
05 68 56 48 52 45 40 49 44 39
06 62 50 42 47 40 35 45 39 34
07 58 46 38 42 36 31 41 35 30
08 54 41 34 39 32 28 37 31 27
09 50 38 31 36 29 25 34 28 24
10 47 35 28 33 27 22 32 26 22
ZONE LUMENS % LAMP % FIXT
00-030 1254 22.0 24.2
00-040 2113 37.1 40.9
00-060 3853 67.6 74.5
00-090 4761 83.5 92.1
90-120 327 5.7 6.3
90-130 365 6.4 7.1
90-150 398 7.0 7.7
90-180 411 7.2 7.9
00-180 5172 90.7 100.0
ZONAL LUMEN SUMMARY
0.0 45.0 90.0 FLUX
0 1547 1547 1547
5 1554 1544 1528 147
15 1506 1523 1526 430
25 1407 1474 1509 677
35 1266 1389 1450 860
45 1065 1236 1302 932
55 773 950 989 808
65 385 493 530 481
75 168 241 331 269
85 54 131 236 158
95 0 91 227 119
105 3 140 222 126
115 6 95 136 82
125 7 46 70 38
135 10 27 41 20
145 12 18 28 12
155 14 15 18 7
165 14 12 14 4
175 15 14 15 1
180 15 15 15
CANDELA DISTRIBUTION
Mod l No. JS4B432UNVH4
LER = FP - 77.2 IW - 108 BF - 0.90
Comparativ y arly lighting n rgy cost p r
1000 lum ns = $3.11
R port Numb r: 2884
Catalog Numb r: JS4B432UNVH4
Lamps: (4) F32T8
Luminair : J t Star surfac luminair with
cl ar wraparound prismatic l ns.
Ballast: ICN-4P32-N
R port is bas d on 2850 Lum ns p r lamp.
Effici ncy: 81.3%
AVERAGE AVERAGE AVERAGE AVERAGE
IN DEG. 0-DEG. 45-DEG. 90-DEG.
45 6717. 6935. 7603.
55 5340. 5624. 6269.
65 3151. 3510. 4382.
75 2063. 2609. 3837.
85 798. 2543. 5408.
LUMINANCE DATA IN CANDELA/SQ. METER
COEFFICIENTS OF UTILIZATION –
ZONAL CAVITY METHOD. EFFECTIVE
FLOOR CAVITY REFLECTANCE 0.200
RC 80 50 30
RW 70 50 30 50 30 10 50 30 10
01 87 83 80 77 74 73 72 70 69
02 80 73 68 67 63 60 64 61 58
03 73 65 58 60 55 51 57 52 49
04 67 57 50 53 48 43 51 46 42
05 62 51 44 48 42 38 46 41 37
06 57 46 39 43 37 33 41 36 32
07 53 42 35 39 33 29 38 32 29
08 49 38 31 36 30 26 34 29 26
09 46 35 29 33 27 23 32 27 23
10 43 32 26 30 25 21 29 24 21
ZONE LUMENS % LAMP % FIXT
00-030 2445 21.4 26.4
00-040 4052 35.5 43.7
00-060 7116 62.4 76.8
00-090 8611 75.5 92.9
90-120 502 4.4 5.4
90-130 576 5.1 6.2
90-150 639 5.6 6.9
90-180 660 5.8 7.1
00-180 9271 81.3 100.0
ZONAL LUMEN SUMMARY
0.0 45.0 90.0 FLUX
0 3116 3116 3116
5 3115 3098 3082 295
15 2982 2992 3024 848
25 2756 2804 2895 1302
35 2422 2545 2696 1607
45 1972 2179 2414 1699
55 1288 1491 1686 1366
65 572 730 930 788
75 240 377 572 443
85 38 195 440 264
95 2 228 342 203
105 6 196 296 178
115 10 128 211 121
125 15 84 146 74
135 20 47 90 41
145 21 30 50 22
155 23 23 29 12
165 25 23 25 7
175 25 23 25 2
180 24 24 24
CANDELA DISTRIBUTION
