Calculite®ProSpec®Linear Downlight PB1H3039
Page 1 of 2 1 Light PAR30 MH Series B
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2011 Genlyte Thomas Group LLC (Lightolier Division) • B0711
Features
1. Aperture Frame: Provides clean support for lamp holders and overlapping
flange or trimless installation. Extruded aluminum. Rigidly welded together
on all corners.
2. Media Cartridge: Allows convenient loading and removal of up to one
accessory. Easily installed and removed for lamping with a simple twisting
motion. Constructed of die-formed aluminum.
3. Ad ustable Ring: Allows 360° horizontal and 40° (on width) and 45° (on
diagonal) vertical adjustment.
4. Tortiontite Spring: For easy installation of aperture frame.
5. Housing: Die-formed 22 ga. steel. Finish: Black
6. Mounting Brackets: Adjustable vertically from outside of housing.
7. Thermal Protector: Meets NEC and UL requirement.
8. Lampholder: Porcelain medium based; nickel plated screw shell. 5KV pulse
rated, prewired with #18 SF-1 leads to Ballast Housing.
9. Ballast Housing: Die-formed 18 ga. steel.
10. Junction Box: 14 ga. steel, 4” x 3 1/2” x 2” box. Allows inspection from
below.
11. Lamp and Accessory Support: .032" steel, flared for easy entry of Media
Cartridge.
12. Lens Retaining Ring: .093" spring steel rod. Holds accessories in place.
Electrical
Electronic Ballast: High Power Factor. Input watts: 44, line current: .37 amps.
Accessible from below.
UL listed for through branch circuit wiring with maximum of (8) no. 12 AWG,
90°C.
Ceiling Cutout: 7 3/16" L x 7 3/16" W
Ordering Information: PAR30 MH Series B
Cat. No. Lamp Ceiling Trim Aperture Finish
PB1H3039BL (1) 39W PAR30 MH Overlap Black with White Flange
PB1H3039WL (1) 39W PAR30 MH Overlap White with White Flange
PB1H3039BTL (1) 39W PAR30 MH Trimless Black
PB1H3039WTL (1) 39W PAR30 MH Trimless White
Finish
All painted finishes are powder coated baked enamel.
Options and Accessories
Accessories: 3 3/4" dia. series, filters, lenses, screens and louvers (1) max.
Label
UL/cul (Suitable for Damp Location), I.B.E.W.
PB1H3039BTL (Trimless) Black
PB1H3039WTL (Trimless) White
15 1/8"
1 3/4"
8"
13"
83/4"
Depth
9"
12 3/8" L X 10" W
6" L X 6" W Opening
123
4
5
68
9
7
10
11
12
Flanged Trimless
Top View
16"
PB1H3039BL (Flanged) Black/White
PB1H3039WL (Flanged) White
Lightolier a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2011 Genlyte Thomas Group LLC (Lightolier Division) • B0711
Job Information Type:
39W PAR30
FL
(FC) is initial footcandles at center of beam.
Beam length (L) and beam width (W) are to
where the candlepower is reduced to 50%
of center beam candlepower.
CBCP is center beam candlepower.
(C) is distance to the center of the beam.
Performance data shown is based on bare
lamp photometrics of MasterColor lamps by
Philips Lighting. Contact lamp manufacturers
for availability and performance.
Accent Lighting Performance Data
00° Aiming Angle 30° Aiming Angle 30° Aiming Angle 40° Aiming Angle
15’ 187 2.6’ 2.6’
20’ 105 3.5’ 3.5’
25’ 67 4.4’ 4.4’
30’ 47 5.2’ 5.2’
7’ 133 3.8’ 3.8’
10’ 65 5.4’ 5.4’
13’ 38 7.0’ 7.0’
16’ 25 8.6’ 8.6’
10’ 5.8’ 273 2.3’ 2.0’
15’ 8.7’ 121 3.5’ 3.0’
20’ 11.5’ 68 4.7’ 4.0’
25’ 14.4’ 44 5.8’ 5.1’
6’ 3.5’ 117 4.4’ 3.7’
9’ 5.2’ 52 6.6’ 5.6’
12’ 6.9’ 29 8.8’ 7.4’
15’ 8.7’ 19 11.0’ 9.9’
5’ 8.7’ 210 3.6’ 1.7’
8’ 13.9’ 82 5.7’ 2.8’
11’ 19.1’ 43 7.9’ 3.8’
14’ 24.2’ 27 10.0’ 4.9’
2’ 3.5’ 203 5.5’ 2.1’
3’ 5.2’ 90 8.2’ 3.2’
4’ 6.9’ 51 10.9’ 4.3’
5’ 8.7’ 33 13.7’ 5.4’
8’ 9.5’ 174 3.4’ 2.2’
12’ 14.3’ 77 5.1’ 3.3’
16’ 19.1’ 44 6.9’ 4.4’
20’ 23.8’ 28 8.6’ 5.5’
4’ 4.6’ 108 5.8’ 3.2’
6’ 7.2’ 48 8.7’ 6.0’
8’ 9.5’ 27 11.6’ 6.7’
10’ 11.9’ 17 14.4’ 8.3’
D FC LW DCFC LW D CFC LW D CFC LW
Beam Spread Rated
50% Max CP CBCP Life-Hrs
9000
9000
42000
6500
39W PAR30
SP
10°
30°
39W
Lamp
40°
Calculite®ProSpec®Linear Downlight PB1H3039
Page 2 of 2 1 Light PAR30 MH Series B
