LR Series Fully Recessed LED Exit Sign LR
Page 1 of 1 AC Only or Emergency Operation Die-Cast Aluminum Housing
Lightolier is a Philips group brand
The LR Series is a fully recessed die-cast aluminum exit sign. The LR Series is ideal for areas where unobtrusive emergency egress lighting is desired.
14.8”
(37.6 cm)
2.5”
(6.4 cm)
9.6”
(24.3 cm)
Front and Side Views of Installed Sign
Drywall
Features
1. Illumination: Illumination is accomplished with long lasting, high output
Light Emitting Diodes (LEDs). LEDs and support electronics have an expected
life of 25 years.
2. Housing: Constructed of die-cast aluminum with NFPA-type field selectable
chevrons. Housing and stencil face castings are available with durable
epoxy-based powder coat paint finishes. Includes 20 gauge galvanized steel
mounting frame for fully recessed drywall installations. The outer trim flange
is painted white or black to match the exit stencil or wall finish. Its slim 2.5”
recessed depth allows mounting flexibility in shallow aluminum stud wall
systems, as well as standard wood stud/sheetrock applications.
3. Electronics: 120/277 VAC dual voltage input with surge-protected, solid-
state circuitry. Charging system is complete with low voltage disconnect, AC
lockout, brownout protection, AC indicator lamp and test switch.
4. Battery: Maintenance free, sealed nickel cadmium battery has an estimated
service life of 12 years, and an operating temperature range of 20°F (-7°C) to
95°F (35°C).
5. Input Power Requirements: AC Only - Red: 3.32 W; Green: 4.11 W
Emergency Operation - Red: 4.39 W; Green: 3.52 W
6. Warranty: Electronics: 3 years, Battery: 5 year full, 5 years pro-rata
Code Compliance
UL 924 listed.
Options
2CKT1 = 120 VAC Two Circuit
2CKT2 = 277 VAC Two Circuit
BF = Buzzer/Flasher (Emergency units only)
BZ = Buzzer (Emergency units only)
DC6 = 6VDC Remote Emergency Power
DC12 = 12VDC Remote Emergency Power
EX= Special Input Transformer (Specify voltage & frequency)
FA = 24 VDC Fire Alarm Interface
FL = Emergency Flasher
LCR = Low Level Matching Exit
TP = Tamperproof Screws (Requires T15TPTOOL)
VRS = Vandal Resistant Lens with Tamperproof Hardware
Multiple option configurations may void UL listing. Consult factory for specifics.
Accessories
T15TPTOOL = Tamperproof Screwdriver
LR
SERIES BATTERY STENCIL LETTER STENCIL FACE/
FACES COLOR HOUSING COLOR
LR = Fully Recessed
Die-Cast
Aluminum LED Exit
N = Nickel Cadmium
A = AC Only
1 = Single
2 = Double
R = Red
G = Green
A = Natural Brushed Aluminum Face w/Black Housing
B = Black Stencil Face w/Black Housing
W = White Stencil Face w/White Housing
WA = Natural Brushed Aluminum Face w/White Housing
Complete Fixture consists of base exit sign. Select options and accessories below.
How to Specify:
Wall cutout: 9.12" x 13.75"
