Lightolier MJ2 Series User manual

MJ2 Series
CHICAGO STEEL UNIT
Page 1 of 2
Job Information Type:
Job Name:
Cat. No.:
Notes:
Features
Illumination: High output
incandescent sealed beam
lamps provide glare-free light
distribution. 6 or 12 V, 12 W
bi-pin halogen has an expected
life of 100 hours.
Housing: Heavy duty steel
cabinet is finished in neutral
cream baked-on powder
paint providing scratch and
corrosion resistance. All
metal lamp housing and swivel
assemblies in neutral cream
color to match unit housing.
Lamp heads are fully adjustable
and feature lockable swivels.
Battery: Maintenance-free,
sealed, lead calcium battery
has an estimated service life
of 5 years, and an operating
temperature range of
68°F (20°C) to 86°F (30°C).
Nickel cadmium batteries are
optional.
Electronics: 120/277 VAC
dual voltage input with surge-
protected, solid-state circuitry.
Fully automatic, temperature
compensating, variable rate
float charging system is
complete with low voltage
disconnect, AC lockout,
brownout protection, AC
indicator lamp and test switch.
Code Compliance
All models are UL 924 listed
and meet NFPA 101 Life Safety
Code, NEC, OSHA and City of
Chicago codes.
Warranty
Three year unit warranty
(excludes lamps). One year full
plus four year prorated battery
warranty (lead calcium). Five
year full plus five year prorated
battery warranty (nickel
cadmium).
MJ2132LH12W

MJ2 Series
CHICAGO STEEL UNIT
Page 2 of 2
Philips Lightolier
e: [email protected]
t: [phone]
w: www.lightolier.com
MJ2 Series September 19, 2011
Specifications are subject to change without notice.
© Koninklijke Philips Electronics N.V., 2011.All rights reserved.
Job Information Type:
Ordering Information
Series
MJ2 = Chicago
Steel Unit
MJ2
6 V, Lead Calcium
32L = 32 W
52L = 52 W
12 V, Lead Calcium
104L = 104 W
6 V, Nickel Cadmium
26N = 26 W
12 V, Nickel Cadmium
30N = 30 W
52N = 52 W
Battery Wattage
1= 6 V
2= 12 V
Voltage
W= Neutral
Cream
Housing Color
W
V= Voltmeter1
A= Ammeter1
A1H = Add One Lighting Head (25 & 30 W units)
LC = 3-Conductor Line Cord - 120 VAC
TD-120 = 15-Minute Re-Transfer Time Delay (120 V)
TD-277 = 15-Minute Re-Transfer Time Delay (277 V)
B= Black Finish - Housing and Lamp Heads
SX = Self-Diagnostic Circuit
Factory Installed Options
H12 = Halogen
12 W
Lamp Type
H12
Note
1) Unit has provisions for one meter option only.
Accessories (order as a separate item)
MJB1 = Mounting Bracket
MJS1 = Mounting Shelf (25 & 30 W units)
MJS2 = Mounting Shelf (50 W units)
MJS3 = Mounting Shelf (72 & 100 W units)
MJS6 = Mounting Shelf (125 & 250 W units)
MJPG1 = Wire Guard (6 V models)
MJPG2 = Wire Guard (12 V models)
MJ908W08 = Matching Remote Head - Single (6 V, 12 W Halogen)
MJ908W54 = Matching Remote Head - Single (12 V, 12 W Halogen)
MJ909W08 = Matching Remote Head - Double (6 V, 12 W Halogen)
MJ909W54 = Matching Remote Head - Double (12 V, 12 W Halogen)
4.75"
(12.0 cm)
6.5"
(16.5 cm)
H
T
WD
2.875"
(7.3 cm)
MJ2132L/26N/30N
MJ2152L/N
MJ22104L
MODEL # D" W" H"
9.0"
(22.9 cm)
8.135"
(20.6 cm)
2.875"
(7.3 cm)
12.25"
(31.1 cm)
8.25"
(21.0 cm)
4.135"
(10.5 cm)
12.25"
(31.1 cm)
8.25"
(21.0 cm)
DIMENSIONS
T"
14.135"
(35.9 cm)
14.25"
(36.2 cm)
14.25"
(36.2 cm)
