Linak TECHLINE LA33 User manual

Page 1 of 80
LINAK.COM/TECHLINE
Actuator LA33
User manual

Page 2 of 80
Contents
Preface ...............................................................................................................4
LINAK application policy......................................................................................5
Chapter 1
Safety instructions...............................................................................................6
Chapter 2
Mounting guidelines...........................................................................................8
Mounting of cables...........................................................................................10
Electrical installation..........................................................................................11
Recommended fuse ..........................................................................................11
Actuator without feedback ...............................................................................12
Actuator with End Stop Signal output...............................................................13
Actuator with End Stop Signal output...............................................................14
Actuator with relative positioning - Single Hall ..................................................15
Actuator with End Stop Signals and relative positioning - Single Hall .................17
Actuator with absolute positioning - Analogue feedback ..................................19
Actuator with End Stop Signals and absolute positioning Analogue feedback ...21
Actuator with absolute positioning - PWM........................................................23
Actuator with End Stop Signals and absolute positioning - PWM.......................25
Actuator with IC Basic.......................................................................................27
Actuator with IC Advanced - with Feedback and End Stop Signal......................29
Actuator with IC Advanced - with Feedback......................................................32
Actuator with IC Advanced - with End Stop Signal ............................................35
Actuator with IC Advanced - without Feedback and End Stop Signal.................37
Actuator with proportional control....................................................................39
IC options overview ..........................................................................................44
Feedback configurations available for IC Advanced, Proportional and Parallel....45
Actuator with Parallel........................................................................................48
Actuator with CANbus J1939:...........................................................................55
Actuator with CANbus J1939:...........................................................................57
System combination possibilities for LA33 IC Advanced.....................................59
TECHLINE signal cables .....................................................................................59

Page 3 of 80
Chapter 3
Troubleshooting................................................................................................60
Troubleshooting for Parallel...............................................................................62
BusLink service counter - Reason for last stop....................................................64
Chapter 4
Specifications ...................................................................................................65
Usage: ..............................................................................................................65
Actuator dimensions.........................................................................................66
Built-in dimensions............................................................................................67
Manual Hand Crank..........................................................................................68
Speed and current curves..................................................................................69
12V motor........................................................................................................69
24V motor........................................................................................................70
Label for LA33 ..................................................................................................71
Key to symbols..................................................................................................72
LA33 ordering example.....................................................................................73
Chapter 5
Maintenance.....................................................................................................75
Repair...............................................................................................................75
Main groups of disposal....................................................................................75
Warranty ..........................................................................................................75
Declaration of conformity .................................................................................76
Declation of conformity of partly completed machinery.....................................79
Contacts...........................................................................................................80

Page 4 of 80
Preface
Dear User,
We are delighted that you have chosen a product from LINAK®.
LINAK systems are high-tech products based on many years of experience in the manufacture and development of
actuators, electric control boxes, controls, and chargers.
This user manual does not address the end-user, but is intended as a source of information for the manufacturer of
the equipment or system only, and it will tell you how to install, use and maintain your LINAK electronics. It is the
responsibility of the manufacturer of the end-use product to provide a User Manual where relevant safety information
from this manual is passed on to the end-user.
We are sure that your LINAK product/system will give you many years of problem-free operation. Before our products
leave the factory they undergo full function and quality testing. Should you nevertheless experience problems with
your LINAK product/system, you are always welcome to contact your local dealer. LINAK subsidiaries and some
distributors situated all over the world have authorised service centres, which are always ready to help you.
LINAK provides a warranty on all its products. This warranty, however, is subject to correct use in accordance with
the specifications, maintenance being done correctly and any repairs being carried out at a service centre, which is
authorised to repair LINAK products.
Changes in installation and use of LINAK products/systems can affect their operation and durability. The products are
not to be opened by unauthorised personnel.
The User Manual has been written based on our present technical knowledge.We are constantly working on updating
the information and we therefore reserve the right to carry out technical modifications.
LINAK A/S

Page 5 of 80
LINAK application policy
The purpose of the application policy is to define areas of responsibilities in relation to applying a LINAK product
defined as hardware, software, technical advice, etc. related to an existing or a new customer application.
LINAK products as defined above are applicable for a wide range of applications within Medical, Furniture, Desk, and
Industry areas. Yet, LINAK cannot know all the conditions under which LINAK products will be installed, used, and
operated, as each individual application is unique.
The suitability and functionality of the LINAK product and its performance under varying conditions (application,
vibration, load, humidity, temperature, frequency, etc.) can only be verified by testing, and shall ultimately be the
responsibility of the LINAK customer using any LINAK product.
LINAK shall be responsible solely that LINAK products comply with the specifications set out by LINAK and it shall be
the responsibility of the LINAK customer to ensure that the specific LINAK product can be used for the application
in question.

Page 6 of 80
Chapter 1
Please read this safety information carefully:
Be aware of the following three symbols throughout the user manual:
Warning!
Failing to follow these instructions can cause accidents resulting in serious personal injury.
Recommendations
Failing to follow these instructions can result in the actuator suffering damage or being ruined.
Additional information
Usage tips or additional information that is important in connection with the use of the actuator.
Furthermore, ensure that all staff who are to connect, mount, or use the actuator are in possession of the necessary
information and that they have access to this user manual.
Persons who do not have the necessary experience or knowledge of the product/products must not use the product/
products. Besides, persons with reduced physical or mental abilities must not use the product/products, unless they
are under surveillance or they have been thoroughly instructed in the use of the apparatus by a person who is
responsible for the safety of these persons.
Moreover, children must be under surveillance to ensure that they do not play with the product.
Before you start mounting/dismounting, ensure that the following points are observed:
• The actuator is not in operation.
• The actuator is free from loads that could be released during this work.
Before you put the actuator into operation, check the following:
• The actuator is correctly mounted as indicated in the relevant user instructions.
• The equipment can be freely moved over the actuator’s whole working area.
• The actuator is connected to a mains electricity supply/transformer with the correct voltage and which is dimensioned
and adapted to the actuator in question.
• Ensure that the voltage applied matches to the voltage specified on the actuator label.
• Ensure that the connection bolts can withstand the wear.
• Ensure that the connection bolts are secured safely.
Safety instructions

Page 7 of 80
During operation, please be aware of the following:
• Listen for unusual sounds and watch out for uneven running. Stop the actuator immediately if anything unusual
is observed.
• Do not sideload the actuator.
• Only use the actuator within the specified working limits.
• Do not step or kick on the actuator.
When the equipment is not in use:
• Switch off the mains supply in order to prevent unintentional operation.
• Check regularly for extraordinary wear.
Classification
The equipment is not suitable for use in the presence of a flammable anaesthetic mixture with air or with oxygen
or nitrous oxide.
• Do not sideload the actuator.
• When mounting the LA33 in the application ensure that the bolts can withstand the wear and that they are
secured safely.
• If irregularities are observed, the actuator must be replaced.
Recommendations
• Do not place load on the actuator housing and do prevent impact or blows, or any other form of stress to the
housing.
• Ensure that the cable cover is mounted correctly. Use 3.5Nm torque.
• Ensure that the duty cycle and the usage temperatures for LA33 actuators are respected.
• Ensure that the cable cannot be squeezed, pulled or subjected to any other stress.
• Furthermore, it will be good practice to ensure that the actuator is fully retracted most of the time.
The reason is that there will be a vacuum inside the actuator when it is extended, which over time can lead to
water entering the actuator.
• If the actuator (without integrated controller) is mounted in an application where a mechanical stop prevents the
endstop switches in the actuator from being activated, the actuator must be equipped with an electrical safety
device (current monitoring) or external limit switch.
Warnings

Page 8 of 80
Chapter 2
Mounting guidelines
LINAK®linear actuators are quickly and easily mounted by slipping pins through the holes on each end of the
units and into brackets on the machine frame and the load.
Figure 2
Right WrongWrong Wrong
Figure 1
The mounting pins must be parallel to each other as
shown in Figure 1. Pins, which are not parallel to each
other, may cause the actuator to bend and be damaged.
The load should act along the stroke axis of the actuator
as off-centre loads may cause bending and lead to
premature failure. See Figure 2.
Make sure the mounting pins are supported in both ends.
Failure to do so could shorten the life of the actuator. Also,
avoid applying a skew load on the actuator.
The actuator can rotate around the pivot point in the front and rear end. If this is the case it is of high importance
that the actuator is able to move freely over the full stroke length, both during the development and daily
operation. Please pay special attention to the area around the housing where parts can be trapped and cause
damage to the application and actuator.
In applications with high dynamic forces LINAK recommends not to use the fully extended or retracted position
over longer time, as this can damage the endstop system permanently.

Page 9 of 80
Mounting guidelines
030618/DS
Instruktion vedr. uddrejning af inderrør – LA27 + LA27C
Til salesbackup, brugsanvisning og datablad.
Ved montage og ibrugtagning, er det ikke tilladt at dreje unødvendigt mange gange på
stempelstangsrøret. Hvis øjet ikke er positioneret korrekt, er det tilladt først at skrue
røret i bund (1), og derefter skrue det maksimalt ½ omgang ud igen (2).
• The mounting pins must have the correct dimension.
• The bolts and nuts must be made of a high quality steel grade (e.g. 10.8).
No thread on the bolt inside the back fixture or the piston rod eye.
• Bolts and nuts must be protected so there is no risk for them to fall out.
• Do not use a torque that is too high when mounting the bolts for the back fixture or the piston rod eye.
This will stress the fixtures.
Please note:
The piston rod eye is only allowed to turn 0-90 degrees.
Instruction concerning the turning of the piston rod eye and inner tube:
• When mounting and taking into use, it is not permitted to make excessive turns of the piston rod eye. In
cases where the eye is not positioned correctly, it is permitted to first screw the eye down to its bottom
position, at a maximum torque of 2Nm (1), and thereafter a maximum 90 degrees turn outwards again
(2).
• As the piston rod eye can turn freely, it is important to ensure that the eye cannot rotate if the actuator
is used in a pull application. If this happens, the actuator will be pulled apart and destroyed.
Warning!
If the actuator is used for pull in an application where personal injury can occur, the following
is valid:
It is the application manufacturer’s responsibility to incorporate a suitable safety arrangement, which will
prevent personal injury from occurring, if the actuator should fail.
LINAK’s actuators are not designed for use within the following fields:
• Offshore installations • Explosive environments
• Aeroplanes and other aircraft • Nuclear power generation

Page 10 of 80
Mounting of cables
When changing the cables on a LINAK actuator, it is important that this is done carefully, in order to
protect the plugs and pins. Before the new cable is mounted, we recommend that the socket is greased
with vaseline, to keep the high IP protection and ensure an easy mounting. Please be sure that the plug
is in the right location and fully pressed in before the cable lid is mounted.
Please note that if the cables are mounted and dismounted more than 3 times the plugs can be damaged.
Therefore, we recommend that such cables are discarded and replaced.
Also note that the cables should not be used for carrying the actuator.
We recommend to take some precaution and design the wire connection in a way, where the cable end
is kept inside a closed, protected area to guarantee the high IP protection.
3.Slide the cover onto
the actuator.
The torque of the
cover screw is
approx. 3.5 ± 0.3 Nm
TORX 25IP
1.Unscrew the cover and
remove the two blind
plugs.
2.Plug in the power
cable and/or the
signal cable.

Page 11 of 80
Type Spindle
Pitch
(mm)
Thrust
max.
Push/Pull
(N)
Typical Amp.
at full load
(A)
24V 12V
Recommended
fuse
24V 12V
33090xxxxxxxxA... 9 5000 - 10 - 20
33150xxxxxxxxA... 15 3500 - 10 - 20
33150xxxxxxxxA... 15 2250 - 10 - 20
33200xxxxxxxxA... 20 1500 - 10 - 20
33090xxxxxxxxB... 9 5000 6.5 - 15 -
33150xxxxxxxxB... 15 3500 7.0 - 15 -
33150xxxxxxxxB... 15 2250 6.6 - 15 -
33200xxxxxxxxB... 20 1500 6.5 - 15 -
Electrical installation
• To ensure maximum self-locking ability, please be sure that the motor is shorted when stopped.Actuators
with integrated controller provide this feature, as long as the actuator is powered.
• When using soft stop on a DC-motor, a short peak of higher voltage will be sent back towards the power
supply. It is important when selecting the power supply that it does not turn off the output, when this
backwards load dump occurs.
The power supply for actuators without integrated controller must be monitored externally and cut off in case
of current overload.
Recommended fuse for actuators without integrated controller

Page 12 of 80
4
2019 © LINAK A/S
Without feedback
33XXXXXX0000XXXX=XXXXXXXXXXXXX
BROWN
BLUE
Powered by Danfoss
2
1
4
2021 © LINAK A/S
Without feedback
Input/Output Specification Comments
Description Permanent magnetic DC motor.
Brown 12 or 24 VDC (+/-)
12 V ±20 %
24V ± 10 %
Under normal conditions:
12 V, max. 13 A depending on load
24 V, max. 9 A depending on load
To extend actuator:
Connect Brown to positive
To retract actuator:
Connect Brown to negative
Blue To extend actuator:
Connect Blue to negative
To retract actuator:
Connect Blue to positive
Red Not to be connected
Black Not to be connected
Green Not to be connected
Yellow Not to be connected
Violet Not to be connected
White Not to be connected
Actuator without feedback
Connection diagram:
Fig. 1 : 33xxxxxx0000xxxx=xxxxxxxxxxxxx
I/O specifications:

Page 13 of 80
5
2019 © LINAK A/S
End Stop Signal output
33XXXXXXXXXXXX0X=XXXXX1XXXXXXX
Powered by Danfoss
YELLOW
GREEN
BROWN
BLUE
RED
BLACK
+
-
2
1
2
5
6
1
AMP
DEUTSCH
Standard signal cabel
Standard signal cabel
Actuator with End Stop Signal output
*YELLOW/GREEN:
End Stop Signals out are NOT potential free!
If you wish to use the End Stop Signals, you will have to keep power on the brown, blue, red and black wires, other-
wise the signal will be lost.
Connection diagram:
Fig. 2 : 33xxxxxxxxxxxx0x=xxxxx1xxxxxxx

Page 14 of 80
5
2021 © LINAK A/S
Endstop signal output
Input/Output Specification Comments
Description The actuator can be equipped withelectronically controlled
Endstop Signals out.
Brown 12 or 24 VDC (+/-)
12 V ±20 %
24 V ± 10 %
Under normal conditions:
12 V, max. 13 A depending on load
24 V, max. 9 A depending on load
To extend actuator:
Connect Brown to positive
To retract actuator:
Connect Brown to negative
Blue To extend actuator:
Connect Blue to negative
To retract actuator:
Connect Blue to positive
Red Signal power supply (+) 12-24 VDC Current consumption:
Max. 40 mA, also when the
actuator is not running
Black Signal power supply GND (-)
Green Endstop signal out Output voltage min. VIN - 2 V
Source current max. 100 mA
NOT potential free
Yellow Endstop signal in
Violet Not to be connected
White Not to be connected
Tip: If you wish to use the endstop signals, you will have to keep power on the brown, blue, red and black wires, otherwise the
signal will be lost.
Actuator with End Stop Signal output
I/O specifications:

Page 15 of 80
8
2019 © LINAK A/S
Relative positioning - Single hall
33XXXXXXXX0KXXXX=XXXX0XXXXXXXX
Powered by Danfoss
VIOLET
BROWN
BLUE
RED
BLACK
+
-
2
1
2
1
4
AMP
DEUTSCH
Standard signal cabel
Standard signal cabel
Actuator with relative positioning - Single Hall
Connection diagram:
Fig. 3 : 33xxxxxxxx0Kxxxx=xxxx0xxxxxxxx

Page 16 of 80
8
2021 © LINAK A/S
Relative positioning - Single hall
Input/Output Specification Comments
Description The actuator can be equipped with Single hall that gives a relative
positioning feedback signal when the actuator moves.
Brown 12 or 24 VDC (+/-)
12 V ±20 %
24 V ± 10 %
Under normal conditions:
12 V, max. 13 A depending on load
24 V, max. 9 A depending on load
To extend actuator:
Connect Brown to positive
To retract actuator:
Connect Brown to negative
Blue To extend actuator:
Connect Blue to negative
To retract actuator:
Connect Blue to positive
Red Signal power supply (+) 12-24 VDC Current consumption:
Max. 40 mA, also when the
actuator is not running
Black Signal power supply GND (-)
Green Not to be connected
Yellow Not to be connected
Violet Single Hall output (PNP)
Movement per Single Hall pulse:
33090: Actuator = 0.3 mm per count
33150: Actuator = 0.5 mm per count
33200: Actuator = 1.1 mm per count
Frequency:
Frequency is up to 125 Hz on Single Hall output depending on load and
spindle.
Overvoltage on the motor can result in shorter pulses.
Output voltage min. VIN - 2 V
Max. current output: 12 mA
Max. 680 nF
N.B. For more precise measurements, please
contact LINAK A/S.
Low frequency with a high load.
Higher frequency with no load.
Input: Single hall output:
White Not to be connected
Actuator with relative positioning - Single Hall
I/O specifications:

Page 17 of 80
9
2019 © LINAK A/S
End Stop Signals and relative positioning - Single hall
33XXXXXXXX0KXXXX=XXXX1XXXXXXXX
*YELLOW/GREEN: Endstop signals out are NOT potential free (see specifications on next page)
Tip: If you wish to use the endstop signals, you will have to keep power on the brown, blue,
red and black wires, otherwise the signal will be lost.
Powered by Danfoss
BROWN
BLUE
YELLOW*
GREEN*
RED
VIOLET
BLACK
+
-
2
1
2
4
1
5
6
AMP
DEUTSCH
Standard signal cabel
Standard signal cabel
Actuator with End Stop Signals and relative positioning - Single Hall
Connection diagram:
Fig. 4 : 33xxxxxxxx0Kxxxx=xxxx1xxxxxxxx

Page 18 of 80
9
2021 © LINAK A/S
Endstop signals and relative positioning - Single hall
Input/Output Specification Comments
Description The actuator can be equipped with Single hall that gives a relative
positioning feedback signal when the actuator moves.
Brown 12 or 24 VDC (+/-)
12 V ±20 %
24 V ± 10 %
Under normal conditions:
12 V, max. 13 A depending on load
24 V, max. 9 A depending on load
To extend actuator:
Connect Brown to positive
To retract actuator:
Connect Brown to negative
Blue To extend actuator:
Connect Blue to negative
To retract actuator:
Connect Blue to positive
Red Signal power supply (+) 12-24 VDC Current consumption:
Max. 40 mA, also when the
actuator is not running
Black Signal power supply GND (-)
Green Endstop signal out Output voltage min. VIN - 2 V
Source current max. 100 mA
NOT potential free
Yellow Endstop signal in
Violet Single Hall output (PNP)
Movement per Single Hall pulse:
33090: Actuator = 0.3 mm per count
33150: Actuator = 0.5 mm per count
33200: Actuator = 1.1 mm per count
Frequency:
Frequency is up to 125 Hz on Single Hall output depending on load and
spindle.
Overvoltage on the motor can result in shorter pulses.
Output voltage min. VIN - 2 V
Max. current output: 12 mA
Max. 680 nF
N.B. For more precise measurements,
please contact LINAK A/S.
Low frequency with a high load.
Higher frequency with no load.
Input: Single hall output:
White Not to be connected
Actuator with End Stop Signals and relative positioning - Single Hall
I/O specifications:

Page 19 of 80
10
2019 © LINAK A/S
Absolute positioning - Analogue feedback
33XXXXXXXX0AXXXX=XXXX0XXXXXXXX
VIOLET
BROWN
BLUE
RED
BLACK
+
-
Powered by Danfoss
The signal power must be turned on at all times when the actuator is running, and minimum one second before it starts to run.
2
1
2
1
4
AMP
DEUTSCH
Standard signal cabel
Standard signal cabel
Actuator with absolute positioning - Analogue feedback
Connection diagram:
Fig. 5 : 33xxxxxxxx0Axxxx=xxxx0xxxxxxxx

Page 20 of 80
10
2021 © LINAK A/S
Absolute positioning - Analogue feedback
Input/Output Specification Comments
Description The actuator can be equipped with an electronic circuit that gives an
analogue feedback signal when the actuator moves.
Brown 12 or 24 VDC (+/-)
12 V ±20 %
24 V ± 10 %
Under normal conditions:
12 V, max. 13 A depending on load
24 V, max. 9 A depending on load
To extend actuator:
Connect Brown to positive
To retract actuator:
Connect Brown to negative
Blue To extend actuator:
Connect Blue to negative
To retract actuator:
Connect Blue to positive
Red Signal power supply (+) 12-24VDC Current consumption:
Max. 60 mA, also when the
actuator is not running
Black Signal power supply GND (-)
Green Not to be connected
Yellow Not to be connected
Violet Analogue feedback
0-10 V (Option B)
0.5-4.5 V (Option C)
Tolerances +/- 0.2 V
Max. current output: 1 mA
Ripple max. 200 mV
Transaction delay 100 ms
Linear feedback 0.5 %
White Not to be connected
For actuators with analogue feedback it is recommended to fully extract and retract the actuator on a regular basis (thereby
activating the limit switches) in order to ensure precise positioning.
Actuator with absolute positioning - Analogue feedback
I/O specifications:
