Linak Homeline TWINDRIVE TD5 Standard User manual

Page 1 of 31
LINAK.COM/HOMELINE
TWINDRIVE®TD5 Standard
User manual

Page 2 of 31
Contents
Preface............................................................................................................................................. 3
Important information .................................................................................................................. 4
Safety instructions......................................................................................................................... 4
Safety issues............................................................................................................................... 5
Before installation, reinstallation or troubleshooting .................................................................... 8
Before start-up ........................................................................................................................... 8
During operation......................................................................................................................... 8
Misc ........................................................................................................................................... 8
Only for EU markets....................................................................................................................... 9
Only for Non EU markets .............................................................................................................. 9
Misuse ............................................................................................................................................. 9
Informations importantes............................................................................................................. 10
Consignes de sécurité.................................................................................................................... 10
Avant l´installation, ré-installation ou le dépannage..................................................................... 11
Avant de démarage..................................................................................................................... 11
Pendant le fonctionnement ......................................................................................................... 11
Divers......................................................................................................................................... 11
Seulement pour les marchés au sein de l´UE.............................................................................. 12
Seulement pour les marchés hors UE.......................................................................................... 12
Utilisation abusive ......................................................................................................................... 12
Repairs............................................................................................................................................. 13
Misc. on the TWINDRIVE®TD5 Standard system........................................................................ 14
Description of the TWINDRIVE®TD5 Standard system.............................................................. 14
Mounting the TD5 Standard ......................................................................................................... 15
Cable strain relief........................................................................................................................ 16
Start-up (How to pair Bluetooth®connection)........................................................................... 17
1. Pairing your control................................................................................................................. 17
2. Pairing your smartphone or your tablet.................................................................................... 18
3. Pairing another device later..................................................................................................... 19
4. Forced pairing mode ............................................................................................................... 19
Mechanical Emergency lowering ................................................................................................. 20
TD5 Twist Bracket
Mounting instructions and parallel tolerance ............................................................................... 21
Welding instructions .................................................................................................................. 22
Functional description................................................................................................................... 23
Labels ............................................................................................................................................. 24
Disposal of LINAK products.......................................................................................................... 25
Main groups of disposal................................................................................................................ 26
Disposal of batteries ..................................................................................................................... 26
Drawing appendix.......................................................................................................................... 27
Addresses........................................................................................................................................ 31

Page 3 of 31
Preface
Dear User,
We are delighted that you have chosen a product from LINAK®.
LINAK systems are high-tech products based on many years of experience in the manufacture and development
of actuators, electric control boxes, controls and chargers.
This User Manual does not address the end-user. It is intended as a source of information for the manufacturer
of the equipment or system only, and it will tell you how to install, use and maintain your LINAK electronics. It
is the responsibility of the manufacturer of the end-use product to provide a User Manual where relevant safety
information from this manual is passed on to the end-user.
We are sure that your LINAK product/system will give you many years of problem-free operation.
Before our products leave the factory they undergo full function and quality testing. Should you nevertheless
experience problems with your LINAK product/system, you are always welcome to contact your local dealer.
LINAK subsidiaries and some distributors situated all over the world have authorised service centres, which are
always ready to help you.
LINAK provides a warranty on all its products. This warranty, however, is subject to correct use in accordance
with the specifications, maintenance being done correctly and any repairs being carried out at a service centre,
which is authorised to repair LINAK products.
Changes in installation and use of LINAK products/systems can affect their operation and durability. The
products are not to be opened by unauthorised personnel.
The User Manual has been written based on our present technical knowledge. We are constantly working on
updating the information and we therefore reserve the right to carry out technical modifications.
LINAK A/S

Page 4 of 31
Safety instruction
General
Important information
Important information on LINAK®products can be found under the following
headings:
Warning!
Failure to comply with these instructions may result in accidents involving
serious personal injury.
Failing to follow these instructions can result in the product being damaged
or being destroyed.
Safe use of the system is possible only when the operating instructions are read
completely and the instructions contained are strictly observed.
Failure to comply with instructions marked with the ”NOTE” symbol may result in
serious damage to the system or one of its components.
It is important for everyone who is to connect, install, or use the systems to
have the necessary information and access to this User Manual. Follow the
instructions for mounting – risk of injury if these instructions are not followed.
The appliance is not intended for use by young children or infirm persons
without supervision.
If there is visible damage on the product it must not be installed.
Note that during construction of applications, in which the actuator is to be
fitted, there must be no possibility of personal injury, for example squeezing
of fingers or arms.
Assure free space for movement of the application in both directions to avoid
blockade.

Page 5 of 31
Assure free space for movement of application in both directions to avoid
blockade.
The appliance is only to be used with the power supply unit provided with the
appliance.
Safety issues
The builder of the equipment shall ensure that the use of the component
complies with relevant standards – like the Machine Directive. Care must be
taken to avoid squeezing of cables as it can cause movement of the system!

Page 6 of 31
This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful
interference, and
(2) This device must accept any
interference received, including
interference that may cause
undesired operation
• Statement – for all intentional and unintentional radiators:
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
• Statement for digital devices for Class B:
NOTE: This equipment has been tested and found to comply with the limits for
a Class B diwgital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions it may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:

Page 7 of 31
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and the receiver.
- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
- Consult the dealer or an experienced radio/ TV technician for help.
Labeling Requirements:
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
This device contains licence-exempt transmitter(s)/receiver(s) that comply with
Innovation, Science and Economic Development Canada’s licence-exempt RSS(s).
Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause
undesired operation of the device.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est
conforme aux CNR d’Innovation, Sciences et Développement économique Canada
applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux
deux conditions suivantes :
(1) l’appareil nedoit pas produire de brouillage, et
(2) l’appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d’en compromettre le fonctionnement.

Page 8 of 31
Before installation, de-installation or troubleshooting:
• Stop the TD5 Standard.
• Disconnect the power.
• Relieve the TD5 of any loads, which may be released during the work.
Before start-up:
• Make sure that the system has been installed as instructed in this User Manual.
• Make sure that the voltage is correct before the system is connected to the mains.
(See TD5 label in the appendix).
• System connection. The individual parts must be connected before connecting to
the mains.
During operation:
• If the control box makes unusual noise or smells, switch off the mains voltage
immediately.
• Take care that the cables are not damaged.
• Unplug the mains cable on mobile equipment before it is moved.
Misc:
The actuator system has a sound level below 55 dB(A) in typical applications.
Updated manuals and declarations can always be found here:
www.linak.com/HOMELINE
Electromagnetic fields (EMF):
This LINAK appliance complies will all standards regarding electromagnetic fields (EMF). If handled properly and according to
instructions in this user manual, the appliance is safe to use based on scientific evidence available today.

Page 9 of 31
Only for EU markets
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved.
Children shall not play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
Only for Non EU markets
Persons who do not have the necessary experience or knowledge of the
product/products must not use the product/products. Besides, persons with
reduced physical, sensory or mental abilities must not use the product/
products, unless they are under surveillance or they have been thoroughly
instructed in the use of the apparatus by a person who is responsible for the
safety of these persons.
Moreover, children must be under surveillance to ensure that they do not
play with the product.
Misuse
Do not overload the actuators – this can cause danger of personal injury and
damage to the system.
Do not use the actuator system for lifting persons. Do not sit or stand on a
table while operating – risk of personal injury.
Do not use the system in environments other than the intended indoor use.

Page 10 of 31
Consignes de sécurité
Géneral
Informations importantes
Les informations importantes sur les produits LINAK®peuvent être trouvées dans
les rubriques suivantes:
Attention!
Le non respect de ces instructions peut entraîner des accidents impliquant
des blessures graves.
Ne pas suivre ces instructions peut entraîner l´endommagement ou
destruction du produit.
Le non respect de ces instructions peut entraîner des accidents impliquant des
blessures graves.
Ne pas suivre ces instructions peut entraîner l´endommagement ou destruction du
produit.
L´utilisation en toute sécurité du système n´est possible que si l´intégralité des
instructions ont été lues et ont été strictement suivies.
Le non respect de se conformer aux instructions marquées du symbole “note”
peut entraîner de graves dommages au système ou à un de ses composants.
Il est important pour tout individu qui connecte, installe, ou utilise le système
d´avoir les informations nécessaires et l´accès à ce mannuel d´utilisation.
Suivez les instructions pour le montage – risque de blessure si ces instructions
ne sont pas suivies.
L´appareil n´est pas destiné à être utilisé par des enfants ou des personnes
handicapées sans surveillance.
S´il y a des dommages visibles sur le produit, l´installation ne doit pas être
effectuée.
Prendre en compte lors de la construction du matériel, dans lequel l´actionneur
est incorporé, qu´il ne doit y avoir aucune possibilité de blessures corporelles,
telles que la compression des doigts ou des bras.
Assurez un espace libre autours du materiel pour éviter tout blocage.

Page 11 of 31
Electromagnetic fields (EMF):
This LINAK appliance complies will all standards regarding electromagnetic fields (EMF). If handled properly and according to
instructions in this user manual, the appliance is safe to use based on scientific evidence available today.
Avant l´installation, ré-installation ou le dépannage:
• Arrêtez TD5 Standard
• Retirez la prise du secteur
• Soulagez TD5 Standard des toutes charges qui pourraient être émises lors de
l´utilisation
Avant de démarage:
• Assurez-vous que le système a été installé comme indiqué dans le mannuel
d´utilisateur.
• Assurez-vous que la tension du boîtier de contrôle est correcte avant que le
système soit connecté sur le secteur.
• Système de connection. Les différentes pièces doivent être connectées entre elles
avant que le boîtier de contrôle soit connecté au secteur. Consultez le manuel
d´utilisation si nécessaire.
Pendant le fonctionnement:
• Si le boîtier de contrôle émet un bruit ou odeurs inhabituelles, éteignez la tension
immédiatement.
• Veuillez à ce que les cables ne soient pas endommagés.
• Débranchez le cable d´alimentation sur l´équipement mobile avant qu´il ne soit
déplacé.
• Les produits ne doivent-être utilisés que dans un environement qui correspond à
leur IP.
Divers:
Le système d´actionneur présente un niveau sonore inférieur à 55 dB(A) dans des
applications typiques.
Les mises à jours des manuels et autres informations peuvent-être trouvées sur
www.linak.com/homeline

Page 12 of 31
Seulement pour les marchés au sein de l´UE:
Cet appareil peut-être utilisé par des enfants âgés de 8 ans et plus, ainsi
que les personnes dont les capacités physiques, sensorielles ou mentales
sont réduites ou ayant un manque d´expérience et de connaissance si elles
ont bénéficié d´une surveillance ou d´instructions concernant l´utilisation de
l´appareil en toute sécurité et compris les risques encourus.
Les enfants ne doivent pas jouer avec l´appareil. Le nettoyage et l´entretien ne
doivent pas être rèalisés par des enfants sans surveillance.
Seulement pour les marchés hors UE:
Les personnes qui n´ont pas l´expérience ou les connaissances nécessaires
sur le ou les produit(s) ne doivent pas le ou les utiliser. Par ailleurs, les
personnes ayant des capacités physiques, sensorielles ou mentales réduites
ne doivent pas utiliser le ou les produit(s), sauf si elles sont sous surveillance
ou ont suivi une formation approfondie de l´utilisation de l´appareil par
l´individu responsable de la securité de ces personnes.
De plus, les enfants doivent-être sous surveillance afin de s´assurer qu´ils ne
jouent pas avec le produit.
Utilisation abusive:
Ne surchargez pas les actionneurs – cela peut engendrer un risque de
blessures corporelles et endommager le système.
Ne pas utiliser les actionneurs pour soulever des personnes. Ne pas s´asseoir
ou se tenir debout sur une table en fonctionnement – risque de blessures.
Ne pas utiliser le système dans dans des environnements autres que
l´utilisation intérieure prévue.

Page 13 of 31
Repairs
In order to avoid the risk of malfunction, all TWINDRIVE®repairs must only be carried out by authorised LINAK workshops or
repairers, as special tools must be used and special gaskets must be fitted.TWINDRIVE under warranty must also be returned
to authorised LINAK workshops.

Page 14 of 31
Misc. on the TWINDRIVE®TD5 Standard system
This system is a TWINDRIVE system developed for leisure beds and for indoor use in private homes.
Warranty
There is 36 months’ warranty on the TWINDRIVE®products against manufacturing faults calculated from the production
date of the individual products (see label). The LINAK®warranty is only valid in so far as the equipment has been used and
maintained correctly and has not been tampered with. Furthermore, the system must not be exposed to violent treatment. In
the event of this, the warranty will be ineffective/invalid. For further details, please see standard terms of sale and delivery for
LINAK A/S.
Maintenance
Clean dust and dirt on the outside of the system at appropriate intervals and inspect them for damage and breaks.
Inspect the connections, cables and plugs and check for correct functioning as well as fixing points.
The cleaners and disinfectants must not be highly alkaline or acidic
(pH value 6-8).
It is not allowed to use solvents for cleaning up.
Max. load running back and leg end motors at the same time in upward direction is 7000 N on back
motor, and 7000 N on leg end motor.
For customers in the US/Canada:
The mains cable for this product has a polarised plug (one blade is wider than the other). It will only fit in a polarised
outlet one way. If it does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician
to install a proper outlet. Do not change the plug in any way.
Description of the TWINDRIVE®TD5 Standard system
Each TWINDRIVE®TD5 Standard unit consists of 2 internal motors and a built-in control box, which makes it a very compact
unit. The mains cable is exchangeable. Only the handset must be paired.
Application of the TWINDRIVE®TD5 Standard system:
Irrespective of the load the Duty cycle: 10 % ~ max. 1 minute at continous use followed by 9 minutes not in use.
Do not turn on the system if it is not mounted in a bed.
TD5 is a Bluetooth®based system, which means you can use hand controls based on Bluetooth®.
LINAK®offers a range of compatible hand controls: HC05BL, HC10BL and HC40BL. Alternatively, the Bed Control App can be
downloaded to use a smartphone as handset.
You can pair eight hand controls to one TD5. You can also pair both hand controls and app controls to the same TD5 Standard,
but only eight controls in total. If you pair more hand controls than the TD5 Standard can manage, the first paired hand control
will be deleted.
This user manual will give you a detailed description on how to pair your hand controls with your TD5 Standard.

Page 15 of 31
Mounting the TD5 Standard
Mounting is made by pushing the TD5 unit into the bed bracket and thereafter slide the closing devices on.
It is IMPORTANT to be completely sure that the closing devices are in place before using the TD5.
Recommendations
• Mains cable and controls must be ordered separately
• The shaft diameter must be Ø25.2 (+0.3/-0.2) mm
• Always use the cable relief for the mains cable on the TD5 to avoid pulling out the mains cable plug from
the TD5 resulting in a malfunction.
• Do not look directly into the light under the bed.
• The default timeout for the Under Bed Light is 30 minutes.
• Do not drive the TD5 system without the closing devices mounted
• The bed brackets must have a smooth surface without burs and welding blops in the area where the TD5 is mounted.
• It is important to turn the key in the direction indicated on the housing. Turning the key in the wrong direction can
wreck the inner hex and make mechanical emergency lowering impossible.
• Do not use an electric screwdriver for lowering, use the enclosed hex key on the TD5.
• The TD5 must be in fully retracted position when starting to lifetime simulator.
1. Push TD5 unit into bed bracket.
2. Slide each closing device on and press it into correct position.
IMPORTANT:
Ensure that the closing devices are in place before using the TD5.
Do not drive the TD5 system without the closing devices mounted.
The bed brackets must have a smooth surface without burs and welding blops in the area where the TD5 is mounted.

Page 16 of 31
Cable strain relief
It is important to use the cable relief on the TD5. By using the relief you avoid that the mains cable plug is pulled out
of the TD5 resulting in a malfunction.
Depending on the thickness of the cable, you can choose to lead the cable through all 3 or just around the middle
relief.

Page 17 of 31
Start-up (How to pair a Bluetooth®connection)
Getting started
It is possible to pair multiple controls to the TD5 via Bluetooth®.
If only one TD5 is to be paired with the control, ensure that only this TD5 is in pairing mode.
Pairing your control
1. Connect TD5 to mains via mains cable.
2. TD5 is in pairing mode for three minutes and Under Bed Light flashes to indicate this.
3. Press the two top buttons on LINAK®hand control at the same time.
The Under Bed Light gives one long flash to indicate that the hand control and the TD5 are paired up.
The TD5 stays in pairing mode and it is possible to connect more controls using the same procedure.
Note:
Wait 5 seconds after pairing control 1 before you can pair control 2.
To get the system out of pairing mode – simply press any button on an already paired control.
Allow for the hand control to go to power-saving mode (backlight turns off) before
disconnecting the actuator system from the mains supply.
Otherwise the pairing will not be saved in the hand control.

Page 18 of 31
Pairing your smartphone or tablet
1. Enable Bluetooth®on smartphone/tablet.
2. Open Bed Control App.
3. Connect TD5 to mains via mains cable.
4. TD5 is in pairing mode for three minutes and Under Bed Light flashes to indicate this.
5. Bed Control App will automatically pair to the closest TD5 in pairing mode.Wait a few seconds to see app confirm
completed pairing.
6. Smartphone/tablet and TD5 are now paired up.App will display operation page and bed can now be adjusted through app.
Note:
The Bluetooth®pairing mode will stop as soon as the phone is connected. Thus, we recommend to start pairing the hand
control and thereafter the phone to avoid having to disconnect the power.

Page 19 of 31
Pairing another device later
It is possible to connect another control or a smartphone/tablet to the TD5 later.
1. Disconnect TD5 from mains.
2. Wait 1 minute.
3. Reconnect TD5 to mains to get it in pairing mode again.
4. Follow instrutions above to pair other devices.
Previously paired devices will not be deleted until a maximum of 8 devices are paired. Pairing a ninth
device will delete the first device paired.
Forced pairing mode
You can also pair a new device by using the forced pairing mode.
1. Turn on Under Bed Light.
2. Disconnect from mains.
3. Wait until Under Bed Light turns off.
4. Reconnect TD5 to mains to get it in pairing mode again.
5. Press two top buttons on your hand control at the same time.
6. Light gives a long flash to indicate that control and TD5 are paired up.
How to unpair one TD5
1. Put the TD5 you want to keep paired into pairing mode and pair the hand control.
2. Send a command from the hand control and the pairing mode stops.
3. The connection between the other TD5 and the hand control is now deleted.

Page 20 of 31
Mechanical emergency lowering
Emergency lowering is meant for lowering the bed if a power failure occurs and the bed needs to be driven down into
horizontal position.
1. Disconnect TD5 from mains.
2. Take hex key on side of TD5.
Underneath the TD5 are two gaps for mechanical lowering.
3. Place hex key in gap, one end at a time, and turn hex key in direction indicated by arrow.
It is important to turn the key in the direction indicated on the housing. Turning the key in the wrong
direction can wreck the inner hex and make mechanical emergency lowering impossible.
Do not use an electric screwdriver for lowering, use the hex key enclosed on the TD5.
