TRANSMITTER DESCRIPTION
The D-22B is a two-button, two-channel hand-held digital radio
transmitter. The transmitter can perform a variety of remote
switching tasks when used with any of Linear’s Standard Digital
“D” Series Receivers. Typically the D-22B is used in wireless or
hybrid wireless/hardwire security systems.
The transmitter is powered by a 9-volt battery. Pressing the right
button will send a “Channel 1” signal, pressing the left button will
send a “Channel 2” signal. Hold buttons for at least 2 seconds
to activate the transmitter. The red LED on the face of the
transmitter will glow as the unit transmits and the receiver with the
matching digital code will activate.
The Standard Digital radio format provides up to 256 different
digital codes. The code is set using the 8-position coding switches
in the transmitter and receiver.
D-22B transmitter switch key 1 is unused and can be set in
any position. The transmitter pushbuttons control the signal that
would normally be controlled by switch key 1. Pressing the right
button sends a signal as if switch key 1 is OFF. Pressing the left
button sends a signal as if switch key 1 is ON.
✶CAUTION: All Standard Digital transmitters and receivers should be
recoded prior to installation and operation.
In order to avoid the possibility of duplicating codes in adjacent
systems, factory set codes should not be used. In addition, among
the valid codes available, four others should not be used. These
include: all keys set ON or OFF and keys set in an alternating
ON/OFF or OFF/ON pattern.
The D-22B will transmit as long as a button is pressed. Depending
onconditions(interference,obstaclesanddistancetothereceiver)
the receiver output may or may not stay activated for as long as
the transmitter is sending a signal.
✶CAUTION: If using tworeceivers, be sure they arelocatedatleast 10 feet
apart.
STEP 1 Locate coding switch. Remove the battery access
door located on the back of the transmitter case. Identify the
coding switch and note that it has eight positions, with ON and
OFF clearly marked.
STEP 2A Coding for single-channel receivers. Pick any valid
combination of OFF/ON codes and set them on switch keys2-8 in
the transmitter Match the same code on switch keys 2-8 in the
receiver. Set receiver switch key 1 to OFF for the receiver to
activate from the
right transmitter button (Channel 1). Set receiver
switch key 1 to ON for the receiver to activate from the
left
transmitter button (Channel 2).
STEP 2B Coding for two-channel receivers. Pick any
combination of OFF/ON codes and set them on switch keys3-8 in
the receiver. Match the same code on switch keys 3-8 in the
transmitter. Set the
transmitter switch 2 to OFF. Right button will
activate Channel 1, left button will activate Channel 2. 2-Channel
receiver switch keys 1 & 2 are unused and can be set in any
position.
STEP 3 Test the equipment. Connect the receiver to its power
source. With relay output receivers, listen for the relay click when
the transmitter is activated. A multi-meter can be used to detect
activation of relay and solid state output receivers. Operate the
transmitter from various locations to determine the radio range.
BATTERY REPLACEMENT
The battery should last 12 to 18 months with normal use. When
the red LED lights dimly, or not at all when transmitting, the battery
needs to be replaced. Remove the battery access door to change
the battery. Any type of 9-volt battery can be used. Replace the
battery door and foam battery pad when finished.
LINEAR LIMITED WARRANTY
This Linear product is warranted against defects in material and workmanship for twelve (12) months. The
Warranty Expiration Date islabeled on the product. This warranty extends only to wholesale customerswho
buy direct from Linear or through Linear’s normal distribution channels. Linear does not warrant this product
to consumers. Consumers should inquire from their selling dealer as to the nature of the dealer’s warranty, if
any. There are no obligations or liabilities on the part of Linear corporation for consequential damages
arising out of or in connection with use or performance of this product or other indirect damages with
respect to loss of property, revenue, or profit, or cost of removal, installation, or reinstallation. All implied
warranties, including implied warranties for merchantability and implied warranties for fitness, are valid only until
Warranty Expiration Date as labeled on the product. This Linear Corporation Warranty is in lieu of all other
warranties express or implied.
For warranty service on Linear equipment return product, at sender’s expense to:
Linear Corporation Repairs Department
2580 Pioneer Avenue, Suite C
Vista, CA 92083
IMPORTANT !!!
Linear radio controls provide a reliable communications link and fill an important need in portable wireless
signalling. However, there are some limitations which must be observed.
✶For U.S. installations only: The radios are required to comply with FCC Rules and Regulations as Part 15
devices. As such, they have limited transmitter power and therefore limited range.
✶A receiver cannot respond to more than one transmitted signal at a time and may be blockedby radio signals
that occur on or near their operating frequencies, regardless of code settings.
✶Changes or modifications to the device may void FCC compliance.
✶Infrequently used radio links should be tested regularly to protect against undetected interference or fault.
✶A general knowledge of radio and its vagaries should be gained prior to acting as a wholesale distributor or
dealer, and these facts should be communicated to the ultimate users.
Copyright © 1995 Linear Corporation 200856 C
REMOVE BATTERY
ACCESS DOOR
CODING
SWITCH
D-22B CODING SWITCH
SET KEYS
2-8 TO ANY
CODE
KEY 1 IS
UNUSED
MATCH
2-8 MATCH
2-8
CODING SWITCHES IN RECEIVER
SET
1 OFF
SET
1 ON
TRIGGERS FROM
RIGHT BUTTON
TRIGGERS FROM
LEFT BUTTON
RECEIVER FOR
CHANNEL 1
RECEIVER FOR
CHANNEL 2
CODING SWITCH IN
TWO-CHANNEL RECEIVER
SET KEYS 3-8 TO
ANY VALID CODE
D-22B CODING SWITCH
MATCH CODE
ON KEYS 3-8
SET KEY
2 OFF
KEY 1 IS
UNUSED KEYS 1 & 2 ARE UNUSED
NORMALLY
OPEN
COMMON
MEASURE
RESISTANCE
RELAY
OUTPUT
RECEIVER
VOLTAGE
OUTPUT
RECEIVER
SHORT
-TO-
COMMON
OUTPUT
RECEIVER
OUTPUT POWER
MEASURE
VOLTAGE
OUTPUT
POWER
MEASURE
VOLTAGE
DCV DCV
REPLACE BATTERY WITH
FRESH 9-VOLT BATTERY
