Linear Multi-Code 1051 User manual

3. You should test your entire system occasionally in
order to be sure that all components are working in
good order.
4. Linear Corporation’s dealers can provide you with
information regarding the use of our radio controls,
and can provide valuable installation and operation
information, when requested.
CAUTION:
Any changes or modifications in intentional or unintentional radiators
which are not expressly approved by LINEAR CORPORATION could void the
user’s authority to operate this equipment. This applies to intentional and
unintentional radiators certified per Part 15 of the F.C.C. rules and regulations.
For service, return to your dealer or shop prepaid to:
LINEAR CORPORATION
2055 Corte del Nogal
Carlsbad, CA 92009
Copyright © 1999 Linear Corporation 216977 A
Model 1051
SAFETY EDGE
TRANSMITTER
Important! Read
Before Installation
The MULTI-CODE 1051 transmitter has been
designed to provide great reliability and safety, but it must
be installed correctly. Read the enclosed instructions
carefully.
The Model 1051 may be used for a variety of purposes,
and wherever remote signaling is desirable, as specified
by FCC regulations. If this transmitter is to be used in an
application which may be safety related be sure to take
special precautions. Linear Corporation has taken every
step to insure the best possible product, but you must be
certain to install the 1051 transmitter correctly.
Before installing the 1051 transmitter, open it up by
removing the four screws which secure the top of the case.
You will note that there is a terminal block (see figure 1), to
which you will secure the wires coming from your device.
Run your wire through the strain relief fitting, leaving
enough wire to provide adequate length for stripping.
YOUR WIRE SHOULD BE 18 TO 24 GAUGE, although any
wire that fits snugly in the strain relief fitting may be used.
Be sure to check the water-tightness of the fitting if you use
anything other than 18-24 gauge wire, as this may
compromise the integrity of the case. Put your two wires
under the terminal blocks, and fasten by screwing down.
Next, code your transmitter and, if necessary, your
receiver. The code switch (see figure 1) allows for 1024
possible combinations. If you have an existing receiver, you
may code the 1051 to the same code, or you may choose to
wire a separate receiver. If you wire a second receiver, be
sure to separate the two receivers as much as possible, to
avoid any possibility of interference.
INSTR,INSTL,MC1051,GATE XMTR LINEAR P/N: 216977 A INK: BLACK MATERIAL: 20 LB. MEAD BOND SIZE: 7.500" x 7.500" SCALE: 1-1 SIDE 1 OF 2
®

If you are going to use the 1051 transmitter in a safety
related device, be sure to read the manufacturer’s
instructions with regard to wiring and limitations of the
safety circuit.
After you have wired and coded the 1051, you are now
ready for mounting. You will note that there are four holes
in the case, through which you can mount your screws,
rivets, or other mounting devices. If the transmitter is to be
used in the proximity of metal, be sure to test the location at
the greatest distance the device will be from its receiver, in
order to be sure that adequate performance is achieved.
ANY METAL, INCLUDING MOUNTING PLATES, ETC., MAY
AFFECT THE PERFORMANCE OF YOUR TRANSMITTER.
Once you are satisfied with the performance of the radio,
you can permanently mount it.
Linear Corporation has taken every precaution to
assure that the 1051 will perform reliably. In order to
provide the greatest reliability, we have fastened the
printed circuit board to the case with a special fastening
agent, such as Loctite. We suggest that you use a similar
material to your fastening screws if vibration is likely to be
encountered.
…IMPORTANT SAFETY TEST…
Before releasing the radio transmitter for use, test the system for
proper operation after installing the radio transmitter and
associated hardware. The system should be tested at various
positions of travel of the gate member to be certain that the gate
edge, radio transmitter, receiver and gate operator are
functioning to detect an obstruction and reverse or stop the
gate.
MAINTENANCE
The 1051 Transmitter needs a minimum of care,
however, certain precautions must be taken:
1. Be sure to check the 1051 Transmitter as a system. Be
sure that the device that is connected to the 1051 is
functioning with the transmitter, and with the
receiver.
2. Check the system to which the 1051 is attached fre-
quently.
3. The 1051 employs long life Alkaline-Manganese Dioxide
Batteries (Eveready Energizer 522 or equivalent). Nominal
life for these batteries is three years, but we suggest you
test the unit more often than this. Test the transmitter any
time you perform maintenance on the rest of the system.
WARRANTY
MULTI-CODE products products carry an eighteen (18)month
warranty against defects in workmanship or material. This
warranty begins at the date of manufacture, for eighteen
months. Linear Corporation warrantees our product only to
our authorized dealers and distributors, and not to the end
customer. If you have questions about our warranty, please
ask your dealer to determine the nature and scope of his
warranty. Linear Corporation does not assume, and is not
responsible for, any real or consequential damages from
claims against the performance of our product, nor is it
liable for any costs related to loss of life, property, or
revenue. Further, Linear Corporation is in no way
responsible for installation of our product, and will assume
no costs to reinstallation or removal. Linear
Corporation’s Warranty is in lieu of all other warrantees, ex-
pressed, or implied.
PLEASE NOTE
Linear Corporation has devoted a great deal of time and
research in order to provide the most reliable equipment
possible. Certain limitations must be observed.
1. MULTI-CODE radio components must conform with
FCC Part 15 requirements. For this reason, the range
and power of our radios is within specified limits.
2. As with all manufacturers, MULTI-CODE radios
must accept all signals that they receive. This may, in
rare instances, create difficulty.
INSTR,INSTL,MC1051,GATE XMTR LINEAR P/N: 216977 A INK: BLACK MATERIAL: 20 LB. MEAD BOND SIZE: 7.500" x 7.500" SCALE: 1-1 SIDE 2 OF 2
TERMINAL BLOCK
MTG. HOLE
BATTERY
MTG. HOLE MTG. HOLE
MTG. HOLE
CODE SWITCH
STRAIN RELIEF
