LK-CP63X SERIES CONTROL PANEL
Feature
The controller consists of a built-in switching power supply, a main control board,
a driver board and a connecting board
Single Channel, dual Channel, 5 Channel and cascade controls
Power indicator/reset, Open/Stop/Close & channel selection buttons with backlight
Can handle external input signals of Manual Switch, Remote Control, Timer
Smoke/Gas/Wind & Rain /Temperature & Humidity Sensors
Output fire feedback signal to fire centre
Switching power supply 10A/15A/20A/25A optional
Specification
Input
Voltage
Output
Voltage
Output
Current
Working
Frequency
Receiving
Sensitivity
Working
Temperature Dimension
AC120V
AC230V
DC12V
DC24V 10-25A 433.92 MHz -100 dBm -20～+65℃272*228*73mm
Button & Dimension
Led/Key Color Status Function
L 1/ K 1 Blue On/Off AC power indicator, Reset
L 2/ K 2 Green On/Off /Flash Open
L 3/ K 3 Red On/Off/Flash Stop
L 4/ K 4 Yellow On/Off/Flash Close
L 5/ K 5 ～L9/K9 Blue On/Off/Flash Channel 1～Channel 5

Terminal & Switch
Symbol Description
Switching Power Supply 10A/15A/20A/25A optional
AC INPUT Input AC120V or AC230V
L AC Live wire
N AC Null wire
E AC Earth wire
M1～M5 Motor group1～group5
M+ Motor DC24V+
M- Motor DC24V-
Signal & DC Terminals
Symbol Description Symbol Description
MU Manual switch up 24V Output DC24V+
MS Manual switch stop 12V Output DC12V+
MD Manual switch down GND GND
MG Manual switch GND WRD Wind/Rain sensor down
SU Slave control up T Temp sensor signal
SD Slave control down H Humidity sensor signal
FC1 Fire center feedback1 TU Timer up
FC2 Fire center feedback2 TD Timer down
FS Fire signal input
Switch
Switch Optional Function
S1 0 Passive Smoke/Gas sensor
1 Active Smoke/Gas sensor
S2 0 Passive Wind/Rain sensor
1 Active Wind/Rain sensor
S3 0 Passive T&H sensor
1 Active T&H sensor
S4 0 Passive Timer
1 Active Timer
Option1 Y Wind/Rain sensor shielded
N Not shield Wind/Rain sensor
Option2 Y T&H sensor shielded
N Not shield T&H sensor
Option3 Y Timer shielded
N Not shield Timer

Signal Processing
Manual signal. Can control the window by the buttons on itself, external dry
contact manual switch and RF remote
Cascaded signal. As a main controller can send a signal to the slave controller, can
also be used as slave controller to receive the signal from the main controller to
drive the window
Fire signal. Capable of receiving a signal from fire center to open the window, after
opening the window to send feedback to the fire center
Smoke signal. After receiving the signal of smoke sensor or gas detector open the
window automatically
Wind/Rain signal. After receiving the signal of wind/rain sensor close the window
automatically
Temperature/humidity signal. Control the window by processing external
temperature/humidity sensor
Time signal. Control the window by working with external timer. For example:
22:00 am to 6:00 closed, open the rest of the time.
Signal and Priority
Signal Manual Signal Fire Signal W/R Signal T/H Signal Time Signal
Priority 1 2 3 4 5
Manual signal includes the signals from buttons on the controller, external dry
contact manual switch, wall transmitter, hand held remote, wireless W/R sensor,
wireless timer and cascaded signal
Fire signal includes the signals from fire centre, smoke sensor and gas detector
W/R signal includes the signals from wired wind and rain sensor, NOT including
wireless W/R sensor
T/H signal includes the signals from temperature and humidity sensor
Time signal is only the signal from WIRED timer
Reset and Shielding
After manual signal processed controller resets & receives input signals in real time
After processing the signals from fire centre, smoke sensor or gas detector, the
controller immediately shields all the input signals, the controller must be reset by
pressing K1 manually. After opening the window returns feedback signal
After wired W/R sensor signal processed, the controller shields lower priority
signals, only receives the higher priority signals until reset or manual signal
processed
After T&H sensor signal processed，the controller shields lower priority signal, only
receives the higher priority signal until reset or manual signal processed
After wired timer signal processed, the controller is in the reset state
Option switch on the control board is for selection of shielding priority 3-5 signal
Option 1-3 priorities 3-5 respectively. The setting takes effect after reset or restart
Matching Code
Power the controller on, choose the channel(s) you want to set, can be set to any
combination of channel 1-5
Keep pressing K3 on the controller for 5 seconds, L3 flashes 3 times and turns off
Choose the channel you want to set on the remote, press [UP] within 15 seconds
LED flashes 3 times and turns off, code matched successfully
Clearing Single Code
Power the controller on
Keep pressing K3 on the controller for 5 seconds, L3 flashes 3 times and turns off
Press [DOWN] on the remote within 15 seconds
LED flashes 3 times and turns off, code cleared successfully
Clearing All Codes
Power the controller on, keep pressing K3 &K4 on the controller for 5 seconds
L3 and L4 flash 3 times and turn off
All the codes will be deleted after this operation

Control Method
Controler stores up to 10 groups of emission coding
The default is multichannel, setting of single channel is as same as multi channel
Maximum running time of motor is 5 minutes
UP/DOWN delay time of switch is 500ms
Power on the controller, all LED turn on for 1 second. In working condition, L1 is lit,
the power supply is working properly
Reset: Press K1, all LED turn on for 1 second and then turn off, reset successfully
Controller receives 2nd priority signal from the fire center, smoke sensor or gas
detector, L2 flashed at 5Hz frequency and the buzzer alarms until reset or restart
External manual switch is equivalent to the switch on the controller
Group Control
By default, L1 is lit, the rest LEDs are off as a group control status.
Press K2, L2 turns on, the windows open, L2 turns off after 5 seconds
Press K4, L4 turns on, the windows close, L4 turns off after 5 seconds
Press K3, L3 turns on, the motors stop, L3 turns off after 1 second
Single Channel Control
Press channel selection keys K5, K6, K7, K8, or K9, the corresponding LED lights,
channel selected
Press the channel selection button again or no operation on K2, K3 or K4 within 10
seconds, LED turns off, channel unselected
Within 10 seconds after selecting channel
Press K2, L2 turns on, the windows open, L2 turns off after 5 seconds
Press K4, L4 turns on, the windows close, L4 turns off after 5 seconds
Press K3, L3 turns on, the motors stop, L3 turns off after 1 second
In the process of opening/closing the current window, you can select another
channel(s) to drive the window
Cascaded Control
The controller can be used as a master controller, a slave controller or play a dual
role of master & slave controller at the same time.
As a master controller, connects to the motors or slave controllers to drive them
As a slave controller, input terminals SU and SD are connected to the output
terminals M+ and M- of the master controller to receive the instructions to drive
motors, or drive the motors independently
Play a dual role of master & slave controller, not only controlled by higher-level
controller, but also drive motors or lower-level controllers independently
No matter master, slave or both, it can process all the external signals such as
manual switch, remote and sensors.
Installation Note
Please observe the following provisions in accord with standard of effective power
The control panel must be installed by professional technician
Maximum output power of single channel controller MUST NOT exceed the total
rated power of the controller
Additive maximum output power of each single channel of double channel
controller MUST NOT exceed the total rated power of the controller
Additive maximum output power of each single channel of 5 channel controller
MUST NOT exceed the total rated power of the controller, and the maximum
output current of each channel MUST NOT exceed 10A
The main power supply must be cut off before installing wiring to ensure safe
operation
Be careful when installing actuators, avoiding the window closed accidentally
causing injuries to person
Do not disassemble the internal parts of the control panel, if unusual please
contact supplier
Do not use metal objects to touch or shade the antenna, avoid the interference of
receiving signals
Transmit distance: 50 meters without obstacle, 20 meters through wall
After the installation, ensure that the cables are not affected by tension
