LinkAYL LK-FP3 User manual


LK‐FP3FireControlPanel















Feature
Thecontrolpanelisusedforthecontrolofelectricwindowopenertoachieve
naturalventilationandfiresmokeremoval
Panelwithopen/stop/closeauto/manualselectionbuttonsandLEDindicators
Singlechannel1‐4group(s)output
CanbecascadecontrolwithLK‐CP6/7/8controllerstoachievethewindowsof
singlecontrol,partitioncontrolandgroupcontrol
CanhandleexternalinputsignalsofManualSwitch,RemoteControl,Timer,
Smoke/Gas/Rain/Temperature&HumiditySensors
Outputfirefeedbacksignaltofirecentre
CompatiblewithallLinkaylremote
OutputDC24V30A‐80A
Size500*400*200mm

LED&KEY


LED/KEYSymbol Color Description
L1RunRedNormallyonwhenmotorrunning
L2Power Green Powerindicator
L3Linkage RedBurstflash,buzzeralarmafterreceivingafiresignal
L4AutoGreen Automodeon,manualmodeoff
K1A/MGreen Defaultisautomaticmode,pressittomanualmode
K2OpenRed Open
K3StopRed Stop
K4CloseRed Close
K5 Resetswitch,onthemotherboard

WiringDescription


Terminals
SymbolDescriptionSymbolDescription
LACLivewireMUManualswitchstop
NACNullwireMSManualswitchdown
EACEarthwireMDManualswitchGND
24V+DC24VPositiveMGManualswitchGND
24V‐ DC24VNegativeSI+Slavecontrolup
M1+/M1‐ MotorGroup1P/NSI‐ Slavecontroldown
M2+/M2‐ MotorGroup2P/NFIFiresignalinput
M3+/M3‐ MotorGroup3P/NWRDRainsensordown
M4+/M4‐ MotorGroup4P/NTUTimerup
12VDC12V+TDTimerdown
24VDC24V+T/HT/Hsensorsignal
GNDDCGNDFO+Firecenterfeedback
FO‐ Firecenterfeedback

PeripheralShielding
SwitchOptionFunction
Option1YRainsensorshielded
NNotshieldRainsensor
Option2YT&Hsensorshielded
NNotshieldT&Hsensor
Option3YTimershielded
NNotshieldTimer


Operatingmode
Controlpanelhasautomaticandmanualmodes,thedefaultisautomaticmode
Inautomaticmode,thecontrollerreceivesallexternalsignalsandcanshield
theexternalsignalbyswitching
Inmanualmode,thecontrollershieldsthefiresignalandreceivesotherinputs

OutputTime
Windowopeningoutputis5minuteswhenthefiresignalandtemperature
andhumiditysensorsignaltriggered,theothersignalsbythesettingtime
windowsettingtimehas8levels,thedefaultis300S,theotheris
20/30/40/50/60/70/80S

Windowclosingoutputis5minutes

Manualcontrol
AfterpoweronalltheLEDslightfor1secondandturnoff,thepowerindicator
LEDandautoLEDnormallyon
Whenthecontrollerreceivesthecommandofthefireinputsignal,the
controllerwillflash,thebuzzerwillalarm,thefirefeedbacksignalwillbesent
tothefirecenter,thealarmwillbereleasedafterresetorpowerfailure
Externalmanualswitchisequivalenttocontrolerpanelswitch
Themotorup/downswitchingtimeis500ms
PressUPbutton,thewindowsopen,LEDturnsonuntiloutputfinished
PressDOWNbutton,thewindowsclose,LEDturnsonuntiloutputfinished
PressSTOPbutton,themotorsstop

Remotecontrol
Thecontrolerencodesby433MHzlearningcode,canstore10setsof
transmissioncodes

MatchingCode
Powerthecontroleron
KeeppressingSTOPbuttononthecontrolerfor5seconds,LEDflashes3times
andturnsoff
PressUPbuttonontheremotewithin15seconds
LEDflashes3timesandturnsoff,
Codematchedsuccessfully

ClearingSingleCode
Powerthecontroleron
KeeppressingSTOPbuttononthecontrolerfor5S,LEDflashes3timesand
turnsoff
PressDOWNbuttonontheremotewithin15seconds
LEDflashes3timesandturnsoff,
Codeclearedsuccessfully

ClearingAllCodes
Powerthecontroleron,keeppressingSTOP&DOWNbuttononthecontroler
for5seconds
LEDflashes3timesandturnoff,allthecodeswillbedeletedafterthis
operation



CascadedControl
Canbeusedasamastercontroler,aslavecontrolerorplayadualroleof
master&slavecontroleratthesametime.
Asamastercontroler,connectstothemotorsorslavecontrolerstodrivethem
Asaslavecontroler,inputterminalsSI+andSI‐ areconnectedtotheoutput
terminalsM+andM‐ ofthemastercontrolertoreceivetheinstructionsto
drivemotors,ordrivethemotorsindependently
Playadualroleofmaster&slavecontroler,notonlycontrolledbyhigher‐level
controler,butalsodrivemotorsorlower‐levelcontrolersindependently
Nomattermaster,slaveorboth,itcanprocessalltheexternalsignalssuchas
manualswitch,remoteandsensors


SignalControl
Manualsignal.Controlthewindowbythebuttonsonitself,externaldry
contactmanualswitchandRFremote
Cascadedsignal.Asamastercontrolersendssignaltotheslavecontroler,can
alsobeusedasslavecontrolertoreceivethesignalfromthemastercontroler
todrivethewindow
Firesignal.Capableofreceivingasignalfromfirecenter,smokesensor,gas
detectoropenthewindowautomatically,sendfeedbacksignaltofirecentre
Rainsignal.Afterreceivingthesignalofrainsensorclosethewindow
Timesignal.Controlthewindowbyworkingwithexternaltimer
Temperature/humiditysignal.Controlthewindowbyprocessingexternal
temperature/humiditysensor




SignalandPriority
Priority12345
SignalManualSignalFireSignalRSignalTimeSignal T/HSignal
Device
Panelbuttons
Manualswitch
Remote
Mastercontroler
Smokesensor
Gasdetector
Wired
rainsensor Wiredtimer
temperature
sensor
humidity
sensor

ResetandShielding
Aftermanualsignalprocessedcontrolerresets&receivesinputsignalinreal
time
Afterprocessingthesignalfromfirecentre,smokesensororgasdetector,the
controlerimmediatelyshieldsalltheinputsignals,thecontrolermustbereset
bypressingK1manually.
Afterwiredrainsensorsignalprocessed,thecontrolershieldslowerpriority
signal,onlyreceivesthehigherprioritysignaluntilresetormanualsignal
processed
Afterwiredtimersignalprocessed,thecontrolershieldslowerprioritysignal,
onlyreceivesthehigherprioritysignaluntilresetormanualsignalprocessed
AfterT&Hsensorsignalprocessed，thecontrolerisintheresetstate
Optionswitchonthecontrolboardisforselectionofshieldingpriority3‐5
signalOption1‐3priorities3‐5respectively.Thesettingtakeseffectafterreset
orrestart
Ifthecontrolerisnotconnectedtoatemperatureandhumiditysensor,the
T/Hportmustbeshielded(putoptionswitchoption3to“Y”position),
otherwiseitwillaffectthecontrolofotherinputsignal




Installationinstruction
Pleasereadthefollowinginstructionscarefullybeforeinstallingthisproduct
Installingthisproductmustcomplywiththeeffectivelocalelectricity
specifications
Thecontrolsystemmustbeinstalledbytheprofessional
Themainpowermustbecutoffbeforewiringtoensuresafeoperation
Thecontrolboxcannotbeinstalledoutdoors
Themaximumoutputpowerofthecontrolboxcannotexceedtheratedtotal
power,otherwiseitwillburnthepower
Themaximumoutputpowerofeachgroupcannotexceedthemaximumrated
powerofthegroup
Donotusemetalobjectstotouchorcoverthecontroler,otherwiseitwill
affecttheremotecontrolsignalreception
Themaximumtransmissiondistanceofthewirelesssignalcanreach50meters
ormoreintheopencondition
Thedistancebetweenthecontrolerandgroundshouldbemorethan1.5
meters
Thedistancebetweenthecontrolerandceilingshouldbemorethan0.3
meters
Thedistancebetweenthecontrolerandmotorshouldbemorethan1.5
meters
Avoidstaticinterferenceandpreventstaticdamagetoelectroniccomponents
Pleaseusethesoftwireandcable,afterinstallationensurethatthecable
carrierisnotaffectedbythelongitudinaltension
Anexternalsensormustuseaproductthatiscompatiblewiththiscontroler
Non‐professionalsisnotallowedtodisassemblethecontroler.Ifanyfunctionis
abnormal,pleasecontactyourlocaldealer


Troubleshooting
No.SymptomSolution
1LEDflashes,receivershutdown
1.Checktheconnectionofwires
2.Checkthereceiversetting
2LEDonthetransmitterisofforweak
1.Makesurebatteryinstalledwell
2.Changethebattery
3
Thetransmitterandthereceiverwork
well,themotordoesnotwork
1.Checkthewiringofmotor
2.Makesurethemotornofailure

ModelList
Model
Max
Current
（A）
Output
Group
Input
Volt
(V)
Output
Volt(V)
Freq
（MHz）
Temp
(℃)
Size
(mm)
LK‐FP31‐30301
AC220 DC24
DC12
433.92
‐20
～
+65
500（L）
400（W）
200（H）
LK‐FP31‐40401
LK‐FP32‐60602
LK‐FP32‐80802
Application
ModelLK‐SCE‐DLK‐LCD LK‐TC LK‐LLK‐L‐SLK‐L38A
600/1000N
LK‐L38A
1500N
LK‐FP31‐302515715151510
LK‐FP31‐4033201020202013
LK‐FP32‐6050301530303020
LK‐FP32‐8066402040404026

