Litepanels Studio LED X6 PLUS User manual

Studio LED X6 PLUS
SKU: 960-6301 / 960-6302
Publication date 25th September 2023
ENGLISH

Table of Contents
Copyright .......................................................................................... 3
Introduction ........................................................................................ 4
General Delivery Notes ............................................................................ 5
Technical Specifications ........................................................................... 6
Safety Notes ....................................................................................... 7
Installation ........................................................................................ 10
Mechanical Installation ................................................................... 10
Electric Installation ....................................................................... 11
Control Menu ..................................................................................... 13
Control Menu Map ................................................................................ 14
DMX Chart ....................................................................................... 15
Programming Control Menu ...................................................................... 18
Maintenance and Cleaning ....................................................................... 20
Warranty .......................................................................................... 21
Disclaimer ........................................................................................ 22
Studio LED X6 PLUS
2

Copyright
Copyright © 2022
All rights reserved.
Original Instructions: English
All rights reserved throughout the world. No part of this publication may be stored in a retrieval system,
transmitted, copied or reproduced in any way, including, but not limited to, photocopy, photograph, magnetic
or other record without the prior agreement and permission in writing of Videndum Plc.
Disclaimer
The information contained in this publication is believed to be correct at the time of printing. Videndum
Ltd reserves the right to make changes to the information or specifications without obligation to notify any
person of such revision or changes. Changes will be incorporated in new versions of the publication. We
are making every effort to ensure that our publications are updated on a regular basis to reflect changes to
product specifications and features. Should this publication not contain information on the core functionality
of your product, please let us know. You may be able to access the latest revision of this publication from
our website. Videndum Production Solutions Ltd reserves the right to make changes to product design and
functionality without notification.
Trademarks
All product trademarks and registered trademarks are the property of Videndum Plc.
All other trademarks and registered trademarks are the property of their respective companies.
Published by:
Videndum Production Solutions Ltd
Email: [email protected]
Studio LED X6 PLUS
3

Introduction
Congratulations on choosing a Litepanels product! We thank you for your custom.
Please note that this product, as well as all the other Litepanels products, has been designed and manufac-
tured with high quality materials and manufacturing processes to ensure excellent performance and to best
meet your expectations and requirements.
Carefully read this instruction manual in its entirety and keep it safe for future reference. It is essential to
know the information and comply with the instructions given in this manual to ensure the fitting is installed,
used and serviced correctly and safely.
Litepanels disclaims all liability for damage to the fitting or to other property or persons deriving from
installation, use and maintenance that have not been carried out in conformity with this instruction manual,
which must always accompany the fitting.
Litepanels reserves the right to modify the characteristics stated in this instruction manual at any time and
without prior notice.
This piece of equipment is for exclusively professional use and must be operated by qualified personnel.
Remember - pieces of equipment which have reached the end of their life cycle are not worthless rubbish:
by recycling old equipment we can recover precious materials.
Studio LED X6 PLUS
4

General Delivery Notes
The basic Studio LED X6 PLUS pack contains the following components:
• Projector
• 4-leaf rotating barndoor
• Instruction booklet
Studio LED X6 PLUS
5

Technical Specifications
LIGHT SOURCE Array LEDs
MAX POWER 300W
CORRELATED COLOR TEMPERATURE Fixed 3200K-5600K
BEAM ANGLE 12° - 60°
LENS DIAMETER 250 mm
POWER SUPPLY 90 – 260 Vac, 50/60 Hz, autosensing
POWER FACTOR (cosφ) 0,97
WEATHERPROOF RATING IP20
OPERATIONAL TEMPERATURE (Ta) 0° – 35°
DIMMING Electronic 16 bit, fully 0 – 100%
CONTROL Internal temperature sensor, LCD graphic display with switch off
function, silent fan, 3 presetting fan speed.
CONNECTIONS DMX In and Through 5-Pin XLR; USB port for firmware and soft-
ware upgrade and diagnostic
FEATURES Internal temperature sensor, LCD graphic display with switch off
function, silent fan, 3 presetting fan speed.
MOUNTING Manual and Pole Operated stirrup.
Dimentions
Studio LED X6 PLUS
6

Safety Notes
Important information on the safe installation and operation of this product. Read this information before
operating the product. For your personal safety, read these instructions. Do not operate the product if you do
not understand how to use it safely. Save these instructions for future reference.
Warning Symbols Used in these Instructions
Important information on the safe installation and operation of this product. Read this information before
operating the product. For your personal safety, read these instructions. Do not operate the product if you do
not understand how to use it safely. Save these instructions for future reference.
WARNING
Where there is a risk of personal injury or injury to others, comments appear suppor-
ted by the warning triangle symbol. Where there is a risk of damage to the product,
associated equipment, process or surroundings, comments appear supported by the
word ‘Caution’.
DANGER
Where there is a risk of electric shock, comments appear supported by the hazard-
ous voltage warning triangle.
Electrical Connection
DANGER
Risk of electric shock. Do not remove cover, no user servicable parts inside the
product.
WARNING
Risk of electric shock. Always check cables for signs of damage. Damaged cables
can cause personal injury and/or damage the equipment.
DANGER
Refer servicing to qualified service personnel.
Operation
WARNING
Special precautions and handling instructions are contained in this user guide and
should be strictly adhered to for safe and reliable operation.
WARNING
Never use flammable or combustible materials and solvents around lights.
CAUTION
The product should not be used outside the operating temperature limits. Refer to the
product technical specifi ations for the operating limits for the product.
Studio LED X6 PLUS
7

WARNING
Protect the product from water, moisture and dust. The presence of electricity near
water can be dangerous.
CAUTION
Do not directly look into the light, it can cause harm to your eyes.
CAUTION
Do not look at the LEDs with a magnifying glass or any otheroptical instrument that
may concentrate the light output.
NOTE
This device is for exclusively professional use and must be operated by qualified
personnel
IMPORTANT
Only substitute fuses with others of the same type and value.
IMPORTANT
This device must be earthed.
IMPORTANT
Class 1 device. The protection conductor must be part of the power cable.
IMPORTANT
Disconnect power before opening the device (authorised personnel).
IMPORTANT
Avoid exposing the device to atmospheric agents such as rain, damp, etc.
IMPORTANT
If the power cable is damaged it must immediately be replaced with a suitable cable
exclusively available from the Litepanels assistance service or authorised Litepanels
service centres.
DANGER
The illuminator must never be used near to inflammable sources or materials.
DANGER
Do not cover the device’s cooling ducts as they are essential for correct ventilation.
IMPORTANT
Use exclusively Litepanels accessories and spare parts.
Studio LED X6 PLUS
8

IMPORTANT
Litepanels does not accept responsibility for damage or malfunctions caused by not
observing these instructions or by unauthorised modifications of the device.
Damage caused by modifications or tampering are not covered by the warranty.
IMPORTANT
THE ILLUMINATOR MUST BE EARTHED
Before connecting the illuminator to the power supply, ensure that the voltage and frequency used corre-
spond to the illuminator’s nominal values. The Studio LED Plus/BICOLOR works at a voltage 90-260V
monophase current and 50-60 Hz.
Maintenance
DANGER
The fitting of non-approved parts or accessories, or the carrying out of non-approved
alterations or servicing can be dangerous and could affect the safety of the product. It
may also invalidate the terms and conditions of the product warranty.
DANGER
Never attempt to service this light. Refer servicing to qualified service personnel.
Studio LED X6 PLUS
9

Installation
MECHANICAL INSTALLATION
The Studio LED X6 PLUS can be positioned directly on the stage floor, on a tripod or hanged on a truss or
on the ceiling or wall without altering its operation characteristics.
Before suspending the illuminator, ensure that the carrying structure is capable of holding the weight of the
device and that it is supplied with suitable secondary safety systems (steel cable, chains, etc.).
The installation must always be secured with a secondary safety attachment, e.g. an appropriate catch net.
This secondary safety attachment must be constructed in a way that no part of the installation can fall down
if the main attachment fails.
When rigging, derigging or servicing the fixture, staying in the area below the installation place, on bridges,
under high working places and other endangered areas is forbidden.
The operator has to make sure that safety-relating and machine-technical installations are approved by an
expert before taking into operation for the first time and after changes before taking into operation another
time.
The operator has to make sure that safety-relating and machine-technical installations are approved by an
expert after every four year in the course of an acceptance test.
The operator has to make sure that safety-relating and machine-technical installations are approved by a
skilled person once a year.
IMPORTANT
OVERHEAD RIGGING REQUIRES EXTENSIVE EXPERIENCE, including (but not
limited to): calculating working load limits, installation material being used, and peri-
odic safety inspection of all installation material and the projector. If you lack these
qualifications, do not attempt the installation yourself, but instead use a professional
structural rigger. Improper installation can result in bodily injury or damage to proper-
ty.
The fixture has to be installed out of the reach of people.
If the fixture shall be lowered from the ceiling or high hoists, professional trussing systems have to be used.
CAUTION
Fixture may cause severe injuries when crashing down! If you have doubts concern-
ing the safety of a possible installation, do not install the fixture.
Before rigging make sure that the installation area can hold a minimum point load of 10 times the fixture’s
weight.
When installing the device, make sure there is no highly inflammable material (decoration articles, etc.) in a
distance of min. 0.4 m.
