Start-up/Maintenance and Cleaning/Disposal/Declaration of conformitySafety/Start-up
Before use, verify the available mains voltage
matches the required operating voltage of the
light (220–240V∼, 50/60Hz).
Never allow the lamp to come into contact
with water or other liquids. Always unplug the
LED plug-in mains adapter from the mains socket
prior to assembly, disassembly, cleaning or if
the lamp will not be used for extended periods.
Never open any of the components of the elec-
trical equipment or insert any objects into the
same components. This will pose a risk of fatal
injury from electric shock.
The light bulb is not replaceable.
The illuminant in this light is not replaceable;
if the illuminant reaches the end of its life,
replace the entire light.
This light is not suitable for dimmer or electronic
switches.
Only use the lamp with the LED plug-in mains
adapter supplied (model EIP021V0240PSS).
Prevent fire and injury
hazards
Do not look directly into the light source (light
bulb, LED etc.).
Do not leave the light or packaging lie about
carelessly. Plastic film or bags, plastic parts etc.
can turn into dangerous toys for children.
Never cover the lamp or the LED plug-in mains
adapter with objects. Excessive heat build-up
can result in fire.
Do not operate the lamp unattended.
Safe working
Mount the light so that it is protected from mois-
ture and dirt.
Always be attentive! Always pay attention to
what you are doing and proceed with caution
at all times.
Never assemble the lamp whilst unfocused or
feeling unwell.
Start-up
Mounting the light
Note: We recommend assembling this light with
2 persons. When assembling the lamp base 6
and the lower gooseneck lamp unit 3, be sure not
to damage the internal connection cable 4. Re-
move all packaging material. You will also need a
cross-tip screwdriver.
Place the lamp base 6with the lower goose-
neck lamp unit 3on the floor in front of you.
Carefully lift the aluminium baffle 1approx.
30cm out of the guide for the lower gooseneck
lamp unit 3. This will expose 4 bores.
Position these bores congruent over the assembly
bracket 5for the lower gooseneck lamp unit 3.
Note: The internal connection cable 4must
be pushed into the lower gooseneck lamp unit
3simultaneously. Choose the ideal angle be-
tween the connection cable 4and the lower
gooseneck lamp unit 3when doing so. Hold
the lower gooseneck lamp unit 3perpendicular
(Fig. A). Holding the connection cable below
the connecting plug 2and carefully pulling it
up can help when inserting the internal connec-
tion cable 4.
Assemble the lower gooseneck lamp unit 3
with 4 cross-head screws 7and slide the alu-
minium baffle 1all the way back (Fig. B).
Plug the connecting plug 2for the lower
gooseneck lamp unit 3into the connecting
plug 9for the upper gooseneck lamp unit 8.
Ensure that it fits securely (Fig. C).
Carefully push the connection cable with the
connecting plug 13 into the lower section of
the gooseneck lamp.
Attach the upper gooseneck light unit 8with
the side guide correctly onto the aluminium baf-
fle 1and simultaneously into the side guides in
the lower gooseneck lamp unit 3(Fig. C).
On reverse, connect the lower and the upper
gooseneck lamp unit 3, 8with two socket
head screws 10 (Fig. C).
Connect the LED plug-in mains adapter 12 to the
connection cable with the connecting plug 13
on the gooseneck lamp (Fig. C).
