Q Assembly
Q Fitting the light
Use a clean, fluff-free cloth when you are fitting
the bulb.
Modell 14119000L /14119006L:
Fit the bulb 2and the glass shade 3on to
the spotlight together (see Fig. B). Use a dry, fluff-
free cloth for this. First put the bulb 2into the
glass shade 3. Insert the bulb 2carefully
into the fitting and attach it along with the glass
shade 3by turning it a ¼ turn clockwise. Now
press the glass shade 3into the spotlight 1
and lock it in place by turning it a ¼ turn clock-
wise. Check that everything is correctly seated.
Model 14119104L/ 14119106L:
Insert the light bulb 2into the socket and
install with a ¼ turn to the right.
Place the chrome ring/ titanium ring 6onto the
light bulb 2and secure with a little pressure.
Check for correct seating.
Screw the light in place in a suitable location.
Make sure the surface for mounting is dry, smoo
th,
and free of dust and grease.
Note: make sure that the anti-slip rubbers and
the bracket 7are secure.
Insert the mains plug 5(attached to the mains
lead) into the mains socket.
Your spotlight is now ready for operation.
QOperation
QOn/Off switch
Flip the ON/ OFF in-line switch 4to turn the
spotlight on or off.
QDirecting the spotlight
Only change the direction of the spotlight 1
after the light has been switched off.
Allow the lamp to cool down completely.
Turn the spotlight 1in the desired direction. The
spotlight 1can be turned to face any direction.
Q Changing the bulbs
DANGER OF ELECTRIC
SHOCK! First pull the plug 5attached to the
mains lead out of the mains socket.
Allow the lamp to cool down completely.
Only change the bulb 2when it has completely
cooled down. Use a clean, lint-free cloth when
changing light bulbs.
Model 14119000L/14119006L:
Release the defective light bulb 2from the
socket with a ¼ turn to the left.
ATTENTION:When you loosen the bulb 2
you also loosen the glass shade 3.
Make sure you hold on to it.
Only use lamps specified in chapter “Technical
information“.
Now fit the new bulb 2and the glass shade 3
on to the spotlight together (see Fig. B). First
put the bulb 2into the glass shade 3. Insert
the bulb 2carefully into the fitting and attach
it along with the glass shade 3by turning it a
¼ turn clockwise. Now press the glass shade 3
into the spotlight 1and lock it in place by
turning it a ¼ turn clockwise.
Check that everything is correctly seated.
Model 14119104L/ 14119106L:
Remove the chrome ring/ titanium ring 6from
the light bulb 2.
Release the defective light bulb 2from the
socket with a ¼ turn to the left.
Install the new light bulb 2with a ¼ turn to
the right.
Place the chrome ring/ titanium ring 6onto
the light bulb 2and secure with a little pres-
sure. Check for correct seating.
Q Maintenance and Cleaning
DANGER OF ELECTRIC
SHOCK! First pull the plug 5attached to the
