Logik L7TDVD10 User manual

Dual 7” LCD
Portable DVD Player
Instruction Manual
L7TDVD10
Logik L7TDVD10_IB_100818.indd 1 18/08/2010 4:10 PM

Logik L7TDVD10_IB_100818.indd 2 18/08/2010 4:10 PM

Contents
Unpacking.....................................................................................................................5
Product Overview.........................................................................................................6
DVD Player.............................................................................................................................................6
Monitor...................................................................................................................................................7
Remote Control ...................................................................................................................................8
Remove the Insulating Strip from the Remote Control ........................................................9
Battery Installation for the Remote Control..............................................................................9
Remote Control Operation Range.............................................................................................10
Battery Pack .......................................................................................................................................10
Using in a Car ............................................................................................................. 11
Using the Car Power Adapter (for in-car use) ........................................................................11
Mounting in a Car............................................................................................................................ 12
Installation Guide ............................................................................................................................12
Using Indoor .............................................................................................................. 13
Using the Mains Adapter (for indoor use)...............................................................................13
Connections ............................................................................................................... 14
Watching a DVD on the DVD Player and the Monitor........................................................14
Connecting a TV (for the DVD Player Only)............................................................................ 14
Connecting a Stereo Receiver or Amplier (for the DVD Player Only) .........................15
Connecting Game Consoles/Video Devices...........................................................................15
Using the Monitor with Other Devices while Playing a DVD on the DVD Player .....16
Using Earphones..............................................................................................................................17
Compatible Disc Types .............................................................................................. 18
Supported Formats......................................................................................................................... 18
Region Code ......................................................................................................................................18
Turning On the Unit................................................................................................... 19
Basic Playback............................................................................................................ 19
Playing a Disc ....................................................................................................................................19
Pausing Playback (Still Mode) .....................................................................................................19
Stopping Playback...........................................................................................................................19
Fast Forward / Fast Reverse.......................................................................................................... 19
Skip (Forward / Reverse)................................................................................................................20
Volume Adjustment........................................................................................................................20
Repeat Viewing.................................................................................................................................20
Displaying Scene Information..................................................................................................... 20
Audio Selection ...............................................................................................................................20
Subtitle Selection ............................................................................................................................20
Angle Selection ...............................................................................................................................21
Using a DVD Menu ..........................................................................................................................21
Contents updated
Logik L7TDVD10_IB_100818.indd 3 18/08/2010 4:10 PM

Using the Title Function ................................................................................................................21
Adjusting the LCD Screen.............................................................................................................21
Audio/MP3 CD Playback ........................................................................................... 22
Basic Audio CDs Playback.............................................................................................................22
Finding File Types ............................................................................................................................22
Sorting Files ....................................................................................................................................... 22
JPEG Picture CDs Playback ....................................................................................... 23
Basic Picture CDs Playback...........................................................................................................23
Finding File Types ............................................................................................................................23
Sorting Files ....................................................................................................................................... 23
Rotating Pictures..............................................................................................................................23
Viewing the Next or Previous Picture....................................................................................... 23
MPEG-4 Playback....................................................................................................... 24
Basic MPEG-4 Playback.................................................................................................................. 24
Finding File Types ............................................................................................................................24
Sorting Files ....................................................................................................................................... 24
Customising the Language Settings ........................................................................ 25
Customising the Screen Settings ............................................................................. 25
Screen Saver ......................................................................................................................................25
TV Type ................................................................................................................................................ 25
TV System ...........................................................................................................................................26
Customising the Audio Settings............................................................................... 26
Customising the Custom Settings............................................................................ 27
Parental Control Setup...................................................................................................................27
Password............................................................................................................................................. 28
Angle Mark.........................................................................................................................................28
Default ................................................................................................................................................. 28
Maintenance .............................................................................................................. 29
Hints and Tips ............................................................................................................ 30
Specications............................................................................................................. 31
Safety Warnings......................................................................................................... 32
Logik L7TDVD10_IB_100818.indd 4 18/08/2010 4:10 PM

Safety Warnings Product OverviewsConnectionsSystem Set-up Playable Disc / Supportive
Formats / Playback Functions
Hints and Tips
and Specification
GB-5
DVD Player x 1
Car Power Adapter x 1
(P.N.: 54-201-00105)
3.5mm to RCA AV Cable x 1
(P.N.: 54-201-00085)
Instruction Manual x 1
(P.N.: 82-230-00770)
Quick Start Guide x 1
(P.N.: 82-230-00780)
Mains Adapter x 1
(P.N.: 43-111-00493)
LCD Monitor x 1
Earphones x 2
(P.N.: 54-401-00033)
Carry Bag x 1
(P.N.: 86-192-01040)
Battery Pack x 1
(P.N.: 94-230-01050)
3.5mm to 3.5mm AV Cable x 1
(P.N.: 54-201-00098)
Remote Control
(with battery) x 1
(P.N.: 92-230-10040)
Mounting Strap x 4
(P.N.: 86-230-00020)
If items are missing or damaged, please contact Partmaster (UK only).
Tel: [phone] for assistance.
Unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
Congratulations on the purchase of your new Logik Dual 7”LCD
Portable DVD Player.
We recommend that you spend some time reading this instruction manual in
order that you fully understand all the operational features it oers. You will
also nd some hints and tips to help you resolve any issues.
Read all the safety instructions carefully before use and keep this instruction
manual for future reference.
Logik L7TDVD10_IB_100818.indd 5 18/08/2010 4:11 PM

Safety WarningsProduct Overviews Connections System Set-upPlayable Disc / Supportive
Formats / Playback Functions
Hints and Tips
and Specification
GB-6
Product Overview
DVD Player
1) OPEN Switch
Unfold the LCD Panel to access the
DVD disc tray door.
2) LCD Screen
3) Speakers
4) Setup Button
5) MENU Button
6) PREV / NEXT Button
Move back to previous chapters/
titles on a disc or move forward to
next chapters/tracks/titles on a disc.
7) / SEARCH Button
Perform fast reverse / fast forward
playback.
STOP Button
Stop playing a disc.
PAUSE Button
Pause playback and frame advance.
PLAY/SEL. Button
Start or resume playback of a disc.
Cursor ( , , , ) Buttons
Move between selections on a menu
screen and adjusts certain settings.
8) LCD Button
9) MODE Button
10) POWER ON Indicator
Illuminates green when the ON/OFF
switch is in the ON position.
11) Remote Sensor
Receives signals from the remote
control.
12) VOLUME Control
Adjusts the volume.
13) Earphones Socket
14) AV IN Sockets
15) AV OUT Sockets
16) POWER Switch
17) DC IN 12V Socket
1 2
3 34 5 6 6 8 9
10
11
7
12
14
15
16
17
13
Logik L7TDVD10_IB_100818.indd 6 18/08/2010 4:11 PM

Safety Warnings Product OverviewsConnectionsSystem Set-up Playable Disc / Supportive
Formats / Playback Functions
Hints and Tips
and Specification
GB-7
Monitor
1) Speakers
2) LCD Screen
3) LCD Button
4) Cursor ( , ) Buttons
Move between selections on a menu
screen and adjusts certain settings.
5) POWER ON Indicator
Illuminates green when the ON/OFF
switch is in the ON position.
6) VOLUME Control
Adjusts the volume.
7) Earphones Socket
8) AV IN Sockets
9) POWER Switch
10) DC IN 12V Socket
1 13 542
6
7
8
9
10
Logik L7TDVD10_IB_100818.indd 7 18/08/2010 4:11 PM

Safety WarningsProduct Overviews Connections System Set-upPlayable Disc / Supportive
Formats / Playback Functions
Hints and Tips
and Specification
GB-8
Remote Control
1
5
10
13
8
2
4
7
12
14
15
9
3
6
11
1) Setup Button
Display the SETUP menu in STOP mode.
2) Info Button
Show status information on the screen.
3) LCD Button
Adjust Panel, Colour, Brightness and
Backlight of the LCD screen.
4) Mode Button
Switch between AV IN and DVD mode.
5) Menu Button
Enter the main DVD menu.
6) Title Button
Enter the title menu (if available).
7) SUBTITLE Button
Select one of the subtitle languages
programmed on a DVD (if available).
8) / SEARCH Buttons
SEARCH: Fast reverse playback.
SEARCH: Fast forward playback.
Cursor ( , , , ) Buttons
Move between selections on a menu
screen and adjusts certain settings.
PAUSE Button
Pause playback and frame advance.
STOP Button
Stop playing a disc.
PLAY/SEL. Button
Start or resume playback of a disc or
conrm selections.
9) ANGLE Button
Switch between multiple camera angles
when the DVD you are playing has been
programmed with multiple camera
angles.
10) PREV Button
Move back to previous chapters/titles for
DVD; or previous track for CD.
11) NEXT Button
Move forward to next chapters/titles for
DVD; or next track for CD.
12) AUDIO Button
Select one of the audio sound tracks on
a DVD (if more than one is available) or
select the audio output mode on a CD.
13) Number (0 - 9) Buttons
Create programs, or enter parental
control password or locate a title/
chapter/track or specic time.
14) REPEAT 1/All Button
Repeat a DVD chapter or title.
Repeat a CD track or the entire disc.
15) Mute Button
Mute and restore your DVD Player
sound.
Logik L7TDVD10_IB_100818.indd 8 18/08/2010 4:11 PM

Safety Warnings Product OverviewsConnectionsSystem Set-up Playable Disc / Supportive
Formats / Playback Functions
Hints and Tips
and Specification
GB-9
Battery Installation for the Remote Control
Remove the Insulating Strip from the Remote Control
Remove the insulating mylar strip from the battery if the battery is
being used for the rst time. It is located at the bottom back side
of the remote control.
Handling the Battery
• Improper or incorrect use of batteries may cause corrosion or battery leakage, which could
cause re, personal injury or damage to property.
• Install the battery correctly by following the polarity (+ and -) indications in the battery
compartment.
• When the battery is exhausted, the remote control will not function.
• Only use the battery type indicated in this manual.
• Do not dispose of the used battery as domestic waste. Dispose of it in accordance with the
local regulations.
• Small button cell batteries such as the one used in the remote control are easily swallowed by
young children and this is dangerous. Keep loose button cells away from young children and
make sure that the battery holder tray is secure in the remote control. Seek medical advice if
you believe a cell has been swallowed.
Handling the Remote Control
• Take care of your ngernails when you press and hold the battery release tab.
• Do not drop or cause impact to the remote control.
• Do not spill water or any liquid on the remote control.
• Do not place the remote control on a wet object.
• Do not place the remote control under direct sunlight or near sources of excessive heat.
• Remove the battery from the remote control when not in use for a long period of time, as it
could cause corrosion or battery leakage and may result in physical injury and/or property
damage including re.
1. Press and hold the battery release
tab and pull out the battery holder
completely.
2. Remove the old battery, and place a
new battery in the holder.
Logik L7TDVD10_IB_100818.indd 9 18/08/2010 4:11 PM

Safety WarningsProduct Overviews Connections System Set-upPlayable Disc / Supportive
Formats / Playback Functions
Hints and Tips
and Specification
GB-10
How to Charge the Battery Pack
1. Connect the DC power cable to the DVD Player’s
DC IN socket.
2. Connect the AC power adapter to the DC IN
socket on the battery pack.
Remote Control Operation Range
Point the remote control at the DVD Player no more than
5 metres from the remote control sensor and within 60° of
the front of the DVD Player. The operating distance may
vary depending on the brightness of the room.
Within about 5 m
30° 30°
Battery Pack
How to Attach the Battery Pack
1. Align the pack with the DVD Player.
2. Slide the pack until the battery is locked securely in
position.
Release button
Battery lock
Power LED indicator
DC IN socket
DC power cable
Guides
• The battery will NOT charge while the DVD Player is turned on and is being used.
• Turn the power o when attaching or removing the battery pack.
• Use the supplied AC power adapter to charge the battery pack.
• The lifetime of the battery pack is limited. Power is slowly drained when not in use. If the battery pack does not
last long even after a full charge, you might have to replace it with a new one.
To remove the pack, press the Release button, then slide it away.
• Ensure the battery is charged for a minimum of 6 hours before rst time use.
The power LED indicator illuminates red during charging. When the battery is
fully charged, the LED indicator illuminates green.
• Normal play time for the fully charged battery is approx 2.5 hours.
Logik L7TDVD10_IB_100818.indd 10 18/08/2010 4:11 PM
