Logik L9DUALM12 User manual

9” Dual Portable
DVD Player
Instruction Manual
L9DUALM12
L9DUALM12_IB_121109_Michelle.indd 1 09/11/2012 11:05 AM

L9DUALM12_IB_121109_Michelle.indd 2 09/11/2012 11:05 AM

Contents
Unpacking.....................................................................................................................5
Product Overview.........................................................................................................6
Front View..............................................................................................................................................6
Top View.................................................................................................................................................7
Left Side View.......................................................................................................................................7
Rear View ...............................................................................................................................................7
Remote Control.............................................................................................................8
Removing the Insulating Strips from the Remote Controls ................................... 10
Battery Replacement for the Remote Control...................................................................10
Remote Control Operation Range............................................................................ 11
In-Car Use ................................................................................................................... 12
Using the DVD Players A and B Together (in-car use).........................................................12
Mounting the DVD in a Car .......................................................................................................... 13
Installation Guide ............................................................................................................................14
Using the DVD Players A and B Indoors................................................................... 15
Using the Mains Adapter (for indoor use)...............................................................................15
Connections ............................................................................................................... 16
Connecting a TV (for the DVD Player Only)............................................................................16
Connecting a Stereo Receiver or Amplier ............................................................................16
Connecting to a Multi-channel Audio Receiver....................................................................17
Using Earphones..............................................................................................................................17
Using The Stand For Indoor Use ............................................................................... 18
Using a USB Device or and SD/MS/MMC Card ......................................................................18
General Operation...........................................................................................................................18
Compatible Disc Types .............................................................................................. 19
Supported Formats.........................................................................................................................19
Region Code ......................................................................................................................................19
Turning On the DVD Player....................................................................................... 20
Basic Playback............................................................................................................ 20
Basic DVD Playback.........................................................................................................................20
DVD Playback on Both DVD Players..........................................................................................21
Pausing Playback .............................................................................................................................21
Selecting Chapter / Title time / Chapter time (for DVD) .................................................... 21
Selecting Disc GOTO / Track GOTO / Select Track (for CD) ................................................21
L9DUALM12_IB_121109_Michelle.indd 3 09/11/2012 11:05 AM

Stop Playback....................................................................................................................................21
Previous and Next............................................................................................................................ 21
Fast Reverse and Fast Forward....................................................................................................21
Repeat Mode .....................................................................................................................................22
Slow ......................................................................................................................................................22
Angle Selection ................................................................................................................................ 22
Audio Channel..................................................................................................................................22
Subtitle Language ...........................................................................................................................22
Info ........................................................................................................................................................23
Programmable Memory................................................................................................................23
Zoom Selection ................................................................................................................................23
Title .......................................................................................................................................................23
Menu ....................................................................................................................................................23
Customising the General Settings............................................................................ 23
Customising the Audio Settings............................................................................... 25
Customising the Video Settings ............................................................................... 26
Customising the Preference Settings....................................................................... 26
Customising the Password Settings......................................................................... 28
Maintenance .............................................................................................................. 29
Cleaning the Unit.............................................................................................................................29
Handling Discs..................................................................................................................................29
Cleaning Discs...................................................................................................................................29
Storing Discs...................................................................................................................................... 29
Hints and Tips ............................................................................................................ 30
Specications............................................................................................................. 32
Safety Warnings......................................................................................................... 33
L9DUALM12_IB_121109_Michelle.indd 4 09/11/2012 11:05 AM

5
Unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
If items are missing, or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
Thank you for purchasing your new Logik Portable DVD Player.
We recommend that you spend some time reading this instruction manual so that you fully
understand all the operational features it offers. You will also find some hints and tips to help you
resolve any issues.
Read all the safety instructions carefully before use and keep this instruction manual for future
reference.
DVD Player x 2 Remote Controls A &B
Mains Adapter x 1
Earphones x 2
Car Power Adapter x 1
Screws x 8 (ø4 x 25mm) Instruction Manual x 1
Support x 2
Quick Start Guide x 1
VOL-
ENTER
VOL+
SOURCE
STEP SEARCH MUTE SOURCE
1234
5678
9 0 10+
DISPLAY
SUBTITLE ANGLE AUDIO MENU
TITLE
ENTER MODE
SETUP VOL- VOL+
REPEAT SLOW
PROGRAM ZOOM
L9DUALM12_IB_121109_Michelle.indd 5 09/11/2012 11:05 AM

6
Product Overview
Front View
1. LCD Display
2. Speakers
3. VOL – Button
• Increases the volume.
• Navigates left on a menu screen and
adjust certain settings.
4. ENTER Button
Conrms selection on a menu screen.
5. / Button
• Skips backwards to the beginning of
the track or to the previous track.
• Allows fast reversing of the current
track.
• Navigates up on a menu screen and
adjust certain settings.
/ Button
• Skips forwards to the next track.
• Allows fast forwarding of the current
track.
• Navigates down on a menu screen
and adjust certain settings.
VOL-
ENTER
VOL+
SOURCE
1
43 6 75 8 22
Battery Indicator
• Indicator lights up red to when
changing.
• Indicator light winks o when the
battery is fully charged.
6. VOL + Button
• Decreases the volume.
• Navigates right on a menu screen and
adjust certain settings.
7. SOURCE Button
Selects the desired input signal source:
DVD / USB / MEMORY CARD.
8. Remote Control Sensor
Receives signals from the remote
control.
L9DUALM12_IB_121109_Michelle.indd 6 09/11/2012 11:05 AM

7
9. SD/MMC/MS Memory Card Slot
OPEN
SD/MS/MMC
9 10
ON OFF AV OUT COAXIAL USB DC OUT DC IN 9-12V
18
Rear View
11 12 13 14 15 16 17
Left Side View
Top View
10. OPEN Latch
Opens the disc door.
11. ON / OFF Switch
12. Earphones Socket
13. AV OUT Socket
14. COAXIAL Socket
15. USB Slot
16. DC OUT Socket
17. DC IN 9~12V Socket
18. Stand
L9DUALM12_IB_121109_Michelle.indd 7 09/11/2012 11:05 AM

8
Remote Control
STEP SEARCH MUTE SOURCE
1234
5678
9 0 10+
DISPLAY
SUBTITLE ANGLE AUDIO MENU
TITLE
ENTER MODE
SETUP VOL - VOL +
REPEAT SLOW
PROGRAM ZOOM
1
2
3
5
8
9
11
10
12
6
4
7
1. STEP Button
Advances frame by frame in DVD mode.
2. SEARCH Button
Searches and starts playback from a
selected point on the disc.
3. 0-9, 10+ Number Buttons
Selects and goes to or locates a title /
chapter / track or specic time.
4. SUBTITLE Button
Selects one of the subtitle languages
programmed on a DVD (if available).
5. ANGLE Button
Switches between multiple camera angles
when the DVD you are playing has been
programmed with multiple camera angles.
6. TITLE Button
Returns to DVD Title Menu.
7. Cursor Buttons
Navigates between selections on a menu
screen and adjust certain settings.
ENTER Button
Conrms selection on a menu screen.
8. SETUP Button
Displays the SETUP menu.
9. REPEAT Button
• Repeats a DVD chapter or title.
• Repeats a CD track or the entire disc.
10. SLOW Button
Enters slow playback mode, and cycles
between dierent speeds.
11. PROGRAM Button
• Programmes the playback of favourite
titles/chapters/tracks from the disc in
DVD / CD mode.
• Selects the slide show mode for
scrolling through JPEG pictures.
12. ZOOM Button
Zooms in during DVD playback. (2x, 3x, 4x,
1
2x, 1 3x, 1 4x)
L9DUALM12_IB_121109_Michelle.indd 8 09/11/2012 11:05 AM

9
STEP SEARCH MUTE SOURCE
1234
5678
9 0 10+
DISPLAY
SUBTITLE ANGLE AUDIO MENU
TITLE
ENTER MODE
SETUP VOL - VOL +
REPEAT SLOW
PROGRAM ZOOM
13. SOURCE Button
Selects an input source: DVD / USB /
Memory Card.
14. MUTE Button
Mutes or restores your DVD sound
output.
15. DISPLAY Button
Displays the playtime and show status
information on the screen.
16. MENU Button
Enters and exit the main DVD menu.
17. AUDIO Button
Selects one of the audio sound
tracks on a DVD (if more than one is
available) or select the audio output
mode on a CD.
18. Button
Starts/pauses/resumes playback.
19. STOP Button
Stops playing a disc.
20. MODE Button
Adjusts Sharpness, Brightness,
Contrast, Hue and Saturation of the
LCD display.
21. VOL + / – Button
Adjusts the volume.
22. Buttons
• Skips backwards to the beginning
of the track or to the previous titles/
chapters/tracks.
• Skips forwards to the next titles/
chapters/tracks.
23. Buttons
• Allows fast reversing/ forwarding of
the current track playback at 5-level
speed (x2, x4, x8, x16, x32).
13
16
17
19
18
20
22
21
23
14
15
L9DUALM12_IB_121109_Michelle.indd 9 09/11/2012 11:05 AM

10
Battery Replacement for the Remote Control
The remote control requires a CR2025, 3V Lithium battery.
1. Slide and hold the battery release tab in the direction
of the arrow. If you are having difficulty with the tab,
use a paperclip to help squeeze the tab.
2. Pull out the battery holder and remove the old
battery.
3. Replace with a new battery.
4. Insert the battery holder back into the remote control.
Handling the Battery
• Improper or incorrect use of batteries may cause corrosion or battery leakage, which could
cause fire, personal injury or damage to property.
• Install the battery correctly by following the polarity (+ and –) indications in the battery
compartment.
• When the battery is exhausted, the remote control will not function.
• Only use the battery type indicated in this manual.
Removing the Insulating Strips from the
Remote Controls
Remove the insulating mylar strips from the batteries
if the batteries are being used for the first time. The
plastic strip tabs are located at the bottom rear side of
the remote controls.
