lopital Tango XL User manual

Instructions for use
Mobile shower/toilet chair Tango XL

2
Important:
Read these instructions carefully before using the Tango XL!
Date of first use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
User. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Name. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adress. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manufacturer
Lopital Nederland B.V.
Laarakkerweg 9
5061 JR Nederland
T (0031) 13 52 39 300
F (0031) 13 52 39 301
www.lopital.com
[email protected]
Symbols
explanation
Read the
instructions
for use
before use
Attention

3
Index
Introduction.............................................................................................................................................. 4
Safety....................................................................................................................................................... 4
Warranty.................................................................................................................................................. 4
Brakes...................................................................................................................................................... 5
Directional caster..................................................................................................................................... 5
Fold away / Detachable foot rests........................................................................................................... 5
Folding armrest........................................................................................................................................ 5
Using the bad pan ................................................................................................................................... 6
Using the toilet function ........................................................................................................................... 6
Cleaning and maintenance of PUR integral foam parts.......................................................................... 7
Transport and storage ............................................................................................................................. 7
Technical data ......................................................................................................................................... 8
Dimensions.............................................................................................................................................. 8
Backrest
2 part seat with toilet
opening
Caster ø125
Double braked
Fold away
legsupport
Folding
Armrest
Guide for badpan
Pushbar
Caster with
directional lock

4
Introduction
The obese mobile shower/toilet chair "Tango XL" is an aid for the ergonomically caring and washing of
people. Comfort is optimal for both the user and the carer.
By using a bed pan or in combination with a toilet, the Tango XL can also be used as a toilet chair.
Its manoeuvrability makes the Tango XL a user-friendly product. The seat component provides the
same comfort as a normal seat and offers the same correct support.
The expected service life of the Tango XL is 10 years, with maintenance as directed.
The Tango XL is a product with a CE mark. This mark complies with the 93/42/EEG directive,
respectively the revised directive 2007/47/EG for medical aids dated 21 March 2010.
Safety
- When transferring a patient, ensure the brake is applied to the Tango XL.
- Ride preferably in reverse over obstacles.
- Close the arm rests before riding the chair.
- Never ride with the user in the chair too close to walls and door frames, as the patient can easily
get pinched between the chair and the wall or door frame.
In case of malfunction always contact Lopital Nederland B.V.
Email: [e-mail]
The Tango XL shower/toilet chair may only be operated by sufficiently instructed and expert
personnel who also have experience working with the target user group.
Applying modifications to the construction can affect the safety of the Tango XL. Liability and
guarantee terms of Lopital will then expire. The product does nog comply with the directive of
medical devices.
Warranty
All lopital B.V. shower and toilet aids come with a 2-year manufacturer’s warrenty. Normal wear and
tear and improper use do not fall under the terms of this warrenty. Lopital Nederland B.V. does not
accept any liability for personal injury which is caused by the improper use of the products.

5
Brakes
The brake can be applied on the Tango XL by pushing the blue lip (1)
on the wheel downwards
In order to take the Tango XL off the brake, the same lip on the wheel
must be moved upwards by tapping the upper side of the lip (2)
Directional caster
- The Tango XL is supplied standard with a directional caster which is mounted on the right front.
- A "directional lock" or directional caster means that a swivelling caster can be locked.
- This makes pushing along greater distances easier because the chair will drift sideways less.
- To block the caster direction, push the Black lip (1) on the wheel downwards.
- To release the caster direction, the same lip on the wheel must be moved upwards by tapping the upper
side of the lip (2)
Fold away / Detachable foot rests
- Before the user positions him or herself on the Tango XL, the legsupport must be lifted slightly and
turned outwards. This provides enough space in front of the chair, so that the user can sit down
easily.
- When the user is seated, the carer or the user must first lift one leg, then the carer turns the foot
rest forwards until it falls in the catch.
- Then follow the same procedure for the other leg.
Do not stand on the footrest while taking place or leaving the chair.
2
1

6
Folding armrest
- The independently folding armrest is easy to operate.
- It can be easily turned backwards.
- To close the arm rest, turn it in the opposite direction..
The arm rests may never be used as a lever (for instance when manoeuvring the chair over a
threshold) or as a pull / push bracket. This can damage the product and/or be dangerous.
Using the bad pan
- If the Tango XL is used as a toilet chair, a synthetic bed pan
can be pushed underneath using the specially made guide.
- The plastic or stainless steel bed pan is pushed in from the
rear of the chair.
To prevent injury to the user we advise that the carer to place
the bed pan before the user is seated.
Using the toilet function
- The Tango XL can also be used over a toilet. When the user is seated and the arm rests are
closed, the carer sets the Tango XL in the correct position.
The Tango XLdoes not fit over every type of toilet.
1

7
Cleaning and maintenance of PUR integral foam parts
The Tango XL has to be cleaned with water and normal household cleaning products after every use.
Remove excess soap residue. PUR integral foam parts with IMC coating preferably using rub cleaned
and disinfected . Do not use abrasive or aggressive solvents ( such as chlorine ) . Practical experience
has shown that household cleaning products are best suited to small amount of alcohol (up 5 % )
above . For disinfection is ( testing based on long-term ) it means Neoquat combi ® recommended . If
necessary, PUR may share with a solution of 70 % ethanol or propanol may be decontaminated.
It must be ensured that both the disinfection and cleaning means rubbing occurs, and not by means of
dipping . The reaction time of the resources share a significant impact on the life of the PUR . Due to
the material properties of PUR contact with sharp objects should be avoided . This can lead to
damage or crack formation in the material. Finally, we note that not sharing critical parts of the PUR
should be cleaned and disinfected.
Check the casters regularly for hairs and dust and remove it if necessary. Maintenance and repairs
may only be carried out by authorized personnel.
Maintenance
After every use
The product has to be cleaned with water and normal household
cleaning products
Daily
PUR integral foam parts cleaned and disinfected
Weekly
Frame has to be cleaned
Check the casters for hairs and dust and remove it if necessary.
Annually
Maintenance on the Tango XL
Transport and storage
During transport and storage environmental conditions must preferably be moderate. That means a
temperature preferably between -40 and +55 degrees centigrade (-40 to 130 degrees Fahrenheit), and
the humidity be kept as low as possible. During transport vibrations must be kept to a minimum to
prevent damage to the hinged connections in the product.

8
Technical data
The product belongs to category "BF"
Structure
Frame consisting of steel tubes covered with a 2-layer powder coat.
Pivoting points of Stainless Steel
casters of synthetic material, Ø 125 mm, double lockable
Body support of polyurethane
Net weight Tango XL 21,5 kg / 47.4 Lbs
Maximum load 250 kg / 550 Lbs
Dimensions
Base area: 67.5 cm / 26.6 inch wide, 69.3 cm / 27.3
inch deep
Set height: 51 cm / 20 inch
Dimensions
