Lorex SWEET PEEP User manual

ENGLISH FRANÇAIS ESPAÑOL
SWEET PEEP
VIDEO BABY MONITOR
Version 1.0
USER’S GUIDE
www.lorexbaby.com

Safety Precautions
• Adult assembly is required. Keep small parts away
from children when assembling.
• This product is not a toy. Do not allow children or
infants to play with it.
• This video monitor is not a substitute for responsible
adult supervision.
• Test the video monitor before use. Become familiar with
its functions.
• Keep the cords out of reach from children and infants.
• Never use extension cords with power adapters.
• Only use the chargers and power adapters provided.
Do not use other chargers or power adapters as this
may damage the device and battery pack.
• Insert battery with the correct polarity.
• Keep all batteries away from children and infants.
• Do not cover the video monitor with a towel or blanket.
• Do not use the video monitor near water.
• Do not use the video monitor near a heat source.
• Do not touch the plug contacts with sharp or metal
objects.
• Keep this user’s guide for future reference.
To Avoid Injury to
Children & Infants:
• MAKE SURE to keep the camera and all power
cords are at least 3ft / 1m away from cribs and out
of reach of your child.
• Use the included cable clips to help keep power
cords away from your child.
3ft / 1m

Product Includes..............................2
Monitor Overview...........................2
Camera Overview...........................3
Getting Started ...............................4
Using Your Baby Monitor ................7
Using the Menus .....................................7
Talking to Your Baby................................8
Changing Channels.................................8
Using Scan Mode (multiple cameras only) ........ 9
Adjusting Volume ..................................11
Adjusting Screen Brightness....................11
Using Pan / Tilt Mode............................12
Using Digital Zoom................................13
Turning on the Night-Light.......................13
Playing Lullabies ................................... 14
Temperature Alerts.................................15
Using VOX Mode (Voice Trigger) ............17
Video Off Mode (Audio Only Mode) ....... 18
Pairing Additional Cameras ..........19
Technical Specifications .................21
Camera ...............................................21
Monitor................................................ 21
Troubleshooting ............................22
Need Help?...................................22
ENGLISH
1
Table of Contents:

2
Product Includes
x1*
x1
Camera
Monitor
Power Adapter
*Contents may vary by model
x1*
Power Adapter
x1
Monitor Overview
Cable Clips
x2*
Sound LED’s
Video Display
Select Channel /
Scan Mode Start / Stop Lullaby
Volume Up / Zoom In
Volume Down /
Zoom Out
Power LED
Link LED
Power / Video Off
Menu / PT Mode*
Talk
* To control the camera’s pan / tilt function, see
“Using Pan / Tilt Mode” on page 12.

ENGLISH
3
Camera Overview
Lens
Night Light
Antenna
Speaker
Fold-out Antenna
Belt Clip
Battery
Compartment
Volume Up / Zoom In
Volume Down /
Zoom Out
Power Switch
Light Sensor
Pairing Button
Temperature Sensor
Infrared LEDs

Make sure all power cables are at least
3ft / 1m away from the crib and out of
reach of your child.
Use the included cable clips to help
keep power cords away from your
child.
4
Getting Started
1
2
Connect the power adapter to the camera.
Slide the power switch to ON.
3Press down on the belt clip to remove it
from the monitor.
Press down on the battery compartment door
with both thumbs to slide it off the monitor.
4

The battery cable only connects one
way. Do not force the battery cable.
8Press and hold the power button to turn on
the monitor. The power LED will light up.
7Connect the power adapter to the monitor.
Ensure you charge the monitor for 6 hours
before using for the first time.
Power Button
Power LED
lights up
ENGLISH
5
5Connect the battery cable to the monitor.
Battery Cable
6Replace the battery compartment door
and the belt clip.
Battery
Terminals
Battery
Press down on the battery compartment door
with both thumbs to slide it off the monitor.

Make sure all power cables are at
least 3ft / 1m away from the crib
and out of reach of your child.
Use the included cable clips to help
keep power cords away from your
child.
Pull up to extend
antenna
• It is recommended to charge the battery for 6hours
before use.
• For overnight monitoring, it is recommended to
connect the power adapter. When fully charged,
the monitor will stay on up to 6 hours in normal
mode, up to 8 hours in VOX mode (page 17),
and up to 10 hours in Video OFF mode (page
18).
• For better reception, flip up the antenna on the
monitor.
Tips
Cable Clips
6
When choosing a location for your camera:
• Determine where you will get the best view of your
baby.
• Ensure the power cable is long enough to power the
camera.

1
Press and hold to
access the menu.
Press repeatedly to
cycle through menu
options.
Press to exit menu.
2
ENGLISH
7
Using Your Baby Monitor
The monitor shows the following icons during use:
Icon Meaning
Signal strength
Selected channel
Scan Scan mode
activated
Volume muted
X2 Digital zoom
activated
Song currently
playing
Talk activated
P/T mode
activated
VOX VOX (Voice
Trigger) on
Icon Meaning
Battery full
Battery low
Battery charging
Battery finished
charging
68°F Current room
temperature
Pairing channel
Camera out of
range or off
(e.g. batteries
dead)
Using the Menus

Press and hold to talk to the
selected camera.
C1
Press to cycle through
connected cameras.
The channel number
for the selected
camera is shown
on screen.
If a lullaby is playing, it will stop playing when
the talk feature is used.

1
Currently selected
channel
2Press to select a channel.
1
The monitor only plays sound from the camera
that is currently being viewed.
8
Talking to Your Baby
Changing Channels

Press to cycle through
connected cameras.
The channel number
for the selected
camera is shown
on screen.
Currently selected
channel
When two or more cameras are connected, you
may use Scan mode to cycle through video from
each camera. Each camera channel is displayed
for 10 seconds.
To connect additional cameras to the monitor,
see “Pairing Additional Cameras” on page 19.
Scan
Press repeatedly until
Scan is shown on screen.
1
2Press to exit menu. The monitor
cycles through the connected channels.
1 Scan
Current channel
Scan mode
activated
To enable Scan mode:
ENGLISH
9
Using Scan Mode (multiple cameras only)

If you wish to only monitor some of your cameras
using Scan mode, you may choose to hide
certain channels. Hidden channels will not be
shown in Scan mode.
C1
Press to change the
checkmark to an X. This
will disable video from
the channel and remove it
from the viewing cycle in
Scan mode.
Press to include it
again.
2
C1
Press to cycle through
connected cameras to
the channel you wish to
show or hide.

1
By default, each channel name has a checkmark
beside it, which means it is enabled for monitoring
and included in the viewing cycle on Scan mode.
10
To show / hide channels in Scan mode:

Press to cycle through
connected cameras to
the channel you wish to
show or hide.
Press to adjust the volume
Press and hold until is
shown.
1
2
Press to adjust brightness
Press to exit menu.
3
ENGLISH
11
Adjusting Volume
Adjusting Screen Brightness

1
Press to activate pan /
tilt mode. Four arrows
appear on the screen.
Using Pan / Tilt Mode
Press to exit P/T mode.
3
You can use pan / tilt mode to move the selected
camera’s viewing area remotely using the
monitor. This feature is only compatible
with the included pan / tilt camera and
BB2415AC1.
Press to move the
camera up / down.
Press to move the
camera left / right.
2
You must exit P/T mode to use other
features that rely on the arrow keys
(e.g., adjusting monitor volume).
12

1
Press and hold to zoom
in. An X2 icon appears
on the screen.
X2
2
The video monitor features a 2x digital zoom
feature for up-close viewing.
Press and hold to return
to normal viewing mode.
1
Press until is shown.
2
OFF
3
Turning on the Night-Light
Press and hold until the first menu
item is shown.
Press or to turn the night-light on and
off for the camera currently being viewed.
x2
x1
ENGLISH
13
Using Digital Zoom

Playing Lullabies
Press to play a song on
the selected camera.
1
2
Immediately after pressing
, press to change the
song.
The song number is shown
on the monitor.
If volume controls
appear, press
twice to restart the
song. Volume controls
will appear if you
press or a
few seconds after
pressing .
3Press to stop playing the song.
The camera can play 5 different pre-loaded
lullabies.
14

Press until Lo is shown.
2
Lo 66° F
Press until is shown.
2
°F
3Press and to select °F(Fahrenheit)
or °C(Celsius)
4Press to exit menu.
1Press and hold until the first menu
item is shown.
ENGLISH
15
Once your preferred temperature unit has been selected,
you can control the high and low temperatures that trigger
alerts or disable temperature alerts.
Temperature Alerts
To select Fahrenheit or Celsius:
You can select if you would like temperature readings and
alerts to be in Fahrenheit or Celsius.
The temperature alert feature allows you to ensure the
baby’s room is at a comfortable, safe temperature. The
monitor beeps if the temperature gets too hot or cold.
Temperature sensor is accurate within 3°F/1°C.
To set temperature alerts:
1Press and hold until the first menu
item is shown.

3Press and to adjust the low
temperature.
If the temperature at the selected camera
goes below this temperature, the monitor
will beep and the temperature reading on
the monitor will say “Lo”.
If you select a temperature below 62°F /
17°C, the low temperature alert will be
turned OFF.
Press until Hi is shown.
4
Press and to adjust the high
temperature.
If the temperature at the selected camera
goes above this temperature, the monitor
will beep and the temperature reading on
the monitor will say “Hi”.
If you select a temperature above 86°F /
30°C, the high temperature alert will be
turned OFF.
5
Press to exit menu.
6
16

2
Press until VOX
is shown
VOX OFF
3Press and to adjust the audio
sensitivity for VOX mode.
VOX OFF
VOX
VOX mode is off
VOX mode is on
Low sensitivity
Medium sensitivity
High sensitivity
If you want softer noises to trigger the monitor (such as a
faint whimper), set the sensitivity setting higher. If you only
want louder noises to trigger the monitor (such as a loud
cry), set the sensitivity setting lower.
4Press to exit menu.
While VOX is activated, the monitor’s
screen and speaker will turn off after a
minute unless sound is detected at the
selected sensitivity level. Press any button
to turn the screen back on. When VOX is
on, a VOX icon is shown on the screen.
VOX mode will not work while
Scan mode is activated.
1Press and hold until the first menu
item is shown.
ENGLISH
17
In VOX mode, the monitor’s screen and speaker
will turn off after a minute unless sound is
detected at the selected sensitivity level. This
conserves battery power, and alerts you only
when needed.
Using VOX Mode (Voice Trigger)

Press to turn the screen off and
monitor sound only.
The monitor will play sound from the
selected channel only.
Video Off Mode (Audio Only
Mode)
Press any button to turn the screen back
on.
1
• If Scan mode is enabled, the monitor will play
sound from the channel that is currently selected.
• VOX mode will override Video Off mode. See
“Using VOX Mode (Voice Trigger)” on page
17 for details.
Notes
2
18
