LORUS RW6 Series User manual

INSTRUCTION MANUAL FOR
WATCH CALIBRE
Z026
THIS PRODUCT CONTAINS A BUTTON BATTERY
If swallowed or placed inside any part of the body, the battery can
cause severe or fatal injuries within 2 hours or less.
Button batteries are hazardous whether new or used. Keep batteries out of
reach of children.
If you think the battery may have been swallowed or placed inside any part
of the body, seek immediate medical attention.Contact the Australian
Poisons Information Centre immediately on 13 11 26
(New Zealand 0800 764 766) for 24 / 7 fast, expert advice.

■CHARACTERISTICS
1. Analogue & digital time displays: Hour,
Minute, Second, Month, Date and Day of the
week.
2. Daily alarm and hourly chime: The alarm
can be set to sound at the designated time
on a 24-hour basis and the chime can be set
to sound every hour on the hour with a single
beep.
3. Stopwatch: The stopwatch can measure
up to 23 hours 59 minutes and 59 seconds
in 1/100-second increments. Split time
measurement is available.
4. Selection of 12 or 24-hour format: The time
display format in either 12-hour indication or
24-hour indication can be selected.
5. EL backlight: The built-in electro-luminescent
(EL) backlight illuminates the display for easy
viewing in darkness.
■DISPLAY AND BUTTON FUNCTION
■SETTING THE TIME (ANALOGUE)
1. Pull the crown out one step, the second hand
will stop.
2. Set the correct time by turning the crown.
3. Push the crown back to the original position.
The watch will start running again.
* The analogue indication and digital display of
the time setting can be adjusted separately.
Z021
Z026
NREZ021C 1-2019
CAL. Z021 (RW6 SERIES)
CAL. Z026 (R2B SERIES)
CROWN
■HOW TO SET TIME/CALENDAR
1. From NORMAL TIME mode, p ress S3 button
three times to begin setting procedure.
The second digits start flashing.
2. Press S1 button to reset the second digits to
zero.
* If S1 button is pressed when the second digits
are in a range between 30 and 59, the second
digits will be reset to 00 and one minute will be
added. If S1 button is pressed when the second
digits are in a range between 00 and 29, the
second digits will be reset to 00 and the minute
digits will be unchanged.
3. Press S2 button to move on to HOURS setting.
* Selection of the digits to be adjusted is made in
the following order by pressing S2 button. Press
S1 button to adjust the value.
* When setting HOURS, “H” stands for 24-hour
format,“A” or “P” stands for 12-hour format.
SECONDS
DATE
DAY OF
THE WEEK MONTH
MINUTESHOURS
S2
S2
S2
S2
S2
12/24H-
FORMAT
S2
S4 (LIGHT)
HOURS
DAY OF WEEK
CHIME
DATE
MINUTES SECONDS
ALARM
S3 (MODE) S2 (RESET)
MONTH
S1(START/STOP)
S3
■HOW TO SET ALARM TIME
■HOW TO CHANGE THE DISPLAY
MODE
STOPWATCH mode
1. From NORMAL TIME mode,
press S3 button
twice to enter the ALARM mode.
2. Press S2 button to begin setting procedure.
The hours digit starts flashing.
3. Press S1 button to set HOURS setting.
4. Press S2 button to move on to MINUTES setting.
Press S1 button to set MINUTES setting.
5. Press S2 button to confirm the settings.
6. Press S3 button to return to NORMAL TIME
mode.
* Press S3 button to show the NORMAL TIME
mode.
* If the NORMAL TIME mode is shown already on
the display, skip the above operation.
* Press S3 button to change the display mode in
the following order.
NORMAL TIME mode
S3
ALARM mode
S3
S3
S2
HOURS SETTING BY
PRESSING S1
MINUTES SETTING BY
PRESSING S1
S2
TIME SETTING mode
ALARM modeNORMAL TIME mode
S3
PRESS
S3
twice
S2
for confirmation
4. Press S3 button after completing the setting.
NORMAL TIME
MINUTES SETTING BY
PRESSING S1
HOURS SETTING BY
PRESSING S1
SECONDS SETTING
BY PRESSING S1
PRESS
S3
3 times
S2
S2
MONTH SETTING BY
PRESSING S1
DATE SETTING BY
PRESSING S1
S3
S2
DAY OF WEEK SETTING
BY PRESSING S1
S2
S2
S2
S4 (LIGHT)
HOURS
DAY OF WEEK
DATE
MINUTES
SECONDS
ALARM
S3 (MODE) S2 (RESET)
S1(START/STOP)
MONTH
CHIME
NREZ021C.indd 1 2018/12/06 14:53

This watch contains precise electronic
components. Never attempt to open the case or
remove the back cover.
• BATTERY
CAUTION
Do not expose the old battery to fire
or recharge it. Keep it at a place
beyond the reach of children. If a
child swallows it, consult a doctor
immediately.
• WATER RESISTANT
Condition
of use Accidental
contact
with water,
such as
splashes
and rain
Swimming
and taking
a shower
Skin
diving
Scuba
diving
Indication
on the dial/
case back
No
Indication
* If your watch is 200 M/20 BAR, 100 M/10 BAR or
50 M/5 BAR water resistant, it is so indicated on
the dial/case back.
• Do not operate the buttons when the watch is
wet.
• If the watch is exposed to salt water, rinse it in
fresh water and then wipe it thoroughly dry.
• Should you find any water or condensation
inside the watch, immediately have it checked.
Water can corrode electric parts inside the
case.
NO NO NO
YES YES NO NO
YES YES NO
NO NO NO
YES
WATER
RESISTANT
WATER
RESISTANT
(50M/5 BAR )
WATER
RESISTANT
100M/10 BAR
or above
(
NO
Caution:
• LEATHER BAND
• A leather band is susceptible to discoloration
and deterioration from moisture, sweat and
direct sunlight.
• Wipe off moisture and sweat as soon as
possible by gently blotting them up with a
dry cloth.
• Do not expose the watch to direct sunlight
for a long time.
• Please take care when wearing a watch with
light-colored band, as dirt is likely to show up.
• Refrain from wearing a leather band watch
other than Aqua Free bands while bathing,
swimming,and when working with water even
if the watch itself is water-resistant enforced
for daily use(10-BAR/20-BAR water resistant).
• PLASTIC BAND
• As for material characteristics, the band
is easily dirtied, and may be stained and
discolored. Wipe off dirt with a wet cloth or
cleaning tissue.
• Unlike bands of other materials, cracks may
result in the band being cut. Take care not to
damage the band with an edged tool.
• ALLERGIC REACTION
Because the case and band touch the skin
directly, it is important to clean them regularly. If
not, shirt sleeves may be stained and those with
delicate skin may develop a rash. Please wear
the watch with some play to avoid any possible
allergic reaction. If you develop a rash on your
wrist, stop wearing and consult a physician.
• MAGNETISM
Your watch will be adversely affected by strong
magnetism. Keep it away from close contact with
magnetic objects.
• SHOCKS AND VIBRATIONS
Your watch may be worn for normal sports
activities, but be careful not to drop it or hit it on
hard surfaces.
• TEMPERATURE
Your watch is preadjusted so that constant
accuracy may be insured at normal temperature.
• CLEANING
Use only a soft cloth and clean water for
cleaning your watch. Never use chemicals, as the
waterproof gasket will corrode.
Printed in China
YES
■CARE OF YOUR LORUS WATCH
■SERVICE
When your LORUS watch requires repair or
servicing, please see the enclosed WARRANTY/
GUARANTEE.
* From NORMAL TIME mode, Press S3 button
once to enter the STOPWATCH mode.
■HOW TO USE STOPWATCH
Standard Measurement
S1
Start Stop Reset
S1 S2
1. Press S1 button alternately to start and stop
the STOPWATCH.
2. Press S2 button to reset the STOPWATCH to
"00:00:00."
START/STOP
RESET/SPLIT
S2
S1
STOPWATCH
MODE
■HOW TO USE EL BACKLIGHT
Note:
1. The backlight of the watch employs an
electro-luminescent (EL) light, which tends to
lose illuminating power after very long use.
2. The illumination provided by backlight may be
hard to see when viewed under direct sunlight.
* When the illuminating light becomes dim,
replace the battery with new one.
* Press S4 button in any mode to turn the
illuminating light on.
S4
LIGHT ON
Split Time Measurement
1. Press S1 to start counting first split time.
2. Press S2 button, the STOPWATCH keeps
counting first split time and showing it on the
display.
3. Press S1 button to stop counting first split time.
4. Press S2 button to release first split time.
5. Press S1 button to start counting second split
time. The STOPWATCH shows second split time.
* This operation can be repeated and the split
time can be read.
6. Press S2 to finish counting the split time.
7. Press S2 again to reset the STOPWATCH to
"00:00:00."
Start Split 1 Reset
Split 2 Stop
S1 S2 S2 S2 S1
* Press S3 button return to NORMAL TIME display.
This watch is powered by two batteries, one for
the analogue movement and the other for the
digital movement.
Analogue quartz movement: The miniature
battery SEIKO SR626SW, Maxell SR626SW or SONY
SR626SW.
Digital quartz movement: The miniature
battery SEIKO CR2025, Maxell CR2025 or SONY
CR2025 which powers your watch should last
approximately 2 years each. However, because
it is inserted at the factory, the actual life of the
battery once in your possession may be less than
2 years.
Be sure to replace the batteries to prevent any
possible malfunction as soon as they run down.
To replace the batteries, we recommend taking
the watch to a local watch repair shop.
Note: If the alarm is used for more than 60
seconds a day, the battery life may be less
than the specified period.
After the batteries are replaced with new
ones, set the time, calendar and alarm.
■BATTERY CHANGE
(
Engagement/Disengagement of ALARM &
CHIME
* In the ALARM setting mode, with each press
of S1 button, the ALARM and CHIME can be
engaged or disengaged in the following order.
The ALARM signal and/or CHIME signal appear
or disappear on the display accordingly.
S1
S1
S3
NORMAL TIME
S1
ALARM ON
CHIME ON
ALARM/CHIME ON
S1
ALARM MODE
How to stop the alarm sound
Press S3 to turn the snooze function on or off
alternately. When the snooze function is enabled,
the alarm will stop sounding temporarily and
go off again 5 minutes later for 20 seconds and
automatically stop.
Press S1 or S2 to stop the alarm while it is sounding.
Snooze function
PRESS
S3
twice
