LOXONE Button Air User manual

Loxone Electronics GmbH
Smart Home 1
4154 Kollerschlag
Austria
loxone.com
Need Help?
loxone.com/support
V250521
Part No: 100465
Button Air
Technical Specifications
Power supply 2x 1.5V AA batteries
Power consumption when Wake Up off (one activation
per month):
standby: 3.9µW
typ: 5.3µW
max: 92mW
when Wake Up on (default settings,
one hour active per day):
standby:118µW
typ: 145µW
max: 92mW
Touch points 1 Touch point, tactile switch
Safety rating IP64
Dimensions 84x84x30.5mm / 3.31x3.31x1.2” (LxWxH)
Maintenance & Cleaning This device is free of maintenance
and may only be cleaned with a dry
cloth.
Power loss max. 92mW
Interfaces Loxone Air:
868MHz (SRD Band Europe), 4
channels available
max. Power 15.1mW e.r.p. 915MHz (ISM
Band Region 2), 10 channels available
max. Power 13.2mW
Ambient temperature -18 … 55°C / 0 … 131°F
Humidity max. 95% r. H. (non condensing)
Feedback visual
Battery lifetime up to 5 years

About the product
The Button Air is a highly visible, battery-powered device
for triggering a button press. The magnetic wall bracket
and non-slip base allow for use in a variety of settings.
The magnetic wall mount and anti-slip base provide
great flexibility and ability to position the Button Air
wherever it is most convenient. An action triggered by the
Button Air is indicated by a flashing red LED.
Features
•Large single push button
•Visual feedback
•Magnetic wall mount
•Anti-slip base
For additional information, declaration of confirmity,
visit www.loxone.com/help/button-air
Information
Contains FCC ID: 2ARRV-000376
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference
2. This device must accept any interference received, including
interference that may cause undesired operation
Installation
The Button Air is powered by two AA batteries, and is
activated by removing the pull tab.
Once the Button Air is activated, simply configure it in
Loxone Config in the usual way.
2x AA
batteries
2
1
learn
button
end
position 3
