LS ELECTRIC XGT Series User manual

LS ELECTRIC strives to maximize your profits in gratitude for choosing us as your partner.
Programmable Logic Control
XG5000
XGT Series
XGK/XGB

Safety Instruction
1
Before using the product …
For your safety and effective operation, please read the safety instructions
thoroughly before using the product.
►Safety Instructions should always be observed in order to prevent accident
or risk with the safe and proper use the product.
►Instructions are separated into “Warning” and “Caution”, and the meaning of
the terms is as follows;
This symbol indicates the possibility of serious injury
or death if some applicable instruction is violated
This symbol indicates the possibility of slight injury
or damage to products if some applicable instruction
is violated
►The marks displayed on the product and in the user’s manual have the
following meanings.
Be careful! Danger may be expected.
Be careful! Electric shock may occur.
►The user’s manual even after read shall be kept available and accessible to
any user of the product.
Warning
Caution

Safety Instruction
2
Safety Instructions when designing
Please, install protection circuit on the exterior of PLC to protect
the whole control system from any error in external power or PLC
module. Any abnormal output or operation may cause serious problem
in safety of the whole system.
- Install applicable protection unit on the exterior of PLC to protect
the system from physical
damage such as emergent stop switch,
protection circuit, the upper/lowest limit switch, forward/reverse
operation interlock circuit, etc.
- If any system error (watch-dog timer error, module installation error,
etc.) is detected during CPU operation in PLC, the whole output is
designed to be turned off and stopped for system safety. However,
in case CPU error if caused on output device itself such as relay or
TR can not be
detected, the output may be kept on, which may
cause serious problems. Thus, you are recommended to install an
addition circuit to monitor the output status.
Never connect the overload than rated to the output module nor
allow the output circuit to have a short circuit, which may cause a
fire.
Never let the external power of the output circuit be designed to
be On earlier than PLC power, which may cause abnormal output or
operation.
In case of d
ata exchange between computer or other external
equipment and PLC through communication or any operation of
PLC (e.g. operation mode change), please install interlock in the
sequence program to protect the system from any error. If not, it
may cause abnormal output or operation.
Warning

Safety Instruction
3
Safety Instructions when designing
Safety Instructions when designing
I/O signal or communication line shall be wired at least 100mm
away from a high-voltage cable or power line.If not, it may cause
abnormal output or operation.
Caution
Use PLC only in the environment specified in PLC manual or
general standard of data sheet. If not, electric shock, fire, abnormal
operation of the product or flames may be caused.
Before installing the module, be sure PLC power is off. If not,
electric shock or damage on the product may be caused.
Be sure that each module of PLC is correctly secured. If the
product is installed loosely or incorrectly, abnormal operation, error or
dropping may be caused.
Be sure that I/O or extension connecter is correctly secured. If
not, electric shock, fire or abnormal operation may be caused.
If lots of vibration is expected in the installation environment,
don’t let PLC directly vibrated. Electric shock, fire or abnormal
operation may be caused.
Don’t let any metallic foreign materials inside the product, which
may cause electric shock, fire or abnormal operation.
Caution

Safety Instruction
4
Safety Instructions when wiring
Prior to wiring, be sure that power of PLC and external power is
turned off. If not, electric shock or
damage on the product may be
caused.
Before PLC system is powered on, be sure that all the covers of
the terminal are securely closed. If not, electric shock may be caused
Warning

Let the wiring installed correctly after checking the voltage rated
of each product and the arrangement of terminals. If not, fire,
electric shock or abnormal operation may be caused.
Secure the screws of terminals tightly with specified torque when
wiring. If the screws of terminals get loose, short circuit, fire or abnormal
operation may be caused.
Surely use the ground wire of Class 3 for FG terminals, which is
exclusively used for PLC. If the terminals not grounded correctly,
abnormal operation may be caused.
Don’t let any foreign materials such as wiring waste inside the
module while wiring, which may cause fire, damage on the product
or abnormal operation.
Caution

Safety Instruction
5
Safety Instructions for test-operation or repair
Safety Instructions for waste disposal
Don’t touch the terminal when powered. Electric shock or abnormal
operation may occur.
Prior to cleaning or tightening the terminal screws, let all the
external power off including PLC power. If not, electric shock or
abnormal operation may occur.
Don’t let the battery recharged, disassembled, heated, short or
soldered. Heat, explosion or ignition may cause injuries or fire.
Warning
Don’t remove PCB from the module case nor remodel the module.
Fire,electric shock or abnormal operation may occur.
Prior to installing or disassembling the module,
let all the
external power off including PLC power.
If not, electric shock or
abnormal operation may occur.
Keep any wireless installations or cell phone at least 30cm away
from PLC. If not, abnormal operation may be caused.
Caution

Product or battery waste shall be processed as industrial waste.
The waste may discharge toxic materials or explode itself.
Caution

Safety Instruction
6

Revision History
1
Revision History
Version Date Remark Revised Page
V 1.0 ’05.03 First Edition -
V 1.1 ’06.05 Word revised and detailed description added -
V 1.2 ’08.06 PID monitor added CH.11
V1.3 ’09.09 1. XG5000 installation modified 1-4~1-6
2. Option modified 2-24~2-36
3. Making new project modified 3-3~3-4
4. Sharing variable, automatic variable added 4-23~4-38
5. Editing tools modified 5-2
6. OR contact modified 5-4~5-5
7. LD screen properties modified 5-29
8. View variable/comment modified 5-33
9. Program optimization modified 5-34
10. I/O parameter modified 9-6
11. Device auto-allocation parameter added 9-25~9-26
12. I/O Skip modified 10-43~10-49
13. Fault mask modified 10-50~10-51
14. module changing wizard modified 10-52
15. Print setting modified 14-8~14-9
16. SFC editing added CH16
17. ST editing added CH17
18. Event input module added CH18
19. coil modified 5-10

Revision History
2
Version Date Remark Revised Page
V1.6 ’10.03 1. User Function/Function Block added
2. System requirements and installation procedure
Modified
3. Contents on basic parameter added
4. PLC information/Password function modified
CH19
CH1
CH9.1
CH10.9.1, CH10.9.3
V1.7 ’10.07 1. Contents on installation of XG5000
(C++ patch) added
2. SOE U device added
CH1.3
CH18.8
V1.8 ’14.02 1. Advice for Help open error
2. Product Table classified by PLC Series added
3. Custom events information modified
4. SOE module’s function added
CH2.1.1
CH3.2.1
CH10.17.2
CH18.4.1, CH18.6
V1.9 ’14.08 1. Integrated Tool UI Updated
V2.0 ’15.02 1. Product Table classified by PLC Series updated CH3.2.1
V2.1 ’17.01 1. Installation of LS Studio and Basic Usage
2. XG5000 variables / comments share
3. Communication parameter setting
CH20.1, CH20.2
CH20.3
CH20.4
V2.2 ’17.07 1. Add race monitor XBMS maximum value CH11
V2.3 ’18.02 1. Data memory function added
2. Find and replace function improved
CH3.4.6
CH8
V2.4 ’19.05 1. Program block password function added CH3.7
V 2.5 ’20.05 LSIS to change its corporate name to LS ELECTRIC Entire

About User's Manual
1
Thank you for purchasing PLC of LS ELECTRIC Co., Ltd.
Before use, make sure to carefully read and understand the User’s Manual about the functions, performances,
installation and programming of the product you purchased in order for correct use and importantly, let the end user and
maintenance administrator to be provided with the User’s Manual.
The User’s Manual describes the product. If necessary, you may refer to the following description and order accordingly.
In addition, you may connect our website (http://www.lselectric.co.kr/) and download the information as a PDF file.
Relevant User’s Manuals
Title Description
XG5000 User’s Manual
(for XGK, XGB)
XG5000 software user manual describing online function such as programming,
print, monitoring, debugging by using XGK, XGB CPU.
XG5000 User’s Manual
(for XGI, XGR)
XG5000 software user manual describing online function such as programming,
print, monitoring, debugging by using XGI, XGR CPU.
XGK/XGB Instructions &
Programming User’s Manual
User’s manual for programming to explain how to use instructions that are used
PLC system with XGK, XGB CPU.
XGI/XGR/XEC Instructions &
Programming User’s Manual
User’s manual for programming to explain how to use instructions that are used
PLC system with XGI, XGR, XEC CPU.
XGK CPU User’s Manual
(XGK-CPUA/E/H/S/U)
XGK-CPUA/CPUE/CPUH/CPUS/CPUU user manual describing about XGK
CPU module, power module, base, IO module, specification of extension cable
and system configuration, EMC standard.
XGI CPU User’s Manual
(XGI-CPUU/CPUH/CPUS)
XGI-CPUU/CPUH/CPUS user manual describing about XGI CPU module,
power module, base, IO module, specification of extension cable and system
configuration, EMC standard.
XGR Redundant Series
User’s Manual
XGR-CPUH/F, CPUH/T user manual describing about XGR CPU module,
power module, extension drive, base, IO module, specification of extension cable
and system configuration, EMC standard.
XG-PM User’s Manual XG-PM software user manual describing online function such as motion
programing, monitoring, debugging by using Motion Control Module.
