Ltech DMX512 User manual

www.ltech-led.com
LT-912-OLED
Dimming Curve: 0.1~9.9
Protection: OTP/OCP/SCP
OLED display
8 bit / 16 bit
12
CHANNELS
3 kinds of DMX interfaces
Product introduction
Gamma value
DMX value
Output
brightness
Photoelectric
isolation
0
100%
2.5 3.5
6.5
1.0
0.8
0.9
<1
>1
1.5
255
Short circuit
protection
5-pin XLR RJ45 RDM Over current
protection
Display
6. With firmware upgrade function.
8. With power-on state management and fast self-testing function.
5. With the operations can be completed via the
RDM master console, such as parameters browsing & setting, DMX address
setting, equipment recognition, etc.
RDM remote management protocol,
4. 5-pin XLR, RJ45 and green terminal DMX interface with photoelectric isolation, improve
signal transmission efficiency and anti-interference ability, the green terminal also
has signal amplifier function.
2. Easy operation with OLED screen and touch buttons.
1. Designed for Hi-power multiple channels application, 12 channels output, and Max.
4A current per channel, up to 1152W output power.
3. 3 kinds of mode optional: single color, color temperature, RGB.
7.
when fault.
With short circuit, over current and over temp. protection, as well as warning function
10. Optional for standard, linear, LOG or custom 0.1-9.9 dimming curve.
www.ltech-led.com
9. 16bit (65536 levels) / 8bit (256 levels) grey level optional.
1
Over temp.
protection
Photoelectric
isolation
E5 00 58 5

2 3
180
156
122
110
39
www.ltech-led.com www.ltech-led.com
Product size
Unit: mm
Technical specs
LT-912-OLED
DMX512/RDM
12~24Vdc
4A × 12CH Max 48A
(0~48W...96W) × 12CH Max. 1152W
5-pin XLR, RJ45, green terminal
Dimming/CT/RGB
0.1~9.9, standard, linear, LOG
8bit (256 levels) / 16bit (65536 levels)
Yes
Short circuit / Over current / Over temperature
-30°C~65°C
L180×W122×H39mm
L193×W127×H41mm
730g
Model :
Input signal :
Input voltage :
Current load :
Output power :
DMX interface :
Control mode :
Dimming curve :
Grey level :
Photoelectric isolation :
Protection:
Working temperature
Dimensions
Package size
Weight (G.W.)
:
:
:
:
Main component description
OLED screen
Power
indicator
Signal
indicator
RJ45
5-pin XLR
12-24V
Power input
dc
Green terminals
(with signal amplifier function)
DMX/RDM input & output
Green terminals
LED lamps connection
DC1 DC2
Powered by DC1
Max. 24A
Powered by DC2
Max. 24A
warranty
5 years
E5 0 0 5 85

4 5
DMX: Hz: High
Mode: RGB 8bit
Curve: Standard
Dim: Smo TOOL&v
001
DMX: 001 Hz:
Mode: RGB 8bit
Curve: Standard
Dim: Smo TOOL&v
High
DMX: 001 Hz: High
Mode: 8bit
Curve: Standard
Dim: Smo TOOL&v
RGB
DMX: 001 Hz: High
Mode: RGB
Curve: Standard
Dim: Smo TOOL&v
8bit
DMX: 001 Hz: High
Mode: RGB 8bit
Curve:
Dim: Smo TOOL&v
Standard
DMX: 001 Hz: High
Mode: RGB 8bit
Curve: Standard
TOOL&v Dim: Smo
M
<
<
Screen: ON+Addr
Contrast: 40%
Beep: ON
EXIT&v
TEST&v
001
DMX: 001 Hz: High
Mode: RGB 8bit
Curve: Standard
Dim: Smo TOOL&v
DMX: 001 Hz: High
Mode: RGB 8bit
Curve: Standard
Dim: Smo TOOL&v
[∧&V]
EXIT &V
ALL: 255
CH01: 255
CH02: 255
CH03: 255 [∧&V]
EXIT &V
www.ltech-led.com www.ltech-led.com
OLED screen interface
Press "M" key, switch entries.
Long press “M” key, back to main page.
Press "∧" or “∨" key, parameter adjustment.
Exit back to previous page.:
1. DMX address
setting
Main page
Press “∧" or “∨" key to set DMX address.
Range: 001~512
2. PWM frequency
Press “∧" or “∨" key to choose.
Optional : Dim
CT
RGB
3. Mode
No flicker in
video camera.
Press “∧" or “∨" key to choose.
Std (standard)
High
Mid (middle)
Low
Optional :
Smooth and exquisite,
human eye is comfortable.
It is recommended to
use standard.
4. Grey scale
5. Dimming
curve
Press “∧" or “∨" key to choose.
Optional : 8bit
16bit (choose it if the master
controller support this function)
Press “∧" or “∨" key to choose.
Optional :
Linear
LOG
0.1~9.9
Standard
It is recommended to use standard,
0.1-9.9 is for special requirements.
Press “∧" or “∨" key to choose.
Optional :
Smo (smooth)
Std (standard)
Smo: This option with smooth processing, realize
the dimming flicker-free and dynamic effects
more downy.
It is recommended to use standard.
6. Enhance
dimming
7. Tool
* Fast self-testing function: press “ or " keys
simultaneously for 2-3 seconds under any page,
decoder will enter self-testing function.
∧"∨"
Press “∧" or “∨"
key to enter submenu
Press “∧" or “∨"
key to enter
submenu of test.
Change all value
simultaneously
(on the last page)
Screensaver open and
black if undo for 2 minutes.
Screen: ON+black
Screensaver not enable.
Screen: OFF
Screensaver open and display
address if undo for 2 minutes.
Screen: ON+Addr
Brightness setting
(range: 0~255)
Press”∧" or "∨"
to next page
Press"∨" to exit

LT-912-OLED
LT-912-OLED
6 7
1
3
2
PUSH
1
3
2
PUSH
LEDs
LEDs
1
1
2
2
3
3
4
4
www.ltech-led.comwww.ltech-led.com
Wiring diagram
2. DMX console onnectionc :
LT-912-OLED is equipped with 3 types DMX terminals for
users’ selection. The following diagram takes 5-pin XLR
as an example, same connecting method for the rest two:
RJ45 & green terminal (with amplifier function).
DMX
console
DMX signal
If the recoil effect occurs because of longer signal line or bad line quality, please try
to connect 0.25W 90-120Ω terminal resistor at the end of each line.
*
DMX signal DMX signal
12-24Vdc 12-24Vdc 12-24Vdc
1. Connecting LED lights:
DMX/RDM signal DMX/RDM signal
Output port
(Wiring method on P7)
12-24Vdc
Power to
LEDS1, 2
LED power supply
Power to
LEDS3, 4
DMX/RDM signal DMX/RDM signal
12-24Vdc
LED
power
supply
LED
power
supply
Power to
LEDS1, 2Power to
LEDS3, 4
RGB LEDs
Color temperature LEDs
CT mode
RGB mode
Dimming mode
Single color LEDs
Resistor
terminal
LT-9 12-OLED LT-912-OL ED LT-9 12-OLED
R
R
R
CH
CH
CH
1
1
1
2
2
2
3
3
3
G
G
G
B
B
B

98
*
www.ltech-led.com www.ltech-led.com
3. The connection diagram of 3 kinds of DMX/RDM terminals:
5-pin XLR
connected
in parallel
Green terminal
connected
in parallel
Installation distance > 20mm
RJ45
connected
in parallel
These 3 terminals can be connected
in a mixed way.
Resistor
terminal
Resistor
terminal
Resistor
terminal
Vent
*
Installation attention : please reserve enough ventilation distance between decoders (>20mm),
be sure not to block the vent, or will affect lifetime of decoder for .poor heat dissipation
4. The connection diagram of :AMP signal amplifier terminal
Connecting with green terminal or an extra amplifier will be needed when more than 32
decoders are connected or use overlong signal wire (as shown below). Signal amplifier
should not be more than 5 times continuously.
Resistor
terminal
Address setting table
Mode Mode
Resolution Resolution
Address
Quantity Address Quantity
Channel Channel
DIM DIM CT CT RGB RGB
4 88 16
12 24
8bit 16bit 8bit 16bit 8bit 16bit
1
2
3
4
5
6
7
8
9
10
11
12
1
2
3
4
5
6
7
8
9
10
11
12
001 001 001
001 002 002
001 002 003
002 003 004
002 004 005
002 004 006
003 005 007
003 006 008
003 006 009
004 007 010
004 008 011
004 008 012
001
002
001
002
001
002
003
004
005
006
005
006
009
010
005
006
005
006
005
006
007
008
007
008
007
008
009
010
011
012
011
012
011
012
013
014
015
016
017
018
001
002
003
004
003
004
003
004
003
004
003
004
001
002
007
008
007
008
013
014
015
016
015
016
019
020
021
022
023
024
007
008
LT-9 12 -OLED
LT-9 12 -OLED
LT-9 12 -OLED
LT-9 12 -OLED
LT-9 12 -OLED
LT-9 12 -OLED
LT-9 12 -OLED
LT-9 12 -OLED
LT-9 12 -OLED
LT-912 -O LE D LT-91 2- OLED LT-91 2- OLED LT-912 -O LE D LT-9 12 -O LE D LT-9 12 -O LE D
AMP

10 11
WIFI-RDM01
…
…
LED LED LED
12-24Vdc 12-24Vdc 12-24Vdc
www.ltech-led.com www.ltech-led.com
Update Time: 2019.10.08_A4
ac
b
d
5-24Vdc power input
LED
power
supply
LED
power
supply
LED
power
supply
LED
power
supply
LED
power
supply
LED
power
supply
Work with RDM editor
LT-912-OLED can work with LTECH RDM editor (Model: WiFi-RDM01) to realize changing the
parameters by long-range setting, wiring diagram as below:
Power bank
available
supply is
RDM editor App interface instruction
Download the App, setting the LT-912-OLED parameters (frequency, bit, curve, modes, dimming
range, screensaver, etc.) after well connecting the RDM editor, more details, please check the
manual of WiFi-RDM01.
Well installation of products first, then working with WiFi -RDM01 to realize setting parameters
and firmware upgrade by App.
a: Click”Add”, edited the address in corresponding box.
b: Click”ID”, get more product details.
c: Click” ”, enter edited interface
d: Click”No.”, issue the recognizing command.
Supporting WiFi-RDM01 upgrade
and DMX driver upgrade.
WiFi-RDM01
upgrade
DMX device
upgrade
No further notice if any changes in the manual.
Product function depends on the goods.
Please feel free to contact your supplier if any question.
…
