LTS 7200-FH Series User guide

Digital Video Recorder
Quick Operation Guide

Quick Operation Guide of -7200/7300FH/WH/ HV Series DVR
1
Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact dealer.
This manual is applicable to the following models:
7200-FH Series, 7200-WH Series, 7200A-WH Series, 7200-HV Series, 7200A-HV Series
7300-FH Series, 7300-WH Series, 7300A--WH Series,
DVR Pre-Installation
This Series DVR is highly advanced surveillance equipment that should be installed with care. Please take into
consideration the following precautionary steps before installation of the DVR.
1. Keep all liquids away from the DVR.
2. Install the DVR in a well-ventilated and dust-free area.
3. Ensure environmental conditions meet factory specifications.
4. Install a manufacturer recommended HDD.
DVR Installation
During the installation of the DVR:
1. Use brackets for rack mounting.
2. Ensure there is ample room for audio and video cables.
3. When installing cables, ensure that the bend radius of the cables are no less than five times than its diameter.
4. Connect both the alarm and RS-485 cable.
5. Allow at least 2cm (~0.75-inch) of space between racks mounted devices.
6. Ensure the DVR is grounded.
7. Environmental temperature should be within the range of -10 ºC ~ 55 ºC , 14ºF ~ 131ºF.
8. Environmental humidity should be within the range of 10% ~ 90%.
Hard Disk Installation
Before you start:
Before installing a hard disk drive (HDD), please make sure the power is disconnected from the DVR. A factory
recommended HDD should be used for this installation.
Tools Required: Screwdriver.
Steps (for 7200-FH/WH/HV and 7300-FH/WH):
1. Remove the cover from the DVR by unfastening the screws on the back and side.
2. Install the HDD in the HDD rack using the provided screws. Fasten the screws on the
bottom to fix the HDD.

Quick Operation Guide of -7200/7300FH/WH/ HV Series DVR
2
3. Connect the HDD to the motherboard of the DVR with the included data cable.
4. Connect the power cable to the HDD.
5. Re-install the cover of the DVR and fasten screws.

Quick Operation Guide of -7200/7300FH/WH/ HV Series DVR
3
Front Panel
7204-FH/WH:
7208/16-FH/WH:
7204/08/16-HV:
7204/08/16A-HV:

Quick Operation Guide of -7200/7300FH/WH/ HV Series DVR
4
Table 1 Description of Control Panel Buttons
No.
Name
Function Description
1
Status Indicators
POWER: the POWER indicator turns green when NVR is
powered up.
READY: The indicator light is green when the device is
running normally.
STATUS: 1.The light is green when the IR remote control is
enabled; 2.The light is red when the function of the composite
keys (SHIFT) are used; 3. The light is out when none of the
above condition is met/
ALARM: the light is red when there is an alarm occurring.
HDD: the indicator flickers red when HDD is reading/writing.
Tx/Rx: TX/RX indicator flickers green when network
connection is functioning normally.
2
USB Interfaces
Universal Serial Bus (USB) ports for additional devices such as
USB mouse and USB Hard Disk Drive (HDD).
3
Composite
Keys
1/MENU:
Enter numeral “1”;
Access the main menu interface.
2/ABC/F1:
Enter numeral “2”;
Enter letters “ABC”;
The F1 button when used in a list field will select all items in
the list.
In PTZ Control mode, it will turn on/off PTZ light and when
the image is zoomed in, the key is used to zoom out.
3/DEF/F2:
Enter numeral “3”;
Enter letters “DEF”;
The F2 button is used to change the tab pages.
In PTZ control mode, it zooms in the image.
4/GHI/ESC:
Enter numeral “4”;
Enter letters “GHI”;
Exit and back to the previous menu.
5/JKL/EDIT:
Enter numeral “5”;
Enter letters “JKL”;
Delete characters before cursor;
Check the checkbox and select the ON/OFF switch;
Start/stop record clipping in playback.
6/MNO/PLAY:
Enter numeral “6”;
Enter letters “MNO”;
Playback, for direct access to playback interface.
7/PQRS/REC:
Enter numeral “7”;
Enter letters “PQRS”;
Open the manual record interface.
8/TUV/PTZ:
Enter numeral “8”;
Enter letters “TUV”;
Access PTZ control interface.

Quick Operation Guide of -7200/7300FH/WH/ HV Series DVR
5
No.
Name
Function Description
9/WXYZ/PREV:
Enter numeral “9”;
Enter letters “WXYZ”;
Multi-channel display in live view.
0/A:
Enter numeral “0”;
Shift the input methods in the editing text field. (Upper and
lowercase, alphabet, symbols or numeric input).
Double press the button to switch the main and auxiliary
output.
4
SHIFT
Switch between the numeric or letter input and functions of the
composite keys. (Input letter or numbers when the light is out;
Realize functions when the light is red.)
5
Control Buttons
Directional buttons:
In menu mode, the direction buttons are used to navigate
between different fields and items and select setting parameters.
In playback mode, the Up and Down buttons are used to speed
up and slow down record playing, and the Left and Right
buttons are used to move the recording 30s forwards or
backwards.
In the image setting interface, the up and down button can
adjust the level bar of the image parameters.
In live view mode, these buttons can be used to switch
channels.
Enter:
The Enter button is used to confirm selection in menu mode; or
used to check checkbox fields and ON/OFF switch.
In playback mode, it can be used to play or pause the video.
In single-frame play mode, pressing the Enter button will play
the video by a single frame.
And in auto sequence view mode, the buttons can be used to
pause or resume auto sequence.
6
IR Receiver
Receiver for IR remote.

Quick Operation Guide of -7200/7300FH/WH/ HV Series DVR
6
7300-FH/WH:
The front panel of 7300-FH/WH is shown below:
Table 2 Description of Control Panel Buttons
No.
Name
Function Description
1
POWER ON/OFF
Power on/off switch.
2
IR Receiver
Receiver for IR remote control.
3
USB
Connect to USB mouse or USB flash memory devices.
4
DVD-ROM
Slot for DVD-ROM.
5
POWER
Power indicator lights in green when DVR is powered up.
READY
Ready indicator is normally green, indicating that the DVR is functioning properly.
STATUS
Indicator turns green when DVR is controlled by an IR remote control with the
address from 1~254;
Indicator turns red when the SHIFT button is used;
Indicator does not light when the DVR is controlled by a keyboard or by the IR
remote control with the address of 255;
Indicator turns green when the DVR is controlled by IR remote control (with the
address from 1~254) and keyboard at the same time , and the SHIFT button is not
used;
Indicator turns orange : (a) when the DVR is controlled by IR remote control (with
the address from 1~254) and keyboard at the same time and the SHIFT button is used
as well; (b) when the DVR is controlled by IR remote control (with the address from
1~254) and the SHIFT button is used.
ALARM
Alarm indicator turns red when a sensor alarm is detected.
HDD
HDD indicator blinks in red when data is being read from or written to HDD.
Tx/Rx
TX/RX indictor blinks in green when network connection is functioning properly.
6
1/MENU
Enter numeral “1”;
Access the main menu interface.
2ABC/F1
Enter numeral “2”;
Enter letters “ABC”;
The F1 button can be used to select all items on the list;
In PTZ Control mode, the F1 button can be used to zoom out (zoom-) the PTZ
camera;
In live view or playback mode, the F1 button can be used to switch between main
and spot video output.
3DEF/F2
Enter numeral “3”;
Enter letters “DEF”;
In PTZ Control mode, the F1 button can be used to zoom in (zoom+) the PTZ
camera;
The F2 button can be used to cycle through tab pages.
4GHI/ESC
Enter numeral “4”;
Enter letters “GHI”;
Exit and back to the previous menu.
5JKL/EDIT
Enter numeral “5”;
Enter letters “JKL”;
Delete characters before cursor;
Select the checkbox and ON/OFF switch;
Start/stop record clipping in playback.
SHIFT
Switch of compound keys between the numeric/letter input and functional control.
6MNO/PLAY
Enter numeral “6”;
Enter letters “MNO”;
In Playback mode, it is used for direct access to playback interface.
7PQRS/REC
Enter numeral “7”;

Quick Operation Guide of -7200/7300FH/WH/ HV Series DVR
7
Enter letters “PQRS”;
Manual record, for direct access to manual record interface; manually enable/disable
record.
8TUV/PTZ
Enter numeral “8”;
Enter letters “TUV”;
Access PTZ control interface.
9WXYZ/PREV
Enter numeral “9”;
Enter letters “WXYZ”;
Multi-camera display in live view;
In Playback mode or MenuPlaybackTag playback interface, this button can be
used to delete the selected tag.
0/A
Enter numeral “0”;
Switch between input methods (upper and lowercase alphabet, symbols and numeric
input).
In Playback mode, this button can be used to add the default tag.
7
DIRECTION
The DIRECTION buttons are used to navigate between different fields and items in
menus.
In Playback mode, the Up and Down button is used to speed up and slow down
recorded video.
In All-day Playback mode, the Left/Right button can be used to select the recorded
video of next/previous day; in Playback by Normal Video Search, the Left/Right
button can be used to select the next/previous recorded file.
In Live View mode, the directional buttons can be used to cycle through channels.
In PTZ control mode, it can control the movement of the PTZ camera.
ENTER
Confirm selection in any of the menu modes. It can also be used to tick checkbox
fields.
In Playback mode, it can be used to play or pause the video.
In Single-frame Playback mode, pressing the ENTER button will advance the video
by a single frame.
In Auto-switch mode, it can be used to stop /start auto switch.
8
JOG SHUTTLE
Control
Move the active selection in a menu. The inner ring will move the selection up and
down; the outer ring will move it left and right.
In Playback mode, the inner ring is used to jump 30s forward/backward in video
files. The outer ring can be used to speed up/slow down the video.
In Live View mode, it can be used to cycle through different channels.
In PTZ control mode, in can control the movement of the PTZ camera.

Quick Operation Guide of -7200/7300FH/WH/ HV Series DVR
8
Rear Panel
7204-FH/HV:
7204-WH :
7216-HV
1 2
3 4 5
6
7 8 9 10
11
12
Note: The rear panels of 7208-HV provide 8 video input interfaces.
7216A-HV:
Note: The rear panels of 7204A-HV and 7208A-HV provide 4, 8 video input interfaces.
7216B-HV:
Note: The rear panels of 7204B/7208B-HV provide 4, 8 video/audio input interfaces.

Quick Operation Guide of -7200/7300FH/WH/ HV Series DVR
9
7216-FH
3 4 5 7 8 9 10
11
1 2 6
12
Note: The rear panels of 7208-FH provide 8 video input interfaces.
7216-WH
Note: The rear panels of 7208-WH provide 8 video/alarm input interfaces.
7216A-WH :
Note: The rear panels of 7204A-WH and 7208A-WH provide 4/8 video/Audio input interfaces.
Table 3 Description of Rear Panel
No.
Item
Description
1
VIDEO IN
BNC connector for analog video input.
2
VIDEO OUT
BNC connector for video output.
3
USB Interface
Connects USB mouse or USB flash memory devices.
4
HDMI
HDMI video output.
5
VGA
DB15 connector for VGA output. Display local video output and menu.
6
AUDIO IN
RCA connector for audio input.
7
AUDIO OUT
RCA connector for audio output.
8
LAN Interface
RJ45 10M / 100M Ethernet interface.
9
RS-485 Interface
Connector for RS-485 devices. Connect the D+ and D- terminals to R+
and R- terminals of PTZ receiver respectively.
10
12V
12VDC power supply.
11
POWER
Switch for turning on/off the device.
12
GND
Ground(needs to be connected when DVR starts up)
13
Alarm In/Out
Connector for alarm input/output.

Quick Operation Guide of -7200/7300FH/WH/ HV Series DVR
10
7304-FH and 7304-WH:
123 4 6 8 9 10 15
57 11 12 13 14
7308-FH and 7308-WH:
1 2 3 4 6 8 9 10 1511
12 13 14
5 7
7316-FH and 7316-WH:
1 2
3 45 6
7 8
9
10 11
12
13 14
15
Table 4 Description of Rear Panel
No.
Item
Description
1
VIDEO IN
BNC connector for analog video input.
2
MAIN VIDEO OUT
BNC connector for video output.
SPOT VIDEO OUT
BNC connector for spot video output.
3
HDMI
HDMI video output.
4
USB Interface
Connects USB mouse or USB flash memory devices.
5
RS-232
Connector for RS-232 devices.
6
VGA
DB15 connector for VGA output. Display local video output and menu.
7
AUDIO IN
RCA connector for audio input.
8
AUDIO OUT
RCA connector for audio output.
9
LAN Interface
RJ45 10M / 100M / 1000M Ethernet interface.
10
RS-485 Interface
Connector for RS-485 devices. Connect the D+ and D- terminals to R+ and
R- terminals of PTZ receiver respectively.
KB
Connect the D+ and D- terminals to Ta and Tb terminals of the controller.
For cascading devices, the first DVR’s D+ and D- terminals should be
connected with the D+ and D- terminals of the next DVR.
11
Alarm In/Out
Connector for alarm input/output.
12
eSATA
Connects external SATA HDD, DVD-R/W.
13
110~240VAC
12VDC power supply.
14
POWER
Switch for turning on/off the device.
15
GND
Ground(needs to be connected when DVR starts up)

Quick Operation Guide of -7200/7300FH/WH/ HV Series DVR
11
7332-FH, 7332-WH:
2
3 4 5 6 7 8 9 10 11 12 13 14 15 16 17
1
Note: 7324-FH/WH/HH models provide 24 video input interfaces on the rear panel.
7332A-WH
Table 5 Description of Rear Panel
No.
Item
Description
1
MAIN VIDEO OUT
BNC connector for video output.
SPOT VIDEO OUT
BNC connector for spot video output.
2
VIDEO IN
BNC connector for analog video input.
3
CVBS AUDIO OUT
RCA connector for audio output. This connector is synchronized with CVBS
video output.
VGA AUDIO OUT
RCA connector for audio output. This connector is synchronized with VGA
video output.
4
LINE IN
RCA connector for two-way audio input.
5
AUDIO IN
RCA connector for audio input.
6
VGA
DB15 connector for VGA output. Display local video output and menu.
7
HDMI
HDMI video output.
8
USB Interface
Connects USB mouse or USB flash memory devices.
9
LAN Interface
RJ45 10M / 100M / 1000M Ethernet interfaces.
10
RS-232
Connector for RS-232 devices.
11
Termination Switch
RS-485 termination switch. Up position is not terminated.
Down is terminated with 120Ωresistance.
12
RS-485 Interface
Connector for RS-485 devices. Connect the T+ and T- terminals to the R+
and R- terminals of PTZ receiver respectively.
KB
Connect the D+ and D- terminals to Ta and Tb terminals of the controller.
For cascading devices, the first DVR’s D+ and D- terminals should be
connected with the D+ and D- terminals of the next DVR.
13
Alarm In/Out
Connector for alarm input/output.
14
eSATA
Connects external SATA HDD, DVD-R/W.
15
GND
Ground(needs to be connected when DVR starts up)
16
110~240VAC
110~240VAC power supply.
17
POWER
Switch for turning on/off the device.

Quick Operation Guide of -7200/7300FH/WH/ HV Series DVR
12
Peripheral Connections
Note: Alarm input/output connections are valid for the 7300 and 8100 models only.
Connecting to Alarm Input / Output Device
The alarm input is an open/closed relay. If the input is not an open/closed relay, follow the connection diagram
below:
To connect to an AC/DC load, use the following diagram:
For DC load, JP4 can be used within the limit of 12V/1A safely. If the interface is connected to an AC load, JP4
should be left open. Use an external relay for safety (as shown in the figure above).
There are 4 jumpers (JP4, JP5, JP6, and JP7) on the motherboard, each corresponding with one alarm output. By
default, jumpers are connected. To connect an AC load, jumpers should be removed.
Note: An external relay is needed to prevent electric shock when connecting to an AC load.
Alarm Connection
To connect alarm devices to the DVR:
1. Disconnect pluggable block from the ALARM IN /ALARM OUT terminal block.
2. Press and hold the orange part of the pluggable block; insert signal cables into slots and release the orange part.
Ensure signal cables are in tight.
3. Connect pluggable block back into terminal block.
RS-485 Connections
To connect RS-485 devices (e.g., pan/tilt unit) to the DVR:
Press and hold the orange part of the pluggable block; insert signal cables into slots and release the orange part.
Ensure signal cables are in tight.
Note: Make sure the pan/tilt receiver unit is connected to the D+ and D- of the RS-485 terminal of 7200-FH/WH
and 7304/7308/7316-FH/WH DVR, or to the T+ and T- of the RS-485 terminal of 7324/7332FH/WH DVR.

Quick Operation Guide of -7200/7300FH/WH/ HV Series DVR
13
Specifications
Table 6 Specifications for 7200-FH
Model
4CH
8CH
16CH
Video/Audio
input
Video compression
H.264
Video input
4-ch
8-ch
16-ch
Video input interface
BNC (1.0 Vp-p, 75 Ω), PAL /NTSC self-adaptive
Audio compression
G.711
Audio input
1-ch, RCA (2.0 Vp-p, 1 kΩ)
Two-way audio input
1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input)
Video/Audio
output
HDMI/VGA output
1-ch, resolution:
1080P:
1920×1080/60Hz
UXGA:
1600×1200/60Hz
SXGA:
1280×1024/60Hz
720P: 1280×720/60Hz
XGA: 1024×768/60Hz
1-ch, resolution:
1080P: 1920×1080/60Hz,
SXGA: 1280×1024/60Hz,
720P: 1280×720/60Hz,
XGA: 1024×768/60Hz
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 ×576, NTSC: 704 ×480
Encoding resolution
4CIF / 2CIF / CIF / QCIF
Frame rate
25 fps (P) / 30 fps (N)
Video bit rate
32 Kbps ~ 3072 Kbps, or user defined (Max. 3072 Kbps)
Audio output
1-ch, RCA (Linear, 1 kΩ)
Audio bit rate
64 Kbps
Dual-stream
Support; Sub-stream: CIF / QCIF @ 25 fps (P) / 30 fps (N)
Stream type
Video, Video & Audio
Synchronous
playback
4-ch
8-ch
16-ch
Hard disk
SATA
1 SATA interface
2 SATA interfaces
2 SATA interfaces
Capacity
Up to 4TB capacity
External
interface
Network interface
1, RJ45 10M / 100M Ethernet interface
Serial interface
1 RS-485 interface, half-duplex
USB interface
2, USB 2.0
General
Power supply
12 VDC
Consumption
(without HDD or
DVD-R/W)
≤ 10 W
≤ 15 W
≤ 20 W
Working
temperature
-10 ºC ~+55 ºC
Working humidity
10% ~ 90%
Chassis
Standalone 1U chassis
19-inch
rack-mounted 1U
chassis
19-inch
rack-mounted 1U
chassis
Dimensions
(W ×D ×H)
315 ×230 ×45 mm
445 ×290 ×45 mm
445 ×290 ×45 mm
Weight
(without HDD or
DVD-R/W)
≤ 2 kg
≤ 4 kg
≤ 4 kg

Quick Operation Guide of -7200/7300FH/WH/ HV Series DVR
14
Table 7 Specifications for 7200-HV
Model
4CH
8CH
16CH
Video/Audio
input
Video
compression
H.264
Video input
4-ch
8-ch
16-ch
Video input
interface
BNC (1.0 Vp-p, 75 Ω), PAL /NTSC self-adaptive
Audio
compression
G.711
Audio input
1-ch, RCA (2.0 Vp-p, 1 kΩ)
Two-way audio
input
1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input)
Video/Audio
output
HDMI/VGA
output
1-ch, resolution:
1080P: 1920×1080/60Hz; SXGA: 1280×1024/60Hz;
720P: 1280×720/60Hz; XGA: 1024×768/60Hz
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 ×576, NTSC: 704 ×480
Encoding
resolution
WD1 / 4CIF / 2CIF / CIF / QCIF
Frame rate
WD1 / 4CIF / 2CIF
@ 15 fps; CIF / QCIF
@ 25 fps (P) / 30 fps
(N)
WD1 / 4CIF / 2CIF
@ 15 fps; CIF / QCIF
@ 25 fps (P) / 30 fps
(N)
WD1 @ 8 fps; 4CIF /
2CIF @ 10 fps; CIF /
QCIF @ 25 fps (P) /
30 fps (N)
Video bit rate
32 Kbps ~ 3072 Kbps, or user defined (Max. 3072 Kbps)
Audio output
1-ch, RCA (Linear, 1 kΩ)
Audio bit rate
64 Kbps
Dual-stream
Support; sub-stream @ CIF / QCIF
Stream type
Video, Video & Audio
Synchronous
playback
4-ch
8-ch
16-ch
Hard disk
SATA
1 SATA interface
Capacity
Up to 4TB capacity
External
interface
Network
interface
1, RJ45 10M / 100M Ethernet interface
Serial interface
1 RS-485 interface, half-duplex
USB interface
2, USB 2.0
General
Power supply
12 VDC
Consumption
(without HDD or
DVD-R/W)
≤ 10 W
≤ 10 W
≤ 15 W
Working
temperature
-10 ºC ~+55 ºC
Working
humidity
10% ~ 90%
Chassis
Standalone 1U chassis
Dimensions
(W ×D ×H)
315 ×230 ×45 mm
Weight (without
HDD or
DVD-R/W)
≤ 2 kg

Quick Operation Guide of -7200/7300FH/WH/ HV Series DVR
15
Table 8 Specifications for 7200A-HV
Model
4CH
8CH
16CH
Video/Audio
input
Video compression
H.264
Video input
4-ch
8-ch
16-ch
Video input interface
BNC (1.0 Vp-p, 75 Ω), PAL /NTSC self-adaptive
Audio compression
G.711
Audio input
1-ch, RCA (2.0 Vp-p, 1 kΩ)
Two-way audio input
1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input)
Video/Audio
output
HDMI/VGA output
1-ch, resolution:
1080P: 1920×1080/60Hz; SXGA: 1280×1024/60Hz;
720P: 1280×720/60Hz; XGA: 1024×768/60Hz
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 ×576, NTSC: 704 ×480
Encoding resolution
WD1 / 4CIF / 2CIF / CIF / QCIF
Frame rate
WD1 / 4CIF /
2CIF @ 15 fps;
CIF / QCIF @
25 fps (P) / 30
fps (N)
WD1 / 4CIF / 2CIF
@ 15 fps; CIF /
QCIF @ 25 fps (P) /
30 fps (N)
WD1 @ 8 fps;
4CIF / 2CIF @ 10
fps; CIF / QCIF @
25 fps (P) / 30 fps
(N)
Video bit rate
32 Kbps ~ 3072 Kbps, or user defined (Max. 3072 Kbps)
Audio output
1-ch, RCA (Linear, 1 kΩ)
Audio bit rate
64 Kbps
Dual-stream
Support; sub-stream @ CIF / QCIF
Stream type
Video, Video & Audio
Synchronous playback
4-ch
8-ch
16-ch
Hard disk
SATA
1 SATA interface
Capacity
Up to 4TB capacity
External
interface
Network interface
1, RJ45 10M / 100M Ethernet interface
Serial interface
1 RS-485 interface, half-duplex
USB interface
2, USB 2.0
Alarm in
4
Alarm out
1
General
Power supply
12 VDC
Consumption
(without HDD or
DVD-R/W)
≤ 10 W
≤ 10 W
≤ 15 W
Working temperature
-10 ºC ~+55 ºC
Working humidity
10% ~ 90%
Chassis
Standalone 1U chassis
Dimensions
(W ×D ×H)
315 ×230 ×45 mm
Weight (without HDD or
DVD-R/W)
≤ 2 kg

Quick Operation Guide of -7200/7300FH/WH/ HV Series DVR
16
Table 9 Specifications for 7200B-HV
Model
4CH
8CH
16CH
Video/Audio
input
Video compression
H.264
Video input
4-ch
8-ch
16-ch
Video input interface
BNC (1.0 Vp-p, 75 Ω), PAL /NTSC self-adaptive
Audio compression
G.711
Audio input
4-ch, RCA
8-ch, RCA
16-ch, RCA
Two-way audio input
1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input)
Video/Audio
output
HDMI/VGA output
1-ch, resolution:
1080P: 1920×1080/60Hz; SXGA: 1280×1024/60Hz;
720P: 1280×720/60Hz; XGA: 1024×768/60Hz
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 ×576, NTSC: 704 ×480
Encoding resolution
WD1 / 4CIF / 2CIF / CIF / QCIF
Frame rate
WD1 / 4CIF /
2CIF @ 15 fps;
CIF / QCIF @
25 fps (P) / 30
fps (N)
WD1 / 4CIF / 2CIF
@ 15 fps; CIF /
QCIF @ 25 fps (P) /
30 fps (N)
WD1 @ 8 fps;
4CIF / 2CIF @ 10
fps; CIF / QCIF @
25 fps (P) / 30 fps
(N)
Video bit rate
32 Kbps ~ 3072 Kbps, or user defined (Max. 3072 Kbps)
Audio output
1-ch, RCA (Linear, 1 kΩ)
Audio bit rate
64 Kbps
Dual-stream
Support; sub-stream @ CIF / QCIF
Stream type
Video, Video & Audio
Synchronous playback
4-ch
8-ch
16-ch
Hard disk
SATA
1 SATA interface
Capacity
Up to 4TB capacity
External
interface
Network interface
1, RJ45 10M / 100M Ethernet interface
Serial interface
1 RS-485 interface, half-duplex
USB interface
2, USB 2.0
Alarm in
4
Alarm out
1
General
Power supply
12 VDC
Consumption
(without HDD or
DVD-R/W)
≤ 10 W
≤ 10 W
≤ 15 W
Working temperature
-10 ºC ~+55 ºC
Working humidity
10% ~ 90%
Chassis
Standalone 1U chassis
Dimensions
(W ×D ×H)
315 ×230 ×45 mm
Weight (without HDD or
DVD-R/W)
≤ 2 kg

Quick Operation Guide of -7200/7300FH/WH/ HV Series DVR
17
Table 10 Specifications for 7200-WH
Model
4CH
8CH
16CH
Video/Audio
input
Video compression
H.264
Video input
4-ch
8-ch
16-ch
Video input interface
BNC (1.0 Vp-p, 75 Ω), PAL /NTSC self-adaptive
Audio compression
G.711
Audio input
1-ch, RCA (2.0 Vp-p, 1 kΩ)
Two-way audio input
1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input)
Video/Audio
output
HDMI/VGA output
1-ch, resolution:
1080P: 1920×1080/60Hz; SXGA: 1280×1024/60Hz;
720P: 1280×720/60Hz; XGA: 1024×768/60Hz
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 ×576, NTSC: 704 ×480
Encoding resolution
WD1 / 4CIF / 2CIF / CIF / QCIF
Frame rate
25 fps (P) / 30 fps (N)
Video bit rate
32 Kbps ~ 3072 Kbps, or user defined (Max. 3072 Kbps)
Audio output
1-ch, RCA (Linear, 1 kΩ)
Audio bit rate
64 Kbps
Dual-stream
Support; sub-stream @ CIF/ QCIF
Stream type
Video, Video & Audio
Synchronous playback
4-ch
8-ch
16-ch
Hard disk
SATA
1 SATA
interface
2 SATA interfaces
Capacity
Up to 4TB capacity for each disk
External
interface
Network interface
1, RJ45 10M / 100M Ethernet interface
Serial interface
1 RS-485 interface, half-duplex
USB interface
2, USB 2.0
Alarm in
4
8
16
Alarm out
1
4
4
General
Power supply
12 VDC
Consumption
(without hard disk or
DVD-R/W)
≤ 10 W
≤ 15 W
≤ 20 W
Working temperature
-10 ºC ~+55 ºC
Working humidity
10% ~ 90%
Chassis
Standalone 1U
chassis
19-inch rack-mounted 1U chassis
Dimensions
(W ×D ×H)
315 ×230 ×45
mm
445 ×290 ×45mm
Weight (without hard disk
or DVD-R/W)
≤ 2 kg
≤ 4 kg
≤ 4 kg

Quick Operation Guide of -7200/7300FH/WH/ HV Series DVR
18
Table 11 Specifications for 7200A-WH
Model
4CH
8CH
16CH
Video/Audio
input
Video compression
H.264
Video input
4-ch
8-ch
16-ch
Video input interface
BNC (1.0 Vp-p, 75 Ω), PAL /NTSC self-adaptive
Audio compression
G.711
Audio input
4-ch, RCA
8-ch, RCA
16-ch, RCA
Two-way audio input
1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input)
Video/Audio
output
HDMI/VGA output
1-ch, resolution:
1080P: 1920×1080/60Hz; SXGA: 1280×1024/60Hz;
720P: 1280×720/60Hz; XGA: 1024×768/60Hz
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 ×576, NTSC: 704 ×480
Encoding resolution
WD1 / 4CIF / 2CIF / CIF / QCIF
Frame rate
25 fps (P) / 30 fps (N)
Video bit rate
32 Kbps ~ 3072 Kbps, or user defined (Max. 3072 Kbps)
Audio output
1-ch, RCA (Linear, 1 kΩ)
Audio bit rate
64 Kbps
Dual-stream
Support; sub-stream @ CIF/ QCIF
Stream type
Video, Video & Audio
Synchronous playback
4-ch
8-ch
16-ch
Hard disk
SATA
1 SATA interface
2 SATA interfaces
Capacity
Up to 4TB capacity for each disk
External
interface
Network interface
1, RJ45 10M / 100M Ethernet interface
Serial interface
1 RS-485 interface, half-duplex
USB interface
2, USB 2.0
Alarm in
4
8
16
Alarm out
1
4
4
General
Power supply
12 VDC
Consumption
(without hard disk or
DVD-R/W)
≤ 10 W
≤ 15 W
≤ 20 W
Working temperature
-10 ºC ~+55 ºC
Working humidity
10% ~ 90%
Chassis
Standalone 1U
chassis
19-inch rack-mounted 1U chassis
Dimensions
(W ×D ×H)
315 ×230 ×45
mm
445 ×290 ×45mm
Weight (without hard disk
or DVD-R/W)
≤ 2 kg
≤ 4 kg
≤ 4 kg

Quick Operation Guide of -7200/7300FH/WH/ HV Series DVR
19
Table 12 Specifications for 7300-FH
Model
4CH
8CH
16CH
24CH
32CH
Video/Audio
input
Video compression
H.264
Video input
4-ch
8-ch
16-ch
24-ch
32-ch
Video input
interface
BNC (1.0 Vp-p, 75 Ω), PAL /NTSC self-adaptive
Audio compression
G.711u
Audio input
4-ch, RCA (2.0 Vp-p, 1 kΩ)
Two-way audio
input
1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input)
Video/Audio
output
HDMI/VGA output
1-ch, resolution:
1080P: 1920×1080/60Hz, SXGA: 1280×1024/60Hz,
720P: 1280×720/60Hz, XGA: 1024×768/60Hz
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 ×576, NTSC: 704 ×480
Video spot out
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 ×576, NTSC: 704 ×480
Encoding resolution
4CIF / 2CIF / CIF / QCIF
Frame rate
25 fps (P) / 30 fps (N)
Video bit rate
32 Kbps ~ 3072 Kbps, or user defined (Max. 3072 Kbps)
Audio output
2-ch, RCA (Linear, 600 Ω)
Audio bit rate
64 Kbps
Dual-stream
Support; Sub-stream: CIF / QCIF @ 25 fps (P) / 30 fps (N)
Stream type
Video, Video
& Audio
Channel 1-4: Video, Video & Audio;
Other channels: Video
Synchronous
playback
4-ch
8-ch
16-ch
Hard disk
SATA
4 SATA interfaces
eSATA
1 eSATA interface
Capacity
Up to 4TB capacity
External
interface
Network interface
1, RJ45 10M / 100M / 1000M Ethernet interface
Serial interface
1 RS-232,
RS-485(half-duplex),
Keyboard
1 RS-232,
RS-485(full-duplex),
Keyboard
USB interface
3 ×USB 2.0
Alarm in
4
8
16
16
Alarm out
1
4
4
8
General
Power supply
100~240VAC, 5A, 50~60Hz
Consumption
(without HDD or
DVD-R/W)
≤ 25 W
≤ 30 W
≤ 35 W
≤ 40 W
Working
temperature
-10 ºC ~+55 ºC
Working humidity
10% ~ 90%
Chassis
19-inch rack-mounted 1.5U chassis
Dimensions
(W ×D ×H)
445 ×390 ×70 mm
Weight
(without HDD or
DVD-R/W)
≤ 5 kg
