LUCHT LHZ TECHNOTHERM VPS Series User manual
Feel good through warmth from electricity - www.technotherm.de
Id_no. 911 360 924
Issue 04/20
Feel good through warmth from electricity - www.technotherm.de
VPS / VPS-Design / SPH / VPN
Feel good through warmth from electricity - www.technotherm.de
GB
VPS / VPS-Design / SPH / VPN
Feel good through warmth from electricity - www.technotherm.de
GB
•
•
•
•
Feel good through warmth from electricity - www.technotherm.de
VPS / VPS-Design / SPH / VPN
Feel good through warmth from electricity - www.technotherm.de
GB
VPS / VPS-Design / SPH / VPN
Feel good through warmth from electricity - www.technotherm.de
GB
Press the
Feel good through warmth from electricity - www.technotherm.de
VPS / VPS-Design / SPH / VPN
Feel good through warmth from electricity - www.technotherm.de
GB
•
•
•
•
•
•
•
•
•
•
•
•
•
VPS / VPS-Design / SPH / VPN
Feel good through warmth from electricity - www.technotherm.de
GB
Digital control display
TDI
–
“
plus
”
Thermostat
Mounting
Mounted on the side of the radiator using
screws.
Connection
Connection on the radiator’s power card.
Adjustment
buttons
part to connect to
the power card
réf : 7709936
On / Off
/
mode
Configuration
Menu 3: Backlight time out setting
The time out can be adjusted between 0
and 225 seconds, in steps of 15 seconds
(set on 90 seconds by default).
To modify, press on the + or - buttons then
press OK to confirm and go to the next setting.
When in Off mode,
press and hold down the On/Off button
for 10 seconds to access the first configuration
menu.
>10 sec.
Menu 4: AUTO mode temperature display option
Menu 1: ECO set-point adjustment
By default, Economy setting = Comfort setting - 3.5°C.
0 = Continuous display of room temperature.
1 = Continuous display of set-point temperature.
To modify, press on the + or - buttons then
press OK to confirm and go to the next setting.
Menu number
Menu 5: Product number
This menu allows you to view the product
number.
This reduction can be set between
0 to -10°C, in steps of 0.5°C.
To adjust the reduction, press on
the +or - buttons then press OKto confirm
and go to the next setting.
To allow the user tomodify the set-point, press
on the + button in Economy mode until “----” is
displayed on the screen.
To exit the configuration mode, press OK.
Menu 2: Correction of the measured
temperature
If there is a difference between the temperature noted with an
external thermometer and the temperature measured and
displayed by the unit, menu 2 acts on the measurement of the
probe so as to compensate for this difference (from -5°C to +5°
Cinsteps of 0.1°C).
To modify, press on the +or - buttons then press
OK to confirm and go to the next setting.
Feel good through warmth from electricity - www.technotherm.de
VPS / VPS-Design / SPH / VPN
Feel good through warmth from electricity - www.technotherm.de
GB
Time Setting
Use
Continuous Frost Protection
Day
In Off mode, press the
The days flash.
mode button.
Hours
Pressing and holding the + or - buttons lets you
change the current set-point (+5 to +15°C) in
steps of 0.5°C.
Press + or - to set the day, then press OK
to confirm and go on to set the hour and then
the minutes.
Minutes
Press
the mode button once to access the pro-
gramming,
and press the On/Off button once to exit the
s
etting mode. AUTOMATIC mode
In this mode the device follows the programming
set.
To modify the programming, press the PROG
button once.
Programming
When starting up, the “Comfort mode from 8am
to 10pm” program is applied to all the days of
the week.
Timer mode
To set a set-point temperature for a certain
To change the programming, press the PROG
button in Off or AUTO mode.
The 1
st
time slot flashes on and off.
period of time, press on the
button once.
To set the temperature you want (+5°C to
+30°C), use the + and - buttons, then press OK
to confirm and go on to set the duration.
To set the duration you want (30 min
to 72 hours, in steps of 30 min), use
Day
the + and – buttons (e.g. 1 hr 30 min), then press OK.
To cancel the timer mode, press on the OK button.
Program
profile
Confirm
and go to
the next day
Frost protection
mode for 1 hour
1
st
time
slot
Comfort
mode for 1 hour
Absence mode
You can set your device to Frost protection
mode for a period between 1 and 365 days,
Economy
mode for 1 hour
by pressing on the
button.
Quick programming:
To
apply the same program to the following day,
press and hold
the OK button
for
approximately 3 seconds until the program of
the following
day is displayed.
To exit the programming mode, press on the On/Off button.
To set the number of days of absence,
press on the + or – buttons, then confirm by
pressing OK.
To cancel this mode, press on the OK button
again.
Use
The Mode button allows you to select the different operating
Locking the keypad
If you press and hold the central buttons
simultaneously during 5 seconds, it enables
you to lock the keypad. A key symbol appears
briefly on the display.
To unlock the keypad, press simultaneously on
the central buttons.
modes:
Comfort,
Economy,
Frost protection,
programming AUTO mode.
Pressing the
i button gives you the temperature of the room
or the set
-
point temperature, according to your configuration
settings in menu 5.
If the
ON icon is displayed, this means that the device is in
heating demand mode.
Once the keypad is locked, the key symbol
appears briefly if you press on a button.
Continuous Comfort
Pressing and holding the + or
-
buttons lets you
change the current set
-point (+5 to +30°C) in
steps of 0.5°C.
Continuous Economy mode
The Economy set
-point is indexed according to
the Comfort set
-point. The reduction can be
modified
in the configuration settings for menu 1.
Modifying the
Economy set-point
The
set-point can be modified if it
was authorized
in the
configuration settings in menu 1 (“----”).
Pressing and holding the + or
- buttons lets you
change the current set
-point (+5 to +30°C) in
steps of 0.5°C.
Menu 5: Open Window detection
The detection of an open window occurs
when the room temperature falls rapidly.
In this case, the display shows a flashing
pictogram, as well as the frost
protection set-point temperature.
0 = Open window detection is deactivated
1 = Open window detection is activated
To modify, press on the + or – buttons,
then press OK to confirm and to go to the
next setting.
Please note: an open window cannot be
detected in OFF-Mode.
This feature can be temporarily interrupted
by pressing on .
VPS / VPS-Design / SPH / VPN
Feel good through warmth from electricity - www.technotherm.de
GB
Technical characteristics
•
Power supplied by the power card
•
Dimensions in mm (without mounting lugs):
H = 71.7, W = 53, D= 14.4
•
Screw-mounted
•
Install in an environment with normal pollution levels
•
Storage temperature: -10°C to +70°C
•
Operating temperature: 0°C to +40°C
Menu 6: Adaptive start control
This feature enables to reach the set-point
temperature at a set time.
When this feature is activated, the display shows a
flashing .
0 = Adaptive start control deactivated
1 = Adaptive start control activated
To modify, press on the +or – buttons, then press
OK to confirm and to go to the next setting.
Adjusting the time-temperature-slope (when
adaptive start control is activated)
From 1°C to 6°C, in steps of 0.5°C.
If the set-point temperature isreached too early,
then a lower value should be set.
If the set-point temperature isreached too late,
then a higher value should be set.
Menu 7: Product number
This menu allows you to view the product
number.
To exit the configuration mode, press OK.
Feel good through warmth from electricity - www.technotherm.de
VPS / VPS-Design / SPH / VPN
Feel good through warmth from electricity - www.technotherm.de
GB
Feel good through warmth from electricity - www.technotherm.de Feel good through warmth from electricity - www.technotherm.de
Technotherm Smart Control Manual
10.0 Opera� ng instruc� ons
10.1 Modes
Auto
Manual
10.2 Adjust programmed temperatures
- Comfort ( ), used normally when the user is at home.
- Eco
- Freeze or minimum temperature ( ) used for periods of absence.
Programming the Temperature of: Comfort, Eco and Frost Protection
Start screen
1 x PROG OK
Start screen
Comfort Temp.
+ -
to select the
temperature
Start screen
to select the
temperature
selected
Comfort Temp.
OK and
+ -
selected Eco
Temp.
selected Frost-Protection
Temp.
OK and
+ -
OK
PROG
Mode
( ), used normally when the user is at home.
or minimum temperature ( ) used for periods of absence.
Feel good through warmth from electricity - www.technotherm.de Feel good through warmth from electricity - www.technotherm.de
18|
Technotherm Smart Control Manual
The radiator allows the crea� on of a weekly programmed schedule which assigns one of the 3 available
temperatures to each hour. The program for each day can be diff erent.
Use Comfort temperature for the hours that you are at home. (Represented by 2 bars on the LCD)
Use Eco-saving temperature for the night hours or short absence periods (Represented by 1 bar on the LCD)
Use Freeze-minimum temperature for long absence periods. (Represented by no bar on the LCD)
Example:
Start screen
3 sec. PROG 7 x PROG
The Day is ashing.
1 for Monday
2 for Thuesday
3 for Wednesday ....
+ -
to select the
day
Programming the Day and Time
7 x PROG
to select the
day
and conrm
with OK
The hour is ashing.
+ -
to select the
minutes
and conrm
with OK
The minutes are
ashing.
Saturday
13:45
VPS / VPS-Design / SPH / VPN
Feel good through warmth from electricity - www.technotherm.de
GB
Feel good through warmth from electricity - www.technotherm.de
Feel good through warmth from electricity - www.technotherm.de
18|
Technotherm Smart Control Manual
The radiator allows the crea� on of a weekly programmed schedule which assigns one of the 3 available
temperatures to each hour. The program for each day can be diff erent.
Use Comfort temperature for the hours that you are at home. (Represented by 2 bars on the LCD)
Use Eco-saving temperature for the night hours or short absence periods (Represented by 1 bar on the LCD)
Use Freeze-minimum temperature for long absence periods. (Represented by no bar on the LCD)
Example:
Start screen
3 sec. PROG 7 x PROG
The Day is ashing.
1 for Monday
2 for Thuesday
3 for Wednesday ....
+ -
to select the
day
Programming the Day and Time
7 x PROG
to select the
day
and conrm
with OK
The hour is ashing.
+ -
to select the
minutes
and conrm
with OK
The minutes are
ashing.
Saturday
13:45
Feel good through warmth from electricity - www.technotherm.de
VPS / VPS-Design / SPH / VPN
Feel good through warmth from electricity - www.technotherm.de
GB
Feel good through warmth from electricity - www.technotherm.de Feel good through warmth from electricity - www.technotherm.de |19
Technotherm Smart Control Manual
Start screen
3 sec. PROG
because Eco-Mode
from 0:00 till 6:00
Press MODE
for select
select +
for the
next
hour
The Eco-Mode is always
the default setting
Weekday programming.
To use weekday programming the comfort, eco and frost protection temperatures have to be programmed before. See chapter 10.2
e.g. Day 1:
Eco from 00.00 till 6:00.
Comfort from 6:00 till 21:00
Frost protection from 22:00 till 24:00
Comfort
Eco
Frost Protection
because Eco-Mode
the bar at 0:00
is ashing Day 1
Eco-Mode
Press MODE
for select
select +till 6:00
bar 6:00 is
ashing
the Comfort -
Mode
Comfort-
Mode
The Eco-Mode is always
the default setting
Press MODE
for select
the Comfort -
Mode
bar 7:00 is now
ashing
Comfort-
Mode
select +
for the next
hour
repeat till
21:00
Comfort-
Mode
select +
for the next
hour
The Eco-Mode is always
the default setting
Press 2x
MODE
for select
the Frost -
Mode
the Frost - Mode
is selected
select +
for the next
hour
and press
2 x MODE
for select the
Frost -Mode
select +
for the next
hour
and press
2 x MODE
for select the
Frost -Mode
Day 2
Frost-Modus
Repeat with Day 2 till day 7
By press PROG at any time you
will change to the next day!
Eco-Mode
VPS / VPS-Design / SPH / VPN
Feel good through warmth from electricity - www.technotherm.de
GB
Feel good through warmth from electricity - www.technotherm.de Feel good through warmth from electricity - www.technotherm.de |19
Technotherm Smart Control Manual
Start screen
3 sec. PROG
because Eco-Mode
from 0:00 till 6:00
Press MODE
for select
select +
for the
next
hour
The Eco-Mode is always
the default setting
Weekday programming.
To use weekday programming the comfort, eco and frost protection temperatures have to be programmed before. See chapter 10.2
e.g. Day 1:
Eco from 00.00 till 6:00.
Comfort from 6:00 till 21:00
Frost protection from 22:00 till 24:00
Comfort
Eco
Frost Protection
because Eco-Mode
the bar at 0:00
is ashing Day 1
Eco-Mode
Press MODE
for select
select +till 6:00
bar 6:00 is
ashing
the Comfort -
Mode
Comfort-
Mode
The Eco-Mode is always
the default setting
Press MODE
for select
the Comfort -
Mode
bar 7:00 is now
ashing
Comfort-
Mode
select +
for the next
hour
repeat till
21:00
Comfort-
Mode
select +
for the next
hour
The Eco-Mode is always
the default setting
Press 2x
MODE
for select
the Frost -
Mode
the Frost - Mode
is selected
select +
for the next
hour
and press
2 x MODE
for select the
Frost -Mode
select +
for the next
hour
and press
2 x MODE
for select the
Frost -Mode
Day 2
Frost-Modus
Repeat with Day 2 till day 7
By press PROG at any time you
will change to the next day!
Eco-Mode
Feel good through warmth from electricity - www.technotherm.de Feel good through warmth from electricity - www.technotherm.de
20|
Technotherm Smart Control Manual
Keypad locking
Advanced engineer se� ngs
lock / unlock the LCD screen
Start screen
press
+ and -
3 sec.
Programming the advanced mode:
e.g. shutt o all additional functions except changing the temperature
Start screen
1 x PROG 5 sec. PROG
Start screen.
C1 till C7
+ -
to select the
conguration
select C7 to shutt
o all additional
functions
OK and
+ -
select for FULL
Mode
select for MANUAL
Mode
or
Start screen.
to select the
conguration
select C7 to shutt
select for FULL
Mode
select for MANUAL
Feel good through warmth from electricity - www.technotherm.de
VPS / VPS-Design / SPH / VPN
Feel good through warmth from electricity - www.technotherm.de
GB
Feel good through warmth from electricity - www.technotherm.de Feel good through warmth from electricity - www.technotherm.de |21
Technotherm Smart Control Manual
Overview
The next confi gura� on op� ons will appear:
• C1: Temperature unit adjustment ºF/ ºC
•
C2: Hea� ng control type adjustment (PID –TRIAC radiators-, PID15min or PID30min- Re
lay radiators-, hysteresis 0.25ºC, 0.35ºC, 0.5ºC or 0.75ºC
• C3: Temperature measurement compensa� on
• C4: Firmware version
• C5:Open window detec� on ac� va� on (the hea� ng stops for 30 min if there is a fall of
2,4ºC or higher within 4 min), indicated with the symbol.
•
C6: Adaptable heat an� cipa� on. The radiator predicts the right moment to start hea� ng
in order to reach the desired temperature according to the programmed schedule, so the
user does not need to take into account the � me needed to heat the room. Maximum
an� cipa� on � me: 24h.
• C7:Select “Full” for Full mode (Auto/Man/OFF) or “Man” for Simple modes (Man/OFF)
Feel good through warmth from electricity - www.technotherm.de Feel good through warmth from electricity - www.technotherm.de
Technotherm Smart Control Manual
12 Specifi ca� ons
Heater
• 1 PCB for control
Comfort
Economic
• External temperature sensor
• Transformerless power stage
Smart Box
• LED status indicators
• Micro USB Adaptor included
13 Reset
At the heater:
At the smartbox:
20S .
Reset the device
Start screen
press
OK and PROG
10 sec.
VPS / VPS-Design / SPH / VPN
Feel good through warmth from electricity - www.technotherm.de
GB
Feel good through warmth from electricity - www.technotherm.de Feel good through warmth from electricity - www.technotherm.de |21
Technotherm Smart Control Manual
Overview
The next confi gura� on op� ons will appear:
• C1: Temperature unit adjustment ºF/ ºC
• C2: Hea� ng control type adjustment (PID –TRIAC radiators-, PID15min or PID30min- Re
lay radiators-, hysteresis 0.25ºC, 0.35ºC, 0.5ºC or 0.75ºC
• C3: Temperature measurement compensa� on
• C4: Firmware version
• C5:Open window detec� on ac� va� on (the hea� ng stops for 30 min if there is a fall of
2,4ºC or higher within 4 min), indicated with the symbol.
• C6: Adaptable heat an� cipa� on. The radiator predicts the right moment to start hea� ng
in order to reach the desired temperature according to the programmed schedule, so the
user does not need to take into account the � me needed to heat the room. Maximum
an� cipa� on � me: 24h.
• C7:Select “Full” for Full mode (Auto/Man/OFF) or “Man” for Simple modes (Man/OFF)
Feel good through warmth from electricity - www.technotherm.de Feel good through warmth from electricity - www.technotherm.de
Technotherm Smart Control Manual
12 Specifi ca� ons
Heater
• 1 PCB for control
Comfort
Economic
• External temperature sensor
• Transformerless power stage
Smart Box
• LED status indicators
• Micro USB Adaptor included
13 Reset
At the heater:
At the smartbox:
20S .
Reset the device
Start screen
press
OK and PROG
10 sec.
Feel good through warmth from electricity - www.technotherm.de
VPS / VPS-Design / SPH / VPN
Feel good through warmth from electricity - www.technotherm.de
GB
1
I. Human Machin Interface (ICT) specifications
1. User interface
a. Display
This display is designed to be viewed with 12-hour or 6-hour viewing angles. It’s dedicated with green
or blue backlight. Its visible surface is 44x29 mm.
1: Operating mode menu (active mode is framed)
2: Program number or parameters number if “3” is displayed
3: Installation parameter menu
4: Key lock function indicator
5: Room temperature indicator
6: Type of time (12H AM/PM or 24H)
7: Temperature unit
8: Heating demand
9: Display zone for time, temperatures and parameters
10: Graphic view for the current day program
11: Current day of the week or Eco design information (comfort mode)
12: Pictogram for pilot wire indication or for edit program mode
13: Overrid function in AUTO mode or ITCS function if blinking
14: Opened window detection
b. Keyboard
Keyboard is composed by 5 buttons:
VPS / VPS-Design / SPH / VPN
Feel good through warmth from electricity - www.technotherm.de
GB
2
: On/Off key
- : minus key
OK : validation key
+ : plus key
►: right navigation key
2. Power ON/first installation
a. Powering up
When the thermostat is powered up, or after product reset (see paragraph II.10), all pictograms of
LCD screen are displayed:
After the user can see a second screen with the version of current software the product:
The third screen corresponds to heater type: Fluid (left picture) or Dry (right picture):
Feel good through warmth from electricity - www.technotherm.de
VPS / VPS-Design / SPH / VPN
Feel good through warmth from electricity - www.technotherm.de
GB
3
This setting can be change as described in the praragraph II.12.
b. First installation
During the first installation of thermostat or when a product reset has been done, user has to set the
hour and the date (see paragraph II.4.g).
3. Menu for mode selection
To change the current mode of the thermostat, the user has to push the right navigation key to
display the working mode line.
User moves the frame cursor to choose a working mode. In order to select choosen mode, user presses
or or . If user doesn’t validate choosen mode, thermostat returns automatically to the older
selected mode.
a. Basic navigation
b. « Easy prog » navigation
In the parameter menu, user can simplify menu navigation. If this parameter is “no” (thermostat can’t
apply a program), menu for mode selection becomes:
VPS / VPS-Design / SPH / VPN
Feel good through warmth from electricity - www.technotherm.de
GB
4
4. Working mode definition
a. Comfort mode
In this mode, comfort temperature
set point will be followed all the
time.
From the screensaver (lighted
backlight), by pressing and
keys, the comfort setting
temperature starts to blink and
can be modified. By pressing
key, t
he set point value is
validated.
From the screensaver (lighted
backlight),
key permits to
switch displaying between
measured temperature and setting
temperature.
In this mode, Ec
o Design
information is
displayed by using
bargraph (see chapter “Eco Design
displaying” for more information).
By pressing
key, navigation
menu is displayed.
Default Value: 21 °C
Range:5.0°C to 30°C
Feel good through warmth from electricity - www.technotherm.de
VPS / VPS-Design / SPH / VPN
Feel good through warmth from electricity - www.technotherm.de
GB
5
b. Reduced mode
In this mode, the reduced setting
temperature qwill be followed all
the time.
From the screensaver (lighted
backlight), by pressing and
keys, the reduced setting
temperature starts to blink and can
be modified. By pressing key,
the set point value is validated.
From the scre
ensaver (lighted
backlight), key permits to switch
displaying between measured
temperature and setting
temperature.
By pressing key, navigation
menu is displayed.
Default Value: 19 °C
Range: 5.0°C to 19°C
c. Automatic mode
In this mode, the thermostat will
follow the chosen program (Built-in
P1 to P9 or customized U1 to U4)
according to the actual time and
the Comfort and Reduced setting
temperature.
From the screensaver (lighted
backlight), key permits to switch
displaying b
etween measured
temperature, setting temperature
and time.
From the screensaver (lighted
backlight), by pressing and
keys, The user can easily override,
until next program step, the current
program temperature by changing
the value. The value starts to blink
and can be modified.
By pressing
This manual suits for next models
49
Table of contents
Other LUCHT LHZ Heater manuals
LUCHT LHZ
LUCHT LHZ Technotherm TTB-E Duo+ Safety guide
LUCHT LHZ
LUCHT LHZ TechnoTherm CHM Series User manual
LUCHT LHZ
LUCHT LHZ TECHNOTHERM TTB-E Duo+ Series Safety guide
LUCHT LHZ
LUCHT LHZ Technotherm TTS 200 User manual
LUCHT LHZ
LUCHT LHZ VPN Series User manual
LUCHT LHZ
LUCHT LHZ TECHNOTHERM VPS User manual
LUCHT LHZ
LUCHT LHZ TECHNOTHERM DTH User manual
LUCHT LHZ
LUCHT LHZ TechnoTherm CHM 500 E User manual
LUCHT LHZ
LUCHT LHZ Technotherm International CPH 1000 User manual
Popular Heater manuals by other brands
Firesense
Firesense 60404 instruction manual
MrHeater
MrHeater Heatstar MH50KT Operating instructions and owner's manual
HydroQuip
HydroQuip Pure Heat Pressure Series installation instructions
MrHeater
MrHeater MH4GC Operating instructions and owner's manual
ENERCORP
ENERCORP MR. HEATER MH35FA parts list
MrHeater
MrHeater HEATSTAR MH35CLP Operating instructions and owner's manual
ENERCORP
ENERCORP MR. HEATER MH40NG Operating instructions and owner's manual
MrHeater
MrHeater MH50KR Operating instructions and owner's manual
Magic-Pak
Magic-Pak MGE4-12 Series Installation and maintenance instructions
MrHeater
MrHeater MH40 LP Installation and operation instructions
ENERCORP
ENERCORP Mr. Heater 1000ID Operating instructions and owner's manual
Classic Flame
Classic Flame INFRARED+HALOGEN 13QI071ARA manual
