Luci FLEX a F IP65 User manual

05/19/2017
LFXF10-1000-＊-CL/DF-O
Please do not do the followings to the product.
- Forcibly remove the product after mounting it.
- Cut this product.
- Disassemble, modify, or add holes to the product.
- Forcibly pull or twist the product.
- Cut or damage the power cable. Use a damaged cable.
- Press down on the product.
- Drop the product or subject the product to intense
vibration or shock.
- Bend more than the max angle(R50mm)
Do not cut this product.
F

DC24V
Power
supply
DC24V
Power
supply
DC24V
DC24V
Luci FLEX F
【LFXF10-1000-＊-CL/DF-O】
1011±2
In&Outdoors (No Condensation)
0℃〜＋35℃(No Condensation)
5m
Soft Acrylic
R50mm
End cap×2
Mounting rail, Mounting parts, Mounting clip, End cap, Sealing glue, Instant glue for mounting
Day light, Natural white, White, Warm white 3000K(L30), Warm white 2700K(L27), Warm white 2400K(L24), Warm white 1900K(L19)
○
Luci FLEX αF
10mm pitch
IP65
LFXF10-1000-＊-CL/DF-O
3.9W /m
192mA（max）
96 LED
40g
Model No.
Power consumption
Input current
Number of LEDs
Weight
Environment
Operating temperature
Max. sets connectable
Material (Body)
Min. allowable bend range
Accessories
Option parts
Light source color (＊)
Dimmable
Item / Product Name
LED pitch ※Amount of the connecting device depends on the power output(W).
※Luci FLEXαFcan be connected up to 5pcs. The max distance between the power to the last device is 20m.
※Divide into multiple lines when the amount exceeds more than the max connectable units.
±2

24V dedicated
power supply
Luci FLEX F
