Lumatek CONTROL PANEL PLUS 2.0 User manual

DUAL SIGNAL LIGHTING CONTROLLER FOR HID & LED
CONTROL
PANEL PLUS
MANUAL

1. Introduction
2.1 Product description
2. Product specifications
2.2 General product information
2.3 Environment
2.4 Technical specifications
3. Components
4. Safety guidelines
5. Installing the controller and functions
5.1 Preparations
5.2 Setting up the controller
5.2.1 Function keys
5.2.2 System settings
5.2.3 Setting signal protocol
5.2.4 Zone parameter settings
5.2.5 Setting pre-set Switch ON/OFF and light intensity times
5.2.6 Real time On/Off switching and adjusting light intensity
6. Controller LED indicator
7. LED failure indicator on electronic ballast
8. Lumatek controller troubleshooting
9. Maintenance and Repair
10. Environment and Disposal
11. Regulatory standards
12. Warranty
TABLE OF CONTENTS
LUMATEK CONTROL PANEL
PLUS 2.0 USER MANUAL
ENGLISH

1. INTRODUCTION
2. PRODUCT DESCRIPTION
2.1 Product description
2.2 General Product Information
2.3 Environment
Warning! The product may not be exposed to moisture, condensing humidity,
contamination or dust.
Operating Storage
TEMPERATURE RANGE (AMBIENT)
OPERATING HUMIDITY (25ºC)
WATERPROOF & DUSTPROOF
DIELECTRIC WITHSTAND VOLTAGE(HI-POT)
-20ºC - +40ºC
-20ºC - 90ºC
non-condensing
Communication line to
GND:500Vac/60S 5.5mA max
10ºC - 95ºC
non-condensing
-40ºC - +70ºC
IP20
PRODUCT NAME
PRODUCT CODE
PRODUCER
Lumatek Control Panel Plus 2.0
LUMM0019
EAN 5060560031079
Lumatek Ltd
The Lumatek Digital Control Panel Plus is a dual signal twin channel digital
lighting controller with each of the two channels (Zones) capable of con-
trolling up to 200 Lumatek controllable HID fixtures or ballasts with a digital
RS485 signal or up to 50 LED fixtures with analog 0-10V signal. It is possible to
use each Zone to control fixtures in two independent separate rooms or to
control up to 400 fixtures in one room with two different light source types.
The Lumatek control panel is a digital lighting controller that offers precise
external control of your Lumatek lighting fixtures and ballasts. Using innovative
technology, this controller smartly monitors your grow room temperatures, light
timing & intensity automation, safety-controlled dimming and switching
On/Off. Simply connect it to your Lumatek Controllable Fixtures or Ballasts and
easily regulate your grow room environment.
Thank you for purchasing the Lumatek Control Panel, we are sure you will be
satisfied for years to come. Please read and understand this manual before
installing and using the control panel as it contains all the information neces-
sary to successfully install, use and maintain the product.Digital Control Panel
will be referred to as “the controller”.

2.4 Technical Specifications
CONTROLLER DIMENSIONS (LxWxH)
MAX NUMBER OF
BALLASTS PER ZONE
TOTAL NUMBER OF
BALLAST PER CONTROLLER
HID POWER DIMMING SCOPE
(1% INCREMENTS)
WEIGHT
POWER SUPPLY
CONTROLLABLE BALLAST TYPE
LED POWER DIMMING SCOPE
TEMPERATURE-CONTROLLED
INSPECTIONSCOPE ADJUSTABLE RANGE
SUNRISE & SUNSET DURATION
TURN ON DELAY PROTECTION TIME
TEMPERATURE-CONTROLLED INSPECTION
SCOPE PROTECTION RANGE
128 x 80 x 25 mm
280g
250W: 60%-110% (150W-275W) | 315W: 50%-100% (158W-315W)
400W: 60%-110% (250W-440W) | 600W: 40%-110% (250W-660W)
630W: 80%-100% (500W-630W) | 945W: 50%-100% (475W-945W)
1000W: 60% - 115% (600W-1150W)
400 (RS485)
250W, 315W, 400W, 600W, 630W, 1000W
CONTROLLABLE LED DRIVER TYPE All Lumatek controllable LED drivers
200 (RS485)
100 (0-10V)
50 (0-10V)
Adaptor 100 - 240V AC 50/60Hz – DC 5V/2A
10% - 100%
POWER REGULATION ACCURACY 1%
0ºC - 40ºC
10ºC - 50ºC
0 - 30min
0, 5, 10, 15, 20, 25, 30mins
3. COMPONENTS
Control Panel Plus
Power Supply
Cable/Plug
HID Control Link Cable
Temperature
Sensor Cable 5m
2 Channel Dual
Signal Light Controller
100-240V 50/60Hz
AC - 5V/2A DC
To Connect Controller
to Ballast, with Magnetic
Ring on Cable
Ambient Temperature
Sensor fo each Zone
1
1
2
2
LED Control Link Cable 2
NAME Qty PHOTO NOTE
Mounting Screws to Mount
Controller on Wall
2
To Connect Controller
to LED fixture

Note! Each of the controller’s two channels (Zone A & Zone B) can control up to
200 Lumatek Control fixtures or ballasts. It is possible to use those channels to
control fixtures in two separate rooms or to control up to 400 fixtures in one room.
4. SAFETY GUIDELINES
5. INSTALLING THE CONTROLLER & FUNCTIONS
5.1 Preparations
For HID:
Warning! Keep the controller away from fire, excessive heat, water, dust and
contamination.
Warning! The Lumatek Digital Control Panel may only be used to control
compatible Lumatek controllable fixtures and ballasts. Do not connect the
controller to other products as this may be dangerous and may cause
malfunctions in the connected equipment. Doing so will void the warranty.
Warning! Do not open or disassemble the controller, it contains no serviceable
parts. Opening the controller will void the warranty.
Warning! Make sure the signal cables do not touch the reflectors as the
reflectors get very hot!
1. Mount the fixtures or ballasts as per your lighting plan.
Interconnect them as described in the manual for the fixture or ballast
using the control cable (TRS) supplied with each controllable fixture or ballast.
Connect ballast 1 control cable from Out socket of ballast 1
to the In socket of ballast 2.
Connect ballast 2 control cable from Out socket of ballast 2
to In socket of ballast 3.
4.
3.
2.
Connect all remaining ballasts in series accordingly.
5. Connect the ballasts or fixtures to the mains.

For LED:
1. Mount the fixtures as per your lighting plan. Interconnect them as
described in the manual for the fixture, using the LED control cable
supplied with the controller and a control link cable purchased separately
for each additional fixture to be daisy-chain connected in series.
Warning! Each Channel (Zone) can only control same-powered LED fixtures/drivers;
Zone A can control the same-powered LED fixtures as Zone B or Zone B B can be set
to control different powered LED fixtures eg: Zone A can be set to control 600W LED
fixtures and Zone B set to control 465W or 1000W LED fixtures.
Note! Each of the controller’s two channels (Zone A & Zone B) can control up
to 50 LED fixtures. It is possible to use those channels to control LED fixtures in two
separate rooms or to control up to 100 fixtures in one room.
Using LED control link cable, connect LED fixture 1 ‘Signal Out’ port
(LED fixture ‘Frame B’) to the ‘Signal In’ port of LED fixture 2.
Connect LED fixture 2 ‘Signal Out’ port to
the ‘Signal In’ port on LED fixture 3.
4.
3.
2.
Daisy-chain connect all remaining LED fixtures in series accordingly.
CONNECT CONTROLLER
CABLE TO SIGNAL IN
5. Connect the LED fixtures to the mains.

Find a suitable place for the temperature sensor and the controller. Hang the
sensor between the plants at average canopy height and preferably not
against the wall. Do not position in direct airflow or light. If you are using another
climate control system, hang temp sensor close to the sensor of that system.
Position and affix controller to the wall using mounting screws (E) through the
mounting loops.
Connect the power input (B) and the temperature probes (E). The display will
light up and you can continue to set up the controller.
Connect controller cable (C/D) from Zone A/B output port (3) to ‘Signal In’
port on LED fixture 1 or ballast 1 IN port.
Warning! The controller may only be connected to compatible Lumatek controllable
LED fixtures and ballasts.
6.
7.
8.
9.
ZONE B LIGHT
SIGNAL OUTPUT
ZONE A LIGHT
SIGNAL OUTPUT
ZONE B THERMO
SENSOR OUTPUT
ZONE A THERMO
SENSOR OUTPUT
POWER ADAPTOR
SOCKET
Note! Whilst keying in settings if no operation is performed within 10 seconds
the display will revert to Home screen.
5.2 Setting up the controller
1. Function keys
RIGHT SHIFT
INCREASE OR
DECREASE
PARAMETERS
OK AND SAVE
SET BUTTON
TOGGLE 0-10V LED
& RS485 HID CONTROL
PAGE UP OR
PAGE DOWN

1. When setting controller for LED drivers/fixtures;
Using a pointed tool (ball point pen) press [SET] button to select 0-10V analogue
signal protocol (0-10V LED indictor light on only). This will make both zones com-
patible for LED drivers.’
2. When setting controller for HID ballast/fixtures;
Press [SET] button to select RS485 digital signal protocol (LED indicator light on).
This will make both Zones compatible for HID electronic ballasts.
3. When setting controller for LED drivers/fixtures and HID ballast/fixtures;
Press [SET] button to select both 0-10V & RS485 signal protocols ( both LED indica-
tor lights on). This will make Zone A compatible for LED drivers and Zone B com-
patible for HID electronic ballasts.
‘To set temperature scale and power output unit of measurement:
Press [OK] and then [>] to ‘System Settings’ and [OK] to enter
Press [<]or[>] to ‘Temp’ and [^]or[v] to toggle between ‘C’ (Celsius) or ‘F’ (Faren-
heit). Press [OK] to save.
Press [<]or[>] to ‘Power’; the display will show either % (percent) when LED is select-
ed in ‘Type’ in Zone A/B page and W (Watts) when HID is selected.
Note! LED driver power output is shown as a percentage of the driver ‘s nominal
power output eg. 50% of a 1000W LED driver is 500W.
To set Time and Date to your local time;
Press [OK] and then [>] to System Settings and [OK] to enter
In System Settings press [<]or[>] to Hour and [^]or[v] to toggle between 24hour and
am/pm clock. Press [OK] to save.
Press [<]or[>] to Time and [^]or[v] to set time in hours and minutes and [OK] to save.
Press [<]or[>] to Date and [^]or[v] to set date in Day [D], Month [M] and Year [Y]
and [OK] to save.’
Press [OK] to enter Home screen
Press [<]or[>] to ZONE A and [OK] to enter
Setting ballast/driver/fixture type:
Press [<]or[>] to Type and [^]or[v] to select ballast/driver type and Press [OK] to save.
Setting light intensity by selecting power output level:
Warning! New HID lamps need to run at nominal power for at least 100 hours to ensure they
don’t fail prematurely. If using new lamp; set Power to 100%. After 100 hours nominal power
use, new HPS lamps may be dimmed and boosted and MH/CMH lamps may be dimmed.
Warning! Do not boost MH/CMH lamps which must not exceed their nominal power.
2. System Settings
3. Setting Signal Protocol
4. Setting Zone Parameters

In ZONE A Press [<]or[>] to Power and [^]or[v] to select required power output and
Press [OK] to save.
Setting simulated sun rise and set period:
To allow crops to adjust to either a lights-On period or lights-Off period, a sunrise
and sunset period may be set. During this period, the light intensity increases from
the lowest dimming level of the fixture up to the desired intensity and the opposite
at the lights-Off. The R/S (Rise/Set) period may be set up to 30 minutes.
In ZONE A Press [<]or[>] to R/S and [^]or[v] to select required time period in minutes
and Press [OK] to save.
Setting Auto-dim and safety shutdown temperature parameters:
Auto-dim and shutdown; if the ambient temperature rises above the set threshold,
the lamps will firstly be dimmed to minimum dim setting and if the temperature
continues to rise and exceeds the second set threshold the lamps will shut down to
prevent crop damage.
In ZONE A Press [<]or[>] to Dim and [^]or[v] to select required temperature to
engage auto-dim and Press [OK] to save.
In ZONE A Press [<]or[>] to Stop and [^]or[v] to select required temperature to
engage auto-shutdown and Press [OK] to save.
Setting Delay time before lamp restart after auto-shutdown
If auto-shutdown has been engaged, the time period after temperature has fallen
below set threshold and lamps are restarted can be set in 5 minute increments from
0 – 30 minutes.
In ZONE A Press [<]or[>] to Delay and [^]or[v] to select required time period in min-
utes and Press [OK] to save.’
Setting pre-set Switch On/Off and light intensity times
The controller has the capacity for up to six different set switching/dimming times
per 24 hour period.
Press [OK] to enter Home screen
Press [<]or[>] to ZONE A and [OK] to enter
In ZONE A Press [<]or[>] to NEXT and [OK] to enter
ZONE A time setting
In ZONE A time setting Press [<]or[>] to first time setting check box and [^]or[v] to
toggle between to activate time setting and to deactivate time setting.
5. Setting pre-set Switch On/Off and light intensity times

Press [OK] to enter Home screen
Press [<]or[>] to ZONE A and [OK] to enter
In ZONE A Press [<]or[>] to Power and [^]or[v] to select required power output (light
intensity) and Press [OK] to action and save.
Selecting 0% will switch lamps Off.
Repeat to set up Zone B.
Note! If controller is disconnected from power supply; any set parameter values
and Time/Date will be saved.
Press [<]or[>] to Hour and Minute settings and [^]or[v] to set time in hours and
minutes and [OK] to save.
Press [>] to Power setting and [^]or[v] to set power output and [OK] to save.
To pre-set switch Off; set Power to 0%.
2
6. CONTROLLER LED INDICATOR
LED ON: Normal status (temperature probe is working normally)
LED OFF: Temperature probe cable not connected correctly or temperature control fail.
LED SLOW FLASH: High temperature auto-dim threshold; ballast will now dim to reduce temperature.
LED FAST FLASH: High temperature auto-shutdown; ballast will switch off.
LED ON: Lamp is on
LED OFF: Lamp is off
The same reading as 1 The same reading as 2
0-10V LED ON only:
0-10V analog signal
to both Zones for LED drivers
RS485 LED ON only:
RS485 digital signal to both
Zones for HID
Both 0-10V & RS485 LED ON:
Zone A is 0-10V for LED drivers and
Zone B is RS585 for HID ballasts.
1
3 4
5 6
6. Real time On/Off switching and adjusting light intensity
7. LED FAILURE INDICATOR ON ELECTRONIC BALLAST
Note! If controller not connected; the power output LED will go On normally and in
the event of any failure; the LED above highest power output setting will flash. See
table below to decode fault.
If controller connected; the ‘controller ‘ LED on electronic ballast will turn Onand
flash every 2 seconds; this means that the controller is working normally.If the
ballast fails to receive signal from the controller (either because of poor signal
cable connection or controller failure) the ‘controller’ LED on ballast will flash
quickly (every 0.2 seconds). In the event of any other failure; the LED above
highest power output setting on ballast will flash. See table below to decode fault.

CONDITION LED STATUS DESCRIPTION
Ballast Locked
Cycle Error
Low Mains
High Mains
Over Temperature
Flash*1
Flash*2
Flash*3
Flash*5
Flash*4
Maximum amount of ignition
attempts without success
Lamp stopped for unknown reason
or output signal interrupted.
Mains Voltage too Low
Mains Voltage too High
Maximum driver temperature exceeded
FAULT INSPECTION METHOD TROUBLESHOOTING
Controller doesn’t have
any display after
connecting to power
Check the Power Supply
Check the Adaptor
Check the Controller
Waiting for power supply to return
Change the Adaptor
Change the Controller
Ballast output power is
not same as command
signal sent from controller
Check the Sun rise and
set time periods
Reset or switch off sun rise
/set time period.
Reset temperature
control values.
When several ballasts
are working together,
some units are working
well but some fail to work
Check control cable
connections
Check if the ballast
is faulty
Disconnect and reconnect
control cable or replace cable.
Check LED failure
indicator on ballast.
Fail to control ballasts
Check the connection between
controller and ballasts;
make sure each connection
is well-plugged.
Reconnect the control cables
Controller doesn’t have
any temperature display
after the temperature
probe is connected
Check ‘controller’ LED
on ballast is flashing normally
Change to another
temperature probe
Fail to turn on lamp
Check if the temperature
probe is damaged.
Reconnect Cables
8. LUMATEK CONTROLLER TROUBLESHOOTING
Check the temperature
probe & temperature
control values set.
Note! To reset ballast; disconnect from mains and reconnect after 30 seconds
Warning! When replacing a lamp, always switch Off ballast first by removing
plug from power supply. Never switch off lamp by removing lamp cable from
a live ballast.

The symbol on the material, accessories or packaging indicates that this prod-
uct may not be discarded as household waste. Dispose of the equipment
through a recycling centre that handles electronics and electrical appliances
within the EU and in other European countries which use separate collection
systems for used electronics and electrical appliances. By disposing of the
equipment in the proper way, you will be helping to prevent possible risks to the
environment and public health which might otherwise be caused by improper
handling of the discarded equipment. Recycling of materials contributes to the
conservation of natural resources. Please do not dispose of your old electronics
and electrical appliances via household waste.
Lumatek Ltd warrants the mechanical and electronic components of their prod-
uct to be free of defects in material and workmanship if used under normal
operating conditions for a period of three (3) years from the original date of
purchase. If the product shows any defects within this period and that defect is
not due to user error or improper use Lumatek Ltd shall, at its discretion, either
replace or repair the product using suitable new or reconditioned products or
parts. In case Lumatek Ltd decides to replace the entire product, this limited
warranty shall apply to the replacement product for the remaining initial warran-
ty period, i.e. three (3) years from the date of purchase of the original product.
For service; return the product to your shop with the original sales receipt.
9. MAINTENANCE AND REPAIR
ATTENTION: THIS PRODUCT CONTAINS A BATTERY.
MUST BE DISPOSED OF PROPERLY.
10. ENVIRONMENT AND DISPOSAL
EN 61347-1:2008
EN 61347-2-12:2005
EN 55015
11. REGULATORY STANDARTS
12. WARRANTY
Warning! Do not open or disassemble the controller as it contains no serviceable
parts. Opening the controller will void its warranty.
Warning! Do not use acids, solvents, abrasives or other aggressive substances to
clean the controller as this may cause damage.
The controller is maintenance free. It may be cleaned with a soft dry
cloth.Please contact your reseller in case of controller malfunction.

PAGE UP OR
PAGE DOWN
POWER ADAPTOR
INPUT
ZONE B THERMO
SENSOR INPUT
ZONE A THERMO
SENSOR INPUT
ZONE B LIGHT
SIGNAL OUTPUT
ZONE A LIGHT
SIGNAL OUTPUT
INCREASE OR
DECREASE
PARAMETERS
RIGHT SHIFT
OK AND SAVE
SET SIGNAL PROTOCOL
PAGE UP OR
PAGE DOWN
POWER ADAPTOR
INPUT
ZONE B THERMO
SENSOR INPUT
ZONE A THERMO
SENSOR INPUT
ZONE B LIGHT
SIGNAL OUTPUT
ZONE A LIGHT
SIGNAL OUTPUT
INCREASE OR
DECREASE
PARAMETERS
RIGHT SHIFT
OK AND SAVE
SET SIGNAL PROTOCOL
