lumishore SMX21 Installation guide

Surface Mount e-lites
Single Colour Lights
Installation and Operating guide

Surface Mount e-lites Page 2
Congratulations! You have purchased a LUMISHOREadvanced LED technology underwater lighting system. Every care has been taken toensure your Surface Mount e-lite
system arrives in perfect condition, so please enjoy the ultimate experience in underwater lighting.
Please read the following pages to ensure a complete understanding of the LUMISHORE LED lighting system before installation.
Adding underwater lighting to your vessel has never been easier. To mount a LUMISHORE Surface Mount e-lite underwater LED light, one small cable hole and three
mounting screws is all it takes. Compact, with a very slim profile and available ina wide variety of colours and powerlevels, the Surface Mount e-lite operates above or
below the water line, at your berth, on dock or underway, thanks to the LUMISHORE Active Thermal Rollback (ATRB) feature.
FEATURES
• Suitable for transom, hull-side, engine room, internal, and external mounting
• Corrosion-proof advanced aluminium, polymer coated over-molded body (bottom paint and bonding is not needed)
• Over voltage/current and reverse polarity protection
• LUMISHORE Active Thermal Rollback (ATRB) manages the light output depending onambient temperatures
• 90°wide, even beam for superior underwatereffects
• Best overall life: 50,000+ hours, approximately 20 years with normal use
PACKING LIST
Your box should contain the following items: One Surface Mount e-lite, three stainless steel Number 8 screws , and one Installation a nd Operating Guide.
If any items are missing, e-mail or call LUMISHORE using the contact information listed in Section 5 (Product Support) of this guide.
ACCESSORIES
RM-12 (12 Volt systems only)
Wireless remote light controller (two remotes and one wireless receiver/relay).
DLX-KIT
Docklight adapter kit. Allows SMX21 and SMX51 mounted on transom without drilling cable hole or
usedas a dock light
DLX-ARM
Used with the DLX-KIT when installed as DockLight. Allows the light fixture to be lifted out of water for
cleaning
TABLE OF CONTENTS
Number
Section
Page
1.0
BEFORE YOU START
2
2.0
PHYSICAL INSTALLATION
3
2.1
Materials
3
2.2
Mounting
3
3.0
ELECTRICAL INSTALLATION
3
3.1
Selecting gauge cable (Conductor Size Tables)
3
3.2
Light connections
4
3.3
Optional RM-12 wireless remote light controller
4
3.4
Connection example
4
4.0
MAINTENANCE
5
5.0
PRODUCT SUPPORT
5
6.0
SPECIFICATIONS
5
7.0
WARRANTY
5
1.0 BEFORE YOU START
The light can be installed above or below the water line.
For best underwater illumination, LUMISHORE recommends installation 4” to 12” (10 0-300mm) below the water line.
Choose a location:
oThe light must be mounted on a flat (not curved) surface. For underwater installs mount on transom or side hull only.
oA hole will be drilled toallow the cable to be inserted; care must be taken to ensure there is unrestricted access (including inside the hull for underwater
installation).
oWhen installing three or more lights, equal spacing 2.5’- 3’ is recommended to give a consistent light pool.
oThe light is temperature sensitive and must not be located close to the exhaust outlet or other heat source.
oThe e-lite series operates on both 12V and 24V DC systems; never connect a light directly to the mains AC voltage.
oEach light should be individually fused and the serial number recorded. Please use the tables below.
Recommended Fuse Size
Light Serial Number
Voltage
SMX21
SMX51
SMX101
12VDC /24VDC
2Amp / 1Amp
3Amp /1.5Amp
6Amp / 3Amp

Surface Mount e-lites Page 3
2.0 INSTALLATION
2.1 Materials:
Drill and bits for cable and pilot hole screws:
Cable
PILOT
3M 4200 sealant (or equivalent)
Philips type screwdriver
On/Off switch (breaker panel)
Waterproof connectors or soldering iron and heat shrink tubing
Rag(s) for cleanup
7/16 (10.5mm)
9/64 (3.5mm)
2.2 Mounting:
1. Select a suitable flat surface that is accessible from behind and ensure the cable can be run without a problem.
IMPORTANT: The ‘LUMISHORE’ logo on the light must be positioned at the top when securing to the hull.
2. Drill the pilot and the power cable holes using the drill bits mentioned in Section 2.1.
3. Applya single bead of sealant around the cable entry and screw holes.
4. Apply a continuous thick bead of sealant approximately 0.4” (10mm) from the edge of the light and around the cable. Refer to image below.
5. Push the power cable through the hole and align the light with the pilot hole screws.
6. Attach the light using the 3 stainless steel screws by hand tightening with a screwdriver.
IMPORTANT: Do Not Over Tighten
7. Use a damp cloth to wipe off excess sealant that was squeezed out around the light.
IMPORTANT: For underwater installation: Refer to the directions on the sealant to make sure it has fully cured before launching the boat in to the water.
3.1 Selecting cable gauge
Proper wire cable size must be considered wheninstalling the lights.
Use the tables below to compute the gauge of the cable needed, noting current draw of each light at 12VDC or 24VDC.
Keep in mind cable lengths referenced in the Conductor Size tables are from the source to the lights and back to the source (twice the actual distance).
Two calculations:
1. Calculate the total current draw of all lights connected to the terminal strip. Then use the table to calculate the cable size needed from the source to the junction box.
2. If the cable supplied on the light is not long enough. Use the calculation table to compute the gauge of the cable needed for each light.
Figure 1: SEALANT AREAS
Figure 2: LIGHT MOUNTING
3.0 ELECTRICAL

Surface Mount e-lites Page 4
3.2 Light Connections
Each light is supplied with 6.5 Feet of 18-gauge cable and should be connected to a terminal strip.
The light cable maybe connected toa larger gauge cable, however care must be taken when making the connections to protect from corrosion.
When connecting the light cable larger gauge cable, LUMISHORE recommends soldering and heat shrinking the wires together or usinga terminal strip with
proper size connectors.
A Single Pole Single Throw (SPST) switch (not supplied) may be installed so the lights may be turned ON or OFF at a convienent location. Refer to Section3.4 for
recommended switch wiring.
3.3 Optional RM-12 wireless remote light controller
When installed, the RM-12 allows the lights to be turned ON or OFF with the click ofa button on the remote. This accessory contains 2 wireless remotes and a 12VDC only
(cannot be used on 24Vsystems) wireless receiver relay box which is sealed; do notattempt to open. The replacement battery type for the wireless remote is
VR22/CN22/CN32A orequivalent. For installation refer to section 3.4.
3.4 Connection example

Surface Mount e-lites Page 5
4.0 MAINTENANCE
LUMISHORE lenses require infrequent or no cleaning if the light is used regularly. In the event that your lens requires clea ning, we recommend the use ofa soft cloth or
soft bristled brush only or the lens and light fixture body may become scratched. To help cleaning, turn on the lights for 15 minutes before cleaning will help to remove
growth especially if the light color is blue.
5.0 PRODUCT SUPPORT
To access LUMISHORE Frequently Asked Questions visit http://www.lumishore.com/general-information/faqs
If you have questions or comments, please e-mail [e-mail] or call USA [phone], United Kingdom [phone], or France [phone].
6.0 SPECIFICATIONS
Feature / Specification
SINGLECOLOR
SMX21
SMX51
SMX101
Fixture Lumens
1,300
2,200
3,600
Available Colors
White, Green or Blue
BeamAngle
90°
LED Power-HICOB Array
Yes
Typical LEDLife
50,000+ hours
DC Voltage
12 and 24VDC
Max Current Draw 12/24VDC
1.2A/0.6A
1.7A/0.85A
3A/1.5A
Bonding / Painting Required
No
Low Voltage & Temperaturewarning
No
Yes
Voltage and Thermal Protection
Yes
‘Soft-Start’ Protection
Yes
Reverse Polarity Protection
Yes
Light Face Diameter
3.5"
(8.9cm)
3.5"
(8.9cm)
4.3"
(10.8cm)
Profile (height) of housing
0.5"
(12.7mm)
0.5"
(12.7mm)
0.7"
(16mm)
Hole Cut out forcable
1/4" (6mm)
Light cable length
6.5" (2m)
Driver
Internal Driver
Specifications are subject to change without notice.
LUMISHORE Ltd warrants the e-lites to be free from defects in workmanship and
materials for a period of two years, starting from the date of original purchase.
Should your e-lite be defective during this period, please contact your dealeras
soon as you become aware of the defect.
Misuse,abuse, improper installation, neglect, improper shipping, damage caused
by disasters such as fire, flood, and lightning, installation by unqualified personnel,
unauthorized repair or modification will void this warranty. For the avoidance of
confusion and doubt, non-compliance with all installation, maintenance and
operating instructions in this document constitute non-conformance with warranty
terms. Full warranty details are available at www.lumishore.com
7.0 WARRANTY INFORMATION

Surface Mount e-lites Page 6
Thank you
for purchasing e-lite Series lights!
LUMISHORE USA
7137 24th Court East
Sarasota, FL 34243
www.lumishore.com
[e-mail]
LUMISHORE UK
Unit 11, Technium 1
King's Road
Swansea SA1 8PH
United Kingdom
