Luxor AVJ-OH User manual

Instruction Sheet - OVERHEAD PROJECTOR TABLES
Model AVJ-OH
Customer Service Dept
2245 Delany Rd
Waukegan, IL 60087
Ph: 847/244-1800 • 800/323-4656
Fax: [phone] • 800/327-1698
1- Top Stand Assembly
1- Bottom Stand Assembly
4- Large Bolts
4- Wing Nuts
2- Casters With Brake
2- Casters Without Brake
1- Power Cord
1- ”U” Bracket
1- Cord Wrap
2- Small Screws
2- Small Nuts
Tools Required:
Screwdriver
PARTS LIST
AVJ-OH
AB
1.Turn bottom stand assembly upside down on a smooth surface. Push the four casters firmly
into the caster socket holes in bottom of each leg as illustrated. IMPORTANT: Casters must
be fullyseated.T
urn the bottom stand assemblyright side up.
2. Position top stand assembly over bottom stand assembly as illustrated. Adjust top stand
assemblyup or down to desired height.Align holes in all four legs, insert bolts and fasten with
four wing nuts as illustrated.
Casters with
brake in front
Bottom
Stand
Assembly
Bolt
Wing Nut
Cabling
Hole
Top
Stand
Assembly
Note: Overhead pan is set flush with top
shelf for
shipping. See B-2 for setting instruc-
tions
1. Measure the height of your overhead projector -
then choose the height of shelf and assemble
2. Adjust braces together with 8 x 3⁄8˝ bolts
and nuts as shown to desired height to
all three supportbraces.
Note:When bottom holes on Brace 1
arematched with holes on Brace 2, it
gives you depth as shown.
3. Reattach platform to bottom holes
of support braces with 8 x 1⁄2˝
bolts.
4. See reverse side for assembly of electric assembly.
10˝
9˝
8˝
7˝
6˝
Inside Brace
Brace 1
Brace 2
Outside

ELECTRIC ASSEMBLY
C
Cord
Gromme
t
Cord Wrap
Bracket
“U”
“U”
Stove
Bolts
Gromme
t Hole
Kep Nuts
Press 3-outlet power cord into ”U” bracket and feed remaining cord through grommet hole and wrap remaining
cord around cord wrap bracket. For safety and neat appearance, secure plug to cord with plug snap.
