LYNXTechnik Yellobrik OTR 1410 User manual

Technical Specications
WARNING: Module laser is active
as soon as power is connected,
regardless of LED indication
OTR 1410
12G SDI Fiber Optic Transceiver
WARNING
LASER RADIATION
Do not view directly with
optical instruments
CLASS 1M LASER PRODUCT
SDI Video
Output
SDI Video
Input
DC Power
Input
LC/PC Fiber
Output
SDI Video 1 x SDI video input on 75 Ohm BNC connector
1 x SDI output on 75 Ohm BNC connector
SMPTE 2082-1, SMPTE 2081-1, SMPTE 424M, SMPTE 292M, SMPTE 259M
Multi-standard operation from 270Mbit/s to 12Gbit/s
Automatic cable EQ
260m @ 1.5Gbit/s, 150m @ 3Gbit/s (Belden 1694A cable)
80m @ 12Gbit/s, 6Gbit/s (Belden 4794R cable)
Fiber Optic 1 x fiber optic input, 1 x fiber optic output
SMF (singlemode) using LC/PC connection
SMPTE 2082-1, SMPTE 2081-1, SMPTE 424M, SMPTE 292M, SMPTE 259M
Transmitter: 1310nm, typical Optical power -3dBm
Receiver: 1260nm - 1620nm (-2dBm to -10dBm)
Max. distance 10km (6.2 miles) @ 3Gbit/s (Singlemode)
TX data active and RX data present LEDs on side of module
Power +12V DC @ 2W nominal (power supply included)
(supports 7 - 24V DC input range)
Power LED on side of module
We are constantly adding more yellobrik modules.
Please visit our website for the latest product updates.
www.lynx-technik.com
Power
RX Data
Present
TX Data
Active
12V 0V
⎓
Power
WARNING
CLASS 1
Laser Product
TX
RX
Fiber Optic / SDI
Transceiver
LYNXTechnik AG
IN OUT
12G
6G/3G/1.5G
yellobrik
®
Quick
Reference
yellobrik
®
LYNX
Technik
AG |
www.lynx-technik.com

Connections
The SDI video input and output are connected to the 75 Ohm BNC
connections (up to 12G). The ber connection is LC/PC Duplex SMF
(singlemode).
Use the included dust plug to protect the optical connection from dust.
Operation
The OTR 1410 combines an independent ber optic transmitter and
receiver in a single package. Dierent SDI video formats and standards
(12G, 6G, 3G, 1.5G and 270M) can be transmitted and received.
For transmission, the SDI video format is automatically detected, reclo-
cked and then transmitted over the ber optic TX connection. For recep-
tion, the optical SDI video input signal on the RX connection is automati-
cally detected, reclocked and provided on the SDI output connection.
Maximum distance supported is 10km (6.2 miles). Data transmission and
reception activity is indicated by the TX and RX LEDs on the side of the
module.
Note: If TX LED is OFF, then this indicates that there is no SDI present or not a valid
input. If RX LED is OFF, then this indicates that no optical input signal is connected
or the optical input power is too low.
Power
The module requires a 12V DC power input and the LED conrms when
power is connected. A power supply is included, however if you use
your own power supply, please provide a clean power source between
7 and 24V DC.
The OTR 1410 has a power consumption of approximately 2W nominal.
Power Lead Strain Relief
The module has a small hole in the case which is located above the
power connection. This prevents the power lead being accidentally
pulled out. Use the supplied tie-wrap and secure the lead as shown
below.
Optional Mounting Solutions
The optional RFR 1001 mounting bracket can be used to permanently
mount the module on any surface or on 19” rack rails.
The optional RFR 1000-1 rack mount can be used to permanently
mount up to 14 yellobrik modules. In addition, the RFR 1000-1 can
provide full power redundancy for all mounted yellobriks.
