LYNXTechnik Yellobrik OTR 1410 User manual

Technical Specications OTR 1410
12G, 6G, 3G, 1.5G SDI Fiber Optic Transceiver
IN
+12V 0V
TX
RX
LYNXTechnik AG
Fiber Optic / SDI
Transceiver
WARNING
CLASS 1
Laser Product
OUT
12G
6G/3G/1.5G
WARNING
LASER RADIATION
Do not view directly with
optical instruments
CLASS 1M LASER PRODUCT
SDI Video
Output
SDI Video
Input
DC Power
Input
LC/PC Fiber
Output
Power
Connected
Receiving
Data
SDI Video 1 x SDI video input, 1 x SDI output
75 Ohm BNC connectors
SMPTE 2082-1, SMPTE 2081-1, SMPTE 424M, SMPTE 292M
Multi-standard operation from 1.5Gbit/s to 12Gbit/s
Multirate reclocking: 1.5Gbit - 3Gbit - 6Gbit - 12Gbit
Automatic cable EQ
260m @ 1.5Gbit/s, 150m @ 3Gbit/s (Belden 1694A cable)
80m @ 12Gbit/s, 6Gbit/s (Belden 4794R cable)
Fiber Optic 1 x fiber optic input, 1 x fiber optic output
SMF (singlemode) using LC/PC connection
SMPTE 297M - 2006
Transmitter: 1310nm, typical Optical power -3dBm
Receiver: 1260nm - 1620nm (-2dBm to -10dBm)
Max. distance 10km (6.2 miles) @ 3Gbit/s (Singlemode)
TX active and RX active LEDs on side of module
Power +12VDC @ 2.2W nominal (power supply included)
(supports 7 - 24VDC input range)
Power LED on side of module
We are constantly adding more yellobrik modules.
Please visit our website for the latest product updates.
www.lynx-technik.com
Transmitting
Data
yellobrik
®
Quick
Reference
yellobrik
®
LYNX
Technik
AG |
www.lynx-technik.com

Connections
The SDI video input and output are connected to the 75 Ohm BNC
connections (up to12Gbit). The ber connection is LC/PC Duplex SMF
(singlemode).
The ber connection comes standard with an installed rubber plug to
prevent dust contamination. Please keep the plug for later use if the
cable is ever disconnected from the cable.
Operation
The OTR 1410 combines an independent ber optic transmitter and
receiver in a single package. Dierent SDI video formats and
standards (12G, 6G, 3G and 1.5G) can be transmitted and received. For
transmission, the SDI video format is automatically detected, reclocked
and then transmitted over the ber optic TX connection. For reception,
the optical SDI video input signal on the RX connection is automatically
detected, reclocked and provided on the SDI output connection.
Maximum distance supported is 10km (6.2 miles). Data transmission
and reception activity is indicated by the TX and RX LEDs on the side of
the module.
Note: If TX LED is OFF, then this indicates that there is no SDI present
or not a valid input. If RX LED is OFF, then this indicates that no optical
input signal is connected or the optical input power is too low.
The OTR 1410 is hot swappable and hot pluggable.
Power
The module requires a 12V DC power input and the LED conrms when
power is connected. A power supply is provided, however if you use
your own power supply, please provide a clean 12V DC power source
between 7 and 24VDC.
The OTR 1410 has a power consumption of approximately 2.2W
nominal.
Power Lead Strain Relief
The module has a small hole in the case which is located above the
power connection. This prevents the power lead being accidentally
pulled out. Use the supplied tie-wrap and secure the lead as shown
below.
Optional Mounting Solutions
The optional RFR 1001 mounting bracket can be used to permanently
mount the module on any surface or on 19” rack rails.
The optional RFR 1000-1 rack mount can be used to permanently
mount up to 14 yellobrik modules. In addition, the RFR 1000-1 can
provide full power redundancy for all mounted yellobriks.
