Macrom M-AN6560D User manual

USER MANUAL
M-AN6560D
ANDROID
ANDROID
MULTIMEDIA
MULTIMEDIA
MONITOR
MONITOR
M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 1M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 1 07/05/2021 16:26:5207/05/2021 16:26:52

- 2 -
Contents
Safety Precautions ............................................................................................................................. 1-2
Warning...................................................................................................................................................2
Product overview....................................................................................................................................3
Setting.....................................................................................................................................................4
Netwrok and Internet.........................................................................................................................4
Car Infotainment ............................................................................................................................ 4-8
System ................................................................................................................................................9
Radio .....................................................................................................................................................10
DAB .......................................................................................................................................................11
Video......................................................................................................................................................12
Music.....................................................................................................................................................13
Bluetooth ........................................................................................................................................ 14-15
Navigation.............................................................................................................................................16
Connection view....................................................................................................................................16
Dual screen ..........................................................................................................................................16
Specifications .......................................................................................................................................17
Declaration of Conformity....................................................................................................................18
M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 2M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 2 07/05/2021 16:26:5207/05/2021 16:26:52

- 1 -
Safety Precautions
Never expose this unit, amplifier, and
speakers to moisture or water to prevent
electric sparks or fire.
Please don't change the fuse on the power
cord without professional guidance, using
improper fuse may cause damage to this unit
or even cause fire.
Please contact your nearest dealer if one of
the following symptoms is experienced:
(a). Water or other objects enters the unit.
(b). There is smoke.
(c). Peculiar smell.
Only connect the unit to a 12-volt power
supply with negative grounding.
MUTE
OK
MUTE
OK
Never install this unit where the operation &
condition for safe driving is impaired.
Never use the video display function in the
front when driving to prevent the violation of
laws & regulations and also to reduce the
risk of traffic accident except for using rear
view video camera.
MUTE
OK
MUTE
OK
MUTE
OK
MUTE
OK
Thank you for purchasing this product. Please
read through these operating instructions
so you will know how to operate your model
properly. After you’ve finished reading the
instructions, keep this manual in a safe place
for future reference.
To ensure safe driving, please adjust the
volume to a safe and comfortable level in
case of emergency situations.
M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 1M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 1 07/05/2021 16:26:5307/05/2021 16:26:53

- 2 -
1. Never disassemble or adjust the unit without any professional guidance.
For details, please consult any professional car shop / dealer for inquiry.
2. If the front panel or TFT monitor is dirty, please use a clean silicone cloth and neutral detergent
to wipe off the spot. Using a rough cloth and non-neutral detergent such as alcohol for cleaning
may result in scratching or decoloration to the monitor.
3. If any abnormal behavior of the unit is found, please refer to trouble shooting guide of this
manual. If no relevant information is found, please press the [RESET] key on the front panel to
resume factory default.
4. If you have parked the car in hot or cold weather for a long time, please wait until the
temperature in the car becomes normal before operating the unit.
5. Using the car heater in low temperature environment may result in moisture inside the unit, DO
NOT use the unit in this situation. Eject the disc and wipe off the moisture on the disc. If the unit
still doesn't work after a few hours, please contact the service center.
6. Do not impact the LCD monitor which could cause damage.
7. To prevent damage to the screen, avoid touching it with sharp objects.
8. To provide a clear demonstration and an alternative for easy understanding to the operation of
this unit, graphic illustrations are used.
However, some illustrations are different from the actual images displayed on the screen.
9. Operate the unit correctly according to this manual to prevent unnecessary problem. The
guarantee won't be valid if the problem is caused by inappropriate operation.
Safety Precautions
Detect parking brake
• In order to be able to install the android application, the handbrake connection must be
connected. Engage the parking brake for APP installation.
• Connect the cable "BRAKE" to the parking brake switch to view video files on the TFT monitor.
Engage the parking brake for viewing videos.
• When the parking brake is not engaged, the monitor displays "Warning!!!, Video playback is
disabled for your safety. Engage parking brake to watch video.", preventing the driver to watch
content while driving. The rear screens are not interested in this inhibition.
Importante note:
This connection is indispensable for the proper operation.
Warning
Brake light
Battery
Pink
Green with White
Black
Orange with white
Brown with white
Blue
SWC &
CAMERA IN
Camera IN
Video Out
PARKING
REVERSE
SWC GND
SWC2
SWC1
P.CONT
Video Out
Yellow
Yellow
To connect to
the Parking cable
M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 2M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 2 07/05/2021 16:26:5307/05/2021 16:26:53

- 3 -
Product overview
Through the home page you can access the functions of the multimedia unit.
Power On / Off the unit
When the unit is connected to the vehicle ignition system, press the front panel to turn on the unit.
To turn off the unit, remove the car ignition key.
2
3
4
57
1
6
1. Screen
Press the icon to turn off the screen. Touch the screen in any position to activate the view.
2. Navigation
Press the icon to go directly to the navigation function.
3. Audio control
Use the audio icon to adjust the sound system.
4. Brightness
Press the icon to access the screen brightness settings.
5. Interface colors
Allows access to the color settings of the user interface.
6. Source selection
Press the app to view Radio, Music, Video, USB Playback, or AVIN mode and other functions.
7. Cursor
Scroll left or right to switch between pages.
Playback mode and position memory
When the car is restarted, the system resumes the previous mode before switching off.
For the radio, it will resume the radio channel before switching off.
For music or video, it will resume playing the last song or video before turning it off.
M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 3M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 3 07/05/2021 16:26:5307/05/2021 16:26:53

- 4 -
Setting
1. Touch setting icon [ ] on the front panel to enter Settings interface. Select the corresponding
option to enter the corresponding settings option. Move the options bar up and down to find the
desired settings.
Note; some settings require activation via the On-OFF selector.
Rete e Internet
WI-FI
Select On to achieve the Wi-Fi, then select the desired
access points and insert the password.
Hostspot
Select On to achieve the Wi-Fi hotspot, then select the
desired Network name and insert the password.
Car Infotainment (Common)
Standby Time
This function allows to delay the switching off of the device
through the selected time.
Option bar
M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 4M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 4 07/05/2021 16:26:5307/05/2021 16:26:53

- 5 -
Car Infotainment (Common)
Boot logo
To select the welcome logo it is necessary to entre the
password (5678).
After selected the desiderd logo press (OK) to confirm the
logo update.
Assistive Touch
User can choose to on or off the touch assist. The touch
assist has 7 most commonly used options and is dispalyed
on top of the screen at the interface where it provides the
user easy maneuver of the unit.
Reset All Setting
In order to restore all factory setting, press the OK button
on popup dialogue. All your settings will be removed.
System Restore
By selecting the System restore, all application installed
by the user will be removed and the system will restore to
the factory settings.
Reverse Volume Suppression
In order to adjust the volume while you drive in reverse
mode, select one of four settings between None, Weak,
Medium and Strong.
The volume will be reduced according the selection.
M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 5M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 5 07/05/2021 16:26:5307/05/2021 16:26:53

- 6 -
Car Infotainment (Common)
Daytime Backligth Set
Adjusts the brightness of the screen in day mode.
Nighttime Backligth Set
Adjust the brightness of the screen in night mode.
Auto Mode
When the vehicle lights are switched on, it is possible to
select automatically the brightness mode of the screen
according to the above settings.
Key Light Color Key Ligth Color
Allows you to select the color of illuminations keys.
Car Infotainment (Volume)
Volume
The volume level can be changed according to the selected
source.
Car Infotainment (Sound)
Sound
The sound can be modified through the graphic equalizer
and at the moment it is possible to modify the prostrate
point by using the four arrows.
M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 6M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 6 07/05/2021 16:26:5407/05/2021 16:26:54

- 7 -
Car Infotainment (Video)
Disable Video in Motion
Video playback is disabled for your safety. Engage parking
brake to watch video or select the switch in ON position.
Reversing Assistant Line
NOTE: This feature can only support certain car models.
By enabling this option at reverse position, the assistant line
will be shown at the display by moving the steering and aligned
in accordance to the steering movement during reverse.
Front Cam
Enabling this option, after having disengaged the reverse
gear, it will be possible to view the front camera for a time
between 3, 5 or 8 seconds.
Car Infotainmen (Navigation)
Autostart Navigation
Allows the user to set the automatic start of the navigation
system when the unit is turned on:
File Path
Allows the user to customize the navigation system
according to the installed applications.
Navi Mixed
Allows the user to mix the audio of the navigation system
with the audio of the media sources being played.
Reversing Warning Line
By enabling this option, while driving at reverse position
the assistent line will be shown at the display.
Air Conditioner
NOTE: This feature can only support certain car models.
By enabling this option, the air condition of the car will be
displayed during adjustment.
M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 7M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 7 07/05/2021 16:26:5407/05/2021 16:26:54

- 8 -
Car Infotainment (Bluetooth)
Auto Connect
By enabling this function, the unit will auto search and
auto connect with the last connected device.
Pin Code 0000
Bluetooth
SWC
About Device
Pin Code
To connect your Bluetooth device to the unit, you need to
pair the device to the unit. Pairing needs only to be done
once. Enter default password “0000”.
Auto Answer
By enabling this function, the unit will auto answer all
incoming calls.
Car Infotainmen (SWC)
Bluetooth
SWC
About Device
Steering Wheel Control Programming
Please follow the steps below to set the functions of your steering wheel.
1. Press CLEAR ALL before proceeding
2. Press a button on the steering wheel
3. Touch the corresponding feature of the control button on the touch screen.
4. When the control button turns blue, it means that the setup was successful.
5. Repeat the steps 2 - 4 to compleate all controll button setting avgailable on your steering wheel.
Car Infotainmen (About Device)
Bluetooth
SWC
About Device
Version Information
System information.
M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 8M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 8 07/05/2021 16:26:5407/05/2021 16:26:54

- 9 -
System
System
Languages & input Languages & input
Allows the user to set the system language.
By "Add a language" it is possible to add the different
language from the default.
Scroll the list of available language, select the desired
language and press to conferm.
To define the system language, drag the desired language
to position 1
<- System
Languages & input
Date & time
About Car
Data & time Data & time
Allows the user to set the Datye & time.
Follow the different options provided by the system to
obtain the time and date displayed on the product.
About Car About car
Information on the product is shown
1 English
2 Italiano (Italia)
3 Espagnol (Espana)
+ Add a language
Touch the System icon to set the language of the user interface and to set the date & time.
M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 9M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 9 07/05/2021 16:26:5407/05/2021 16:26:54

- 10 -
Radio
Touch the radio icon on the main interface to enter radio mode. You may also touch the radio icon
at the application page.
2 8
3 4 5 6 7
1
1. Band search
Press Band to select FM1, FM2, FM3 and for AM1, AM2
2. Search for radio channels
Use the arrow icon (< / >) to search for the next or previous radio station.
When a radio station is found, the search will stop automatically and the unit will sound.
3. Automatic search
When you press the search button, the system will automatically search for frequency 88.00 at
frequency 108.00 until unit find the radio station with the strongest signal.
To stop the search, tap the icon again.
4. Stere/Mono
Allows you to select the reception mode between Stero or Mono.
5. Volume
Scroll the bars left and right to adjust the volume level.
6. Audio settings
Use the icon to adjust the sound of the system.
7. Sound settings
When ACC is connected, press the power button on the front panel to turn on the unit. Turn off
the unit and disconnect the car key to turn off.
8. Preselection of radio channels
Each band can store up to 6 radio channels.
The system can store 24 radio channels (18 FM channels and 6 AM channels).
M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 10M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 10 07/05/2021 16:26:5507/05/2021 16:26:55

DAB
Touch the radio icon on the main interface to enter DAB mode. You may also touch the radio icon
at the application page.
2
8
3 4 5 6 7
1
DAB radio overview
Overview
1. DAB signal level
2. Broadcaster logo
(this service may not be
provided by the tuned broadcaster)
3. Information
4. Previous station
5. Next station
6. List of favorite stations
7. General settings
8. List of received stations
Settings
1. General
App startup settings
2. Cage
Graphic personalization of the screen
3. Audio
Audio settings
4. Stations
Automatic scan
5. Channel logos
Issuer logos update
6. Information
Application info
1
2
3
4
5
6
- 11 -
M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 11M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 11 07/05/2021 16:26:5507/05/2021 16:26:55

- 12 -
Video
1
5
4
Touch the music video icon at the main interface. It supports flash internal storage card, music
and video stored in USB drive, ape, flac and other formats.
VIDEO
2
3
1. Video folder
The video folder contains all the folders containing the videos.
2. Collection
The collection contains your favorite videos file
In the video list you can select videos that will be directly visible in the list of the collection.
3. History
The list shows the video previously played on
4. Video files
Press the desired video to start playback
5. Favorite
Highlight the icon to allocate the video in the favorites collection list.
6
6. Screen video format
Best fit - Fit horizontal - Fit vertical - Full screen - 16:9 - 4:3 - Center.
7. Repeat file
Press to repeat single or folder playback.
8. Previous video
Press to return to the previous video.
9. Play & Pause
Press to start playback or to Pause the video.
10. Next video
Press to go to the next video.
11. Collection favorite
Press to select the favorite videos in the collection list.
12. Back to video home
Press to go back to the home page.
7 8 9 10 11 12
M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 12M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 12 07/05/2021 16:26:5507/05/2021 16:26:55

- 13 -
Music
1
5
4
Touch the music icon at the main interface. It supports flash internal storage card, music and
audio stored in USB drive. The unit supports MP3 cover display.
2
3
1. Audio folder
The audio folder contains all the folders containing the audios.
2. Collection
The collection contains your favorite audios file.
In the audio list you can select audios that will be directly visible in the list of the collection.
3. History
The list shows the audios previously played on
4. Audio files
Press the desired audio to start playback
5. Favorite
Highlight the icon to allocate the audio in the favorites collection list.
6
6. Volume
Press to adjust the volume.
7. Equalizer
Press to adjust the sound of system .
8. Previous audio
Press to return to the previous audio track.
9. Play & Pause
Press to start playback or to Pause the video.
10. Next audio
Press to go to the next audio track.
11. Collection favorite
Press to select the favorite audios in the collection list.
12. Back to audio home
Press to go back to the home page.
7 8 9 10 11 12
M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 13M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 13 07/05/2021 16:26:5607/05/2021 16:26:56

- 14 -
Bluetooth
1
Bluetooth's hands-free function enables you to call safely while driving. Touch the Bluetooth icon
to enter in the bluetooth setting.
2
3
1. Pairing
• To activate the bluetooth hands-free function, pair your mobile phone with the unit.
• Turn on bluetooth and bluetooth device search function on your mobile phone.
• Search for the name M-AN6560 of the unit.
• You are required to key in the corresponding PIN number i.e. 0000 on your mobile phone to
connect to the unit.
• Once connected, a "CONNECTED" sign will appear on the screen.
2. Keyboard
Upon establishing the bluetooth connection, user can dial directly on the phone or key in
telephone numbers on the dial pad.
4
5 6
MACROM
3. Phonebook
The contacts can be download from mobile phone to the unit.
4. Call history
Call history shows outgoing call, incoming call and missed call. User can perform call or delete
in call history.
5. Connection
If the mobile phone has already been paired with the unit, press to re-connect the device.
6. Disconnection
Press unplug the device.
7. Phonebook synchronization
The contacts can be download from mobile phone to the unit.
• Touch ( A ) to delete the incorrect number dialed.
• When you dialed telephone number, press ( B ) to
call or ( C ) to hang off.
• During conversation, user can touch ( D ) on the
screen to switch between private mode and loud
speaker.
A
B
D
C
• Once bluetooth is connected, touch to
download the contacts.
• Once download is completed, name of the contact
will be shown on the display screen during phone
call. Press ( A ) to view the contact list.
• Forquick access to the contacts, use the name
search begins with first alphabet ( B ).
B
7
A
M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 14M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 14 07/05/2021 16:26:5607/05/2021 16:26:56

- 15 -
Bluetooth
1. Call history
Call history shows outgoing call, incoming call and missed call. User can perform call or delete
in call history.
2. Bluetooth Muisc
This unit supports bluetooth music playing.
2
Navigation
GPS Satellite Navigation Operation
The invention of GPS navigation has brought to the convenience of travelling today. By using the
GPS positioning and electronic navigation map, user can reach the destination faster and more
efficiently. To navigate accurately, both the GPS positioning and navigation map are equally
important. The GPS provides precise positioning and fast calculating speed while the navigation
map provides huge information, data and route planning.
Navigation Map Data
The data of some navigation applications can be stored externally in SD card or USB drive.
Note:
Some navigation application defaulted its route planning on the map and may not support storage
in external SD Card and USB Drive.
Installation of APK Navigation Application
Before navigation, please install APK Navigation Application and ensure the APK navigation map is
correctly installed.
Navigation Activation
Upon successful installation of APK Navigation Application, there will be a corresponding icon on
the homepage. Touch the icon to launch the application.
User can also go to "Car Infotainment" > "Navigation">"File Path " to link the navigation button
and application. Upon linkage, user may press the "Navigation Button" to start the navigation
directly.
Navigation Application Operation
Please refer to the corresponding operation manual for details in navigation application.
User can play music on the mobile phone and transfer
it to the loud speaker of the car via bluetooth. It also
supports simplified controls such as "Previous",
"Next", "Pause" and "Play".
NOTE: Due to bluetooth compatibility, the unit may not support all features or all phone models.
1
M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 15M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 15 07/05/2021 16:26:5607/05/2021 16:26:56

- 16 -
Connection view
Dual screen
Dual screen function
Some applications are supported by the dual screen function. It is therefore possible to divide the
screen in half and display two applications simultaneously.
Press to view the open applications and then select
the desired applications to be displayed on the screen
simultaneously.
Note: some applications may not be supported by
screen sharing.
Diagram of M-AN6560
WIFI
RADIO
GPS
RCA CONNECTION
RCA Video Out 1
RCA Audio L. Out
RCA Audio R. Out
AUX Video In
SUB Audio Out
RCA Video Out 2
1
11
11
20
POWER CABLE CONNECTION
1 Front Left +
2 Front Left -
3 Front Right +
4 Front Right -
5 Brake (Parking)
6 Illumination
7 NC
8 SWC KEY 1
9 Reverse
10 Camera Video In
1 Rear Left +
2 Rear Left -
3 Rear Right +
4 Rear Right -
5 Battery + (Yellow)
6 GND (Black)
7 ACC Power (Red)
8 Antenna Power
9 SWC KEY 2
10 NC
MIC
USB
* Camera Front
* The Aux In input, if necessary become an input for the front camera video.
Through the settings found in the CAR INFOTAINMNET in the VIDEO> FRON CAM section it is possible to
activate the auxiliary input for viewing the front video camera. See page 7
M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 16M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 16 07/05/2021 16:26:5607/05/2021 16:26:56

- 17 -
Specifications
General
Reference Supply Voltage ...........................................................................................................12V
Operating Voltage Range ...................................................................................................... 9 - 16V
Max Operating Current....................................................................................................................15A
Grounding System Car Battery Negative Pole
FM
Signal Noise Ratio ....................................................................................................................≥55dB
Residual Noise Sensitivity (S/N=30dB) ............................................................................... ≤10dBµV
Frequency Response (±3dB) ......................................................................................... 40Hz~12KHz
Station Seeking Level........................................................................................................ 23±3dBµV
Distortion ................................................................................................................................. ≤1.0%
Stereo Separation (1KHz)........................................................................................................ ≥25dB
Antenna Impedance..................................................................................................................... 75Ω
Frequency range.........................................................................................................87,5 /108,0MHz
AM
Residual Noise Sensitivity (S/N=20dB) ................................................................................ ≤28dBµV
Selectivity (±9KHz ..................................................................................................................... ≥50dB
Frequency range............................................................................................................522/1620KHz
DAB
Residual Noise Sensitivity (RF=72dBM)...................................................................................... 60dB
Stereo Separation (1KHz).......................................................................................................... ≥55dB
Frequency range............................................................................................................. 174 /240MHz
BT
Frequency ............................................................................................................... 2,402 - 2,480GHz
Power output
Frequency Response (±3dB .......................................................................................... 50Hz~16KHz
Maximum Output Power ......................................................................................................... 4×45W
Load Impedance ............................................................................................................................ 4Ω
AUX IN
Distortion .................................................................................................................................. ≤0.5%
Frequency Response (±3dB .......................................................................................... 50Hz~20KHz
Audio Input Level.................................................................................................................. 0.5Vrms
Audio
Audio Output Impedance........................................................................................................... 100Ω
Audio Output Level ......................................................................................................... 2Vrms(Max)
Video
Normal Video Input Level (CVBS ......................................................................................... 1.0±0.2V
Video Input Impedance................................................................................................................ 75Ω
Environment
Operating Temperature.............................................................................................. -20°C ~ +70°C
Storing Temperature.................................................................................................. -30°C ~ +80°C
Operating Humidity........................................................................................................ 45%~80%RH
Storing Humidity............................................................................................................ 30%~90%RH
M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 17M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 17 07/05/2021 16:26:5607/05/2021 16:26:56

The manufacturer GMA ITALIA s.r.l. declares that the type of radio equipment - Multimedia Monitor,
model M-AN6560D, brand Macrom - complies with the 2014/53 / EU Directive.
The full text of the EU Declaration of conformity is available at the following internet address:
www.macrom.it, or at GMA ITALIA s.r.l. - V. Di Vittorio, 7/33 Rho - 20017 (MI) Italy
Made in China by
GMA ITALIA s.r.l. - Via G. Di Vittorio, 7/33 Rho - 20017 (MI) Italy
Declaration of Conformity
Information on disposal of unit
This product bears the selective sorting symbol for waste electrical and electronic
equipment (WEEE).
This means that this product must be handled to the local collecting points or given back to
retailer when you buy a new product, in a ratio of one to one (or one to zero if the external
dimension is less than 25 cm) pursuant to European Directive 2012/19/EC in order to be
recycled or dismantled to minimize its impact on the environment.
For further information, please contact your local or regional authorities.
Electronic products not included in the selective sorting process are potentially dangerous for the
environment and human health due to the presence of hazardous substances.
The unlawful disposal of the product carries a fine according to the legislation currently in force.
www.macrom.it
.
M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 18M-AN6560 comune User manual_ENG-IT_1220.GMA.indd 18 07/05/2021 16:26:5707/05/2021 16:26:57
