Magnum Energy ME-MR Series User manual

Owner’s Manual
(for Revision 1.0 or higher)
ME-MR
Inverter Remote Control
www.aarrss.com

ii ©2009 Magnum Energy Inc.
Disclaimer of Liability
Since the use of this manual and the conditions or methods of installation,
operation, use and maintenance of the ME-MR are beyond the control of
Magnum Energy Inc., this company does not assume responsibility and
expressly disclaims liability for loss, damage or expense, whether direct,
indirect, consequential or incidental, arising out of or anyway connected with
such installation, operation, use, or maintenance.
Due to continuous improvements and product updates, the images shown in
this manual may not exactly match the unit purchased.
Restrictions on Use
The ME-MR remote shall not be used in connection with life support systems,
life saving or other medical equipment or devices. Using the ME-MR with this
particular equipment is at your own risk.
Important Product Safety Instructions
This manual contains important safety instructions that must be followed
during the installation and operation of this product. Read all instructions
and safety information contained in this manual before installing or using
this product.
• All electrical work must be performed in accordance with local, state and
federal electrical codes.
• This product is designed for indoor / compartment installation. It must not
be exposed to rain, snow, moisture or liquids of any type.
• Use insulated tools to reduce the chance of electrical shock or accidental
short circuits.
• Remove all jewelry such as rings, watches, bracelets, etc., when installing
or performing maintenance on the inverter.
Safety Symbols
To reduce the risk of electrical shock, fire, or other safety hazard, the fol-
lowing safety symbols have been placed throughout this manual to indicate
dangerous and important safety instructions.
WARNING: This symbol indicates that failure to take a specified
action could result in physical harm to the user.
CAUTION: This symbol indicates that failure to take a specified ac-
tion could result in damage to the equipment.
Info: This symbol indicates information that emphasizes or supple-
ments important points of the main text.
Remedy: This symbol provides possible solutions for related is-
sues.

©2009 Magnum Energy Inc. iii
Table of Contents
1.0 Overiew.................................................................................... 2
2.0 Installation............................................................................... 3
3.0 Setup ....................................................................................... 6
4.0 Menu Map: ME-MR Remote Control......................................... 18
5.0 Operation .............................................................................. 19
6.0 Troubleshooting .................................................................... 34
7.0 Limited Warranty ................................................................... 37
List of Figures
Figure 1-1, Front Panel Features .................................................... 2
Figure 2-3, Remote Control Connections ........................................ 5
Figure 4-1, Inverter/Charger Menu Map....................................... 18
Figure 6-1, Performing an Inverter Reset..................................... 36
Table of Tables
Table 3.1, Battery AmpHrs to Absorb Charging Time...................... 9
Table 3.2, Battery Size to Battery Amp-Hours (estimated)........... 10
Table 3.3, Battery Type to Charge Voltages.................................. 11
Table 3.4, Inverter/Charger Default Settings............................... 17
Table 5.1, LED Indicator Guide ..................................................... 33
Table 6.1, Remote Troubleshooting ............................................ 34

2 ©2009 Magnum Energy Inc.
Introduction
1.0 Overiew
The ME-MR remote control allows you to monitor and customize basic operat-
ing parameters to your Magnum inverter/charger. The ME-MR remote can be
used on all Magnum inverter/charger models.
INFO: The ME-MR remote control has minimal settings available
in the Setup Menu. Careful consideration should be given to
choosing this remote over the full featured ME-RC when custom
izing the inverter/charger for your particluar system.
The ME-MR25 comes standard with a 25 foot, 4-conductor telephone cable
and includes non-volatile memory (preserves adjustable settings, even if
power to the remote or inverter is removed).
This manual is for the ME-MR with revision 1.0 or higher; see the TECH: 02
Revisions display on page 16 for information on how to determine your revi-
sion level.
Figure 1-1, Front Panel Features
The ME-MR is equipped with the following features:
• LED Indicators - at-a-glance LEDs provide the inverter/charger status
in a straightforward way.
• LCD Display - is a 8 x 2 line (16 characters total), alphanumeric display,
used for setting up the inverter/charger operation as well as viewing current
status or fault messages.
• ON/OFF or CHANGE Pushbutton - allows the inverter to be turned
On and Off. The “ON/OFF” button also serves as an “CHANGE” button when
navigating through SETUP and TECH menus.
• MENU or HOME Pushbutton - accesses SETUP and TECH menus. The
“MENU/HOME” button also serves as a “HOME” button to return directly to
the “Status” menu
• SAVE or HOLD Pushbutton - button serves as a “SAVE” button to
save settings when in the SETUP menus The “HOLD” button stops the status
screen scrolling.

©2009 Magnum Energy Inc. 3
Installation
2.0 Installation
Before installing the remote, read the entire installation section to determine
how you are going to install your ME-MR. A thoroughly planned system is
much more likely to meet your inverter system needs.
Info: Installations should be performed by qualified personnel, such
as a licensed or certified electrician. It is the installer’s responsibility
to determine which safety codes apply and to ensure that all appli-
cable installation requirements are followed. Applicable installation
codes vary depending on the specific location and application.
Info: Review the “Important Product Safety Information” on the
front inside cover page before any installation.
• Before connecting any wires, determine the remote cable route throughout
the home or vehicle/boat both to and from the inverter.
• Always check for existing electrical, plumbing or other areas of potential
damage before drilling or cutting into walls to mount the remote.
• Make sure all wires have a smooth bend radius and do not become
kinked.
• If installing this remote in an boat, RV or truck; ensure the conductors
passing through walls, bulkheads or other structural members are protected
to minimize insulation damage such as chafing, which can be caused by vi-
bration or constant rubbing.
Installing the remote control is a simple process and requires the following
tools:
• Phillips screwdriver • Level • Drill Motor
• Cut-out tool (knife/saw) • Pencil • Drill Bit (7/64”)
2.1 Installation Procedure
Select an appropriate location to install the remote control. Allow ample
room to access the remote’s buttons and to view the LEDs. Ensure the
viewing angle of the display is appropriate.
Refer to figure 2-1 for flush mount hole cutout dimensions.
Refer to figure 2-2 for Surface Mount Bezel dimensions.
Run the remote cable between the remote and the inverter/charger. This
cable is a 4-wire telephony standard with RJ11 connectors on each end.
A standard telephone cable may be substituted if the provided remote
cable is not able to be used.
Connect the remote cable into the RJ11 “Remote” port (has blue label)
on the inverter/charger (see figure 2-3).
Have the inverter connected to batteries, but ensure the inverter is off
and that no AC power is connected to the inverter.
While monitoring the front of the remote, connect the other end of the
cable into the RJ11 jack on the back-side of the remote (see figure 2-
3).
1.
2.
3.
4.
5.
6.

4 ©2009 Magnum Energy Inc.
Setup
23/8"
11/8"
Figure 2-1, Flush Mount Remote Cut-Out Dimensions
23/8"
11/8"
211/16"
11/8"
31/8"
31/8"
21/8"
21/8"
Bezel Side view Bezel Front view
Remote Side view Remote Back View
Figure 2-2, Surface Mount Bezel Dimensions
After selecting the desired location for Flush mounting the remote cutout a
mounting hole measuring 2 3/8” x 2 3/8”. Mount the remote into the cutout
and use the remote to mark and predrill 2 holes for the 6 x 1/2” phillips flat
head mounting screws.
After selecting the desired location for the Surface Mount Bezel mount the
Bezel using the Bezel as a template. Mark and predrill 4 1/8” holes. Mount
the Bezel using the four #6 x 3/4” screws. Next mount the remote to the
Bezel using the two #6 x 1/2” Phillips flat head screws.

©2009 Magnum Energy Inc. 5
Setup
Immediately upon connecting the remote cable, all the LED’s will come on
as the unit goes through a self-test. After the initial self-test completes,
text should appear with a system status message indicating the current
state of the inverter/charger. If not, please refer to the troubleshooting
section.
The remote is ready for setup.
Info: All power to operate the remote control is provided by the
inverter/charger through the remote cable
7.
8.
Figure 2-3, Remote Control Connections
BACK
RJ11 Connection
Magnum Inverter
Remote Cable
REMOTE Port (blue)

6 ©2009 Magnum Energy Inc.
Setup
3.0 Setup
When the remote is connected to a Magnum inverter/charger, the settings in
the remote control determine the inverter/charger operating parameters. The
default settings in the remote control (see Table 3-4, Inverter/Charger Default
Settings) are adequate for most installations, however you have the option to
change some of the operating parameters if required. This section will show
you how to navigate the remote, give you an understanding of the function of
each adjustable setting and help you decide what setting should be used.
3.1 Navigating the Remote’s Menu
The ME-MR has an internal structure that provides menu items and adjust-
able settings that provide the ability to configure your inverter/charger to
your specific parameters.
Info: See figure 4-1, Inverter/Charger Menu Map for a complete map
of the inverter/charger menu items and adjustable settings.
Familiarize yourself with the items on the front panel which are used to find,
adjust and save the desired setting. They are:
• LCD Display - The bottom line of the LCD display shows the menu items,
adjustable settings or the meters display information.
Info: The bottom line of the LCD display returns to the Home
Screen to show DC voltage and current (see Figure 3-1) after 30
Seconds - if no buttons have been pressed.
Info: When the ”←” (left facing arrow) symbol is shown on the dis-
play, it indicates that the displayed setting has been selected and
will be used.
• Menu Pushbutton - Allows simple access to the menu items that can
help with configuring, monitoring and troubleshooting your inverter/charger
system.
• Change Pushbutton - This button allows you to quickly scroll through
and select various menu items and settings after pressing the menu pushbut-
ton.
• Save Pushbutton - This button saves the menu item displayed on the
screen. A saved setting is indicated by arrow symbol.

©2009 Magnum Energy Inc. 7
Setup
3.2 Menu Pushbuttons and Menu Items
Read this section to help understand the function of each menu pushbutton
and the configurable settings - to determine if they should be changed to
optimize the operation of the inverter/charger.
This menu pushbutton gives a quick means of changing your Shore setting to
coordinate with the circuit breaker rating from the incoming AC source.
SETUP: 01 SHORE - This selection ensures the inverter AC loads
receive the maximum current available from the utility or generator power.
Whenever the utility or generator is connected to the inverter (thru AC HOT
1), the current used to power the AC loads and to charge the batteries is
monitored. When the total current used to power the AC loads and charge
the batteries begins to approach the Shore setting, the current that was
used for charging the batteries will automatically be reduced. This ensures
the AC loads have all the available current when needed. The feature is not
available on the MM and MMS inverter/chargers.
Default setting: Shore Max = 30A
Where to set: Set the Shore setting to match the current rating of the utility
power or generator’s circuit breaker. If using multiple AC sources (utility and
generator) through an AC transfer switch, adjust this setting to the smaller
AC breaker size. This setting is very dependent on the stability of the AC
source. If using a generator, factors such as altitude and output voltage
regulation may require a lower setting than the generator’s breaker size. If
the input breaker to the charger is tripping, because it is a weak breaker, try
reducing this setting to next lower level.
CAUTION: The Shore Max setting does not limit the current to the
inverter loads. If the current from the loads on the output of the
inverter are greater than the circuit breaker rating on the incoming
AC source, you may experience nuisance tripping of this breaker.
•
Bottom line shows
current “saved” setting
If this setting is correct, press
menu button to access
different menu items
If a different setting is
required:
SHORE
30 Amps
.......
press press press
To save the current
setting displayed :
SHORE
5 Amps SHORE 15 Amps ....... SHORE 30 Amps
ON/OFF
CHANGE
MENU
HOME
SAVE
HOLD
Figure 3-1, SHORE: Shore Max Selections

8 ©2009 Magnum Energy Inc.
Setup
SETUP: 02 SEARCH - Allows you to turn off the Search Watts
feature or adjust the power level to determine when the search watts fea-
ture becomes active. The power level range selection is 0W(off) to 20W. If
this feature is not needed, select Search=Off. When search is turned off, the
inverter continuously provides full AC voltage to the loads.
Default setting: Search= 5W.
Info: When the Search Watts feature is active, “Search” appears on
the top line of the LCD display and the green ‘INV’ LED
will slowly flash.
What is the Search watts feature? This feature is used to help save
battery power by reducing the inverter’s output to search pulses when there
is no detectable load. If someone turns on a load greater than the wattage
level setting while the inverter is searching, the inverter will start inverting
to provide full voltage on its output.
Should I use the Search watts feature? If the inverter can spend a great
deal of time searching (to reduce the power drain on your batteries) and you
can tolerate small loads (less than 5 watts) from being on, then the search
mode feature should be used. However, if you require some small load (i.e.
digital clocks, satellite receivers, answering machines, etc.) to always be on,
then this feature should be turned off (Search = Off).
I want to use the Search watts feature, how do I determine where
to set it? The search watts setting should be adjusted to the same power
level (or the next lower setting) of the smallest load that you want to run. If
you don’t know the wattage of the smallest load you want to run, turn the
load on and decrease the Search watts setting until the load comes on and
stays on.
Example: You have reviewed all the loads you want to run and determined
that the smallest load is a 20 watt light, then set the Search = 20W. Whenever
you turn on any load (because all the loads are greater than 20 watts), the
inverter will stop searching and start inverting to deliver power to the load.
Info: Even though the search feature is on, some connected
equipment may draw enough current even while off keep the
inverter in the “invert”.
•
Figure 3-2, SEARCH: Search watts
Bottom line shows
current “saved” setting
If this setting is correct, press
menu button to access
different menu items
If a different setting is
required:
SEARCH
5 Watt
.......
press press press
To save the current
setting displayed :
SEARCH
Off SEARCH 5 Watt ....... SEARCH 20 Watt
ON/OFF
CHANGE
MENU
HOME
SAVE
HOLD
