Mainstays CONRAD MS17-D4-1007-03 User manual

1PB
model# MS17-D4-1007-03
model# MS17-D4-1007-04
model# MS18-D1-1007-08
model# MS18-D1-1007-09
Lot#_________Date________
Customer Service:
1.877.436.7290
[email protected]
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
black
white
gray
navy
Manufactured By:
BDDMI
1321 Tyler St NE, Minneapolis, MN 55413
Assembly Instructions
CONRAD 3 SHELF BOOKCASE

2
TOP PANEL
SHELF PANEL [X2]
LEFT SIDE ASSEMBLY
RIGHT SIDE ASSEMBLY
SHELF RAIL [X3]
CROSS BRACE
A
B
C
D
E
F
Before you begin:
1. Check for damaged or missing parts.
2. Use the carton as a working surface to prevent product damage during assembly.
TOOLS NEEDED
Hammer Flat Head Screwdriver Phillips Head Screwdriver
PARTS LIST

2 3
HARDWARE LIST
CAUTION:
1. Make sure the screws go through the pre-drilled holes properly.
2. Do not over tighten bolts.
3. Allen Wrench
x1
1. Large Bolt
x18
2. Small Bolt
x12
4. Short Pan Head Screw
x5
5. Long Pan Head Screw
x1
6. Wall Strap
x1

4
HARDWARE LIST
CAUTION:
1. Make sure the screws go through the pre-drilled holes properly.
2. Do not over tighten bolts.
7. Wall Anchor
x1
8. Washer
x2

4 5
x12 x1
STEP 1
1. Make sure the bolts go through the pre-drilled holes properly.
2. Do not over tighten bolts.
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.
2. Small Bolt 3. Allen
Wrench

6
x18 x1
STEP 2
1. Make sure the bolts go through the pre-drilled holes properly.
2. Do not over tighten bolts.
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.
1. Large Bolt 3. Allen
Wrench

6 7
x4
STEP 3
1. Make sure the screws go through the pre-drilled holes properly.
2. Do not over tighten screws.
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.
4. Short Pan
Head Screw

8
x1x1x1x1
x2
7
5
8
4
8
6
STEP 4
5. Large Pan
Head Screw
4. Short Pan
Head Screw
6. Wall Strap
8. Washer
7. Wall
Anchor
position against wall
mark position of strap hole on wall
drill 1/4”hole
tap in wall anchor
fasten anti-tip strap with wall
screw provided
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.

8 9
60 lbs. / 27.2 kg.
60 lbs. / 27.2 kg.
60 lbs. / 27.2 kg.
!WARNING
Serious or fatal crushing injuries can occur
from furniture tip-over. To help prevent
tip-over:
• Install tip-over restraint provided.
• Place heaviest items in the lowest drawers.
• Do not set TV’s or other heavy objects on top
of this product, unless the product is
specifically designed to accommodate them.
• Never allow children to climb or hang on drawers,
doors, or shelves.
• Never open more than one drawer at a time.
(OR)
• Do not defeat or remove the drawer interlock
system.
Use of tip-over restraints may only reduce,
but not eliminate, the risk of tip-over.
This is a permanent label. Do not remove.
WARNING: Do not exceed the maximum load capacity. Exceeding the maximum load capacity may result in
collapse and possible injury.
Furniture Care Instructions:
Dust with clean, lint-free cloth.
Use furniture spray polish as needed.
Customer Service:
877.436.7290
[email protected]
Your complete satisfaction is our number 1 priority. Our product is designed and manufactured to meet the
highest quality of standards. In the event that you have assembly questions, or parts are missing or damaged,
our customer service department would appreciate the opportunity to assist you.
This product carries a one (1) year warranty against defects in workmanship and materials. Defective product
will be replaced free of charge within the stated warranty period, when returned by the original purchaser with
proof of purchase. This product is not guaranteed against wear or breakage due to misuse and/or abuse. Please
contact our Customer Service at 1-877-436-7290 to obtain information on warranty performance. This warranty
gives you specic legal rights and you may also have other rights which vary from State to State.
