Mainstays MSW-10003 User manual

THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2019-09-03 Rev. 0001-A
Gaming Desk
Model # MSW-10003
ADULT ASSEMBLY REQUIRED
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our customer service number and have your instructions
and parts list ready to provide the model name, part name or factory number:
866-942-5362
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or visit our web site 24 hours a day, 7 days a week for product assistance at
www.whalenstyle.com
Or e-mail your request to [e-mail]
LOT NUMBER:
DATE PURCHASED: / /

2
MANUFACTURER: Whalen Furniture Manufacturing
CATALOG: Gaming Desk
MODEL # MSW-10003
MADE IN CHINA
SPECIAL NOTE
Please read the instruction sheets completely before assembly. Examine all packaging
material before discarding carton. Remove any remaining staples from the carton before
discarding. Remove all parts from carton and separate into groups as indicated on part
list. Please ensure all parts are included prior to assembly. Use of power tools to
complete assembly is not recommended.
M A X I M U M R E C O M M E N D E D W E I G H T L O A D S
THIS UNIT IS INTENDED ONLY FOR USE WITHIN THE MAXIMUM
WEIGHTS INDICATED. USE WITH LOAD HEAVIER THAN THE MAXIMUM WEIGHTS
INDICATED MAY RESULT IN INSTABILITY, CAUSING POSSIBLE INJURY.
MAXIMUM LOAD 22.7 kg / 50 lb.
MAXIMUM LOAD 90.8 kg / 200 lb.

3
Parts and Hardware List
Please read completely through the instructions and verify that all listed parts and hardware are present
before beginning assembly.
A- Desk Top (Qty. 1) B- Riser Top (Qty. 1)
C- Riser Left Side Frame (Qty. 1) D- Riser Right Side Frame (Qty. 1)
E- Desk Side Frame (Qty. 2) F- Stretcher (Qty. 2)
G- Cup Holder (Qty. 1) H- Accessory Hook (Qty. 3)
(1) 1/4" x 5/8" Bolt (2) Lock Washer (3) Flat Washer
(Qty. 24+1 extra) (Qty. 20+1 extra) (Qty. 20+1 extra)
(4) 1/4" x 1 1/8" Bolt (5) 1/4" x 1 1/2" Bolt Hex Wrench
(Qty. 4+1 extra) (Qty. 2+1 extra) (Qty. 1)
Tools required: Hex wrench (included).

4
Assembly Instructions
1. Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a
carpeted floor or the empty carton to avoid any scratch.
2. Align and attach the Riser Side Frames (C and D) to the Riser Top (B) using the 5/8" Bolts (1) with the
Lock Washers (2) and Flat Washers (3) through the metal brackets and securely screw into place.
① x 4 ② x 4 ③ x 4
D
C
B
1
2
3
1
2
3

5
Assembly Instructions
3. Align and fasten the Desk Side Frames (E) to the Desk Top (A) with eight 5/8" Bolts (1) and eight
Washer (2 and 3).
① x 8 ② x 8 ③ x 8
2
3
A
E
E
E
A
1
