Mainstays MS17-D4-1007-08 User manual

1PB
model# MS17-D4-1007-08
model# MS17-D4-1007-05
model# MS17-D4-1007-11
Lot#_________Date________
Customer Service:
1.877.436.7290
[email protected]
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
gray
white
black
Manufactured By:
BDDMI
1321 Tyler St NE, Minneapolis, MN 55413
Assembly Instructions
LOOP LOUNGE CHAIR

2
CHAIR FRAME
LEG [X2]
A
B
Before you begin:
1. Check for damaged or missing parts.
2. Use the carton as a working surface to prevent product damage during assembly.
TOOLS NEEDED
Flat Head Screwdriver Phillips Head Screwdriver
PARTS LIST

2 3
HARDWARE LIST
CAUTION:
1. Make sure the screws go through the pre-drilled holes properly.
2. Do not over tighten bolts.
4. Allen Wrench
x1
3. Mending Plate
x2
1. M6x20mm Bolt
x24
2. 25mm Flat Head
Screw
x8

4
STEP 1
1. Open zippered pouch.
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.
zippered pouch
parts stored inside

4 5
x24 x1
STEP 2
1. Make sure the bolts go through the pre-drilled holes properly.
2. Do not over tighten bolts.
3. If purchased multiple units, move on to step 3.
1. M6x20mm
Bolt
4. Allen
Wrench
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.

6
x8x2
STEP 3
1. Use the mending plates to attach multiple units together.
2. Make sure the screws go through the pre-drilled holes properly.
3. Do not over tighten screws.
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.
2. 25mm
Flat Head
Screw
3. Mending
Plate
pre-drilled holes
pre-drilled holes
Legs not shown for clarity.

6 7
250 lbs. / 113.4 kg.
WARNING: Do not exceed the maximum load capacity. Exceeding the maximum load capacity may result in
collapse and possible injury.
Furniture Care Instructions:
Dust with clean, lint-free cloth.
Use furniture spray polish as needed.
Customer Service:
877.436.7290
[email protected]
Your complete satisfaction is our number 1 priority. Our product is designed and manufactured to meet the
highest quality of standards. In the event that you have assembly questions, or parts are missing or damaged,
our customer service department would appreciate the opportunity to assist you.
This product carries a one (1) year warranty against defects in workmanship and materials. Defective product
will be replaced free of charge within the stated warranty period, when returned by the original purchaser with
proof of purchase. This product is not guaranteed against wear or breakage due to misuse and/or abuse. Please
contact our Customer Service at 1-877-436-7290 to obtain information on warranty performance. This warranty
gives you specic legal rights and you may also have other rights which vary from State to State.

1PB
model# MS17-D4-1007-08
model# MS17-D4-1007-05
model# MS17-D4-1007-11
Lot#_________Fecha_______
Servicio al Cliente:
1.877.436.7290
[email protected]
ESTE MANUAL DE INSTRUCCIONES CONTIENE INFORMACIÓN IMPORTANTE DE SEGURIDAD.
POR FAVOR LEA Y GUARDE PARA REFERENCIA FUTURA.
gris
blanco
negro
Fabricado Por :
BDDMI
1321 Tyler St NE, Minneapolis, MN 55413
SILLA LOUNGE LOOP
Instrucciones de Ensamble

2
Antes de comenzar:
1. Compruebe si hay piezas dañadas o faltantes.
2. Utilice la caja de cartón como supercie de trabajo para evitar daños al producto durante el montaje.
MARCO DEL SILLA
PATA [X2]
A
B
Destornillador de Cabeza Plana Destornillador Phillips
HERRAMIENTAS NECESARIAS
LISTA DE PARTES

2 3
LISTA DE ARTÍCULOS DE FERRETERÍA
PRECAUCIÓN:
1. Cerciórese que los tornillos pasen por los agujeros pretaladrados de manera apropiada.
2. No sobreapriete los tornillos.
4. Llava Allen
x1
3. Placa Para Arreglar
x2
2. 25mm Tornillo de
Cabeza Plana
x8
1. M6x20mm Perno
x24
