Mainstays MS18-D2-1011-02 User manual

THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2018-04-10 Rev. 0001-A Factory: KONRIC
2-Piece Shelf Set
Stock # MS18-D2-1011-02 White
# MS18-D2-1011-03 Canyon Walnut
ADULT ASSEMBLY REQUIRED
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store
where it was purchased. Please call our customer service number and have your instructions and parts list
ready to provide the model name, part name or factory number:
866-942-5362
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or visit our web site 24 hours a day, 7 days a week for product assistance at
www.whalenstyle.com
Or e-mail your request to [e-mail]
LOT NUMBER:
DATE PURCHASED: / /
(Optional Configuration)

2
MANUFACTURER: Whalen Furniture Manufacturing
CATALOG: 2-Piece Shelf Set
MODEL # MS18-D2-1011-02 / MS18-D2-1011-03
MADE IN CHINA
1. Please read the Assembly Instructions prior to assembling the unit.
2. To avoid damage, assemble the unit on a sturdy, level and non-abrasive surface.
3. Keep all hardware part out of reach of children.
MAXIMUM RECOMMENDED WEIGHT LOADS
MAXIMUM LOAD 50 lb. (22.7 kg)
MAXIMUM LOAD 135 lb. (61.3 kg)
THIS UNIT IS INTENDED ONLY FOR USE WITHIN THE
MAXIMUM WEIGHTS INDICATED. USE WITH HEAVIER THAN THE MAXIMUM
WEIGHTS INDICATED MAY RESULT IN INSTABILITY CAUSING POSSIBLE INJURY.
G
ENERAL INFORMATION, TIPS
AND
TRICKS

3
IMPORTANT
Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non-
abrasive surface. You will need the parts identified on page 4 of this instruction manual.
NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH DOWELS. EXCESS GLUE CAN BE WIPED
OFF WITH DAMP CLOTH.
Insert the wood dowel at least half way by tapping lightly with a rubber mallet, IF NECESSARY.
CAM LOCK SYSTEM OPERATION
HOW THE KNOCK DOWN (KD) ASSEMBLY SYSTEM WORKS
1. Screw the Cam Bolt into the threaded inserts on the panel. Connect both panels together; making sure Cam
Bolt goes into the pre-drilled hole on the end of panel for Cam Lock.
2. Insert the Cam Lock into the pre-drilled large hole on the panel. Make sure the arrow on the face of Cam
Lock faces out and points towards Cam Bolt.
3. Take a Phillips screwdriver and rotate the Cam Lock clockwise to lock the Cam Bolt in place.
4. Plug the Cam Lock Cover into the cross slot of the Cam Lock to conceal the Cam.
You are now ready to assemble the unit.
XX
FINAL
1 2 43

4
Parts and Hardware List
Please read completely through the instructions and verify th at all listed parts and hardware are present
before beginning assembly.
A- Large Shelf Panel (Qty. 2) B- Middle Shelf Panel (Qty. 2) C- Small Shelf Panel (Qty. 2)
D- Large Side Panel (Qty. 2) E- Middle Side Panel (Qty. 2) F-Small Side Panel (Qty. 4)
(1) Cam Lock (2) Cam Bolt (3) M10 x 40 mm Wood Dowel
(Qty. 32+1 extra) (Qty. 32+1 extra) (Qty. 32+1 extra)
(4) Cam Lock Cap (Qty. 32+1 extra) (5) M3.5 x 15 mm Screw (Qty. 4+1 extra) (6) Metal Bracket (Qty. 2)
Glue (Qty. 1) Touch-up Pen (Qty. 1) Tipping Restraint Hardware Kit (Qty. 2)
(not included for white finish) (Inside Plastic Bag)
Tools required: Phillips screwdriver and hammer (not provided).

5
Assembly Instructions
1. Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a
carpeted floor or the empty carton to avoid any scratch.
2. Securely screw the Cam Bolts (2) into the designated small holes on the Shelf Panels (A, B and C) using
a Phillips screwdriver.
2
x 2
B
A
C
Cam Bolt
(28 used in this step)
②

6
Assembly Instructions
3. Insert two Wood Dowels (3) into the inner holes of each Small Side Panel (F) and attach it to the Large
Shelf Panel (A) by engaging two Cam Locks (1).
1
A
F
F
3
Cam Lock
(4 used in this step )
①
M10 x 40 mm Wood Dowel
(4 used in this step)
③

7
Assembly Instructions
4. Attach one Middle Shelf Panel (B) onto the Small Side Panels (F) with four Cam Locks (1) and four
Wood Dowels (3).
A
F
F
B3
1
Cam Lock
(4 used in this step )
①
M10 x 40 mm Wood Dowel
(4 used in this step)
③

8
Assembly Instructions
5. Securely screw the Cam Bolts (2) into the designated small holes on the Middle Shelf Panel (B)
Cam Bolt
(2 used in this step)
②
B
2
2

9
Assembly Instructions
6. Attach the Middle Side Panel (E) to the Middle Shelf Panel (B) with two Cam Locks (1) and two Wood
Dowels (3).
Cam Lock
(2 used in this step )
①
M10 x 40 mm Wood Dowel
(2 used in this step)
③
B
E
3
1

10
Assembly Instructions
7. Attach the Large Side Panel (D) to the Large Shelf Panel (A) with two Cam Locks (1) and two Wood
Dowels (3).
A
D
3
1
Cam Lock
(2 used in this step )
①
M10 x 40 mm Wood Dowel
(2 used in this step)
③
