ASSEMBLY AND CARE GUIDE
MAINSTAYS RICHMOND HILLS 7-PIECE OUTDOOR
PATIO SOFA SECTIONAL SET - BEIGE
Contact our toll free Customer Service Hotline at:
[phone]
-Monday through Friday 7:30am until 3:30pm PST-

Warranty
2 YEAR LIMITED WARRANTY
WHAT IS COVERED
We warrant the frame to be free of manufacturing defects to the original purchaser for two years.
WHAT IS NOT COVERED
This warranty does not cover commercial use, hardware, acts of nature, fire, freezing, and abusive use. In
addition, purchased parts are not covered under this warranty. We reserve the right to make substitutions
with similar merchandise, if the model in question is no longer in production.
Important Safety Instructions
PLANNING ASSEMBLY
Read all instructions before assembly
To avoid damanging this product, assembly it on a soft non-abrasive surface such as carpet or carboard.
NOTE: More than one person may be required to assemble this product.
Attention
○Use the correct bolts as indicated. Do not tighten any of the bolts until the product is completely assembled
○Do not discard of any of the packaging until you have checked that you have all of the parts and fittings
required
○Keep children away during assembly. This item contains small parts that can be swallowed by children.
Children should always be under direct adult supervision while using this product.
○Retain these assembly instruction for future reference.
MSS129900298079
1

MSS129900298079
No. Qty Picture
A
B
C
1
1
1
1
D
BB
A. Read instructions thoroughly. Acquaint yourself with the inventory of parts and the accompanying
drawings to ensure safe and proper assembly.
B. Lay out all of the parts on a flat surface and identify them using the table below.
C. One ratchet tool is provided used for installation.
2
Seat Panel
Back
Left Frame
Right Armrest
Bolt
M6X18
Bolt
M6X30
Bolt
M6X55
Ratchet Tool
AA
DD
CC
4
3
2
Right Armchair
No. Qty Picture
E
F
G
1
1
1
1
H
BB
Seat Panel
Back
Right Frame
Left Armrest
Bolt
M6X18
Bolt
M6X30
Bolt
M6X55
Ratchet Tool
AA
DD
CC
4
3
2
Left Armchair

MSS129900298079
3
No. Qty Picture
I
J
C
1*2
1*2
1*2
1*2
G
BB
Seat Frame
Back
Left Frame
Right Frame
Bolt
M6X18
Bolt
M6X30
Bolt
M6X55
Ratchet Tool
AA
DD
CC
4*2
4*2
2*2
Armless Chair*2
No. Qty Picture
K
L
M
1
1
1
1
C
BB
Seat Panel
Back
Right Armrest
Left Frame
Bolt
M6X18
Bolt
M6X30
Bolt
M6X55
Ratchet Tool
AA
DD
CC
4
4
2
Corner Sofa
No. Qty Picture
N
O
1*2
4*2
Seat Panel
Leg
Bolt
M6X18
Ratchet Tool
AA
DD
8*2
Foot Stool*2

Assembly
Step 1: Insert seat panel(A) into the hole of back(B), then assemble by using bolts(CC) and ratchet tool
(DD) as below picture.
Step 2: Attach left frame(C) to the seat panel(A) and back(B) using two bolts(AA) at front and two bolts
(BB) at the back.Then attach right armrest(D) to seat panel(A) and back(B) using two bolts(AA)
at front and one bolt(BB) at the back.
MSS129900298079
Note: Do not tighten bolts until all parts are connected
Step 1. Step 2.
Right Armchair
Step 1: Insert seat panel(E) into the hole of back(F), then assemble by using bolts(CC) and ratchet
tool(DD) as below picture.
Step 2: Attach right frame(G) to the seat panel(E) and back(F) using two bolts(AA) at front and two
bolts(BB) at the back. Then attach left armrest(H) to seat panel(E) and back(F) using two
bolts(AA) at front and one bolt(BB) at the back.
Step 1. Step 2.
Left Armchair
Note: Do not tighten bolts until all parts are connected
4
Note:pay attention to the direction of seat panel(A).
Note:pay attention to the direction of seat panel(E).

Assembly
four bolts(BB) at the back.
MSS129900298079
Step 1. Step 2.
Armless Chair
Note: Do not tighten bolts until all parts are connected
Step 1: Insert seat panel(I) into the hole of back(J), then assemble by using bolts(CC) and ratchet tool
(DD) as below picture.
Step 2: Attach left&right frame(C&G) to the seat panel(I) and back(J) using four bolts(AA) at front and
Step 1: Insert seat panel(K) into the hole of back(L), then assemble by using bolts(CC) and ratchet tool
(DD) as below picture.
Step 2: Attach right armrest(M) to the seat panel(K) and back(L) using two bolts(AA) at front and two bolts
(BB) at the back.
Step 3: Attach left frame(C) to the seat panel(K) and back(L) using two bolts(AA) at front and two bolts(BB)
at the back.
Step 1. Step 2. Step 3.
Corner Sofa
Note: Do not tighten bolts until all parts are connected
5
Note:pay attention to the direction of seat panel(I).
Note:pay attention to the direction of seat panel(K).

Assembly
Step 1:
MSS129900298079
Note: Do not tighten bolts until all parts are connected.
Step 1.
Foot Stool
Attach four legs(O) to seat panel(N) using bolts(AA) and ratchet tool(DD).
6
Maintenance
We recommend the use of furniture covers when not in use.
In order to prolong the life and beauty of your furniture , we recommend that it be stored in a dry and
protected area during off season periods.
.
○
○
○
Inspect and tighten all bolts and fasteners on a regular basis to ensure the proper performance and
safety of your product.
