Mainstays STACK MS16-D4-1007-02 User manual

PB 1
model# MS16-D4-1007-02
Lot#_________Date________
Customer Service:
1.877.436.7290
[email protected]
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Manufactured By:
BDDMI
1321 Tyler St NE, Minneapolis, MN 55413
Assembly Instructions
STACK DESK

2
LEFT SIDE PANEL
DESK BOTTOM PANEL
LEFT DESK SIDE PANEL
RIGHT DESK SIDE PANEL
DESK TOP PANEL
DESK BACK PANEL
STORAGE LEFT SIDE PANEL
STORAGE RIGHT SIDE PANEL
STORAGE TOP PANEL
STORAGE BOTTOM PANEL
STORAGE BACK PANEL
ADJUSTABLE SHELF [X2]
A
B
C
D
E
F
G
H
I
J
K
L
Before you begin:
1. Check for damaged or missing parts.
2. Use the carton as a working surface to prevent product damage during assembly.
TOOLS NEEDED
Hammer Flat Head Screwdriver Phillips Head Screwdriver
PARTS LIST

2 3
HARDWARE LIST
CAUTION:
1. Make sure the screws go through the pre-drilled holes properly.
2. Do not over tighten bolts.
5. Brown Cam Cover
x2
3. Cam
x18
4. Black Cam Cover
x8
1. Wooden Dowel
x25
2. Cam Bolt
x18
6. White Cam Cover
x10

4
HARDWARE LIST
CAUTION:
1. Make sure the screws go through the pre-drilled holes properly.
2. Do not over tighten bolts.
11. Shelf Pin
x8
9. Binding Bolt
x2
10. Flat Head Screw
x4
7. Allen Wrench
x2
8. Bolt
x4
12. Washer
x2

4 5
HARDWARE LIST
CAUTION:
1. Make sure the screws go through the pre-drilled holes properly.
2. Do not over tighten bolts.
15. Truss Head Screw
x1
16. Wall Screw
x1
13. Wall Anchor
x1
14. Wall Strap
x1

6
1 2
3 4 5
180º
HOW TO USE THE CAM LOCK SYSTEM

6 7
x4 x4 x4 x4
STEP 1
1. Carefully tap small wooden dowels into place. Leave 1/2”of the dowels sticking out.
2. Screw-In cam bolts must be screwed down ush.
3. Refer to page 6 for instructions on how to use the cam lock system.
1. Wood
D o w e l
2. Cam Bolt 3. Cam 4. Black Cam
Cover
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.

8
x4 x4 x4 x4
STEP 2
1. Carefully tap small wooden dowels into place. Leave 1/2”of the dowels sticking out.
2. Screw-In cam bolts must be screwed down ush.
3. Refer to page 6 for instructions on how to use the cam lock system.
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.
1. Wood
D o w e l
2. Cam Bolt 3. Cam 4. Black Cam
Cover

8 9
x4 x4 x4 x4
STEP 3
1. Carefully tap small wooden dowels into place. Leave 1/2”of the dowels sticking out.
2. Screw-In cam bolts must be screwed down ush.
3. Refer to page 6 for instructions on how to use the cam lock system.
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.
1. Wood
D o w e l
2. Cam Bolt 3. Cam 6. White Cam
Cover

10
x2 x2 x2
STEP 4
1. Carefully tap small wooden dowels into place. Leave 1/2”of the dowels sticking out.
2. Screw-In cam bolts must be screwed down ush.
3. Refer to page 6 for instructions on how to use the cam lock system.
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.
1. Wood
D o w e l
2. Cam Bolt 3. Cam

10 11
x4 x4
1. Carefully tap small wooden dowels into place. Leave 1/2”of the dowels sticking out.
2. Make sure the screws go through the pre-drilled holes properly.
3. Do not over tighten screws.
STEP 5
1. Wood
Dowel
10. Flat Head
Screw
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.

12
x6 x2
x2
x2
x2
x2
x2
6
5
STEP 6
1. Carefully tap small wooden dowels into place. Leave 1/2”of the dowels sticking out.
2. Screw-In cam bolts must be screwed down ush.
3. Refer to page 4 for instructions on how to use the cam lock system.
4. Make sure the bolts go through the pre-drilled holes properly.
5. Do not over tighten bolts.
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.
1. Wood
D o w e l
2. Cam Bolt
7. Allen
Wrench
6. White
Sticker
9. Binding
Bolt
5. Brown
Sticker
8. Bolt

12 13
x1 x2
1. Carefully tap small wooden dowels into place. Leave 1/2”of the dowels sticking out.
2. Make sure the screws go through the pre-drilled holes properly.
3. Do not over tighten screws.
STEP 7
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.
1. Wood
Dowel
2. Cam Bolt

14
x1 x2
STEP 8
1. Make sure the bolts go through the pre-drilled holes properly.
2. Do not over tighten bolts.
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.
7. Allen
Wrench
8. Bolt

14 15
x4 x4
STEP 9
1. Refer to page 4 for instructions on how to use the cam lock system.
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.
3. Cam 6. White
Sticker

16
x8
STEP 10
1. Insert shelf supports into desired holes. Dierent holes accommodate dierent shelf heights.
2. Angle shelves to t between the rails and set on top of shelf supports.
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.
11. Shelf Pin

16 17
x1x1x1x1
x2
13
16
12
15
12
14
STEP 11
15. Truss
Head Screw
16. Wall
Screw
14. Wall
Strap
12. Washer
13. Wall
Anchor
position against wall
mark position of strap hole on wall
drill 1/4”hole
tap in wall anchor
fasten anti-tip strap with wall
screw provided
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.

18
50 lbs. / 22.7 kg.
25 lbs. / 11.3 kg.
25 lbs. / 11.3 kg.
25 lbs. / 11.3 kg.
25 lbs. / 11.3 kg.
WARNING: Do not exceed the maximum load capacity. Exceeding the maximum load capacity may result in
collapse and possible injury.
Furniture Care Instructions:
Dust with clean, lint-free cloth.
Use furniture spray polish as needed.
Customer Service:
877.436.7290
[email protected]
Your complete satisfaction is our number 1 priority. Our product is designed and manufactured to meet the
highest quality of standards. In the event that you have assembly questions, or parts are missing or damaged,
our customer service department would appreciate the opportunity to assist you.
This product carries a one (1) year warranty against defects in workmanship and materials. Defective product
will be replaced free of charge within the stated warranty period, when returned by the original purchaser with
proof of purchase. This product is not guaranteed against wear or breakage due to misuse and/or abuse. Please
contact our Customer Service at 1-877-436-7290 to obtain information on warranty performance. This warranty
gives you specic legal rights and you may also have other rights which vary from State to State.
!WARNING
Serious or fatal crushing injuries can occur
from furniture tip-over. To help prevent
tip-over:
• Install tip-over restraint provided.
• Place heaviest items in the lowest drawers.
• Do not set TV’s or other heavy objects on top
of this product, unless the product is
specifically designed to accommodate them.
• Never allow children to climb or hang on drawers,
doors, or shelves.
• Never open more than one drawer at a time.
(OR)
• Do not defeat or remove the drawer interlock
system.
Use of tip-over restraints may only reduce,
but not eliminate, the risk of tip-over.
This is a permanent label. Do not remove.

PB 1
model# MS16-D4-1007-02
Lot#_________Fecha_______
Servicio al Cliente:
1.877.436.7290
[email protected]
ESTE MANUAL DE INSTRUCCIONES CONTIENE INFORMACIÓN IMPORTANTE DE SEGURIDAD.
POR FAVOR LEA Y GUARDE PARA REFERENCIA FUTURA.
Fabricado Por :
BDDMI
1321 Tyler St NE, Minneapolis, MN 55413
ESCRITORIO STACK
Instrucciones de Ensamble

2
Antes de comenzar:
1. Compruebe si hay piezas dañadas o faltantes.
2. Utilice la caja de cartón como supercie de trabajo para evitar daños al producto durante el montaje.
PANEL DEL LADO IZQUIERDO
PANEL INFERIOR DEL ESCRITORIO
PANEL IZQUIERDO DEL ESCRITORIO
PANEL DERECHO DEL ESCRITORIO
PANEL SUPERIOR DEL ESCRITORIO
PANEL POSTERIOR DEL ESCRITORIO
PANEL LATERAL IZQUIERDO DEL ALMACENAMIENTO
PANEL LATERAL DERECHO DEL ALMACENAMIENTO
PANEL SUPERIOR DEL ALMACENAMIENTO
PANEL INFERIOR DEL ALMACENAMIENTO
PANEL POSTERIOR DEL ALMACENAMIENTO
REPISA AJUSTABLE [X2]
A
B
C
D
E
F
G
H
I
J
K
L
Martillo Destornillador de Cabeza Plana Destornillador Phillips
HERRAMIENTAS NECESARIAS
LISTA DE PARTES
