Mainstays Z005.2318-MP User manual

MAINSTAYS 42" ROUND
MODERN DINING TABLE STOCK # Z005.2318-MP
WARNING:
ADULT ASSEMBLY REQUIRED
RECOMMENDED NUMBER OF PEOPLE FOR ASSEMBLY: 2
ESTIMATED ASSEMBLY TIME: 30 MIN
Manufactured By: Saigon Furniture Co.,Ltd.
Zhejiang , China
We are available to assist you Monday - Friday
from 9:00 am - 5:00 pm Eastern Standard Time.
1-877-637-3590
MAXIMUM LOAD 110 LB (50KG)
TEL: [phone] EMAIL: [email protected]
● CALL OUR TOLL FREE NUMBER 1-877-637-3590 FOR ASSISTANCE.WE ARE AVAILABLE TO ASSIST YOU
MONDAY-FRIDAY FROM 9am-5pm EASTERN STANDARD TIME OR SEND US YOUR QUESTIONS TO
[email protected].
● ADDITIONAL PARTS ARE AVAILABLE FOR A FEE.
● THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
● DO NOT ALLOW CHILDREN TO CLIMB OR PLAY ON THE UNIT.
● CLEAN THE PRODUCT WITH YOUR FAVORITE FURNITURE POLISH AND A SOFT CLOTH.
● DO NOT USE HARSH CHEMICALS OR ABRASIVE CLEANERS.
● MOVE YOUR NEW FURNITURE CAREFULLY WITH TWO PEOPLE. NEVER PUSH OR DRAG THE UNIT.
FOR MISSING OR DAMAGED PARTS,PLEASE CALL
1-877-637-3590 BEFORE RETURNING THE PRODUCT
TO STORE. PARTS WILL BE SHIPPED FREE OF
CHARGE WITHIN 90DAYS OF PURCHASE WITH
PROOF OF PURCHASE.PLEASE CALL OUR TOLL
FREE NUMBER OR E-MAIL TO
[email protected]
FOR PROMPT, RELIABLE SERVICE, PLEASE
HAVE YOUR ASSEMBLY MANUAL READY.
LOT NUMBER
DATE OF PURCHASEDATE OF PURDATE OF PURC

STOCK # Z005.2318-MP
DO NOT USE POWER TOOLS TO ASSEMBLE
YOUR FURNITURE. POWER TOOLS MAY
DAMAGE THE PARTS AND RESULT IN
DAMAGE.
BEFORE STARTING
Manufactured By: Saigon Furniture Co.,Ltd.
Zhejiang , China
We are available to assist you Monday - Friday
from 9:00 am - 5:00 pm Eastern Standard Time.
1-877-637-3590
MAINSTAYS 42" ROUND
MODERN DINING TABLE
Bolt M6x20mm
Qty: 6 (2 for spare)
Bolt M6x45mm
Qty: 10 (2 for spare)
Gasket M6x18mm
Qty: 6 (2 for spare)
Nut
Qty: 10 (2 for spare)
Allen Wrench
Qty: 1
Wrench
Qty: 1
2
1 2 3
4 5 6
TEL: [phone] EMAIL: [email protected]
● Read and understand all the steps carefully before starting. Please
follow the steps in the correct orders to avoid difficulties or damages
to the parts during assembly.If each step is not followed in the
correct order the assembly will be difficult and may result in
damages.
● Work in a spacious area, preferably on a carpeted surface, near
where the unit will be used.
●Make sure all the parts are included. Most boards are labeled with a
removable sticker.

STOCK # Z005.2318-MP
VERIFY THAT ALL PARTS ARE
LISTED BEFORE BEGINNING
MAINSTAYS 42" ROUND
MODERN DINING TABLE
Table top
(Qty: 1)
Wooden legs
(Qty: 4)
Bottom foot
(Qty: 4)
Metal angel bracket
(Qty: 4)
Metal crosses
(Qty: 4)
3
A
BC
DE

Assemble the metal bottom foot E and the wooden leg D.
1
4
2
x 4
1
Bolt M6x20mm
Install the metal angel bracket B on the back of the tabletop A with a
bolts and a gasket . Place the angle bracket B in the right
position as indicated in the drawing.
ATTENTION: TIGHTEN THE SCREW AT 50% ONLY.
E
D
B
1
1 3
1
3
5
3
1
3
1
3
1
3
x 4
3
Gasket
x 1
5
Gasket
Long side
Short side
A
BB
B
B

5
Place the metal crosses C on the back of tabletop A in the right position
as indicated in the drawing.
x 4
2
Bolt M6x45mm
x 4
4
Nut
Install the wooden leg D from the top on the long edge of the angle
bracket B, fix the bolts and nut through the upper hole.
x 1
6
Wrench
2 4
3 4
C
C
C
C
A
D
DD
D
BB
2
2
2
2
4
4
44
6
5
50%
Middle hole
Top hole
Outside
Inside
ATTENTION: KEEP OUTWARD THE BIGGER OUTCUT OF HOLE.
TIGHTEN THE SCREW AT 50% LNLY.

6
x 4
Assemble the wooden legs D and the metal crosses C by fixing the bolts
and nut through the lower hole.
2
Bolt M6x45mm
Fully tighten all bolts & and nuts installed in previous steps.
Put the table on the floor. Adjust the metal bottom foot E to stabilize
the table.
2 4 1 2
x 4
4
Nut
5 6
D
DD
D
22
2
2
4
44
4
6
5
50%
ATTENTION:
KEEP OUTWARD THE BIGGER
OUTCUT OF HOLE. TIGHTEN
THESCREW AT 50% LNLY.
ATTENTION: 100% TIGHTEN ALL BOLTS
100%
C
C
100%
100%

7
Parts
Hardware
1
4
56
2 3
7
B
B
B
B
D
D
D
D
E
EE
E
C
C
C
C
A
Table top
Metal angel bracket
Metal crosses
Wooden legs
Bottom foot
M6 x 20mm Bolt
M6 x 45mm Bolt
M6 Gasket
M6 Nut
Allen Wrench
Wrench
If you need to order parts please use the list below.
Please email defect photo and proof of purchase to [email protected]
Parts will be shipped free of charge within 90 days of purchase with proof of purchase.
Spare parts and services only support the purchase made from Walmart store or Walmart.com
