Parts Breakdown BML184
Page 1 of 2 8/18/2010

Parts Breakdown BML184
Fig # Part ID Part Name Quantity
Products with multiple versions are listed in subsiding order with the newest version on top not indented
1 GM00001021 REFLECTOR, BML184 1
2 A-94502 LIGHT BULB SET,BML184 1
3 GM00001020 BULB HOLDER, BML184 1
4 GM00001019 LOCK RING, BML184 1
5 GM00001017 LAMP COVER, BML184 1
6 GM00001023 ABSORBER, BML184 1
7 SM00000050 FLUORESCENT TUBE, BML184 1
8 SM00000190 RING, ML123 1
9 GM00001024 SCREW 3X12, BML184 6
10 GM00001047 HOUSING SET, BML184 1
11 GM00001025 SWITCH, BML184 1
12 SM00000190 RING, ML123 1
13 GM00001049 PCB, BML184 1
14 GM00000530 BATTERY HOLDER,BML184 1
14 GM00001117 BATTERY HOLDER, BML184 1
15 GM00001022 SWITCH COVER, BML184 1
16 GM00001018 HOLDER, BML184 1
17 GM00001047 HOUSING SET, BML184 1
1,001 GM00001027 METAL HOOK, BML184 1
1,002 GM00001028 SHOULDER HOOK SET,BML184 1
5,001 810321-0 N/A 1
Page 2 of 2 8/18/2010
