Makita DPT353 User manual

DPT353
EN Cordless Pin Nailer INSTRUCTION MANUAL 5
PL Sztyfciarka akumulatorowa INSTRUKCJA OBSŁUGI 11
HU Akkumulátoros szögbelövő HASZNÁLATI KÉZIKÖNYV 18
SK Akumulátorová klincovačka NÁVOD NA OBSLUHU 24
CS Akumulátorová sponkovačka NÁVOD K OBSLUZE 30
UK Акумуляторний
цвяхозабивний інструмент ІНСТРУКЦІЯ З ЕКСПЛУАТАЦІЇ 36
RO Capsator fără r pentru cuie MANUAL DE INSTRUCŢIUNI 43
DE Akku-Pintacker BETRIEBSANLEITUNG 49

1
2
3
Fig.1
1
2
Fig.2
1
Fig.3
1
2
Fig.4
A
B
Fig.5
AB
1
Fig.6
2
13
Fig.7
1
Fig.8
2

3
2
4
1
Fig.9
4
3
1
2
Fig.10
Fig.11
1
2
3
Fig.12
1
Fig.13
4
1
3
2
Fig.14
1
2
Fig.15
3

Fig.16
Fig.17
1
2
Fig.18
1
2
3
Fig.19
4

5ENGLISH
ENGLISH (Original instructions)
SPECIFICATIONS
Model: DPT353
Pin nail size ø0.6 mm x 15, 18, 25, 30, 35 mm
Pin nail magazine capacity 100 pcs.
Dimensions without hook (L x W x H) 257 mm x 79 mm x 226 mm
Rated voltage D.C. 18 V
Battery cartridge BL1815, BL1815N, BL1820,
BL1820B
BL1830, BL1830B, BL1840,
BL1840B, BL1850, BL1850B,
BL1860B
Net weight 2.0 kg 2.2 kg
• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange
without notice.
• Specicationsandbatterycartridgemaydifferfromcountrytocountry.
• Weight,withbatterycartridge,accordingtoEPTA-Procedure01/2003
Intended use
Thetoolisintendedforpressingpinnailsintoconstruc-
tionmaterialssuchastimbers.
Noise
ThetypicalA-weightednoiseleveldeterminedaccord-
ingtoEN60745:
Soundpressurelevel(LpA):76dB(A)
Uncertainty(K):3dB(A)
Thenoiselevelunderworkingmayexceed80dB(A).
WARNING: Wear ear protection.
Vibration
ThevibrationtotalvaluedeterminedaccordingtoEN60745:
Vibrationemission(ah):2.5m/s2or less
Uncertainty(K):1.5m/s2
NOTE: Thedeclaredvibrationemissionvaluehasbeen
measured in accordance with the standard test method
andmaybeusedforcomparingonetoolwithanother.
NOTE: Thedeclaredvibrationemissionvaluemay
alsobeusedinapreliminaryassessmentofexposure.
WARNING: Thevibrationemissionduringactual
useofthepowertoolcandifferfromthedeclaredemission
value depending on the ways in which the tool is used.
WARNING:Besuretoidentifysafetymeasures
toprotecttheoperatorthatarebasedonanestima-
tionofexposureintheactualconditionsofuse(taking
accountofallpartsoftheoperatingcyclesuchas
thetimeswhenthetoolisswitchedoffandwhenitis
running idle in addition to the trigger time).
EC Declaration of Conformity
For European countries only
TheECdeclarationofconformityisincludedasAnnexA
to this instruction manual.
SAFETY WARNINGS
General power tool safety warnings
WARNING: Read all safety warnings, instruc-
tions, illustrations and specications provided
with this power tool.Failuretofollowallinstructions
listedbelowmayresultinelectricshock,reand/or
seriousinjury.
Save all warnings and instruc-
tions for future reference.
Theterm"powertool"inthewarningsreferstoyour
mains-operated(corded)powertoolorbattery-operated
(cordless) power tool.
Cordless nailer safety warnings
1. Always assume that the tool contains fasten-
ers.Carelesshandlingofthenailercanresultin
unexpectedringoffastenersandpersonalinjury.
2. Do not point the tool towards yourself or any-
one nearby. Unexpected triggering will discharge
thefastenercausinganinjury.
3. Do not actuate the tool unless the tool is
placed rmly against the workpiece.Ifthetool
isnotincontactwiththeworkpiece,thefastener
maybedeectedawayfromyourtarget.
4. Disconnect the tool from the power source
when the fastener jams in the tool. While
removingajammedfastener,thenailermaybe
accidentallyactivatedifitispluggedin.
5. Use caution while removing a jammed fas-
tener.Themechanismmaybeundercompression
andthefastenermaybeforcefullydischarged
whileattemptingtofreeajammedcondition.
6.
Do not use this nailer for fastening electrical
cables. Itisnotdesignedforelectriccableinstalla-
tionandmaydamagetheinsulationofelectriccables
therebycausingelectricshockorrehazards.
