Parts Breakdown HM1800
Page 1 of 5 2/8/2008

Parts Breakdown HM1800
Page 2 of 5 2/8/2008

Parts Breakdown HM1800
Fig # Part ID Part Name Quantity
1 322566-3 SCREW SEAL, HM1800 1
2 211256-2 B. BEARING 6203LLB, GA7001L 1
3 267706-5 WASHER 17, HM1800 1
4 514990-6 ARMATURE ASS'Y 115V, HM1800 1
5 681624-7 INS. WASHER, HM1800,T1 1
5 681635-2 INSULATION WASHER, HM1211B 1
5 681646-7 INSULATION WASHER, HM1800 1
6 211066-7 B. BEARING 6200LLB, BO4552 1
7 213406-5 O RING 30, HR5000 1
8 159530-9 MOTOR HSG. B COMP., HM1800 1
9 191957-7 A.C.CARBON BR.SET,CB-204,HM1800 1
10 643700-5 BRUSH HOLDER CAP 7-18 , HM1500B 2
10 643710-2 BRUSH HOLDER CAP, HM1800 2
11 941151-9 F. WASHER 6, 5007NB 4
12 922341-3 H.S.H. BOLT M6X25, HM1100C 4
12 265914-2 H.S.H.BOLT M6X25, HM1211B 4
13 240024-6 FAN 100, HM1800 1
13 241854-8 FAN 100, HM1800, T1 1
14 253165-9 F. WASHER 8, 4303C 1
14 942201-3 SPRING WASHER 8, 2414NB 1
15 931402-8 HEX NUT M8, 5037NB 1
15 252105-4 HEX LOCK NUT M8-13, HM1800 1
16 265344-7 HEX BOLT M5X85, HM1800 2
17 624951-9 FIELD 115V, HM1800 1
18 414787-2 MOTOR HOUSING A, HM1800 1
19 212358-7 NEEDLE BEARING 2520, HM1800 1
20 254001-2 WOODRUFF KEY 4, HM1303B 2
21 213507-9 O RING 40, HR1821 1
22 256151-9 PIN 5, HM1800 1
23 159531-7 GEAR HSG. COMP., HM1800 1
23 153368-4 N/A 1
24 211209-1 BALL BEARING 6202, HM1211 1
25 254001-2 WOODRUFF KEY 4, HM1303B 2
26 226251-9 SPUR GEAR 22, HM1800 1
27 211361-5 BALL BEARING 6305LLB, HM1800 1
28 213476-4 OIL SEAL 35, HM1800 1
29 213721-7 O RING 61, HM1800 1
30 213806-9 O RING 90, HM1500 1
31 152414-0 CRANKSHAFT COMP., HM1800 1
32 159659-1 CRANK HOUSING, HM1800, T2 1
32 153370-7 N/A 1
32 153370-7 N/A 1
32 316550-8 CRANK HOUSING, HM1800 1
33 213806-9 O RING 90, HM1500 1
34 414785-6 CRANK HOUSING CAP, HM1800 1
35 414786-4 CAP COVER, HM1800 1
36 251390-6 P.H.SCREW M5X18, HM1800 4
37 221793-8 HELICAL GEAR 50, HM1800 1
38 211209-1 BALL BEARING 6202, HM1211 1
39 922496-4 H.S.H. BOLT M8X75, HM1800 4
40 262526-2 RUBBER SLEEVE 8, HM1800,T1 1
40 262538-5 RUBBER SLEEVE 8, HM1800 (T2) 1
41 251389-1 C.H.SCREW M8, HM1800 1
42 322481-1 HANDLE BASE, HM1800,T1 1
42 324062-7 HANDLE BASE, HM1800(T3) 1
42 322847-5 HANDLE BASE, HM1800 (T2) 1
43 414807-2 SIDE HANDLE, HM1800 1
43 418415-1 SIDE HANDLE, HM1800 1
44 941152-7 F. WASHER 6, HM1500 4
45 922341-3 H.S.H. BOLT M6X25, HM1100C 4
Page 3 of 5 2/8/2008

Parts Breakdown HM1800
46 254001-2 WOODRUFF KEY 4, HM1303B 2
47 931602-0 HEX NUT M12, 2708 2
48 942301-9 SPRING WASHER 12, HM1800 2
49 941301-6 F. WASHER 12, HM1800 2
50 322565-5 HANDLE SHAFT, HM1800 1
51 415148-9 NYLON BUSH 15, HM1800 2
52 316792-4 GEAR HOUSING COVER, HM1800 (T2) 1
52 317584-4 N/A 1
52 316311-6 GEAR HSG. COVER, HM1800,T1 1
53 211214-8 BALL BEARING 6302, HM1800 1
54 961060-6 RETAINING RING S-20, 2708 1
55 226242-0 SPUR GEAR 47, HM1800 1
56 331416-1 SLEEVE 25, HM1800 1
57 962301-3 RETAINING RING R-62, HM1800 1
58 922331-6 H.S.H. BOLT M6X20, LS1013 4
59 941152-7 F. WASHER 6, HM1500 4
60 419324-7 MOTOR HSG COVER, HM1800 1
60 414788-0 MOTOR HSG. COVER, HM1800 1
61 322476-4 CONNECTING ROD, HM1800 1
62 213469-1 O RING 35, HM1800 1
63 268061-8 PIN 15, HM1800 1
63 257653-8 SLEEVE 8, HM1800,T1 1
64 322480-3 PISTON CYLINDER, HM1800 1
65 213666-9 O RING 52, HM1800 1
66 322563-9 STRIKER, HM1800 1
67 262050-5 RUBBER RING 54, HM1500 1
68 322548-5 CYLINDER B, HM1800 1
69 213660-1 O RING 53, HM1500 1
70 922677-0 H.S.H.BOLT M12X55, HM1800 4
71 942301-9 SPRING WASHER 12, HM1800 4
72 316313-2 CYLINDER A, HM1800 1
72 317585-2 N/A 1
73 213805-1 O RING 85, HM1800 1
74 322560-5 RETAINER RING, HM1800 2
75 233083-7 COMP. SPRING 12, HM1800 2
76 322477-2 TOOL RETAINER POLE, HM1500B 2
77 256219-1 PIN 4, HM1500 2
78 322478-0 TOOL RETAINER, HM1500B 1
78 324236-0 TOOL RETAINER, HM1800 1
79 324238-6 TOOL RETAINER SHAFT, HM1800 1
79 322550-8 TOOL RETAINER SHAFT, HM1500B 1
80 951272-9 SPRING PIN 8-40, HM1500B 2
81 265989-1 H.S.BOLT M12X45, HM1800 4
82 253989-3 SPRING WASHER 12, HM1500 4
83 322551-6 TOOL HOLDER 29,HM1800 1
84 213755-0 O RING 75, HM1500 1
85 213517-6 X RING 40, HM1500 1
86 322564-7 IMPACT BOLT, HM1800 1
87 213667-7 O RING 61, HM1800 1
88 322549-3 IMPACT BOLT HOLDER, HM1800 1
89 664290-5 CORD (2X14X16), HM1800 1
90 682547-2 CORD GUARD 15, HM1800 1
91 922341-3 H.S.H. BOLT M6X25, HM1100C 4
91 922381-1 H.S.H. BOLT M6X60, HM1800 4
92 941152-7 F. WASHER 6, HM1500 4
93 182553-2 HANDLE SET, HM1800,T1 1
94 322847-5 HANDLE BASE, HM1800 (T2) 1
94 324062-7 HANDLE BASE, HM1800(T3) 1
94 322481-1 HANDLE BASE, HM1800,T1 1
95 233051-0 COMP. SPRING 46, HM1800,T1 2
95 233149-3 COMPRESSION SPRING 12, HM1800 (T2) 1
Page 4 of 5 2/8/2008

Parts Breakdown HM1800
96 953106-2 RIVET 0-5, HM1500 4
97 850639-7 N/A 1
97 857090-2 NAME PLATE, HM1800 1
98 922356-0 H.S.H.BOLT M6X35, HM1500 3
99 317583-6 N/A 1
99 316312-4 REAR CASE, HM1800 1
100 256151-9 PIN 5, HM1800 1
102 687066-3 STRAIN RELIEF HM1800 1
103 265999-8 TAPPING SCREW M4X25, HM1800 2
104 182553-2 HANDLE SET, HM1800,T1 1
105 911248-8 P.H. SCREW M5X28, HM1500 3
108 651131-4 SWITCH, HM1800 1
109 414046-4 SWITCH LEVER, 9627 1
109 418332-5 SWITCH LEVER, HM1800 1
110 421330-0 DUST COVER, 9627 1
111 341397-1 PLATE 50, HM1303B 1
111 153666-6 PLATE 50 COMPLETE 1
112 442009-0 PACKING 50, HM1303B 1
113 911211-1 P.H. SCREW M5X12, HM1500B 4
114 421484-3 CUSHION RUBBER, HM1800 1
115 265995-6 TAPPING SCREW 4X18, 4323K 2
116 418331-7 SWITCH COVER, HM1800 1
117 418333-3 HANDLE, HM1800 1
118 421850-4 DUST PLATE, HM1800 1
119 256206-0 PIN 4, T220DW 1
120 345355-9 SUPPORT, HM1800 1
121 265995-6 TAPPING SCREW 4X18, 4323K 2
122 418334-1 HANDLE SUB BASE, HM1800 1
122 419044-3 HANDLE SUB BASE, HM1800 1
1,001 783203-8 HEX WRENCH 5, 2708 1
