Parts Breakdown 6821
Page 1 of 2 2/8/2008

Parts Breakdown 6821
Fig # Part ID Part Name Quantity
1 152483-1 LOCATOR 1/4, 6821 1
2 213373-4 O RING 22, GEO600 1
3 415570-0 LOCK RING, 6821 1
4 421519-0 DUST RING, 6821 1
5 214154-9 P. BEARING 14, 6820V 1
6 421392-8 RING 20, 6820V 1
7 216001-0 STEEL BALL 3.5, 6800DBV 1
8 223107-7 SPINDLE, 6821 1
9 233126-5 COMP. SPRING 6, 6832 1
10 256699-1 PIN 8, 6832 1
11 226444-8 HELICAL GEAR 46, 6821 1
12 256439-7 PIN 4, 6821-T1 3
12 256467-2 PIN 4, 6821-T2 3
13 212047-4 THRUST NEEDLE BEARING 821, 6821 1
14 152531-6 BEARING BOX COMPL., 6821 1
15 232050-9 LEAF SPRING, 6820V 1
16 211031-6 BALL BEARING 608LLB, HR2400 1
17 241881-5 FAN 52, 6904VH 1
18 517151-7 ARMATURE ASSEMBLY, 115V, 6821 1
19 211028-5 B. BEARING 627LB, 6510LVR 1
20 633321-1 FIELD 115V, 6821 1
21 232147-4 LEAF SPRING, 6821 1
22 911138-5 P.H. SCREW M4X20, 9218SB 9
23 858465-8 NAME PLATE 1
24 182856-4 HOUSING SET, 6821 1
24 182856-4 HOUSING SET, 6821 1
25 660061-8 CORD, BO4550,T1 1
25 660069-2 CORD 1
26 651935-4 SWITCH, HP2030-T1 1
26 651986-7 SWITCH, 6410 1
26 651987-5 SWITCH, HP2040 1
26 651987-5 SWITCH, HP2040 1
26 651987-5 SWITCH, HP2040 1
27 191927-6 CARBON BRUSH SET CB-407, 6821 1
28 643923-5 BRUSH HOLDER, HR2410 2
28 643936-6 BRUSH HOLDER, 6821 2
29 182856-4 HOUSING SET, 6821 1
29 182856-4 HOUSING SET, 6821 1
30 819063-3 MAKITA LABEL, 6992DWDE 1
1,001 784807-9 MAGNETIC BIT HOLDER, 6820V 1
1,002 784211-2 INSERT BIT 2-25, 6800DBV 1
5,001 810146-2 N/A 1
Page 2 of 2 2/8/2008
