Makita 6824 Quick start guide

Parts Breakdown 6824
Page 1 of 3 2/8/2008

Parts Breakdown 6824
Fig # Part ID Part Name Quantity
1 151726-8 LOCATOR CPL., 6823 1
2 421631-6 DUST SEAL RING, 6823 1
3 213373-4 O RING 22, GEO600 1
4 416994-3 LOCK RING., 6823 1
5 232154-7 LEAF SPRING, 6823 1
5 232154-7 LEAF SPRING, 6823 1
6 265999-8 TAPPING SCREW M4X25, HM1800 3
7 151720-0 GEAR HOUSING CPL., 6824, 6825 1
8 421710-0 RING 20, 6823,T1 1
8 421766-3 RING 20, 6827 1
8 421766-3 RING 20, 6827 1
9 232050-9 LEAF SPRING, 6820V 1
10 216001-0 STEEL BALL 3.5, 6800DBV 1
11 151788-6 SPINDLE CPL,6823 1
12 233257-0 COMP. SPRING 8., 6823 1
13 267202-3 FLAT WASHER 8., 6823 2
14 151790-9 GEAR COMPRESSION, 6824 1
15 256439-7 PIN 4, 6821-T1 3
15 256467-2 PIN 4, 6821-T2 3
15 256467-2 PIN 4, 6821-T2 3
16 216213-5 WASHER 824, 6824 1
17 216415-3 THRUST NEEDLE GAUGE 821, 6824 1
18 216212-7 WASHER 821, 6824 1
19 151722-6 GEAR HOUSING COVER CPL., 6824 1
20 210007-0 BALL BEARING 608VV, 6825 1
21 517321-8 ARMATURE ASS'Y 115V, 6824 1
22 681636-0 INSULATION WASHER, 4304 1
23 211021-9 BALL BEARING 607LLB, LS1013 1
24 421479-6 RUBBER RING 19, JN1601 1
25 416993-5 BAFFLE PLATE, 6823 1
26 266147-2 TAPPING SCREW 4X55, 6824 2
27 633441-1 FIELD, 6823 1
28 416996-9 HOOK, 6823-T1 1
28 417625-7 HOOK, 6827 1
28 417625-7 HOOK, 6827 1
29 183285-4 MOTOR HOUSING SET, 6827 1
29 183285-4 MOTOR HOUSING SET, 6827 1
30 819063-3 MAKITA LABEL, 6992DWDE 1
30 819063-3 MAKITA LABEL, 6992DWDE 1
31 851654-4 NAME PLATE, 6824 1
31 860144-6 NAME PLATE, 6824 1
32 643948-9 BRUSH HOLDER, 6823 1
33 191927-6 CARBON BRUSH SET CB-407, 6821 1
34 682559-5 CORD GUARD 8, 6824 1
35 664064-4 CORD (2X18X8 SJ), HR2400 1
35 664891-9 CORD 1
35 664891-9 CORD 1
36 687063-9 STRAIN RELIEF, 4323K 1
37 265995-6 TAPPING SCREW 4X18, 4323K 2
38 651978-6 SWITCH, 6823 1
38 651978-6 SWITCH, 6823 1
38 651978-6 SWITCH, 6823 1
38 651978-6 SWITCH, 6823 1
39 151725-0 HANDLE COVER CPL., 6823 1
39 151961-8 HANDLE COVER COMPLETE, JS1300 1
39 151961-8 HANDLE COVER COMPLETE, JS1300 1
40 265999-8 TAPPING SCREW M4X25, HM1800 3
41 253139-0 F. WASHER 8, 6510LVR 1
42 643951-0 BRUSH HOLDER, 6824 1
43 262087-2 RING 8, 6824 1
Page 2 of 3 2/8/2008

Parts Breakdown 6824
1,001 784211-2 INSERT BIT 2-25, 6800DBV 1
1,002 784801-1 MAGNETIC BIT HOLDER, 6801DBV 1
5,001 810134-9 N/A 1
Page 3 of 3 2/8/2008
