Makita 9020L User manual

INSTRUCTION MANUAL
No load speed
(RPM)
6,000
DOUBLE
INSULATION
Overall length Net weight Spindle thread
5/8-11
UNC
4.7 kg (10.4 lbsl
462 mm (18-3/16")

IMPORTANT
SAFETY INSTRUCTIONS
(For All Tools)
WARNING: WHEN USINGELECTRIC TOOLS, BASICSAFETY
PRECAUTIONSSHOULD ALWAYS BE FOLLOWED
TO REDUCE
THE RISK OF FIRE, ELECTRIC SHOCK, AND PERSONAL
INJURY, INCLUDING THE FOLLOWING:
READ ALL INSTRUCTIONS.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
KEEP WORK AREA CLEAN. Cluttered areas and benches invite injuries.
CONSIDER WORK AREA ENVIRONMENT. Don't use power tools
in damp
or wet locations. Keep work area well lit. Don't expose powertoolstorain.
Don't use tool
in presence of flammable liquids or gases.
KEEP CHILDREN AWAY. All visitors should be kept away from work area.
Don't let visitors contact tool
or extension cord.
STORE IDLETOOLS. Whennot
in use, tools shouldbestored in dry, and high
or locked-upplace - out of reach of children.
DON'T FORCETOOL.
It willdothejob betterandsaferattheratefor which
it was intended.
USE RIGHT TOOL. Don't force small tool
or attachment to do thejob of a
heavy-duty tool. Don't use tool for purpose not intended.
DRESSPROPERLY. Don't wear
loose clothingorjewelry. Theycanbecaught
in moving parts. Rubber gloves and non-skid footwear are recommended
when working outdoors. Wear protective haircoveringtocontain long hair.
USE SAFETY GLASSES. Also useface
or dust mask if cutting operation is
dusty.
DON'T ABUSE CORD. Nevercarrytoolbycord
or yank it todisconnectfrom
receptacle. Keep cord from heat, oil, and sharp edges.
SECURE WORK. Use clamps or a vise to hold work. It's safer than using
your hand and
it frees both hands to operate tool.
DON'T OVERREACH. Keep proper footing and balance at all times.
MAINTAINTOOLS WITH CARE. Keep tools sharp and cleanfor better and
safer performance. Followinstructionsfor lubricating andchangingacces-
sories. Inspecttoolcordsperiodicallyandifdamaged, have repairedbyautho-
rized service facility. Inspect extension cords periodically and replace
if
damaged. Keep handles dry, clean, and free from oil and grease.
DISCONNECTTOOLS. Whennot
in use, beforeservicing, andwhen chang-
ing accessories, such as blades, bits, cutters.
2

14. REMOVE ADJUSTING KEYS AND WRENCHES. Form habit of checking to
see that keysand adjustingwrenches are removedfromtoolbeforeturning
it on.
15. AVOID UNINTENTIONAL STARTING. Don't carrytool withfinger onswitch.
Be sure switch is OFF when plugging
in.
16. EXTENSION CORDS. Make sure your extension cord is in good condition.
When using an extension cord, be sure to use one heavy enoughto carry
the current your product will draw. An undersized cord will cause a drop
in line voltageresulting in loss of powerand overheating.Table 1 showsthe
correct sizetousedependingoncord lengthand nameplateampere rating.
If
in doubt, use the next heavier gage. The smaller the gage number, the
heavier the cord.
TABLE 1 MINIMUM GAGE FOR CORD SETS
0- 6
6
- 10
10
- 12
12
- 16
I
Total Length of Cord in Feet
18 16
14
16 16 14 12
14 12 Not Recommended
18 16 :9 1 12
I 0 - 25 I 26 - 50 I 51 - 100 I 101 - 150
Ampere Rating
More
Not MOW
Than Than AWG
17. OUTDOOR USE EXTENSIONCORDS. Whentoolisusedoutdoors, useonly
extension cords intended for use outdoors and
so marked.
18. STAY ALERT, Watchwhat youaredoing, usecommon sense. Don't operate
tool when you are tired.
19. CHECK DAMAGED PARTS. Beforefurther use of the tool, a guard or other
part that isdamaged should be carefully checked to determinethat
it will
operateproperlyand perform itsintendedfunction. Check for alignmentof
moving parts, binding of moving parts, breakage of parts, mounting, and
any other conditions that may affect its operation. A guard
or other part
that isdamaged should be properly repaired or replacedby an authorized
service center unless otherwise indicated elsewhere
in this instruction
manual. Havedefectiveswitchesreplaced
by authorizedservicecenter. Don't
use tool if switch does not turn
it on and off.
20. GUARD AGAINST ELECTRICSHOCK. Prevent body contact with grounded
surfaces. For example; pipes, radiators, ranges, refrigerator enclosures.
21. REPLACEMENTPARTS. Whenservicing, useonly identicalreplacementparts.
22. POLARIZEDPLUGS. To reducethe riskof electric shock, thisequipmenthas
a polarizedplug (one blade is wider than the other). This plug will
fit in a
polarizedoutlet only one way. If the plug does not fit fully
in the outlet,
reversetheplug. If
it stilldoesnot fit, contact aqualifiedelectriciantoinstall
the proper outlet. Do not change the plug
in any way.
3

VOLTAGE WARNING: Beforeconnecting the tooltoa powersource (receptacle.
outlet, etc.) be sure the voltage supplied is the same as that specified on the
nameplateof the tool. A power source withvoltage greater than that specified
for the toolcan result
in SERIOUS INJURY tothe user - as well as damageto
the tool. If
in doubt, DO NOT PLUG INTHE TOOL. Using a power source with
voltage
less than the nameplate rating is harmful to the motor.
ADDITIONAL SAFETY RULES FOR SANDER
1. Check the backing pad carefully for cracks, damage or deformity before
2. Hold the tool firmly.
3. Keep hands away from rotating parts.
4. Make sure abrasive disc is not contacting the workpiece before the switch
5. Do not leave the tool running. Operate the tool only when hand-held.
6. Do nottouchtheworkpieceimmediatelyafter operation; it maybeextremely
operation. Replace cracked, damaged or deformed pad immediately.
is turned on.
hot and could burn your skin.
4

ADDITIONAL SAFETY RULES FOR GRINDER
1. Keep guards in place.
2. Use only wheels havingamaximumoperatingspeedat leastas highas "No
LoadRPM" markedonthe tool's nameplate.When usingdepressedcenter
wheels, be sure to use only fiberglass-reinforcedwheels.
3. Check the wheel carefully for cracks or damage beforeoperation. Replace
cracked or damaged wheel immediately.
4. Use only flanges specified for this tool.
5. Be careful not to damage the spindle, the flange (especiallythe installing
surface) or the lock nut. Damage to these parts could result
in wheel
breakage.
6. Hold the tool firmly.
7. Keep hands away from rotating parts.
8. Make sure the wheel is not contacting the workpiece before the switch is
turned on.
9. Before usingthe tool on an actual workpiece, let it run for a while. Watch
for vibration or wobbling that could indicate poor installation or a poorly
balanced wheel.
10. Use the specified surface of the wheel to perform the grinding.
11. Watch out for flying sparks. Holdthe tool so that sparksfly away from you
12. Do not leave the tool running. Operate the tool only when hand-held.
13. Do nottouch the workpieceimmediatelyafter operation; it may beextremely
and other persons or flammable materials.
hot and could burn your skin.
SAVE THESE INSTRUCTIONS.
5

Installing side grip (auxiliary handle)
Always installthe side grip on the machine
securely before operation. The side grip can
be installed in any of three positionson the
sides of the machine, whichever is con-
venient and keeps the guard properly posi-
tioned. Always hold the machine's switch
handle and the side grip firmly with both
hands during operation.
Switch handle mounting positions
The switch handle can be rotatedto either
90° left or right to fit your work needs. To
changethe position, first unplugthe machine
from the power source. Remove only the
screw which secures the middle of the
switch handle Rotate the switch handle to
the desired angle
(90° left or right). Insert
the screw intothe hole inthe middleof the
switch handle. Make sure that the switch
handleis securedand thentightenthe screw
firmly.
L Side grip
Screw
WARNING:
Positionswitch handle mountingangle and side grip only insuch a way that grinding wheel
will not contact any part of your body and that wheel guard always remains positioned
as
a barrier betweenthe grinding wheel and the operator. Failure to do so may result in
serious injury.
CAUTION:
Never mountthe switch handle
at any other angles than Oo (originalmountingangle), 90°
left of right. Repositionthe side grip if necessary to assure firm and proper control of the
machine.
6

Installing or removing abrasive disc
CAUTION:
Always be sure that the tool is switched off and unplugged before installing or removing
the disc.
NOTE:
Use sander accessories specified in this manual. These must be purchased by separate.
To tighten the lock
nut, pressthe shaft lock
firmly
so that the spindle cannot revolve,
then use the lock nut wrench and securely
tighten clockwise.
Mount the rubber pad onto the spindle.
Fit
the disc OR over the rubber pad and screw
the lock nut onto the spindle.
Lock nut wrench
Lock
nut
I
~
To remove the disc, follow the installation procedure in reverse.
7

IF USED AS A GRINDER
NOTE:
Usegrinder accessoriesspecifiedinthis manual.These must be purchasedseparately.
WARNING:
Always use guard assembly or accessory kit, noted below, for type 27 depressed center
wheel.
Guard assembly
Part
No. 192413-0 ... For 180 mm (7")
Part No. 192414-8
... For 230 mm 19")
Installing wheel guard
When usingadepressedcenter wheel, always
use a wheel guard. Mount the wheel guard
withthe tab on the wheel guard band aligned
withthe notchonthe bearingbox.Thenrotate
the wheel guard
160 degrees counter-
clockwise. Be sure to tighten the screw
securely.
c Wheel guard
1
I screw Notch
8

Installing or removing depressed center
wheel
CAUTION:
Always be surethat the machine is switched
off and unpluggedbeforeinstallingor remov-
ing the wheel.
Mountthe inner flange onto the spindle. Fit
the wheel on over theinnerflangeandscrew
the lock nut onto the spindle.
Use only lock nut part no.
192568-1,
equipped with tool.
Install locknut
as shown, with locknut
wrench holes facing out.
To tightenthelock nut, pressthe shaft lock
firmly
so that the spindle cannot revolve,
then use the lock nut wrench and securely
tighten clockwise.
To removethe wheel, follow the installation
procedure in reverse.
Lock nut -
Depressed
center whee
Lock nut wrench
>/-
Shaft lock --
9

Switch action
To start the tool, simply pull the trigger.
Release the trigger to stop. For continuous
operation, pull the trigger and then push
in
the lock lever. To stop the tool form the
locked position, pull the trigger fully, then
release
it.
Lock lever
-
CAUTION:
Before plugging
in the tool, always check tosee that the switchtrigger actuates properly
and returns tothe "OFF" position when released.
Operation I
Hold the tool firmly. Turn the tool on and
then apply the wheel or disc to the work-
piece.
In general, keep the edge of the wheel or
disc at an angle of about
15O tothe work-
piece surface.
Duringthe break-inperiodwitha new wheel,
do notwork thegrinder
in the Bdirection or
it will cut intothe workpiece. Oncethe edge
of the wheel has been rounded off by use,
the wheel may be worked
in both A and B
directions.
-
WARNING:
It should never be necessary to force the tool. The weight of the tool applies adequate
pressure. Forcing and excessive pressure could cause dangerous wheel breakage.
Continued use of a worn-out wheel may result in wheel explosion and serious personal
injury. Depressed center wheel should not be used after
it has been worn down to
1 15 mm (4-1 12") in diameter. Use of the wheel after this point is unsafe and it should
be removed from service and rendered unusable by intentional destruction.
10

MAINTENANCE
CAUTION:
Always be sure that the tool is switched off and unplugged before attempting to perform
inspection or maintenance.
Replacingcarbon brushes
When the resin insulating tip inside the
carbon brush
is exposed to contact the
commutator,
it will automatically shut off
the motor. When this occurs, both carbon
brushes should be replaced at the same
time. Use only identical carbon brushes.
Use a screwdriver to remove the brush
holder caps. Take out the worn carbon
brushes, insert the new ones and securethe
brush holder caps.
> 7 Insulating tip
- Carbon brush
1
I,
Brush holder cap
To maintain product SAFETY and RELIABILITY, repairs, any other maintenance or adjust-
ment should be performed by Makita Authorized or Factory Service Centers, always using
Makita replacement parts.
11

ACCESSORIES
CAUTION :
These accessoriesor attachmentsare recommendedfor use with your Makitatool specified in this
manual.The use of any other accessoriesor attachmentsmight present a risk
of injury to persons.
The accessories or attachmentsshould be used only in the proper and intended manner.
I I I
~
1924 13-0
@Rubber pad 170 mm (6-3/4")
Part
No. 743012-7
180 (7")
@Abrasive disc (5 per pkg)
192414-8
PartNo. I Grit I Diameter In"
742067-A-5 I 16 I
230 19")
742069-A-5
I 24 I
742089-A-5
742070-A-5
742071-A-5
742091-A-5 120
180 17")
@Lock nut 48 (For abrasive discs)
Part
No. 22451 7-1
@Guard assembly
Part No. I Size (mm)
@Inner flahge
89
(For depressed center wheel)
Part No. 22431 5-3
12

@(A) Depressed center wheel (1 per pkg)
24 741421-4
@Wire cup brush
230 x 6 x 22
(9" x 1/4" x 7/67
Part No.
I Grit I Size (mm)
Part No. I Grit
180 x 6 x 22
741413-3
I 24 I (7,, 114, 718,,)
Size (mml
741313-7A
(B) Makita zirconate (5 per pkg)
(7" x 118" x 718")
180
x 6 x 22
24
,7,,
114, 718,,)
Part No. I Diameter (mml
Part Na Grit
743206-A 150
16')
743206-8
Size
@Flexible grinding wheel
(10 per pkg)
741414-A A24R
Part Na I Grit I Size (mml
7" x 114' x 98''
741445-0
I 36
741443-4 I 80 I . Part No. 74302f-4). -
(C) Best edge (5 per pkgl
Part No. I Grit I Size (mml
180 x 3 x 22
741413-6A
I 24 I (7,, 118" 718,,)
@Lock nut 45
(For depressed center wheel)
Part No. 192568-1
@Urethane washer 14
Part No. 261039-0
741444-2 I 120 I
@Hubbed grinding wheel
Lock nut wrench 28
Part No. 78241 2-6
Grip 35
Part No. 273503-9
When usingwire brush, mount urethane washer
14 to the spindle. It will makeiteasier to remove
wire brush.
13

fib-03-'94 US
ANGLE SANDER
Model 9020L
Note: The switch, noise suppressor and other part configurations
may differ from country to country.
14

MODEL 9020L
ITEM NO.
NO. USED DEscWPTIDN
Feb-03-'94 US
ITEM NO.
NO. USED DEsCRIPTON
MA1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
-
NE
1
1
1
1
1
1
1
1
1
1
4
1
1
1
1
1
1
1
1
1
1
Ball Bsannp 62MK)DW
I"."l.tlgn w..her
Field
Baffle Plate
ARMATURE ASSEMBCY
(With Item
1, 2 h 61
Fan 80
Bamng Retalnmr 57
Ball Bsanng 6301DDW
Spnl BaVd Gem 12
Ratammg Ring S-9
Pan bad Screw M5x40 IWith Washer1
Tool
Rasl
Rn Cap
Compression
Spring 12
Hex Socket Head Bolt M5r20
Pm 6
Grip 35
Hex Sockel Head Bolt M5x10
RetaininQ Ring 5-17
Spral BsVd Gear 50
Retmmma Rim R-40
MACHINE
~
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
42
43
44
-
1
1
1
1
4
1
1
1
1
2
1
1
4
1
1
1
2
1
1
2
2
1
-
Ball Bserinp 6203DDW
Bssnng Box
Spmdle
Wwdruff Key
4
Pan Head Screw MSxl6 IWith Washer1
Gear
Housmg
MOTOR HOUSING ASSEMBLY
Name Plate
Band
Pan Head Screw M5x70 IWith Washer1
Handle
Set (With Item 451
Pan Head Screw M6r85
Pan Head Screw M4x25 IWilh Washer1
Cord
Cwd Guard
Stram
Reld
Tappmg krsw 4x18
Switch
Handle Set IWbth Item 361
Carbon hsh
Brush Holder Cap
MakLa Mark
Nom: The switch and ohr pan ap&ficmbns may differ fmm comity to country.
15

MAKITA LIMrrED ONE YEAR WARRAECTY
Warranty Policy
Every Makita tool is thoroughly inspectedand tested before leavingthe factory. It is warranted to
be free of defects from worlananshipand materials for the period of ONE YEAR from the date of
original purchase. Should any trouble develop during this one-year period. retum the COMPLETE
tool, freight prepaid,
to one of Makita’s Factory or Authorized ServiceCenters. If inspection shows
the trouble is caused by defective workmanship or material, Makita will repair (or at our option,
replace) without charge.
ThisWarranty does not apply where:
0 repairs have been made or attempted by others:
0 repairs are required because of normal wear and tear:
The tool has been abused, misused or improperly maintained;
0 alterations have been made to the tool.
IN NO EVENT SHALL MAKlTA BE LIABLE FOR ANY INDIRECT. INCIDENTALOR CON-
SEQUENTIAL DAMAGES FROM THE SALE
OR USE OF THE PRODUCT.THIS DISCLAIMER
APPLIES BOTH DURING AND AFTER THE TERM OFTHIS WARRANTY.
MAKITA DISCLAIMS LIABILITY FOR ANY IMPLIED WARRANTIES, INCLUDING IMPLIED
WARRANTIES
OF “MERCHANTABILITY” AND “FITNESS FOR A SPECIFIC PURPOSE,”
AFTER THE ONE-YEAR TERM OFTHIS WARRANTY.
This Warranty gives you specific legal rights, and you may also have other rights which vary from
state
to state. Some states do not allow the exclusion or limitation of incidental or consequential
damages,
so the above limitation or exclusion may not apply to you. Some states do not allow
limitation on how long an implied warranty lasts,
so the above limitation may not apply to you.
-
MAKITA MANUFACTURING EUROPE LTD
TELFORD, SHROPSHIRE, U.K.
883880- 069 SM-1095-8M MA-1930-95
