Parts Breakdown 9911
Page 1 of 3 2/8/2008

Parts Breakdown 9911
Fig # Part ID Part Name Quantity
1 122548-3 DUST BAG ASS'Y, 9910 1
2 265999-8 TAPPING SCREW M4X25, HM1800 4
3 222144-8 PULLEY 8.5-45.1,9910 1
4 210005-4 BALL BEARING 608DDW, 9031 1
5 226494-3 HELICAL GEAR 6, 9910 1
6 212009-2 NEEDLE BEARING 509, 9910 1
7 416420-2 BRACKET, 9910 1
8 153252-3 HELICAL GEAR 31 CPL., 9910 1
9 253758-2 F. WASHER 10, 9901 1
10 211061-7 B. BEARING 6000LLB, 6222DWE 1
11 650232-5 SWITCH, 9911 1
11 651285-7 SWITCH, 9910 1
12 682502-4 CORD GUARD 8-85, HP1621F 1
13 664891-9 CORD 1
14 687063-9 STRAIN RELIEF, 4323K 1
15 265995-6 TAPPING SCREW 4X18, 4323K 2
16 416418-9 BAFFLE PLATE, 9910 1
17 266052-3 TAPPING SCREW FLANGE PT4X60,HR2410 2
18 633391-0 FIELD 115V, 9910 1
19 931202-6 HEX NUT M5, HR2410 1
20 150958-4 HOUSING L, CPL.,9911 1
21 233219-8 COMPRESSION SPRING 6, 9910 1
23 911252-7 P.H. SCREW M5X30, 2711 1
24 859230-8 NAME ?LATE, 9911 1
25 643550-8 BRUSH CAP , 9031 2
26 191938-1 CARBON BRUSH 408 SET, 3901 1
27 643922-7 BRUSH HOLDER, JN1601 2
28 416416-3 SCROLL PLATE, 9910 1
29 241660-1 FAN 68, 9910 1
30 252153-3 HEX NUT M6-10, 9910 1
31 344584-1 PLATE, 9910 1
32 225079-2 SYNCHRO BELT 6-300, 9910 1
33 183021-8 BELT COVER SET, 9910 1
33 416415-5 BELT COVER, 9910 1
34 265999-8 TAPPING SCREW M4X25, HM1800 4
35 267177-6 FLAT WASHER 12, 9910 1
36 253865-1 F. WASHER 8, HR5000 1
37 422032-1 RUBBER SLEEVE 29, 9910 1
38 316971-4 DRIVING ROLLER, 9910 1
39 252154-1 HEX NUT M8-13, 9910 1
40 253077-6 F. WASHER 6, 2040 1
41 210022-4 BALL BEARING 626DDW, 9910 1
42 210023-2 BALL BEARING 627DDW, 9910 1
43 253823-7 F. WASHER 7, LS1011 1
44 681648-3 INSULATION WASHER, 9910 1
44 681658-0 INSULATION WASHER 1
45 517241-6 ARMATURE ASS'Y 115V, 9910 1
46 240008-4 FAN 60, 9910 1
47 211021-9 BALL BEARING 607LLB, LS1013 1
48 182982-9 HOUSING R, 9911 1
49 265999-8 TAPPING SCREW M4X25, HM1800 7
50 416419-7 SHOE, 9910 1
51 265999-8 TAPPING SCREW M4X25, HM1800 2
52 344586-7 STEEL PLATE, 9910 1
52 344586-7 STEEL PLATE, 9910 1
52 345503-0 STEEL PLATE, 9910 1
53 233221-1 COMP. SPRING 12, 9910 1
54 231038-6 COMP. SPRING 5.5, LS1011 1
55 819063-3 MAKITA LABEL, 6992DWDE 1
56 344585-9 LEVER, 9910 1
Page 2 of 3 2/8/2008

Parts Breakdown 9911
57 150837-6 TENSION ROLLER ARM CPL., 9910 1
58 267731-6 CUP WASHER, 9910 1
59 416417-1 ROLLER, 9910 1
60 265059-6 SHOULDER SCREW M4, 9910 1
61 323776-5 TENSION ROLLER SHAFT, 9910 1
62 152585-3 TENSION ROLLER CPL., 9910 1
63 961004-6 RETAINING RING S-8, DA391D 1
64 631182-3 CONTROLLER, 4304 1
64 631675-0 CONTROLLER, 4304 1
66 344703-9 EARTH SUPPORTER, 9910 1
67 344701-3 EARTH PLATE, 9910 1
1,001 794551-0 ABRASIVE BELT 76X457 WA80, 9911 1
Page 3 of 3 2/8/2008
